Baja motorsports STR125 Manual

Removal from crate
1. Remove cardboard carton
from metal frame.
2. Carefully remove metal
frame, wheels, nerf-bars, front
bumper and hardware.
Front wheels
19x6-10
Front bumper
Nerf bars
Rear wheels
18x6.50-8
STR125 ATV Set Up Instructions

2
4. Attach front and rear wheels with spacer, lock
washer and lug nuts provided. Torque to 35 ft.lb.
3. Remove wire straps
from front and rear axles.
Front Wheel
19x6-10
Rear Wheel
18x6.50-8
Removal from crate
Wheels
Spacer Spacer
Lock washer
Lock washer
Lug nut
Lug nut

3
5. Install handlebars by using handlebar clamp provided.
Torque bolts to 25Nm (18.5ft.lb.)
6. Attach left and right nerf-bars to to frame with
8mm allen head screws and nuts provided. 7. Attach front bumper to frame with 8mm
allen head screws and nuts provided.
Handlebar
Nerf bar Attachment Front bumper Attachment

4
Battery
BATTERY INSTALLATION
INITIAL SERVICE AND INSTALLATION OF BATTERY:
WARNING
The following procedure is very dangerous and should be performed with
utmost care and attention. Wear protective eye wear, rubber gloves, and have
water available should electrolyte come in contact with skin or eyes. KEEP
ALL CHILDREN AWAY FROM THE AREA WHILE THIS PROCEDURE IS BEING
PERFORMED.
POISON – CAUSES SEVERE BURNS
Contains sulfuric acid.
Avoid contact with skin, eyes, or clothing
To prevent accidents, rinse empty container with water.
ANTIDOTE:
External – ush with water
Internal – Call physician immediately. Drink large quantities of water or milk.
Follow with milk of magnesia, beaten eggs or vegetable.
Eyes – Flush with water for 15 minutes and get prompt medical attention.
KEEP OUT OF REACH OF CHILDREN.

5
Note: The following page is for vehicles with battery’s containing separate electrolyte pack.
Preparing the battery:
· Place battery on level surface. Remove cap strip from top of
battery. (see gure 20)
. Wear eye protection and rubber gloves for this step. Once battery
strip is removed, locate electrolyte in bottle and place over the
six openings. Press rmly down on bottle allowing the battery to
pierce the six in-line openings in bottle. Let electrolyte drain into
battery until bottle is completely empty. (see gure 21)
· Discard empty electrolyte container in a waste area that is
inaccessible to children and animals.
· After lling let battery stand for at least 30 minutes before
charging. This allows the electrolyte to penetrate plates for
optimum performance and ensures longer battery life.
· After 30 minutes the battery is ready for its initial charge. Place
caps loosely over battery cell holes (see gure22)
How to Initially Charge the battery:
1. Connect the red positive (+) cable to the red positive (+) pole of the
battery.
(see gure 24)
2. Connect the black negative (-) cable to the black negative (-) pole
of the battery. (see gure 25)
Note: The red positive (+) cable has a larger diameter than the
black negative y cable.
3. Charging rate: Charge battery @ 0.7 Amps for
5 ~ 10 hours.
• After charging is complete, install securely all six battery caps
(see gure 26)
• Install battery into battery tray located under seat (see gure
27).
• Once battery is rmly seated in tray, attach red positive (+) wire to
positive (+) terminal on battery, then attach black negative (-) wire
to negative (-) terminal on battery (see gure 27)
Figure 20
Figure 21
Figure 22
Battery
WARNING
NEVER REMOVE THE STRIP OF CAPS
NOR ADD ANY WATER OR ELECTROLYTE.
Figure 27
Red +
Green -
Figure 25
Figure 24
Figure 26

6
8. Fill engine with correct amount of oil. Refer to owners
manual for oil types and quantity.
9. Fill gas tank as specied in
owners manual.
Oil Cap
10. Refer to owners manual for
proper starting instructions. !!WARNING!!
This engine may be shipped with packing oil. This
oil should be drained and replaced with new engine
oil as described in owners manual. Never attempt
to start engine without rst replacing engine oil
with the proper amount and grade as described in
the owners manual.
Handlebar
Gas and Oil
