Bannon 57941 User manual

READ & SAVE THESE INSTRUCTIONS
12In. Utility Blower
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #57941

Page 2 of 14
Thank you very much for choosing a Bannon™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This blower is designed for certain applications only. Northern Tool and
Equipment is not responsible for issues arising from modification or
improper use of this product such as an application for which it was not
designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 14
Table of Contents
Intended Use..........................................................................................................................................4
Packaging Contents..............................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Grounding..............................................................................................................................................6
Extension Cords....................................................................................................................................7
Before Each Use....................................................................................................................................8
Operating Instructions..........................................................................................................................8
After Each Use.......................................................................................................................................9
Maintenance ..........................................................................................................................................9
Troubleshooting..................................................................................................................................10
Parts Diagram......................................................................................................................................11
Parts List..............................................................................................................................................12
Replacement Parts..............................................................................................................................12
Limited Warranty.................................................................................................................................13

Page 4 of 14
Intended Use
The Bannon 12 Inch Utility Blower can be used as a blower, circulator, or simply as a fan. It's perfect
for exhausting fumes, ventilating confined spaces, and spot cooling.
Packaging Contents
Blower (1)
Owner’s Manual (1)
Technical Specifications
Property
Specification
Motor
120 Volt DC
Airflow
2600 CFM
Max Current Consumption
8.2 Amps
Watts
1000
Horsepower
1.0
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas

Page 5 of 14
may put you dangerously close to cutting tools and rotating parts.
Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
Do not allow the fan to come into contact with an electrical source. The tool is not insulated and
contact will cause electrical shock.
Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
⚠WARNING
PERSONAL SAFETY
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts. Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
Do not overreach. Keep proper footing and balance at all times.
Do not use the tool when tired or under the influence of drugs, alcohol or medication.
⚠CAUTION
BLOWER USE AND CARE
Do not force the blower. Products are safer and do a better job when used in the manner for which
they are designed. Plan your work, and use the correct product for the job.
Check for damaged parts before each use. Carefully check that the product will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative
before using.
Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety

Page 6 of 14
measures reduce the risk of starting the tool accidentally.
Store the blower when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
Keep guards in place and in working order. Never operate the product without the guards in place.
Do not leave the tool running unattended.
Specific Operation Warnings
⚠WARNING
Electric shock hazard. Do not expose to water or rain. Never place blower in standing water.
Be sure equipment is properly grounded.
Use only outdoor-rated extension cords of proper size.
Do not use this product with any solid-state speed control device.
Rotating Blade Hazard. Can cause serious injury or cut. Keep hands clear.
For indoor use only. Do not use outdoors. Do not place the fan in or near a window. Rain may
create an electrical hazard.
DO NOT operate without guards in place.
Never allow air intake grill to become blocked.
Never discharge flammable solvents or kerosene based chemicals through the grill.
Do not use the blower in areas where flammable or combustible liquids, gases, vapors, dust,
fibers, or filings may be present.
Never put any object in the air intake grill.
Turn power OFF before servicing.
Not for use by or around children.
Grounding
⚠WARNING
This machine must be grounded while in use to protect the operator from electrical shock. This
unit is equipped with an electrical cord that has an equipment grounding conductor and a
grounding plug. The plug MUST be plugged into a matching receptacle that is properly installed
and grounded in accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PROVIDED PLUG. If it will not fit the receptacle, have the proper
receptacle installed by a qualified electrician.
CHECK with a qualified electrician or service person if you do not completely understand the

Page 7 of 14
grounding instructions, or if you are not sure the tool is properly grounded.
Grounded Tools: Tools with 3-Prong Plugs
Tools marked with Grounding Required have a 3-wire cord and 3-prong grounding plug. The plug
must be connected to a properly grounded outlet. If the tool should electrically malfunction or break
down, grounding provides a low resistance path to carry electricity away from the user, reducing the
risk of electric shock. (See Figure A.)
The grounding prong in the plug is connected through the green wire inside the cord to the grounding
system in the tool. The green wire in the cord must be the only wire connected to the tool’s grounding
system and must never be attached to an electrically live terminal.
Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance
with all codes and ordinances. The plug and outlet should look like those in the following illustration.
Double Insulated Tools: Tools with Two-Prong Plugs
Tools marked Double Insulated do not require grounding. They have a special double insulation
system which satisfies OSHA requirements and complies with the applicable standards of
Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code.
(See Figure B.)
Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration.
Extension Cords
⚠WARNING
USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When
using an extension cord, be sure to use one heavy enough to carry the current your product will
draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause
overheating.
Be sure your extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it. Protect your extension

Page 8 of 14
cords from sharp objects, excessive heat and damp or wet areas.
Grounded tools require a 3-wire extension cord. Double Insulated tools can use either a 2- or 3-
wire extension cord.
As the distance from the supply outlet increases, you must use a heavier gauge extension cord.
Using extension cords with inadequately sized wire causes a serious drop in voltage, resulting in
loss of power and possible tool damage.
The smaller the gauge number of the wire, the greater the capacity of the cord. For example, a
14-gauge cord can carry a higher current than a 16-gauge cord. Minimum extension cord wire
size is shown in the following table:
Minimum Wire Size Of Extension Cords
Nameplate AMPS
Cord Length
25'
50'
100'
150'
0-6
18 AWG
16 AWG
16 AWG
14 AWG
6-10
18 AWG
16 AWG
14 AWG
12 AWG
10-12
16 AWG
16 AWG
14 AWG
12 AWG
12-16
14 AWG
12 AWG
NOT RECOMMENDED
When using more than one extension cord to make up the total length, make sure each cord
contains at least the minimum wire size required.
If you are using one extension cord for more than one tool, add the nameplate amperes and use
the sum to determine the required minimum cord size.
If you are using an extension cord in damp locations, make sure it is marked with the suffix W-A
(Win Canada) to indicate it is acceptable for outdoor use.
Make sure your extension cord is properly wired and in good electrical condition. Always replace
a damaged extension cord or have it repaired by a qualified electrician before using it.
Protect your extension cords from sharp objects, excessive heat, and damp or wet areas.
Before Each Use
⚠WARNING
Be sure parts are not damaged.
Be sure all parts are secure.
Operating Instructions
⚠WARNING
Electric shock hazard. Do not expose to water or rain. Never place blower in standing water.
Be sure equipment is properly grounded.
Use only outdoor-rated extension cords of proper size.
Do not use this product with any solid-state speed control device.
Rotating Blade Hazard. Can cause serious injury or cut. Keep hands clear.
For indoor use only. Do not use outdoors. Do not place the fan in or near a window. Rain may
create an electrical hazard.

Page 9 of 14
DO NOT operate without guards in place.
Never allow air intake grill to become blocked.
Never discharge flammable solvents or kerosene based chemicals through the grill.
Do not use the blower in areas where flammable or combustible liquids, gases, vapors, dust,
fibers, or filings may be present.
Never put any object in the air intake grill.
1) The blower is completely assembled and ready to operate--only the duct must be attached. Upon
removing the blower and duct from the carton, inspect them for any possible damage in transit.
2) Before operating the blower, read all the safety precautions and general safety information about
the proper and safe use of the blower.
3) Assess your job site; certain job site locations are classified as being hazardous because the
atmosphere may contain gas vapor or dust in explosive quantities.
4) Locate a properly grounded outlet.
5) Prior to plugging the blower into a grounded outlet, inspect the inlet and outlet grills; remove debris
that may restrict airflow movement. Never operate the blower without the inlet and outlet grills
properly secured and in place. Never replace the grills with other than factory supplied
replacement units.
6) Note the directional airflow indicator on the external shell. This is the way the air moves.
7) Place the blower on secure footing to prevent it from shifting while in use.
8) Do not stand directly in front of and/or face the blower outlet. Personal injury can result from being
struck by debris thrown at a relatively high velocity from the blower blade.
9) If ducting is used, place end of duct over the blower end and note direction of the airflow.
10) When ducting is used, be aware that the airflow rate decreases as the length of duct increases.
Airflow rates will vary with specific duct types and manufactures.
11) Position blower air inlet away from walls and other obstructions to allow for maximum air intake.
12) For safe operation, use the blower only in combination with thorough gas detection tests and
continual retesting.
After Each Use
⚠WARNING
Be sure the blower is in the OFF position.
Inspect blower for damages.
Store in a secure, dry location.
Maintenance
⚠WARNING
Always shut off the blower and unplug it from its power source to prevent accidental starting and

Page 10 of 14
the possibility of electrical shock and/or electrocution.
Be sure the fan blade has stopped rotating before placing any objects or fingers near the grill.
Do not pressure-wash the blower.
Visually check all fasteners and individual components for loose or broken parts. Tighten or
replace items as required, with genuine, factory approved replacement parts only.
Keep the blower blade clean from debris. Accumulation of dust, dirt, paint, etc., on the blower
blade will throw the blade rotation out of balance resulting in damage.
To clean the blower blade, be sure the plug is disconnected and the blade has stopped rotating.
Remove one grill and wipe the blade and interior shell housing clean of debris with a damp cloth
and mild liquid soap.
Dry all parts thoroughly.
Replace grill prior to next operation.
Maintenance Interval
Maintenance Point
DAILY BEFORE OPERATION
VERIFY all parts are in good condition without
obstructions to the grill.
VERIFY that the blower cord and plug are intact.
Troubleshooting
⚠WARNING
All service procedures should be executed with the unit unplugged.
All service procedures should be performed by a qualified service technician.
Use the procedures below to troubleshoot problems before contacting service personnel.
Failure
Possible Cause
Corrective Action
Unit will not run
1) No power to unit.
2) Switch not on.
3) Switch is faulty.
4) Faulty / broken cord or motor wire.
1) Plug unit in. Check circuit breaker.
2) Place in “ON” position.
3) Replace switch.
4) Perform continuity check using
volt/amp meter. Repair/replace
faulty/broken wire.
Unit runs but fan
makes loud
scraping noise
1) Unit has been severely jolted causing
fan to rub against housing.
2) Unit has been severely jolted causing
housing to deform.
1) Replace entire blower unit.
2) Replace entire blower unit.
Unit runs but
vibrates
excessively
1) Severe jolt has caused unit to be out
of balance.
2) Fan blade damaged.
3) Dirt build up on one side of fan blade.
1) Replace fan blade if necessary.
2) Replace fan blade.
3) Clean fan blade.

Page 11 of 14
Failure
Possible Cause
Corrective Action
Unit runs but fan
does not turn
1) Fan is jammed against housing.
2) Capacitor wire has broken/come
loose, capacitor has failed.
3) Housing has been damaged such
that it presses on the fan blade.
1) Replace fan blade if necessary.
2) Repair/replace wires/capacitor as
necessary.
3) Replace entire blower unit.
Unit runs briefly,
then shuts off on
overload
1) Motor bearings are failing, or motor
has developed an internal electric fault.
2) Intake grill and/or exhaust grill is
obstructed.
3) Excessive duct length.
1) Replace entire blower unit.
2) Remove obstruction.
3) Reduce duct length to
recommended maximum.
Parts Diagram

Page 12 of 14
Parts List
Reference
Part Description
Quantity
1
Front Guard
1
2
Blade
1
3
Capacitor
1
4
Back Guard
1
5
Hook
2
6
Power Cord
1
7
Rocker Switch
1
8
Rubber Foot
4
Replacement Parts
For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
When ordering parts, the following information will be required: item description, item model
number, item serial number/item lot date code, and the replacement part reference number.
The distributor reserves the rights to make design changes and improvements to product lines
and manuals without notice.

Page 13 of 14
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only
("You" or ''Your'') that the Bannon product purchased will be free from material defects in both
materials and workmanship, normal wear and tear excepted, for a period of two years from date of
purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in
accordance with product instructions. There are no other warranties, express or implied, including the
warranty of merchantability or fitness for a particular purpose. If the product does not comply with this
limited warranty, Your sole and exclusive remedy is that We will, at our sole option and within a
commercially reasonable time, either replace the product or product component without charge to You
or refund the purchase price (less shipping). This limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse, neglect,
misuse, or as a result of any accident or in any other manner; (c) damage from misapplication,
overloading, or improper installation; (d) improper maintenance and repair; and (e) product alteration
in any manner by anyone other than Us, with the sole exception of alterations made pursuant to
product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the original
purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the product by make
and model number, and follow the claim instructions that will be provided. The product and the
purchase receipt must be provided to Us in order to process Your warranty claim. Any returned
product that is replaced or refunded by Us becomes our property. You will be responsible for return
shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty
or any other warranty related to the product. We shall not be liable for: service or labor charges or
damage to Your property incurred in removing or replacing the product; any damages, including,
without limitation, damages to tangible personal property or personal injury, related to Your improper
use, installation, or maintenance of the product or product component; or any indirect, incidental or
consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the specified
use(s) stated in the product instructions is at Your own risk.
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which vary
from state to state. Some states do not allow limitations or exclusions on implied warranties or
incidental or consequential damages, so the above limitations may not apply to You. This limited
warranty is governed by the laws of the State of Minnesota, without regard to rules pertaining to
conflicts of law. The state courts located in Dakota County, Minnesota shall have exclusive jurisdiction
for any disputes relating to this warranty.

Page 14 of 14
Distributed by:
Northern Tool & Equipment Company, Inc.
Burnsville, Minnesota 55306
www.northerntool.com
Made in China
