Zenith Z32LC2D User manual

Super IPS Technology
Reduces common distortion and blurring caused by fast motion
video and also provides one of the industry’s widest viewing
angles (178˚).
High Definition TV
Built-in ATSC tuner allows this TV to receive over-the-air
digital broadcast signals and unscrambled digital cable.
Advanced Connectivity
Includes inputs for the most advanced components which allows
simultaneous PC interactivity while watching your favorite TV
programming.
• 1366 x 768p Resolution
• 1600:1 Contrast Ratio
• ATSC/NTSC/QAM Clear Tuners
• Super IPS Technology
• HDMI with HDCP
• PC Input
Z32LC2D
32" LCD Integrated HDTV

Rear
Front
TV Rear
HDMI/DVI IN DIGITAL AUDIO OUT
(OPTICAL)
RS-232c IN
(CONTROL SERVICE)
ANTENNA IN
CABLE IN
AUDIO IN (RGB/DVI) REMOTE CONTROL IN
RGB IN (PC/DTV)
AUDIO (R)(L)
AUDIO (R)(L)
AUDIO (R)(L)PrPbY
AUDIO (R)(L)PrPbY
COMPONENT IN 2
(480i, 480p, 720p, 1080i)
COMPONENT IN 1
(480i, 480p, 720p, 1080i)
S-VIDEO
VIDEO
VIDEO
AV OUT
AV IN 1
(L) - AUDIO IN - (R)
VIDEO IN S-VIDEO IN
TV Side
© 2006 Zenith and the “Z Bolt” are registered trademarks of Zenith Electronics Corporation.
Marketed and Distributed by LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
www.zenith.com Rev: 11.22.06
Z32LC2D
32" LCD Integrated HDTV
SYSTEM
ATSC/NTSC/QAM Tuners •
Program Guide Type PSIP
VIDEO
Native Display Resolution 1366 x 768p
Contrast Ratio 1100:1
Brightness 500 cd/m2
Lifetime 60,000 Hours*
Viewing Angle 178º x 178º
Super IPS •
Response Time (Grey to Grey) 8ms
Comb Filter 3D Y/C
Color Temperature Adjustment 3 Modes
Aspect Ratio Adjustment 7 Modes
3:2 Pull-Down Cinema Correction 480i
EZ Video/Picture Selection Mode 7 Modes
XD Engine •
Black Stretcher (Black Level Enhancer) •
DTV Signal Strength Indicator •
Displayable Colors 1.07 Billion
Noise Reduction (Video Noise Filter) 3D
Decoder Formats MPEG2
Screen Pitch 0.681 (Pixel Pitch)
AUDIO
Audio Output Power 30W (15W x 2)
Speaker System Details 2 Way 2 Speaker
Surround System Type SRS TruSurround
3D EchoSound System •
BBE •
AUDIO (continued)
Bass/Treble/Balance •
EZ SoundRite (Volume Leveler) •
EZ Sound/Sound Selection Mode 6 Modes
Mute •
Mono/Stereo/SAP •
SPECIAL FEATURES
Custom Input Labels •
Defeatable Inputs •
Auto Input Detect •
Channel Block •
Freeze •
Discrete IR Codes •
Favorite Channel Selection/Surf •
Trilingual Menus English, Spanish, French
On/Off Timer •
Sleep Timer •
Auto Off (When no Video is Present) •
Flashback (Previous Channel) •
Parental Control w/ V-Chip •
EZ Menus (High Performance Interface) •
EZ Scan (Auto Channel Programming) •
Closed Caption •
AUDIO/VIDEO INPUTS/OUTPUTS
TV Rear
- Antenna In (RF) 1
- Cable In (RF) 1
- HDMI (DVI w/ Adapter) 1
- Digital Audio Out (Optical) 1
AUDIO/VIDEO INPUTS/OUTPUTS (continued)
- RS-232c In (Software Upgrade Interface and Control) 1
- Remote Control In (IR) 1
- RGB In (PC/DTV Input) 1
- Audio In (RGB/DVI w/ Adapter) 1
- Composite Video and Audio L/R In 1
- Composite Video and Audio L/R Out 1
- Component HD/DVD and Audio L/R In 2
- S-Video In 1
TV Side
- Composite Video and Audio L/R In 1
- S-Video In 1
SPECIFICATIONS
Cabinet Color Silver
Cabinet Style Table Top
Remote Control Type Universal
VESA Compatible •
Power Consumption (TV On) 148W
Power Consumption (Standby) 0.5W
Dimensions w/Out Stand
- Width x Height x Depth 31.9" x 22.3" x 4.9"
- Weight Out of Package 40.8 lbs.
Dimensions w/ Stand
- Width x Height x Depth 31.9" x 24.8" x 9.3"
- Weight Out of Package 48.6 lbs.
Dimensions w/ Packaging
- Width x Height x Depth 35.3" x 28.3" x 11.8"
- Weight In Package 56.3 lbs.
UPC 71919216980 7
Warranty 1 Year Parts/Labor
