BALAY 3VI340XP User manual

9000 233 089 
   en

en Index
Safety instructions 4. . . . . . . . . . . . .
Getting to know your appliance 6. .
Water softener 7. . . . . . . . . . . . . . . .
Filling the salt dispenser 8. . . . . . . .
Adding rinse aid 9. . . . . . . . . . . . . . .
Utensils 10. . . . . . . . . . . . . . . . . . . . . .
Detergent 12. . . . . . . . . . . . . . . . . . . .
Programme overview 14. . . . . . . . . .
Washing dishes 15. . . . . . . . . . . . . . .
Additional functions * 16. . . . . . . . . . .
Maintenance and care 17. . . . . . . . . .
Fault finding 19. . . . . . . . . . . . . . . . . .
Customer Service 22. . . . . . . . . . . . .
Information 23. . . . . . . . . . . . . . . . . . .
Installation 23. . . . . . . . . . . . . . . . . . . .
Waste disposal 25. . . . . . . . . . . . . . . .

en
4
Safety instructions
Delivery
Immediately check the packaging and
dishwasher for any damage which may
have been caused in transit. Do not use
a damaged appliance, but consult your
supplier.
Please dispose of packaging material
properly.
Installation
Install and connect the appliance
according to the installation and
assembly instructions.
The dishwasher must NOT be
connected to the power supply during
installation.
Ensure that the protective conductor
system of the domestic electricity
supply has been installed correctly.
Electrical connection conditions must
correspond with the specifications on
the rating plate of the dishwasher.
If the dishwasher is to be installed
in a high-sided unit, ensure that the unit
is attached properly and also at the
rear.
Built-under and built-in appliances
should always be installed under a
continuous work surface which is
attached to the adjacent cupboards, in
order to ensure that the appliance is
entirely stable.
After the appliance has been installed,
the mains plug should still be easily
accessible.
Not on all models:
The plastic housing on the water input
contains an electrically operated valve.
The connecting wires are inside the
inlet hose. Do not cut through this hose
and do not immerse the plastic housing
in water.
Warning
For safety reasons, if the appliance is not
fitted in a recess, thereby making a side
wall accessible, the door hinge area
should be covered at the side.
(Risk of injury)
Covers are available as optional
accessories from customer services or
specialist stores.
In daily use
Warning
Knives and other sharp-pointed utensils
must be placed with the points down
in the cutlery basket or horizontally in
the utensils basket.
Use the dishwasher only in the
household and only for its designed
purpose, i.e. for washing domestic
dishes.
Do not lean or sit on the open door.
The appliance could tip.
Please note that free-standing
appliances may tip over if the baskets
are overloaded.
The water in the appliance is not
drinking water.
Do not add any solvents to the washing
chamber. Danger of explosion!
Open the door carefully when
the programme is still running. There
is a risk of hot water spraying out of
the appliance.
To prevent injuries, e.g. caused
by stumbling, open the dishwasher
only briefly in order to load and unload
the dishwasher.
Read and observe the safety
nformation and instructions for use on
the packaging for cleaning and rinsing
agents.

en
5
Children in the household
If fitted, use the childproof lock. An
exact description can be found in the
back of the envelope.
Do not allow children to play with
or operate the appliance.
Keep children away from detergents
and rinse aid. These may cause
chemical burns in the mouth, throat and
eyes or asphyxiation.
Keep children away from an open
dishwasher. There could still be
detergent residue inside.
If the appliance is installed at eye-level,
ensure when opening and closing the
door that children are not caught
or crushed between the appliance door
and the cupboard door situated below.
Damage
The appliance may be repaired and
opened up by a technician only. First
disconnect the appliance from the
power supply. Pull out the mains plug
(do not tug the power cord!) or switch
off the fuse. Turn off the tap.
Disposal
Make redundant appliances unusable
to prevent subsequent accidents.
Dispose of the appliance in an
environmentally friendly manner.
Warning
Children could get locked in the appliance
(risk of suffocation) or get stuck in other
positions.
Therefore: Remove the mains plug, cut the
mains wire and set aside. Damage the
door lock so that the door can no longer
be closed.
Before using for the first time
The appliance was checked before it left
the works. In order to remove possible
water test remains, use the appliance for
the first time without any dishes, using
the highest temperature. Also fill salt, rinse
aid and detergent in the filling
compartments.

en
6
Getting to know your
appliance
Diagrams of the control panel and the
interior of the appliance can be found
in the envelope at the front.
Individual positions are referred to in
the text.
Control panel
1Main switch
2Door Opener
3Programme selector (retractable*)
4Additional options*
5“Check water supply” display
6Programme sequence display
7“End of programme” display
8Rinse-aid refill indicator
9Salt refill indicator
* some models
Appliance interior
20
Top basket
21
Additional cutlery basket for the top
basket *
22
Top spray arm
23
Additional cup rack *
24
Bottom spray arm
25
Float **
26
Bottom basket
27
Salt dispenser
28
Filters
29
Cutlery basket
30
Dispenser for rinse aid
31
Detergent dispenser
32
Catch
33
Rating plate
* some models
** The float ensures that the appliance
interior is not overfilled. Only customer
service may maintain, remove and install
the float.
You will need to purchase the
following before using the
dishwasher for the first time:
–special salt for use in dishwashers
– detergent
– rinse-aid
Only use products, which are suitable for
dishwashers.

en
7
Water softener
In order to rinse dishes and glasses
satisfactorily, the dishwasher requires soft
water, i.e. containing little or no lime,
otherwise water stains will be left behind
on crockery and glasses, etc.
If the tap water exceeds a certain level of
hardness, it must be softened, i.e.
decalcified, so that it can be used in the
dishwasher.
This is achieved by adding a special salt
to the water softener inside the
dishwasher.
The water softener, that is the required
amount of salt, is set up according to how
hard the tap water is.
Setting up the water softener
Determine the level of hardness of your
tap water. Your local water company or
service agent can help you with this.
Identify setting from the following water
hardness table.
Close the door
Rotate the programme selector
3
from the 12 o’clock position by one
notch to the left.
Switch on main switch
1
and hold
down for at least 3 sec.
The display
9
flashes and the lamps
above the symbols and light up.
(hardness value has been set to 2
at the factory).
To change the setting: Rotate the
programme selector
3
.
You can select a set value between
0 and 3 according to the hardness
of your water.
If the lamps , and light up,
the maximum set hardness value
has been reached. If the set hardness
value is now increased again, the
lamps go out and the set hardness
value is set to 0 (no lamp lights up).
Switch off the main switch
1
.
The chosen setting has now been
stored.
Water hardness table
_dh _Clarke mmol/l_fH
0–6
17–21
7–16
22–35
0
2
1
3
0–11
30–37
12–29
38–62
0–8
21–26
9–20
27–44
0–1,1
3,0–3,7
1,2–2,9
3,8–6,2

en
8
Filling the salt dispenser
Salt must always be filled before the
appliance is switched on, so that excess
salt solution is immediately flushed away
to prevent corrosion.
Open the screw-type cap of the
compartment 27 .
Before using the appliance for the first
time, pour about 1 litre of water in the
salt container.
Then refill with salt (not cooking salt)
until the salt container is full
(max. 1.5 kg). When you refill the salt,
water is being displaced and drains off.
The LOW SALT indicator
9
on the front
panel will light up initially but will extinguish
again after a short period when the salt
solution has become sufficiently
concentrated.
If the set hardness value is ”0”, do not
add salt because no salt is used during
operation; the salt refill indicator
is switched off.
Warning
Do not pour detergent into the container
for special salt. This would destroy the
water softener.
Salt refill indicator
As soon as the salt refill indicator
9
is lit
on the control panel, refill with salt
immediately before the next rinse cycle.
Depending on the washing frequency and
the hardness setting, the regeneration salt
may not have to be topped up for several
months.

en
9
Adding rinse aid
The rinse aid is required for stain-free
utensils and clear glasses.
Use only rinse aid for domestic
dishwashers.
Open the cover on the rinse-aid
dispenser 30 . To do this, press the
mark (1 ) on the cover and
simultaneously lift the cover on the
control plate (2 ).
Carefully pour in the rinse aid to just
below the edge of the filler opening.
Close the lid, ensuring that you hear it
snap closed.
To prevent excessive foam formation
during the next rinse cycle, remove any
rinse aid which has run over with a cloth.
Adjusting the amount of
rinse-aid
The amount of rinse-aid added to the
water can be varied by adjusting the
stepless control. The rinse-aid control has
been set to ”4” in the factory.
Do not alter the setting of the rinse-aid
control unless streaks (turn knob towards
”–”) or water marks (turn knob towards ”+”)
are left on the dishes.
30
Rinse aid controller
Rinse-aid refill indicator
As soon as the rinse-aid refill indicator
lights up on the control panel
8
,
refill with rinse aid.

en
10
Utensils
Not suitable
Cutlery and utensils made of wood.
Fragile decorative glasses,
hand-crafted and antique utensils.
These decorative items are not
dishwasher-proof.
Plastic parts sensitive to hot water.
Copper and tin utensils.
Utensils which are soiled with ash,
wax, lubricating grease or ink.
Absorbent materials such as sponges
and cloths.
Aluminium and silver parts have a
tendency to discolour and fade during the
wash cycle. Even some types of glass
(e.g. crystal glass objects) may turn cloudy
after many wash cycles.
Recommendation:
In future buy utensils which are identified
as dishwasher-proof.
Damage to glassware and other
dishes
Possible causes:
type of glass or manufacturing process
chemical composition of detergent
water temperature and duration of
dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that
have been marked ’dishwasher–proof’
by the manufacturer.
Use a mild detergent that is described
as ’kind to dishes’. If necessary, seek
further information from detergent
manufacturers.
Select a programme with as low a
temperature and as short a duration as
possible.
To prevent damage, take glass and
cutlery out of the dishwasher as soon
as possible after the programme has
ended.
Loading the dishwasher
It is not necessary to rinse them off
under running water.
When loading the dishwasher, ensure
that
Dall utensils are secure and cannot
fall over.
Dthe openings of all receptacles are
face down.
Dcurved or indented utensils are at
an incline, allowing water to drain.
Dthe two spray arms can rotate freely.
Very small items should not be washed in
the dishwasher as they could easily fall out
of the baskets.
Removing the dishes
To prevent water dripping from the top
basket onto the dishes in the lower basket,
we recommend that you empty the lower
basket first and then the top basket.
Cups and glasses
Upper basket 20
*on applicable models

en
11
Pots and pans
Lower basket 26
Cutlery
Cutlery should be placed in the
dishwasher always unsorted and with the
eating surface pointing downwards. The
spray jet is then better able to reach the
individual parts.
To prevent injuries, place long, pointed
accessories and knives on the étagère
(some models) or on the knife shelf
(available as an accessory).
Folding spikes *
*on applicable models
To improve stacking of pots and pans, the
spikes can be folded down.
Shelf *
*not on all models
Lean tall glasses and those with long
stems against the shelf – not against other
items to be washed.
Long items, serving cutlery, salad servers
or knives should be placed on the shelf so
that they do not obstruct the rotation of the
spray arms. The shelf can be folded back
when not required for use.
Small accessories holder*
*some models
Light-weight plastic accessories, e.g. cups,
lids, etc. can be held securely in the small
accessories holder.

en
12
Adjusting position of basket *
*not on all models
If required, the height of the top basket can
be adjusted in order to create more space
for large utensils either in the top or bottom
basket.
Pull out the top basket.
Remove the top basket and re-attach it
to the upper or lower rollers.
Detergent
You can use commercially available liquid
or powder proprietary detergents for
dishwashers or TABS (do not use
handwash!).
If phosphate-free detergents are used with
hard tap water, white deposits may be
deposited more easily on utensils and
the container walls. This can be remedied
by adding more detergent.
See detergent packaging to determine
whether a detergent is suitable for silver
parts.
If you have any other questions, we
recommend that you contact the helplines
of the detergent manufacturers.
Detergent dispenser with
dosing aid
The graduated detergent dispenser helps
you pour in the correct amount.
Lower line: 15 ml
Middle line: 25 ml
Full to the brim: 40 ml
If the detergent dispenser 31 is still
closed, press the lock 32 to open the
detergent dispenser.
Adding detergent
Fill the dispenser 31 with detergent.
Dosage: see manufacturer’s
instructions on the detergent
packaging.
Important
Due to the different solvency properties of
the detergent tablets supplied by various
manufacturers, the cleaning efficiency of
the detergent may not be fully utilised by
short programmes. It is recommended to
use washing powder for these
programmes.
The Intensive programme (on some
models) requires one tab only. When using
washing powder, you can apply some
of this cleaning agent to the inside of
the appliance’s door.

en
13
Reduce costs!
If your dishes are only moderately dirty,
you may be able to use less detergent
than recommended.
Close the lid on the detergent
compartment.
Press down the lid (1) until it clicks
shut (2).
If you are using detergent in tablet form,
read the manufacturer’s
recommendations on the packaging in
order to
determine where the tablets should be
placed inside the dishwasher (e.g. in
cutlery basket, detergent compartment,
etc.).
Make sure that the lid on the detergent
compartment is closed, even if you are
using tablets.
CAUTION
IMPORTANT NOTE
ON THE USE OF
COMBINED CLEANING
PRODUCTS
Please note the following when using
”combined cleaning products” which
eliminate the need for a rinsing agent or
salt, for example:
Some products with a built-in rinsing
agent are only used to their full effect in
certain programmes.
This type of product does not generally
produce the desired effect with
automatic programmes.
Products which eliminate the need for
regeneration salt can only be used
within a certain water hardness range.
If you wish to use these combined
products, please read the instructions
carefully and heed any notes on the
packaging.
Contact the manufacturer of the cleaning
agent if you have any questions,
particularly if:
the crockery is very wet once the
programme has finished.
limescale deposits are formed.
Any problems which arise as a direct
result of the use of these products are not
covered by our warranty.

en
14
Programme overview
This overview lists the max. possible number of programmes. The programmes supplied with your
appliance are indicated on the fascia.
Type of crockery
e.g.china,
pots/pans,
cutlery,
glasses,
etc.
Type of food
remains
Amount of
food remains
Condition of
food remains
Wash
programme
Programme
sequence
Non-
delicate
Soups, casseroles,
sauces, potatoes,
pasta, rice, eggs,
roast or fried food
Soups, potatoes,
pasta, rice, eggs,
roast or fried food
Coffee, cakes,
milk, sausage,
cold drinks,
salads
a lot very little
stuck on hard
Normal
65°
Intensive
70°Eco
50°Quick
35°Pre-rinse
Rinse-aid
70°
Drying
Drying
Rinse-aid
70°Drying
Main rinse Main rinse
Rinse-aid
55°
Wash
35°
Rinse-aid
65°
Wash
50°
Rinse off if
the dishes
have been
stacked for
several
days in the
dishwasher
prior to
washing.
Pre-rinse
Mixed Delicate Mixed
Gentle
40°
Pre-rinse
Wash
40°
Main rinse
Rinse-aid
55°
Drying
a little
loosely attached
Second
rinse
First rinse
Wash
65°
Pre-rinse Pre-rinse
Third
rinse
Pre-rinse
50°
Wash
70°
First rinse
Second
rinse
Programme selection
The most appropriate programme can be
identified by comparing the type of
crockery, cutlery, etc., as well as the
amount and condition of food remains,
with the details contained in the
programme overview.
You will find the appropriate programme
information in the introduction.

en
15
Washing dishes
Reduce costs!
If only a small number of dishes have
been loaded into the dishwasher, selecting
a programme that operates at the next
lowest temperature will usually suffice.
Programme data
The programme data (duration, energy
and water consumption) can be found in
the summary of instructions and refers to
standard conditions. Greater deviations
may be caused by:
different quantities of utensils
inlet temperature of the water
water pressure
ambient temperature
mains voltage tolerances
and appliance-specific tolerances
(e.g. temperature, water flow rate, etc.)
The water consumption values refer
to water hardness value 2.
Switching on the appliance
Close the door.
Turn on the tap fully.
Rotate programme selector
3
to the
required programme.
Switch on the main switch
1
.
The programme sequence display
6
lights up, the programme sequence starts
automatically.
End of programme
The programme ends when
the Programme progress indicator
6
has gone out and
the End-of-programme indicator
7
illuminates. When the programme
ends, the ”Top basket washing” function
is de-activated if required (only some
models).
Several minutes after the programme has
ended:
Open the appliance door.
Wait until the dishes have cooled down
and then remove.
When the programme has ended, you can
either switch off the appliance or restart it
with the same or another programme.
Switching off the appliance
Several minutes after the end
of the programme:
Switch off the main switch
1
.
”End of programme” display
7
goes out.
Turn off the tap
(does not apply to Aqua Stop).
It is not necessary to adjust the
programme selector.
Remove the utensils when they have
cooled down.
At the end of the programme please open
the door fully and not partially when
emptying the dishwasher. Any escaping
water vapour could damage sensitive
worktops.

en
16
Interrupting the programme
Set the main switch
1
to OFF.
Indicator lights extinguish.
If the hot water was switched ON or the
appliance has already heated up and then
the appliance door opened, leave the door
ajar for several minutes and then close.
Otherwise, the appliance door may fly
open due to expansion.
In order to resume the programme, set
the main switch to ON again.
Terminating the programme
(Reset)
Only when the main switch is on:
Rotate programme selector to the
Reset position.
The programme sequence lasts
approx. 1 min.
When the programme has run,
switch off the main switch
1
.
To restart, rotate the programme selector
3
to the required programme. Switch on
the main switch
1
. The programme
sequence starts automatically.
Changing the programme
It is possible to change the programme
within 2 minutes after you have switched
the dishwasher on.
Should it be necessary to change the
programme after this period, the
programme cycle that has already been
begun (e.g. washing) will be completed
first of all.
Note
If the power supply is disconnected while
the appliance is operating, e.g. by
switching off the appliance or due
to a power failure, all settings remain
stored. Operation continues automatically
as soon as the power supply is restored.
Additional functions *
*on some models additional functions
4
can be set with the buttons.
Pre-Soak *
The Pre-Soak programme option serves to
perform a pre-soak cycle before the main
programme. This cycle enables cookware,
e.g. pans, bowls, etc. to be pre-soaked
and pre-rinsed in the lower rack. If you
wish to pre-soak the dishes, this
programme option must be selected by
pressing the “Pre-Soak” button before the
programme starts. The recommended
detergent amount is approx. 5 g poured
onto the inside of the door.
Time reduction/ time saving *
Pressing the “Time reduction/time saving”
button provides a short wash cycle by
curtailing the drying phase and the
washing time. The washing and drying
performance will be reduced with the Time
reduction/time saving programme option.
Half load*
If you have only a few items to wash (e.g.
glasses, cups, plates), you can switch to
“Half load”. The “half load” additional
function saves water, energy and time. It is
recommended to put a little less detergent
in the detergent dispenser than for a full
load.
Extra dry*
If you press the “Extra dry” button, you
will receive a higher temperature in all
programmes in the final rinse and
therefore an improved drying result.
(please note that higher temperatures
might have an effect on delicate items).

en
17
Maintenance and care
Aregular inspection and maintenance of
your machine will help to prevent faults.
This saves time and prevents problems.
Overall condition of the
machine
Check washing chamber for grease
and limescale deposits.
If you find such deposits:
Fill the detergent dispenser with
detergent, start the appliance without
utensils in the programme which has
the highest wash temperature.
Clean the appliance with detergents/
appliance cleaners which are particularly
suitable for use with dishwashers.
Regularly wipe the door seal with a
damp cloth.
Never use a steam cleaner to clean your
dishwasher. The manufacturer is not liable
for any consequential damage.
Regularly wipe the front of the appliance
and panel with a damp cloth; water and
a little washing-up liquid will suffice.
Do not use sponges with a rough surface
or abrasive detergents, as these could
scratch the surfaces.
Attention!
Never use other chlorinated household
detergents! Health hazard!
Salt and rinse aid
Check the refill indicators
9
8
.
If required, top up the salt and/or rinse
aid.
Filters
Waste which is deposited on the filters
28 may result in a blockage.
After each washing cycle check the
filters for residue.
Unscrew the filter cylinder and remove
the filters. The filters are permanently
attached to each other and cannot be
dismantled.
Remove large foreign objects. Clean
the filters under running water.
Re-installation:
Insert the filters and screw the filter
cylinder tight.

en
18
Spray arms
Lime and remnants of food in the washing
water can block the nozzles in the spray
arms 22 and 24 and the arm
mountings .
Inspect the nozzles in the spray arms
for blocked holes due to remnants of
food.
If necessary, pull the lower arm 24
upwards and lift it off.
Unscrew the upper spray arm 22 .
Clean both spray arms under running
water.
Refit the spray arms. Ensure that the
lower arm has locked into place and the
upper one is screwed tight.
Spray arms
Waste water pump *
*some models
Large food remnants in the rinsing water
not retained by the filters may block the
waste water pump. The rinsing water is
then not pumped out and covers the filter.
In this case:
Set the main switch
1
to OFF.
Scoop out any water.
Remove the filters 28 .
Remove the cover.

en
19
Check the inner compartment for
foreign objects and, if required,
remove foreign objects.
Re-insert the cover.
Re-insert the filters and screw
into position.
Fault finding
Resolving minor problems
yourself
Experience has shown that you can
resolve most problems that arise during
normal daily usage yourself, without
having to call out a service engineer. Not
only does this save costs, but it also
means that the appliance is available for
use again that much sooner. The following
list of common occurrences and their
remedies should help you identify the
causes of most problems.
Problems ...
Attention
Remember: Repairs may be carried out by
a technician only. If a component has to be
replaced, ensure that only original spare
parts are used. Improper repairs or use of
non-original spare parts may cause
considerable damage and put the user at
considerable risk.

en
20
... when the appliance
is switched on
The appliance does not start.
The mains fuse has tripped.
The appliance plug has not been
inserted.
The appliance door has not been
shut properly.
The tap has not been turned on.
The filter on the water supply hose
is blocked.
Switch off the appliance and pull
out the mains plug. Turn off the
tap. Then clean the filter which is
situated at the connection of the
supply hose. Finally, restore the
power, turn on the tap and switch
on the appliance.
... with the appliance itself
Lower spray arm rotates with
difficulty
Spray arm is blocked by small
items or food remains.
Lid in detergent compartment
cannot be closed
Detergent compartment has been
overfilled.
Mechanism is clogged with
remnants of detergent.
Indicator lamps do not extinguish
after washing has finished.
Indicator lights flash after
the programme has started.
No programme selected.
Indicator lamps do not extinguish
after washing has finished
Main switch is still set to ON.
Remnants of detergent stuck inside
dispenser
Compartment was damp when it
was filled up with detergent.
Compartment must be dry before
detergent is added.
“Check water supply” display
5
lights up.
Tap turned off.
Water supply interrupted.
Filter in the water supply blocked.
Supply hose kinked.
Water remains inside appliance
after programme has ended
Blockage or kink in drainage hose.
Pump is jammed.
Filters are blocked.
The programme is still running.
Wait for the programme to end.
Perform “Reset” function.
The door opens and closes
incorrectly on appliances which
are designed to be built-in.
The attached door panel is not the
correct weight. Observe the weight
indicated in the enclosed
installation instructions.
Incorrectly set door spring
tension.Set the tension according
to step (point) 26 in the enclosed
installation instructions.
