BALLARD Ceylon Sofa SO623 User manual

PRODUCT NAME: Ceylon Sofa
ITEM NUMBER: SO623
DIMENSIONS OF ITEM ASSEMBLED: 34 1/4”H x 79 1/5”W X 30”D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE. Page 1 of 5
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN VIETNAM

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 5
TOOLS NEEDED:
2 Person assembly Required.
Ltr.
A 4 50mm Allen Screws
60mm Allen Screws
90mm Allen Screws
70mm Allen Screws
Seat
Legs
Wood Bolts
Right Leg
Left Leg
Seat Back
Back Cushions
Seat Cushions
B 6
C 6
E 12 Screw Plugs
D 6
F 1 Allen Wrench
Qty. Hardware Included
Ltr.
G 1
H 2
J 1
L 1
M 3
N 3
K 1
I 2
Qty. Components

Page 3 of 5
STEP 1: Attach the Legs (H) to the Seat (G) using the Allen Wrench (F) and 4 50mm Allen Screws (A).
STEP 2: Attach the Wood Bolts (I) to the Legs (H) and Seat (G) using the Allen Wrench and
6 60mm Allen Screws (B).
STEP 3: Attach the Left Leg (J) and Right Leg (K) to the Seat (G) using the Allen Wrench (F) and
2 90mm Allen Screws (C).
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
(C)
(J)
(K)
(G)
(B)
(H) (I)
(G)
(H) (A)
(G)

(E)
(C)
(G)
(J)
(K)
(L)
(D)
Page 4 of 5
STEP 4: Use 4 90mm Allen Screws (C) and the Allen Wrench (F) to attach the Seat Back (L) to the
Left (J) and Right (K) Leg. Then use 6 70mm Allen Screws (D) and the Allen Wrench (F)
to attach the Seat Back (L) and Seat (G).
STEP 5: Insert the Screw Plugs (E) in the Screw Holes.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Page 5 of 5
STEP 6:
Put the Seat Cushions (N) on the Seat (G) and then put the Back Cushions (M) on.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Clean & Care
Please refer to the care instructions on the hang tag.
(G)
(N)
(M)
