B&B Electronics 3PCIOSD2A User manual

Documentation Number 3PCIOSD2x-3903 Manual Cover Page
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Optically Isolated Dual Port PCI Bus CE
RS-232/422/485 Serial Card
with Send Data Control
MODELS: 3PCIOSD2A 3PCIOSD2B
Documentation Number 3PCIOSD2x-3903m (pn4824-r004)
This manual applies to models 3PCIOSD2A and 3PCIOSD2B. The “2” suffix
designates the number of ports on the card. The “A” models are equipped with 16550
UARTs with 16 byte transmit and receive buffers. The “B” models come with 16850
UARTs with 128 byte transmit and receive buffers. The model number of each card is
printed on a sticker on the board.
This product designed and manufactured in Ottawa, Illinois USA
of domestic and imported parts by
International Headquarters
B&B Electronics Mfg. Co. Inc.
707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 USA
Phone [phone] -- General Fax [phone]
Home Page: www.bb-elec.com
Orders e-mail: [email protected] -- Fax [phone]
Technical Support e-mail: [email protected] -- Fax [phone]
European Headquarters
B&B Electronics Ltd.
Westlink Commercial Park, Oranmore, Co. Galway, Ireland
Phone [phone] -- Fax [phone]
Home Page: www.bb-europe.com
Orders e-mail: [email protected]
Technical Support e-mail: [email protected]
2000 B&B Electronics -- Revised October 2003

2000 B&B Electronics . No part of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photography, recording, or any information storage and retrieval
system without written consent. Information in this manual is subject to change without notice, and does not
represent a commitment on the part of B&B Electronics.
B&B Electronics shall not be liable for incidental or consequential damages resulting from the furnishing,
performance, or use of this manual.
All brand names used in this manual are the registered trademarks of their respective owners. The use of
trademarks or other designations in this publication is for reference purposes only and does not constitute an
endorsement by the trademark holder.

Documentation Number 3PCIOSD2x-3903 Manual Table of Contents i
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
TABLE OF CONTENTS
CHAPTER 1: GENERAL INFORMATION......................................1
INTRODUCTION .......................................................................................1
DESCRIPTION ..........................................................................................1
FEATURES ...............................................................................................1
SPECIFICATIONS......................................................................................2
CHAPTER 2: SETUP .........................................................................5
INSPECTION.............................................................................................5
RS-232 MODE.........................................................................................7
RS-422 MODE.........................................................................................8
RS-485 MODE.......................................................................................10
INSTALLING THE CARD..........................................................................13
CHAPTER 3: WINDOWS INSTALLATION ..................................15
WINDOWS 95 AND WINDOWS 98...........................................................15
WINDOWS 2000 PROFESSIONAL............................................................25
WINDOWS NT 4.0 .................................................................................30
CHAPTER 4: TROUBLESHOOTING.............................................37
APPENDIX A: 3PCIOSD2X I/O SCHEMATIC........................... A-1
APPENDIX B: RS-232 & RS-422/485 PINOUTS.........................B-1
APPENDIX C: JUMPER MODE TABLES.................................. C-1
APPENDIX D: TROUBLESHOOTING WITH COMTEST........ D-1
APPENDIX E: RENAMING COM PORTS - WIN 95/98/ME......E-1
APPENDIX F: DECLARATION OF CONFORMITY..................F-1

ii Table of Contents Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]

Documentation Number 33PCIOSD2x-3903 Manual Chapter 1 1
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Chapter 1: GENERAL INFORMATION
Introduction
The B&B Electronics 3PCIOSD2x isolated serial interface card is
designed for IBM compatibles with a PCI Bus. The PCI design is
Plug and Play compatible which allows the driver and Operating
System to select the IRQ and addresses used by the card. This is a
full size card with maximum length and height according to the PCI
Specification 2.1. This card requires a PC that can accommodate
this length.
The 3PCIOSD2x cards offer exceptional setup flexibility with a mix of
selectable operating modes. If you are writing your own
applications, be sure that the communications routine supports
Windows communication drivers and a wide range of COM ports.
Description
The two isolated ports can be independently configured for RS-232,
RS-422, or RS-485 data protocols. The RS-485 mode Automatic
Send Data Control feature transparently handles the enable and
disable functions of the RS-485 transceiver. Buffered, high speed
UARTs (16550 or 16850) make them ideal for high-speed (modem)
and multitasking applications.
Features
IBM compatible, PCI Version 2.1 bus
Supports baud rates to 460.8K baud with 4X clock option
enabled
Provides 2000 VDC minimum isolation on all lines from one DB-
9 male connector to the other and to the host computer
RS-232/422/485 Mode Independently Configurable for Each
Port
High speed 16 byte FIFO 16550A UARTs (Model 3PCIOSD2A),
128 byte FIFO 16850 UARTs (Model 3PCIOSD2B)
RS-485 Automatic Send Data Control or RTS control
2-wire or 4-wire RS-485 operation (half or full duplex)
120 Termination Select Jumpers for RS-422/RS-485 Networks

2 Chapter 1 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
RS-232 Mode Signal lines: TD, RD, RTS, CTS, DTR, DSR, &
DCD, and Signal Ground.
2 Channel RS-422 Signal Lines: TD(A), TD(B), RD(A), RD(B)
and Signal Ground.
RS-485 Signal Lines: TD(A), TD(B), RD(A), RD(B) and Signal
Ground. (Data A & Data B lines when wired for 2-wire
operation.)
Specifications
Bus: PCI bus version 2.1
Slot: Requires one full size PCI slot
Dimensions: 12.3 x 4.2 in (31.2 x 10.7 centimeters)
I/O Connections: Two 9-pin male D-sub (DB9M) connectors
OS Supported: Windows 95, 98, 2000 and NT 4.0
Baud rates: 460.8K baud maximum in RS-232/422/485 modes
UARTs: 6550 16 byte TX and RX buffers (3PCIOSD2A), or
16850 128 byte TX and RX buffers (3PCIOSD2B)
Character length: 5, 6, 7, or 8 bits
Parity: Even, odd or none
Stop bits: 1, 1.5, or 2
RS-232 Control/Data Lines Drivers/Receivers:
Device: SP211H Transceiver
High level output voltage: 5.0 V minimum
Low level output voltage: 5.0 V minimum
Output current limited to: 25 mA
Input high threshold voltage: 1.7 V maximum
Input low threshold voltage: 0.8 V minimum
Device will withstand: 15 V
RS-422/485 Driver/Receiver:
Device: 75ALS180 or MAX491
Differential driver output voltage: 1.5 - 6 V
Differential input high-threshold voltage: 0.2 V maximum
Differential input low-threshold voltage: 0.2 V minimum
Automatic RS-485 Driver Control Timing:
Driver is enabled when data is a logic “0” (start bit). Driver
remains enabled for one character transmission time (10 bits of data
at current baud rate). Each additional logic “0” resets the timeout.

Documentation Number 33PCIOSD2x-3903 Manual Chapter 1 3
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Termination: A 120 termination resistor is jumper selectable on
each 422/485 receiver.
Optical Isolation:
Data Line Device: HCPL-0600
Handshake Line Device: IL-207
The two serial ports are isolated from each other and the host
Max. Power Consumption: All ports loaded
+5 V @ 454.0 mA or 2.27 W
Accessories:
Software: Driver Disk (3.5) for Windows 95/98/2000/NT 4.0
PCI/USB COM Port Utility Disk (3.5)
Manual: Instruction Manual (this booklet)

4 Chapter 1 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]

Documentation Number 3PCIOSD2x-3903 Manual Chapter 2 5
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Chapter 2: SETUP
Inspection
Your 3PCIOSD2x serial card was tested for proper operation before
shipment. It should be in perfect mechanical and electrical condition
upon receipt.
The card is normally pre-configured for RS-232 operation.
The data clock speed for both ports is set by one jumper to x1
(normal) operation or to x4 operation.
The operating mode of each port on the card is set using 8 jumpers,
4 jumpers select RS-232 operation or RS-422/485 operation, one
jumper sets RTS for RS-232 & RS-485 modes or Send Data for RS-
485 mode, 2 jumpers select RS-422 or RS-485 operating modes for
Receive and Transmit, and the last selects 120 ohm termination for
the RS-422 or RS-485 Receiver.
Refer to Jumper Mode Table in Appendix C.
Before removing the card from the anti-static protective packaging:
Discharge any static electricity build-up on your body by
touching a large grounded metal surface or the metal chassis on
equipment connected to earth ground by a 3-wire power cord.
Avoid touching the gold connectors or other parts on the card
except as necessary to set the configuration jumpers for each
port. After setting the jumpers, ground yourself to the computer
chassis before and while inserting the card.
Remove AC power from the computer and unplug the power
cord before inserting the card.
Retain the ESD bag for handling the card.
Save the packaging for storage or shipping.
CAUTION: ELECTROSTATIC SENSITIVE DEVICE
Use ESD precautions for safe handling.

6 Chapter 2 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Figure 1. Silk Screen Plot of 3PCIOSD2x PCB

Documentation Number 3PCIOSD2x-3903 Manual Chapter 2 7
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
PORT1 JP3
A232
B232
C232
D232
422/485
422/485
422/485
422/485
PORT1
TX422
RX422
IN
485
485
OUT
PORT2
A232
B232
C232
D232
422/485
422/485
422/485
422/485
CONTROL
RTS(232)
RTS(232) SDPORT1
SDPORT2
CLOCK
*4 *1
TERMINATION
PORT2
TX422
RX422
IN
485
485
OUT
TERMINATION
JP4
JP6
JP5
JP2
JP1
CONNECTED
NOMEANING
RS-232 Mode
To configure one port for RS-232 mode, 5 jumpers must be
set/checked (5 for each port). The following settings will configure
Port 1 as RS-232. Jumpers for Port 2 shown in italics.
1. Set the four jumpers of JP3 (A-D) to the "232" (left) position.
Use JP5 for Port 2.
2. Set the top Control jumper (Port 1) of JP2 to "RTS (232)" (left)
position. Use the lower Control jumper (Port 2) for Port 2.
The remaining jumpers, JP4 and JP6, are unused in the RS-232
mode and may be in either position. Figure 2 shows the jumper
configuration to set both ports for RS-232 mode with *1 clock
enabled.
Figure 2. RS-232 Mode Jumper Settings
RS-232 Pinouts
The RS-232 ports on the 3PCIOSD2x cards are configured as
standard DTE RS-232 serial ports. Table 1 shows the signal
connections on the DB-9 male connectors.

8 Chapter 2 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Table 1: RS-232 Pinouts
RS-422 Mode
To configure one port for RS-422 mode, 7 jumpers must be
set/checked. The following settings configure Port 1 as RS-422.
Jumpers for Port 2 shown in italics
1. Set the four jumpers of JP3 (A-D) to the "422/485" (right)
position. Use JP5 (A-D) for Port 2.
2. Set the top jumper "TX" of JP4 to the “422” (left) position. Use
"TX" of JP6 for Port 2.
3. Set the second jumper "RX" of JP4 (Port1) to the “422” (left)
position. Use "RX" of JP6 for Port 2.
2. The bottom jumper "Termination" of JP4 switches the 120
Termination resistor IN or OUT. Use JP6 for Port 2. Typically
this resistor is not used. In some cases using high baud rates
and very long cables, termination is needed. See B&B’s free
RS-422/485 Application Note, Termination section, page 16,
for more information (available on our websites).
4. The top Control jumper "Port 1" of JP2 is unused in RS-422
mode. The lower Control jumper "Port 2" is unused in RS-422
mode for Port 2.
Figure 3 shows the jumper configuration for both ports set to RS-422
mode, with termination out and *1 clock enabled.
Name
Description
Direction
DB9M Pin
DCD
Data Carrier Detect
Input
1
RD
Receive Data
Input
2
TD
Transmit Data
Output
3
DTR
Data Terminal Ready
Output
4
GND
Signal Ground
------
5
DSR
Data Set Ready
Input
6
RTS
Request to Send
Output
7
CTS
Clear to Send
Input
8
NC
Not Connected
------
9

Documentation Number 3PCIOSD2x-3903 Manual Chapter 2 9
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
PORT1 JP3
A232
B232
C232
D232
422/485
422/485
422/485
422/485
PORT1
TX422
RX422
IN
485
485
OUT
PORT2
A232
B232
C232
D232
422/485
422/485
422/485
422/485
CONTROL
RTS(232)
RTS(232) SDPORT1
SDPORT2
CLOCK
*4 *1
TERMINATION
PORT2
TX422
RX422
IN
485
485
OUT
TERMINATION
JP4
JP6
JP5
JP2
JP1
CONNECTED
NOMEANING
Figure 3. RS-422
Mode Jumper Settings
RS-422 Pinouts
The RS-422 mode supports 2 channels (transmit and receive).
Table 2 shows the signal connections on the DB-9 male connectors.
Table 2: RS-422/485 Pinouts
With 2-wire RS-485 mode operation, your connection cable must
jumper TD(A) to RD(A) and TD(B) to RD(B). Connect from TD(A)
and TD(B) to the Data A( ) and Data B(+) wires of your RS-485
network.
Note that the EIA RS-422 Specification labels data lines with an "A"
and "B" designator. Some RS-422 equipment uses a " " and "+"
designator. In almost all cases, the "A" line is the equivalent of the
" " line and the "B" line is the equivalent of the "+" line. More
information on RS-422 communications can be found in B&B’s free
RS-422/485 Application Note (available on our websites).
Name
Description
Direction
DB9M
Pin
RD (A)
Receive Data A
Input
1
TD (B) +
Transmit Data B
Output
2
TD (A)
Transmit Data A
Output
3
GND
Signal Ground
------
5
RD (B) +
Receive Data B
Input
9

10 Chapter 2 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
RS-485 Mode
To configure one port for RS-485 mode, 8 jumpers must be
set/checked. The following settings configure Port 1 as RS-485.
Jumpers for Port 2 shown in italics.
1. Set the four jumpers of JP3 (A-D) to the "422/485" (right)
position. Use JP5 (A-D) for Port 2.
3. Set the top jumper "TX" of JP4 to the “485” (right) position. Use
"TX" of JP6 for Port 2.
4. For 2-Wire 485 operation, set the second jumper "RX" of JP4 to
the "485" (right) position (half duplex). For 4-wire 485 operation,
set it to the "422" (left) position (full duplex, Receive enabled).
Use "RX" of JP6 for Port 2.
5. Set the top Control jumper "Port 1" of JP2 to select the type of
RS-485 transmit driver control, automatic Send Data (SD) or
RTS. Select SD control (right) unless you are sure that your
software requires RTS control (left). Use "Port 2" of JP2 for Port
2.
6. The bottom jumper "Termination" of JP4 switches the 120
Termination resistor IN or OUT. Use JP6 for Port 2. Typically
this resistor is not used. In some cases using high baud rates
and very long cables, termination is needed. See B&B’s RS-
422/485 Application Note, Termination section, page 16, for
more information (available on our websites).
Figure 4 on the next page shows the jumper configuration for both
ports set for 2-wire RS-485 mode with Termination OUT, Send Data
Control, and *1 clock enabled.
RS-485 Pinouts
The pinouts in RS-485 mode are the same as those listed in
Table 2: RS-422/485 Pinouts on the previous page.

Documentation Number 3PCIOSD2x-3903 Manual Chapter 2 11
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
PORT1 JP3
A232
B232
C232
D232
422/485
422/485
422/485
422/485
PORT1
TX422
RX422
IN
485
485
OUT
PORT2
A232
B232
C232
D232
422/485
422/485
422/485
422/485
CONTROL
RTS(232)
RTS(232) SDPORT1
SDPORT2
CLOCK
*4 *1
TERMI NATION
PORT2
TX422
RX422
IN
485
485
OUT
TERMI NATION
JP4
JP6
JP5
JP2
JP1
CONNECTED
NOMEANI NG
Figure 4. RS-485 Mode Jumper Settings
Explanation of RS-485 Operation
In RS-485 mode the transmit driver must be enabled to transmit, and
set to a high impedance (tri-state) mode at the end of transmission.
In a 2-wire (half duplex) mode, the receiver is disabled during
transmit and enabled when not transmitting.
The 3PCIOSD2x card provides two methods of enabling/disabling
the transmit driver: automatic Send Data (SD) control and Request
To Send (RTS) control. With automatic SD control, the driver is
enabled when data is sent. The driver remains enabled for the
transmission time and ten data bits after data transfer is complete.
The SD circuit automatically adjusts its timing to the baud rate of the
data. With RTS control, software must assert the RTS line to enable
the driver and de-assert to disable the driver. To select SD control
for either port, place the JP2 "Port 1" or "Port 2" jumper in the “Send
Data” (right) position for that port. Place the jumper in the
“RTS(232)” (left) position for RTS control.
The receiver can also be enabled and disabled, a useful feature
in two-wire communications to prevent the transmitted data from
"echoing back" on its own receiver. The second jumper "RX" of JP4
(Port 1) or JP6 (Port 2) determines the receiver mode. If the
jumpers are placed in the “485” position, the "echo" is turned off.
This is achieved by disabling the receiver when the driver is
enabled. Placing the "RX" jumper in the “422” position will hold the
receiver enabled at all times. More information on RS-422
communications can be found in B&B’s free RS-422/485
Application Note (available on our websites).

12 Chapter 2 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
RS-422 and RS-485 Termination
A 120 termination resistor has been provided for the RS-
422/485 receivers. Note that termination should only be used in
systems with both high baud rates (>19200) and over several
thousand feet of cable. If a value other than 120 is desired, space
for a through-hole resistor has been provided on the board over the
top of the surface mount termination resistor. These through-hole
termination resistors are labeled as RTAB for Port 1 and RTBB for
Port 2, both by its respective connector. See our RS-422/485
Application Note for more discussion on termination (available on
our websites).
RS-485 Network Biasing
Biasing is required on an RS-485 network to hold the network in the
marking state between transmissions. The 3PCIOSD2x RS-485
receiver is biased with a 4.7 K pull-up surface mount resistor on
the Receive Data B line and a 4.7 K pull-down surface mount
resistor on the Receive Data A line. These values are usually
adequate for networks without termination and small numbers of
nodes. For more complex networks, the user must calculate the
required value and replace these resistors. Space for through-hole
resistors has been provided over the top of the surface mount
components placed at the factory. The through-hole resistor for the
pull-up is marked as R5B and the pull-down is marked as R13B for
Port 1. Similarly, the pull-up is marked as R30B and the pull-down is
marked as R36B for Port 2.
4X Baud Rate Option
Baud rates higher than 115,200 are possible with the 3PCIOSD2x
card in RS-232, 422, or 485 mode. Jumper JP1 controls the clock
frequency (for both ports) supplied to the UARTs. By moving this
jumper to the “*4” (left) position, the clock frequency is increased
from 1.8432 to 7.3728 MHz. This multiplies all UART baud rates by
4 times. For example, if the software is set for 57.6K baud, the
actual baud rate will be increased by a factor of four to 230.4K baud.
In many systems, these higher baud rates can improve throughput
significantly. However, remember that baud rates and actual
throughput are only proportional if the system can keep up with the
communications, otherwise increasing the baud rate effectively only
increases the idle time between characters.

Documentation Number 3PCIOSD2x-3903 Manual Chapter 2 13
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Installing the Card
1. Ground yourself by touching the metal chassis of the computer
to discharge any static electricity.
2. Turn off the power to your computer and unplug the power cord.
3. Remove the cover of the computer.
4. Locate a free PCI expansion slot.
5. Remove the expansion slot cover. Save the screw for
installation of the 3PCIOSD2x card.
6. Install the card into the unused slot. Be certain that the card is
inserted completely (fully seated) in the slot.
7. Secure the card with the mounting screw from step 5.
6. Replace the cover, plug in the power cord, and power up the
system.

14 Chapter 2 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]

Documentation Number 3PCIOSD2x-3903 Manual Chapter 3 15
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
Chapter 3: WINDOWS INSTALLATION
Windows 95 and Windows 98
Any prior installation using previous B&B Serial drivers must be
removed before installing the new drivers. (Refer to page 23.)
Windows 98 screens are shown for this section. Windows 95 is a bit
different with fewer steps and the screen names and text shown
differs. Windows 95 differences are noted (W95:…)
1. Configure each port on the PCI card to the desired RS-
232/422/485 mode using the jumpers.
2. Install the card in the slot, start the computer.
3. Windows will detect the PCI card, start the Add New Hardware
Wizard, and begin driver installation. When installation is
complete, Windows will set the hardware addressing & interrupt
using the drivers and the Plug and Play function of the
Operating System.
4. The driver installation proceeds in two parts: the first part installs
the driver for the PCI Serial card and the second part installs the
serial driver for the Com Port A & B (Port A=Port 1, Port B=2).
NOTE: The Optically Isolated 3PCIOSD2x PCI Serial Adapter card
will be identified as the 2-Port PCI Serial Adapter (3PCISD2). Both
cards use the same drivers and are functionally the same to the
Operating System.
continued next page

16 Chapter 3 Documentation Number 3PCIOSD2x-3903 Manual
B&B Electronics Mfg Co –707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax [phone]
B&B Electronics Ltd –Westlink Comm. Pk. –Oranmore, Galway, Ireland –Ph [phone] –Fax [phone]
5. After new hardware is detected, this screen will appear. (W95:
This screen is named Update Device Driver Wizard).
6. Click Next to continue. (W95: Insert the Driver Disk in Drive,
then click Next - skip to step 9)
continued next page
