BALMUDA K01M Series User manual

Important
Besuretoreadthismanualbeforeuse.
Keepinasafeplaceforfuturereference.
Forinformationonwarrantypolicy,pleasereferto
theBALMUDAwebsite(https://us.balmuda.com).
ThankyouforpurchasingBALMUDATheToaster.
InstructionManual
K01MSeries
SteamToasterOven(ForHouseholdUse)
LimitedWarranty
FOR USE IN U.S. ONLY
WARRANTY VOID IF USED OUTSIDE U.S.
Contents
IMPORTANTSAFEGUARDS .........................1
SHORTCORDINSTRUCTIONS....................2
SafetyPrecautions....................................3-7
ContentsofthePackage ............................8
NamesofParts..............................................8
WhenUsingfortheFirstTime ............9,10
ControlPanel/Display .............................. 11
Cooking.................................................. 12-14
CookingGuidelines .................................. 14
Cleaning................................................. 15,16
Troubleshooting........................................ 16
FrequentlyAskedQuestions ............17-18
WarrantyPolicyandPrivacyPolicy ....... 19
ProductSpecifications ............................. 19
SupportCenter........................................... 19

ー1ー
1. Readallinstructionscarefullyandthoroughly.
2. Donottouchhotsurfaces.Alwaysholdthehandleordials.
3. Toprotectagainstfire,electricshockorinjury,donotimmersethecord,plugor
applianceinwaterorotherliquids.
4. Closesupervisionisnecessarywhentheapplianceisusedbyornearchildren.
5. Unplugtheappliancefromtheoutletwhennotinuseandbeforecleaning.Letit
cooldownbeforeputtingonortakingoffparts,andbeforecleaning.
6. Donotoperatetheapplianceifthecordorplugisdamagedorafterithas
malfunctionedorbeendamagedinanymanner.Sendtheappliancetothe
BALMUDASupportCenterforinspection,repairorreplacement.
7. TheuseofaccessoryattachmentsnotrecommendedbyBALMUDAmayresultin
fire,electricshockorinjury.
8. Donotuseoutdoors.
9. Donotletthecordhangovertheedgeofatableorcounter,ortouchhot
surfaces.
10. Donotplacetheapplianceonornearhotgasorelectricburners,orinaheated
oven.
11. Usecautionwhenremovingheatproofdishescontaininghotliquidsfromthe
appliance.
12. Todisconnect,turntheapplianceoff,thenremoveplugfromoutlet.
13. Donotusetheapplianceforotherthanintendedpurposes.
14．Donotputoversizedfoodsormetalutensilsintheappliance.Doingsomaycause
fireorelectricshock.
15．Donotcovertheapplianceorallowittotouchflammablematerialssuchas
curtains,draperies,walls,etc.
16. Donotstoreanyitemontopoftheappliancewheninoperation.
17．Donotcleanwithmetalscouringpads.Piecesofthepadcanbreakoffandtouch
electricalparts,creatingariskofelectricshock.
18．Usecautionwhenusingcontainersmadeofmaterialsotherthanheatproofmetal
orglass.
19．DonotstoreanymaterialsotherthanBALMUDArecommendedaccessoriesinthe
appliancewhennotinuse.
20. Donotplaceanyofthefollowingmaterialsintheappliance:flammableitems
(paper,cardboard,plastic,wood,etc.)oranyitemsotherthanfoodorBALMUDA
recommendedaccessories.
21. Donotcoverthecrumbcatcheroranypartoftheappliancewithmetalfoil.Doing
somaycauseoverheating.
22. Afteruse,pressthepowerbuttontoturnoffthepowerandremovetheplugfrom
theoutlet.
23. Theapplianceisforhouseholduseonly.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFEGUARDS

ー2ー
•Ashortpower-supplycordisprovidedtoreducerisksresultingfrombecoming
entangledinortrippingoveralongercord.
•Extensioncordsareavailableandmaybeusedifcareisexercisedintheiruse.
•Ifanextensioncordisused:
1)Themarkedelectricalratingoftheextensioncordshouldbeatleastashighasthe
electricalratingoftheappliance.
2)Thisapplianceisequippedwithagroundedplug.Theextensioncordshouldbea
groundingtype3-wirecord.
3)Theextensioncordshouldbearrangedsothatitdoesnotdrapeoverthecounter
toportabletopwhereitcanbepulledonbychildrenortrippedover.
Abouttheplug
Thisappliancehasagroundedtypeplugforsafetypurposes.This
plugisonlycompatiblewith3-pinoutlets.
Inordertoavoiddisablingthissafetyfunction,connectitto
correctlygroundedoutletsonly.Donotremovethegrounding
prong.
Failingtoconnectthegroundingconductorcorrectlymaycause
electricshock.Ifitisunclearwhethertheoutletiscorrectly
grounded,consultaqualifiedelectrician.
SHORT CORD INSTRUCTIONS
Groundingprong

ー3ー
SafetyPrecautions
ReadtheSafetyPrecautionscarefullybeforeusetoensurecorrectoperation.The
precautionsdescribedinthismanualmustbefollowedtoensuresafeuseofthis
applianceandpreventhazardstoyouandotherpeople,aswellasdamagetothe
applianceandyourhomeorproperty.
●Thesesymbolsindicaterequirementsduringuseofthisappliance.
WARNING
CAUTION
NOTICE
Donotdisassemble,repair,ormodifythisappliance.
Doingsomaycausemalfunctionorfire.Forrepair,pleasecontactBALMUDASupport
Center(p.19).
Donotusetheappliancenearflammablematerialssuchascurtains.
Doingsomaycausefire.
WARNING
●Thesesymbolsindicatethedegreeofharmordamagethatmaybecausedby
improperuse.
Indicatesactionsthatmaycausedeathorseriousinjury.
Indicatesprohibitedactionsthatmustnotbeperformed.
Indicatesrequiredactionsthatmustbeperformed.
Indicatesriskofelectricshock.
Indicatesriskofscaldingorburns.
Indicatesgeneralrisk.
Indicatesactionsthatmaycauseminorinjury.
Indicatesapropertydamage.
Thisapplianceisnotintendedforusebypersons(includingchildren)with
reducedphysical,sensoryormentalcapabilities,orlackofexperienceand
knowledge,unlesstheyhavebeengivensupervisionorinstructionconcerning
useoftheappliancebyapersonresponsiblefortheirsafety.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Doingsomaycausescalding(orburns),injury,orelectricshock.
Donotplacetheapplianceonflammablesurfacessuchaswoodencounters,
woodflooringorcarpet.
Doingsomaycausefire.
Donotsubmergetheapplianceinwater.Donotsplashwaterontheappliance.
Doingsomaycauseashortcircuitorelectricshock.

ー4ー
Donotapplypressureonthepowercord.
Donotdoanyofthefollowing,asthismaycausethepowercordtooverheatandcatchfire:
Scratch,modify,bend,pull,stepon,twistorplacethecordnearheatingdevices.Donot
placeheavyitemsonthecord,orusewhileitisbundled.
Donotcarryortilttheappliancewithwaterintheboiler.Tocheckifthereis
waterintheboilerwaituntiltheunitiscoolandremovetheboilercover.
Thewatermayspill,causingscaldingorelectricshock.
Donotusetheapplianceforanypurposeotherthanthoserecommendedinthis
instructionmanualandbyBALMUDA.
Doingsomaycauseaccidentssuchasfireorelectricshock.BALMUDAacceptsno
responsibilityincaseofimproperuseorfailuretofollowtheseinstructions.
Ifsmokeorfireappearsduringcooking,donotopenthedooruntiltheflames
gooutanddonotattempttoextinguishwithwater.Turnthepoweroffandthen
unplugthepowercord.
Doingsomaycausetheglasstoshatterorthefiretospread.
Donotblocktheairinlets(thesidesandunderneaththedoor,andthebottom
backsideofthemainunit)orcovertheappliance.
Doingsomaycauseburns,fire,ormalfunction.
Donotputanymetalobjectsorforeignobjectsintotheairinlet.
Doingsomaycauseelectricshockormalfunction.
Donotinsertfoodthatismorethan2.2incheshigh.
Toavoidexcessiveheatingtothetop,donotinsertfoodthatexceeds2.2inchesinheight.
Doingsomaycausefire.
Donotputanythingotherthantapwaterinthewaterinletorboilertray.
Addingoil,seasonings,orfoodmaycauseelectricshockorfire.
Donotinsertorremovethepowerplugwithwethands.
Doingsomaycauseelectricshock.
DonotusetheapplianceinanycountriesotherthantheU.S.
Doingsomaycausefireormalfunction.
Donotaddmorethanone5cccupofwatertothewaterinletatonetime.Do
nottopupthewater.Donotpourwateranywhereotherthanintothewater
inlet.Donotuseanycontainerotherthanthe5cccup.
Doingsomaycausewatertospill,causingmalfunction,scalding,orelectricshock(also
see“Cooking”onp.12).
Donotuseparchmentpaper,bakingpaper,orpaperbakingcups.
Doingsomaycausefire.
Donotconnecttheappliancetoanexternaltimerorseparateremote-control
system.
Theapplianceisnotintendedtobeusedwithanexternaltimerorseparateremote-control
system.

ー5ー
CAUTION
Stayneartheappliancewhileoperating.
Failuretodosomaycausefire.Besuretoturnthepoweroffbeforeleavingtheappliance.It
isparticularlyimportanttostayneartheapplianceandkeepaneyeontheprogressoffoods
thatarerichinoilorsugarsuchasbutter,jamorcheese.
Donottouchanypartsexceptthehandleordialsduringorimmediatelyafter
operation.
Doingsomaycauseburns,astheappliancebecomeshotduringtoasting.
Insertthepowerplugfullyintotheoutlet.Donotuseadamagedpowerplugor
apowerplugthatcannotbepluggedfullyintotheoutlet.
Iftheplugisnotinsertedproperly,itmaycausefireduetoelectricshockorheat.
Cleanthepowerplugregularly.
Dustaccumulatedonthepowerplugmaycausecondensation,whichcandamagethe
cableandcausefire.Removethepowerplugandwipeitwithadrycloth.
Besuretocleantheapplianceafteruse.
Failuretodosomaycausefoodresidueleftinsidetheappliancetocarbonize,causingfire
andsmoke.
Whenunpluggingthecord,pullontheplugratherthanthecord.
Failuretodosomaycausefireduetoelectricshockorshortcircuit.
Keepaccessoriessuchasthe5cccupoutofthereachofchildren.
Ifthe5cccupisaccidentallyswallowedbyinfantsorchildren,itmaycausechoking.Ifthe
appliancefalls,itmaycauseinjuryorburns.
Unplugtheappliance,allowittocool,andwipeawayanywaterfromtheboiler
traybeforecleaningormovingit.
Failuretodosomaycausescalding,burns,injury,orelectricshock.
Useanoutletthatmeetstheappliancerating(10.9A/1300W).Donotplug
otherelectricaldevicesintotheoutletwhenusingtheappliance.
Usingtheappliancewithanoutletthatdoesnotmeettheappliancerating,oronashared
outletwithotherdevices,maycauseoverheating,resultinginfire.
Besuretouseagroundedoutlet.
Thisapplianceusesagrounded3-pinplugforsafety.Ifthegroundisnotconnected,itmay
causeelectricshock.
Intheeventofanabnormalityormalfunction,stopusingtheappliance
immediately.
Failuretodosomaycausefire,electricshock,orinjury.Intheeventofanabnormalityor
malfunction,contactBALMUDASupportCenter(p.19).
[Examplesofabnormalitiesandmalfunctions]
·Thepowerdoesnotturnoff.
·Thepowercordandpowerplugareunusuallyhot.
·Theapplianceisdeformedorunusuallyhot.
·Theappliancefallsortipsover.
·Thepowercordisbrokenorstopspoweringtheappliancewhentouched.
·Theapplianceishotwhenitisnotinuse.
·Waterisleakingfromtheapplianceorboilertray.
·Theheatertubeiscracked.

ー6ー
Aftercookingorwhentheapplianceisnotinuse,unplugthepowercordfrom
theoutlet.
Failuretodosomaycausefireorelectricshockduetodeteriorationoftheinsulation.
Donotcookforlongerthannecessary.
Failuretodosomaycausefire.InmodesotherthanOvenMode,heataccordingtothetime
providedintheInstructionManualorontheappliance.InOvenMode,cookaccordingto
thestandardtime,andkeepaneyeontheprogressofthecooking.
Donotapplyexcessiveforcetotheglasswindoworallowittobecomewet.
Theglassmaybreak,causinginjury.
Donotcookwiththedooropen.
Steamfromtheboilermaycausescaldingorinjury.
Donotheatcannedorbottledfooddirectly.
Thecanorbottlemaybreakorbedeformed,causingburnsorinjury.
Donotaddwatertotheboilerduringheating.
Doingsomaycausescalding.
Wearthickgloveswhencleaning.
Failuretodosomaycauseinjurytothehandsorfingers.
Besuretoturnthepoweroffwhenremovingfoodfromtheappliance.
Failuretodosomaycauseburns.
Besuretoattachthetoastingrackframe.
Ifitisnotattachedthedoormayopenunexpectedly,resultingininjuryormalfunction.
Besuretounplugtheappliancefromtheoutletandallowtheappliancetocool
completelybeforecleaning.
Failuretodosomaycauseinjuryorburns.
Usetheincludedbakingpan.
Cautionshouldbeexercisedwhenusingotherpansordishesandmayleadtoinjuriesor
accidents.
Whentakingoutfoodorcontainers,usetongsorpotholders.
Failuretodosomaycauseburns.
Donotstareattheheatertubeforextendedperiodsoftime.
Doingsomaydamageyoureyes.
•Donotallowthewatersupplycovertobecome
jammedbetweenthedoorandthemainunit.
Doingsomaycausemalfunction.
•Whennotinuse,donotplaceanythingotherthanthe
toastingrackorboilercoverintheappliance.
Doingsomaycausemalfunction.
•Besuretoattachthecrumbcatcher,toastingrack,and
boilercoverwhentoasting.
Doingsomaycausemalfunction.
NOTICE

ー7ー
Besuretouseaheatproofdishwhenheatingpizzaandotherfoodsthatmay
dripoilontheheatertube.
Foodoroilmayfallontotheheatertubeandcatchfire.
Installtheappliancewithclearancestothetop,left,right,andrearasillustrated
below.Ifthewallismadeofheat-sensitivematerialsuchasplastic,leavemore
spacearoundtheappliance.
Heatandsteammaybuildup,causingmalfunction,fire,ordiscoloration/deformationof
thesurroundingwalls.
Donotinstalltheapplianceinalocationwhichmaybeaffectedbyheat.
Doingsomaycausefire.
Placetheapplianceonaflat,stablesurface.
Otherwise,thedoormayopenduringoperation.Thismaycausewatertospill,causing
electricshock.Itmayalsocausetheappliancetotipover.
Donotplaceobjectsoraccessoriessuchasthe5cccupontopof,underneath,
nextto,inside,oringapsaroundtheappliance.
Doingsomaycausesmoke,fire,orburns.
•Donotplacetheapplianceontopofotherequipment,suchasamicrowaveoven,or
placeotherequipmentontop.
Heatfromtheotherequipmentmaycausemalfunction,ortheheatandsteamfromthe
appliancemaycausetheotherequipmenttomalfunction.
Atleast
6inchesabove
Atleast4inches
oneachside
Atleast
4inchesbehind
WARNING
NOTICE
InstallationPrecautions

ー8ー
NamesofParts
Glass Powerbutton/Powerindicator/
Timerdial/Timerindicator
Powerplug
ContentsofthePackage
Toasting
rack
Modeselectiondial
Crumbcatcher
Powercord
Watersupply
cover
(retractable)
Door
Handle
Waterinlet
Toastingrackframe
Heatertube
(top/bottom)
Boilercover
Boilercover
Boilertray
Boilertray
Instructionmanual
Guidebook
5cccup
(locatedinthestyrofoamatthetop) Mainunit
Preinstalledaccessories
Toastingrack Bakingpan Boilercover Crumbcatcher
·Donotblocktheholesofthecrumbcatcher.
Doingsomaycausemalfunction.

ー9ー
WhenUsingfortheFirstTime
Whenusingtheapplianceforthefirsttime,removethetapesandattachthepartsbyfollowing
thestepsbelow.
Removethetapesfromlocations①to
④.
Makesurethecrumbcatcheris
properlyattached.
Thecrumbcatcherisattachedbeforethe
applianceisshippedfromthefactory.
1
4
3
2
Attachthetoastingrack.
Openthedoorandplacethetoastingrack
onthetoastingrackframeinsidethe
appliance.
Whenattachingtherack,makesurethe
four“feet”matchthecorresponding
locationsontheframe.
Crumbcatcher
Makesuretheboilercoverisattached
properly.
· Openthedoorandmakesurethatthe
boilercoverisinplace.
· Ifitisoutofplace,placeitontheboiler
traywith“Front▽”facingthefront.
· Placetheboilercoverbetweenthe
guidesatbothends.
Attachedcorrectly
Ifthecrumbcatcherisoutofposition,
insertitcorrectlyasillustratedbelow.
Boilercover
Boilercover
GuideGuide
③④
①
②
