BB200 Weighing Indicator
Programming and User’s Manual
B and B Scales Inc.
P.O. Box 812
Santa Teresa, NM 88008
www.bbscales.com
© B and B Scales Inc. All rights reserved.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 2
B and B Scales, Inc. is a registered trademark of B and B Scales, Inc.
All other brand or product names within this publication are trademarks or registered
trademarks of their respective companies. All information contained within this publication
is, to the best of our knowledge, complete and accurate at the time of publication. B and B
Scales, Inc. reserves the right to make changes to the technology, features, specifications
and design of the equipment without notice.
The most current version of this publication and other product updates can be found on
the product website:
www.bbscales.com/bb_200.html

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 3
Important Safety Information
WARNING
Failure to follow warnings could result in serious injury or death. Some
procedures described in this manual require work inside the indicator enclosure.
These procedures are to be performed by qualified service personnel only.
•Do not allow minors (children) or inexperienced persons to operate this unit.
•Do not operate without enclosure completely assembled.
•Do not place fingers into slots or possible pinch points.
•Do not use this product if any of the components are cracked.
•Do not make alterations or modifications to the unit.
•Do not remove or obscure warning labels.
•Do not submerge.
•Before opening the unit, ensure the power cord is disconnected from the power source.
WARNING
Calibration, Inspection and Maintenance of this indicator should be performed by
qualified staff only.
NOTICE
This indicator can be placed in service as Legal for Trade in certain jurisdictions.
Removing or Modifying Calibration Stickers, Opening the Indicator Housing,
Junction Boxes, Cabling, or other parts of the scale may VOID your commercial
certification.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 4
Table of Contents
Important Safety Information ..............................................................................................................3
Table of Contents ................................................................................................................................ 4
List of Tables........................................................................................................................................5
CHAPTER 1. INTRODUCTION ................................................................................................................ 6
Indicator Configurations ......................................................................................................................6
Basic Features ..................................................................................................................................... 6
Optional Features ................................................................................................................................6
Technical Parameters ..........................................................................................................................6
Physical Characteristics........................................................................................................................ 6
Battery Information............................................................................................................................. 7
CHAPTER 2. INSTALLATION ..................................................................................................................8
Power supply connection.....................................................................................................................8
Connection of Load Cell(s) and Indicator.............................................................................................. 8
Communication Interface ....................................................................................................................9
RS-232/RS-485................................................................................................................................. 9
4-20mA output (optional) .............................................................................................................. 10
CHAPTER 3. Basic Operation .............................................................................................................. 14
Keypad .............................................................................................................................................. 14
LCD Version: .................................................................................................................................. 14
LED Version ................................................................................................................................... 15
Key Functions .................................................................................................................................... 16
Power on & off .............................................................................................................................. 16
Zero operation............................................................................................................................... 16
Tare operation............................................................................................................................... 17
Accumulation operation ................................................................................................................ 17
Print .............................................................................................................................................. 18
Hold............................................................................................................................................... 18
COUNT........................................................................................................................................... 19
CHAPTER 4. PROGRAMMING and CALIBRATION ................................................................................ 20
Calibration Overview ......................................................................................................................... 20
Test Weights...................................................................................................................................... 20
Calibration Lock................................................................................................................................. 21
Entering Calibration Mode................................................................................................................. 21

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 5
Navigating the Calibration and Programming Menus ..................................................................... 21
Calibration and Programming Menus................................................................................................. 22
Setting Up Scale Functions ............................................................................................................. 23
CHAPTER 5. Output Formats .............................................................................................................. 31
Remote Displays................................................................................................................................ 31
Sending Data to/from a PC ................................................................................................................ 32
Serial Interface Reception Commands ............................................................................................... 33
R command data format ................................................................................................................ 33
N command data format................................................................................................................ 33
Print key data format..................................................................................................................... 33
Print Formats..................................................................................................................................... 33
PC or Remote Display Continuous Sending Formats........................................................................... 34
CHAPTER 6. Maintenance .................................................................................................................. 35
Common Errors and Solutions ........................................................................................................... 35
Daily Maintenance............................................................................................................................. 35
Restoring the Indicator to Factory Defaults........................................................................................ 36
Defalt Parameters.............................................................................................................................. 36
List of Tables
Table 1: DB9 Plug Pinout.................................................................................................................... 9
Table 2: RS-232 Pin Definitions ........................................................................................................ 10
Table 3: Relay Functions .................................................................................................................. 11
Table 4: Checkweigh Port Settings ................................................................................................... 12
Table 5: Setpoint Port Settings......................................................................................................... 12
Table 6: DB9 Pin Settings ................................................................................................................. 12
Table 7: LED Light Descriptions ........................................................................................................ 15
Table 8: Key Functions ..................................................................................................................... 16
Table 9: C11 (Hold Function) Menu Settings .................................................................................... 18
Table 10: Keypad Navigation ............................................................................................................. 22
Table 11: Indicator Menus and Functions .......................................................................................... 24
Table 12: Continuous Output Format................................................................................................. 31
Table 13: Output State A ................................................................................................................... 31
Table 14: Output State B.................................................................................................................... 31
Table 15: Output State C.................................................................................................................... 32
Table 16: Serial Interface Reception Commands ................................................................................ 33
Table 17: Common Errors and Solutions ............................................................................................ 35

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 6
CHAPTER 1. INTRODUCTION
The BB-200 Family of Indicators is a group of general purpose weighing indicators that are designed for
use in Agricultural and Industrial environments. Typical uses for this indicator include bench scales, floor
scales, agricultural feeders, including cake feeders, auger or gravity fed box feeders, squeeze chute
scales, single animal platform scales, calf table scales, and other agricultural applications.
Indicator Configurations
The indicator is available in four different configurations:
•Mild Steel, 110 volt A/C
•Stainless Steel Washdown, 110 volt A/C
•Mild Steel 110 volt A/C with rechargeable battery
•Stainless Steel Washdown, 110 volt A/C with rechargeable battery
Basic Features
All four available configurations share the following features:
•Weighing Functions: Zero, Tare, Accumulation, and Animal Weighing / Motion Filtering
•Total / Accumulation: Allows you to keep a running total of items weighed or counted.
•Count:Allows you to count items of a similar weight, for example, screws or nails.
•Checkweighing: The indicator can be programmed to support OVER / OK / UNDER warnings.
•Print:Can be printed to print Date, Time, Net, Tare and Gross.
•kg/lb/g/oz conversion: converts the shown weight between different units.
•RS-232 Output for a printer or external display: Used to connect to a printer or an external
display (sold separately).
Optional Features
This indicator can be special ordered or upgraded to support Digital I/O functions with 4-20mA output.
Technical Parameters
•Accuracy class (III)
•Maximum number of scale intervals n ≤ 10000
•Minimum input voltage per verification scale interval 1 μV /e
•Input signal voltage -5~20mV DC
•Excitation circuit 5 VDC, 4 wire connection, optional 6 wire connection
•Minimal load cell impedance 87 Ω, Maximum connection - 6 load cell of 350Ω
•AC power AC100~240V
•Battery life (if equipped) 6V4Ah lead battery or 7.4V4Ah Li battery 30h
•Operation temperature - 10 °C ~ + 40 °C
•Operation humidity ≤85%RH
Physical Characteristics

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 7
Images shown in millimeters.
Note: The housing below depicts the indicator configuration that includes a rechargeable battery. The
versions of this indicator without a batter do not have an extruded back panel.
LP7510
ON
OFF Total Count Units Gross Tare Zero Print
Class Capacity=
LP7510 Weighing Indicator
Hi
ok
Lo
Gross Net Tared Total pcs lb kg Battery
ON
OFF Total Count Gross Tare Zero Pri nt
Units
Class Capacity= d=
Battery Information
•To charge the battery, simply plug in the indicator with the included A/C Power Cord.
•Your battery will arrive partially charged from the factory. Prior to using the indicator for the
first time, charge the battery for 10-12 hours to prevent damage and prolong the life of the
battery.
•Battery life can be checked from the light on the right bottom of the display. When the voltage
is getting low, the battery symbol will flicker, and the LCD display will show “LOBAT.” On the LED
display, the red light will flicker.
•Average Charge time: 10-12 hours.
•Average Battery Life with normal use: 30 hours.
•When fully charged, the light turns green on the LED display; the battery symbol shows full on
LCD display.
•If the indicator is not used for an extended period, remove the battery to avoid leakage.
•If you use the indicator regularly, battery life may be extended by fully discharging the battery
every month. To do this, simply leave the indicator on until the battery dies, then plug it in to
recharge it.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 8
CHAPTER 2. INSTALLATION
Power supply connection
The indicator is powered by the included A/C adapter or by the optional 6v battery. Simply plug the
adapter directly into the “DC” port on the indicator housing. This action also charges the battery, if
equipped.
Connection of Load Cell(s) and Indicator
This indicator can power from one to six 350Ω load cells, with either a 4-wire or 6-wire configuration.
There are two methods to connect the load cells to the indicator:
A. Quick disconnect, as below:
4 wire load cell connectors
6 wire load cell connector
For most applications, the BB-200 Indicator comes with a five-pin male plug on the bottom of the
indicator. This pigtail/plug is connected directly to the motherboard on the inside of the indicator.
Having this plug allows you to disconnect the indicator from the rest of the scale, which is convenient
should you need to charge the battery or protect the indicator from theft or weather. The typical
exception to this is if you purchased a stainless steel washdown version of the indicator. In this case,
Option B, below, is preferred, as it provides a better watertight connection.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 9
B. Direct internal connection
The signal cable for load cell (or the junction box) is connected to the Load cell terminal strip on
the motherboard. To make this connection,
1. Open Weighing indicator back cover
2. Insert the cable through one of the strain reliefs on the underside of the indicator
3. Run the cable to the load cell terminal strip, as shown below.
4. Connect the wires as indicated below and ensure that the screws are tightly secured.
For 4 wire load cell, connect EXC+ SIG+ SHD SIG- EXC-.
For 6 wire load cell, remove RJ4 and RJ7 above the terminal trip, then connect SEN+ EXC+ SIG+ SHD SIG-
EXC- SEN-.
Important: Most vendors use a junction box with an internal summing card to combine the signals from
all the attached load cells. However, different vendors use different plugs. Most cables that are used are
simple four or five-pin microphone cables, however even these come in different sizes. B and B Scales,
Inc. typically stocks four and five-pin microphone cables. See www.bbscales.com for more information
about Home Run Cables and load cell cabling in general.
Communication Interface
RS-232/RS-485
The BB-200 supports an RS-232 connection on the motherboard however there is typically not an
external port pre-wired when the indicator ships. You will notice in the packaging that was included with
your indicator that there is a DB-9 RS-232 plug that can be wired to the motherboard and installed. DB9
Pin and 3 Pin are both supported.
DB9 definition
Table 1: DB9 Plug Pinout
DB9 joint
Definition
Function
2
TXD
Sending data
3
RXD
Receiving data

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 10
5
GND
Ground interface
Note: RS485 uses pin 2 and 5 for connection
3 Pin definition
Internal connection
Table 2: RS-232 Pin Definitions
Pins Definitions Function
RS232
TXD Sending data
RXD Receiving data
GND Ground
RS485
A RS485 output “A” port
B
RS485 output ”B” port
4-20mA output (optional)
Technical parameters:

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 11
•Resolution: 1/1000
•Outside Load: 0-500Ω
Connection:
Outside connection: 4~20mA
analog input + port connected to “1” pin of DB9
analog input - port connect with “6” pin of DB9.
Testing :
Connect the 4~20mA to the analog input module, then read the value of 4~20mA at analog input
channel of an external computer.
If you do not have ananalog input module, adjust a multimeter to the current stalls, series connection
with the 4~20mA.
During Calibration
1. Press[ ] and [ ] go to C32.
2. Show[out-4], the output current should be 4mA.
3. When you press [ ]show[out-5]，Pres[ ]show[out-20]，the output current should be 20mA.
4. Adjust the current as needed, for example, adjust to [out-20], Press [ ] or [ ] to adjust the
current.
Digital I/O Function instructions:
4~20mA corresponds to Zero ~Max. capacity. After pressing ” TARE”, the weight will start from 4mA. Set
C31=0, 0~20mA output mode; C31=1 4~20mA output mode.
If you need 0~5V output, Set C31=0, then connect 250Ω at the two ends of current output, that will get
5 voltage at resistance two ends.
Relay output function (optional)
The indicator can be equipped with up to four optional relays that can be used to control external
equipment based on data gathered by the indicator. This can include controlling actions caused by
weight, piece count, upper or lower weight limits, or other data points that the indicator can identify.
If equipped, these functions are controlled through the C33 menu, as described below.
Table 3: Relay Functions
Function Definition

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 12
C33＝0 No output none
C33＝1 Weight comparison Hi OK Low Zero
C33＝2 Stable weight comparison Hi OK Low Zero
C33＝3 Set point output Set point 1 Set point 2
Table 4: Checkweigh Port Settings
Output port output condition definition
C33＝1
C33＝2
OUT1
weight>=C13
Hi (over)
OUT2
C13> weight >=C14
OK (accept)
OUT3
weight<C14
Low (under)
OUT4
weight <20d
Zero
Table 5: Setpoint Port Settings
Output port output condition definition
C33＝3
OUT1
weight >=C14
Set point 1
OUT2
weight >=C13
Set point 2
For example, for a check weight application, connect the indicator with three lights; yellow, green, and
red. The yellow light comes on when the scale is overloaded, the green light comes on if the seight is in
the “OK” range, and the red light comes on if the weight is underweight.
Table 6: DB9 Pin Settings

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 13
DB9 pin
definition
port
1 pin
1st output signal pin
Out1
6 pin
1st output signal pin
Out1
2 pin
2nd output signal pin
Out2
7pin
2nd output signal pin
Out2
3 pin
3rd output signal pin
Out3
8 pin
3rd output signal pin
Out3
4 pin
4th output signal pin
Out4
9 pin
4th output signal pin
Out4
Internal Pin Connections

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 14
CHAPTER 3. Basic Operation
This chapter describes the basic operation of the indicator.
Keypad
The indicator is available with either an Light Emitting Diode display panel (LED) or a Liquid Crystal
Display display panel (LCD). Generally speaking, the LCD panel is better for outdoor use, as the
characters are more visible. It can be difficult to read the LED display in direct sunlight, but the LED
display is far preferable in low light situations, such as warehouses, barns, etc.
The LCD display is available in both B and B colors and with the Stull Feeders design. There is no
functional difference between these two indicators.
LCD Version:
LCD Indicator Faceplate
Alternate LCD Indicator Faceplate produced for Stull Feeders
Note that the Stull Feeders Indicator is available in LCD only.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 15
LED Version
Table 7: LED Light Descriptions
Symbol
Meaning
Weighing data
Stable signal at ZERO pounds.
weight is stable
Gross
Gross weight
Net
Net weight
Tared
Tare status
Total
Go to accumulation mode
Hold
Data hold
PCS
Show the counting status
lb
lb
kg
kg
.
Decimal
Hi
Over load
OK
accept
Lo
Under load

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 16
Key Functions
The table below describes the functions of the keys in standard operating mode, for both the LED and
LCD versions of the indicator. In programming mode, the keys have different functions, which are
described in PROGRAMMING and CALIBRATION PROCEDURES.
Table 8: Key Functions
Key
Key function
Print
Zeros the weight if the displayed weight is within the zero range
1. In Gross Weight mode, get the tare weight and zeros the
indicator.
2. In Net Weight Mode, clears the tare value and gets the Gross
Weight.
1. Displays the Piece Count when in Counting Mode.
2. Used with the PRINT Key to set up the scale for Counting
mode. See description below.
Coverts between Kg, Lbs, Oz and g.
1. Shows the total accumulated weight in Accumulation mode.
2. works with the Print key to perform the accumulation function.
Press 2 seconds to power on or power off
Enter Hold Mode
Power on & off
Press for 2 seconds to power on or power off the indicator. When the indicator starts up, it
performs a Power On Self-Test (POST), during which it will light all of the lights, and test the screen
functions, check for load cell connectivity, etc. After the POST, it will go to basic weighing mode.
Zero operation
Initial zero setting

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 17
By default, when you power on the indicator it will show zero, even if there is weight on the indicator.
This is preferable if you have a squeeze chute, platform, floor scale, or other scale that has a heavy
platform. In most cases, you really don’t care about the actual weight of the scale itself. However, if you
are weighing feed, grain, or another commodity that is routinely not removed from the scale when you
shut it off, you can program the scale NOT to zero when it is first powered on. See Menu C-21 in
CHAPTER 6 to change this setting.
Manual zero setting
Press the key when the scale is stable (and not negative) to zero the display. This is a good habit
to get into every time you are preparing to weigh something.
Tare operation
Press the key to zero the weight of an empty container, then fill the container with a
commodity to weigh it. If necessary, you can press and hold the for two seconds to manually
enter the tare weight.
Accumulation operation
Enter Accumulation Mode
The key allows you to keep a running total of the commodities you are weighing. Follow the
instructions below to use this function:
1. Zero the scale.
2. Place an item on the scale.
3. Press .. The display will show “n 001”, then display the current weight.
4. Remove the load from the scale. The scale will return to zero.
5. Load the second weight. Press . The display will show “n 002”
6. Repeat for as many items as you have to weigh, up to 999 items.
mode, ”Total” light on, display” n 001”, and then display loaded weight; Unload the weight , back to
zero, load the second weight again till stable. Press display”n002” then display the second loaded
weight. Repeat it agin and again, maximum 999 times.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 18
Check the Accumulation
Press and simultaneously to show the number of weighments and the total weight of
the items weighed.
EXIT Accumulation Mode
Press and hold the key for two seconds to exit Accumulate Mode.
Print
Press the key to print.
Note: The scale must be stable and showing a positive number to print.
Hold
There are five different hold functions. You set up the Hold function in the C11 menu when you program
the indicator. Press the key to activate the specific function that you have programmed. The
available functions are:
Table 9: C11 (Hold Function) Menu Settings
C11 Menu Value
Function
0
Hold is disabled.
1
Peak Hold. The scale will lock on to the maximum weight attained. Imagine
jumping on the scale.
2
Simple Hold. The scale will lock on to the weight on the scale.
3
Basic Animal Weighing. The scale will take a series of averages over six
seconds, then display the average. (The scale takes hundreds of weights per
second)
4
Manual Animal Hold. The scale will take a series of averages over a time
period set in C39, then display the average. Press and hold the key
to activate. Press the key again to return to normal weighing mode.
5
Configurable Animal Weighing: Use C39 and C40 to set the parameters for
animal weighing.
C-39: Set the period of time that the animal is actively standing and moving
around on the scale.

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 19
C11 Menu Value
Function
C-40: Set the period of time between animals, when the scale is empty.
Important: Some versions of this indicator do not have advanced hold functions. Navigate to C-11. If
you are not able to set a value of 0 to 5, your indicator is not equipped with advanced hold. The only
way to fix this is to upgrade your motherboard. See www.bbscales.com for options.
COUNT
The counting feature allows you to count commodities that weigh the same; things like nuts, bolts, nails,
beads, etc. To use the counting feature:
1. Turn on the scale in normal weighing mode.
2. Identify a known number of your commodity to use a sample, and place it on the scale.
3. Press the button. The display will read, “PCS 0.”
4. Use the and keys (the Tare and Zero keys) to adjust the number of items in your
sample. Press to confirm.
5. Load your commodity on the scale. The indicator will show the quantity of items in your batch.
(this is the QUANTITY, not the WEIGHT).

BB-200 Weighing Indicator – Programming and User’s Manual
Copyright © 2023 – B and B Scales, Inc. All Rights Reserved.
Page 20
CHAPTER 4. PROGRAMMING and CALIBRATION
IMPORTANT
This indicator can be commercially Legal for Trade in all 50 states and
Canada. If your scale is certified as Legal for Trade, the following procedures
must be performed by a technician who is licensed in your jurisdiction.
Failure to do so will void your calibration.
WARNING
If you remove or damage the wire seal and/or calibration sticker, your
calibration is void.
Calibration Overview
Calibrating an indicator – almost any indicator – is an exercise in recording the signal the indicator is
receiving from the load cell(s). You need at least two points. One of those points is “zero,” and one of
those points is a known weight placed at a point higher on the graph. This point is called the “Span.”
The closer you can get to true linearity, the more accurate your scale will be. It is typically suggested that
you calibrate a scale with at least 80% of the capacity of the scale. This is not always practical, since you
would need 4000lbs of test weights to calibrate a 5000lb floor scale or livestock scale. Instead, it is good
practice to use a test weight that is close to the weight of what you will actually be weighing.
Test Weights
Certified scale companies and regulatory agencies will typically use test weights that are certified and
traceable to a government standard. If you are doing this yourself, you likely won’t have these. Here are
some acceptable alternatives for scales that do not need to be certified as Legal for Trade:
•Tractor Weights
•Unopened bags of feed, grain or mineral
•Anything made of steel that you know the weight of.
Do not use people or animals or anything that breathes or has a pulse.
