Model XSG-36
SPECIFICATIONS
STANDARD FEATURES
CERTIFICATIONS
Gas counter top griddles with a low profile design that are only 13
1/4" tall to grilling surface making them ideal for use on
refrigerated cabinets or counter tops.
XG Series Griddles are designed to mix and match with the XX
Series Char Broilers and XOB Series Open Burner counter top
ranges.
The griddle plate is 1" thick (25.4mm) and 24" deep (610mm),
polished, cold- rolled steel. Six widths are available from 24"
(610mm) to 72" (1829mm) in one foot increments.
The XG Series features high-performance, energy-efficient, 30,000
BTUH burners located every 12" with individual, operator-controlled
valves and are available in three control types: manual,
thermostatic or snap-action. Snap-action controls are supplied with
NEMA 15-P cord & plug in 120V.
The interior combustion chamber is heavy-duty heat resistant 11-
and 16-gauge steel, and is hand-welded for strength and durability.
Standard features include all stainless steel exterior, spatula-width
front grease trough, stainless steel landing ledge and large
capacity, slide-out grease pan. Additional features include
individual 3/4" NPT rear gas connection in natural or LP gas,
pressure regulator and 4" (102mm) NSF approved legs with
adjustable bullet feet. Stainless steel splash guards are
continuously welded to the griddle plates.
One year limited parts and labor warranty.
q
q
q
q
q
q
q
q
q
q
q
q
q
q
q
1" thick griddle plate
24" deep grilling surface
Heavy gauge, hand-welded, heat-resistant steel combustion
chamber
30,000 BTUH burners every 12"
Up to 180,000 total BTUH in natural or LP gas
Individually operated burner valves with manual, thermostatic
or snap-action controls
All stainless steel exterior
Stainless steel landing ledge
Stainless steel, welded splash guards
Low profile, counter top design - only 13 1/4" to grilling
surface
Front grease trough
Stainless steel, slide-out grease pan
Heavy-duty 4" NSF approved adjustable chrome legs with
bullet feet
3/4” (19mm) NPT rear gas connection
Limited one year parts & labor warranty
OPTIONS & ACCESSORIES
q
q
q
q
q
q
Stainless steel front-mounted work deck with or without
sauce pan cut-outs
Condiment rail
Gas connector hoses
Equipment stands with or without casters
Grooved griddle surface in 12" increments
Two year limited warranty
BAKERS
PRIDE
qXMG-24
Manual
qXTG-24
Thermostatic
qXSG-24
Snap-Action
qXMG-36 qXTG-36 qXSG-36
qXMG-48 qXTG-48 qXSG-48
qXMG-60 qXTG-60 qXSG-60
qXMG-72 qXTG-72 qXSG-72
COUNTERTOP GAS
GRIDDLES
BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com
GAS COUNTER TOP GRIDDLES G
NEW
Job ____________ Item # ___________
CookLine
SERIES

BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
TS:04/04
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com
SHIPPING INFORMATION
SPECIFICATIONS
GAS SUPPLY
Model
Model
Model
XG-24
XG-36
XG-48
XG-60
XG-72
XG-24
XG-36
XG-48
XG-60
XG-72
XG-24
XG-36
XG-48
XG-60
XG-72
290
430
520
710
860
23 7/8x24
35 7/8x24
47 7/8x24
59 7/8x24
71 7/8x24
60,000
90,000
120,000
150,000
180,000
32
34
34
34
34
36
52
64
69
74
16.0
24.6
30.2
32.6
34.9
24
24
24
24
24
132
195
236
323
391
606x610
911x610
1216x610
1521x610
1826x610
2
3
4
5
6
17.57
26.36
35.15
43.94
52.72
813
864
864
864
864
914
1321
1626
1753
1880
.46
.71
.88
.95
1.01
610
610
610
610
610
Shipping Weight
Grilling Area # of
Burners
Carton Dimensions
Overall Dimensions*
Lbs.
in.
BTUH
Inches
Width Depth CubicHeight
Inches FeetInchesKilos
mm
KW
mm mm Metermm
Inches
Width Depth Height
Inches Inchesmm mm mm
MINIMUM CLEARANCES
Right
Left
Rear
0
0
0
0
0
0
• From non-combustable construction
• Install only with non-combustable material above griddle surface
120V Cord & plug provided with Snap-Action control
Inches
Non-combustable construction only
mm
30 5/8
30 5/8
30 5/8
30 5/8
30 5/8
13 1/4
13 1/4
13 1/4
13 1/4
13 1/4
24
36
48
60
72
337
337
337
337
337
776
776
776
776
776
610
914
1219
1524
1829
*Height includes 4" (102 mm) standard legs to grilling surface
WIDTH
24"
(610mm)
13" (332mm)
5 5/8" (143mm)
to center of gas connection
17"
(433mm)
30 5/8"
(776mm)
3/4" NPT Gas Connection
4"
(102mm)
13 1/4"
(337mm)
FRONT VIEW
TOP VIEW
NEMA 15-P
SIDE VIEW
ALL DIMENSIONS NOMINAL
3/4”
3/4”
3/4”
3/4”
3/4"
CONNECTION
