Baratza Encore ESP User manual

®
January 2023 (v1.0)
ENCORE ESP™ OPERATIONS MANUAL
Barista-quality coffee is just a
few clicks away!

®
January 2023 (v1.0) 2
ENCORE ESP™ OPERATIONS MANUAL
TABLE OF CONTENTS
SAFETY INFORMATION 3
PARTS IDENTIFICATION 4
OPERATION 5
CARE & CLEANING 7
CONE BURR ASSEMBLY 9
WARRANTY & SERVICE 12

®
January 2023 (v1.0) 3
ENCORE ESP™ OPERATIONS MANUAL
SAFETY INFORMATION
Please read the information below very carefully.
It contains important safety information for this
appliance. Please keep these instructions for future
reference.
CAUTION: ALWAYS unplug the electrical supply cord prior to cleaning the grinder.
! Use only with AC current and the correct voltage. See the label on the
base of the grinder to determine the correct voltage.
! Only clean the grinder housing with a dry or slightly damp cloth. Do not
immerse the grinder, plug or cord in water or any other liquid.
! Baratza will not accept any liability for damage, injury, or warranty if the
grinder is used other than for its intended purpose (i.e. grinding roasted
whole coee beans) or is improperly operated or repaired.
! Keep the appliance and its cord out of reach of children aged less than
8 years.
! Do not operate the grinder with a damaged cord or plug. If the supply
cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualiied persons in order to avoid a hazard.
! Do not leave your grinder unattended while turned ON.
! This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
! Cleaning and user maintenance shall not be made by children without
supervision.
! Always unplug the grinder from the electrical supply before assembling,
disassembling or cleaning. To unplug, grasp plug and remove from the
outlet. Never pull on the cord.

®
January 2023 (v1.0) 4
ENCORE ESP™ OPERATIONS MANUAL
10 20 30
PARTS IDENTIFICATION
1. Hopper Lid
2. Bean Hopper
3. Grind Setting Indicator
4. Hopper Gasket
5. Removable Ring Burr
6. Grind Settings
7. Pulse Button
8. 58mm Adapter Ring*
9. Dosing Cup*
10. Dosing Cup Base*
11. On/O Knob*
12. Weighted Base
13. Grind Adjustment Ring
14. Grind Adjustment Tab
15. Burr-Lifting Tabs
16. Quick-Release Knob
17. Center Cone Burr
18. Brush*
19. Grounds Bin with Max Fill Line
20. Shims
*Included in grounds bin
2
5
9
12
8
4
11
10
7
6
1
3
17
1416 15
13 18 20 19

®
January 2023 (v1.0) 5
ENCORE ESP™ OPERATIONS MANUAL
OPERATION
INITIAL SETUP
1. Remove the contents from the packaging and hand-wash the hopper lid (1), bean hopper (2), dosing cup (9), and grounds bin (19) in warm,
soapy water. Let air dry. Do not wash the ring burr (5) in water or it will rust.
2. To install the hopper, align the silver grind setting indicator (3) with the triangle near grind setting 40 (6). Press the hopper down and twist
clockwise into place. The grinder will not start without the hopper installed.*
3. If grinding for espresso, insert the dosing cup base (10) and dosing cup (9). If grinding for ilter brewing, insert the grounds bin (19).
4. To install the on/o knob (11), align it with the stem of the switch on the right side of the unit and press into place. Use either the on/o knob or
the pulse button (7) to begin grinding.
*If there is diiculty in installing the hopper: Ensure that the ring burr (5) is fully seated in place. The grind adjustment ring (13) must be rotated fully
counterclockwise using the adjustment ring tabs (14) for the hopper to be installed.
When grinding into the grounds bin, coee tends to mound up in the center. To prevent clogging, empty the grounds before they reach the max ill line.
RECOMMENDED INITIAL GRIND SETTINGS
The Encore ESP has a unique adjustment system that is divided into two parts: the espresso range (settings 1-20) and the ilter coee range (settings
21-40). When brewing espresso, very small changes to the grind size are needed to ine-tune the perfect espresso shot. The espresso range of the Encore
ESP’s adjustment system allows for these precise adjustments, meaning each grind setting from 1-20 will only change the grind size by small amounts
between settings. More information can be found on dialing in espresso shots in our brew guides at Baratza.com. In order for the grind range to span from
the inest espresso to the coarsest cold brew in just 40 clicks, adjustments in the ilter coee range (settings 21-40) result in relatively larger changes to
the grind size from setting to setting.
Below are suggested starting points for what grind settings to use for common brew methods. Coarser or iner grinding may be needed depending on
recipe requirements and taste preference. More information can be found on this in our brew guides at Baratza.com.
Espresso AeroPress Hario V60 Automatic
Brewer
Chemex French
Press
Suggested Setting 15 22 25 28 30 32
Note: The espresso grind setting above is based on a medium roast and a dose of 18g of coee. For darker roasts, or larger doses, set the grinder to a
higher number. For lighter roasts, or smaller doses, set the grinder to a smaller number.

®
January 2023 (v1.0) 6
ENCORE ESP™ OPERATIONS MANUAL
GRINDING OPERATION
1. Rotate the hopper so the grind setting indicator (3) is aligned with the desired grind setting (6).
2. When making grind adjustments, the grinder must either be running or completely empty of beans to prevent damage to the unit.
3. If grinding for espresso, the included espresso dosing cup (9) and 58mm adapter ring (8) allow for easy transfer of coee into a 54mm or
58mm portailter.
• If using a 54mm portailter, remove the adapter ring before dosing.
• Grind into the dosing cup, it the portailter upside-down on top of the dosing cup, and, keeping them together, lip both over to
seamlessly dose the grounds into the portailter basket.
4. To begin grinding, either the on/o switch or the pulse button can be used:
• To use the on/o switch, rotate it to the “I” position to start grinding, and to the “O” position to stop. Do not leave the grinder
unattended while grinding. If the ground coee surpasses the maximum ill line on the grounds bin, the grinder may become clogged
and damaged as a result.
• To use the pulse button to grind small amounts of coee, or to have more precise control in how much coee is ground, simply press
and hold the pulse button. The grinder will run for as long as the button is held down, and will stop when the button is released.

®
January 2023 (v1.0) 7
ENCORE ESP™ OPERATIONS MANUAL
CARE & CLEANING
The main components of the Encore ESP can be removed from the grinder for cleaning or maintenance.
REMOVING AND REINSTALLING THE HOPPER
The hopper may be removed for cleaning or maintenance of the burrs.
TO REMOVE:
1. Remove all coee beans from the hopper and grind any remaining beans through using either the On/O switch or the pulse button. Unplug
the grinder from the power outlet before removing the hopper.
2. Rotate the hopper completely counterclockwise so that the grind setting indicator is aligned with the triangle near
grind setting 40.
3. Lift the hopper o of the grinder.
Note: The hopper gasket may come o with the hopper. If it does, install it on the ring burr by placing it thick side down within the plastic rim on top of the
ring burr to ensure that it is not lost during cleaning.
TO REINSTALL:
1. Check that the hopper gasket, ring burr, and cone burr are all installed properly.
2. Grip the two grind adjustment tabs and ensure that the grind adjustment ring is rotated fully counterclockwise.
3. Align the grind setting indicator on the hopper with the triangle near grind setting 40. Push down on the hopper and rotate it clockwise until it
starts to click.
Caution: Do not put the hopper, hopper lid or grounds bin in the dishwasher. Hand wash only. Do not
immerse the grinder housing in water. Do NOT wash the burrs with water, or they will rust.

®
January 2023 (v1.0) 8
ENCORE ESP™ OPERATIONS MANUAL
REMOVING AND REINSTALLING THE RING BURR
The ring burr may be removed for cleaning or maintenance.
TO REMOVE:
1. Grip the two grind adjustment tabs and ensure that the grind adjustment ring is rotated fully counterclockwise. Otherwise, the ring burr will
be locked into place.
2. Using the two burr lifting tabs, lift the ring burr straight up and out of the grinder. Ensure that the hopper gasket is not lost in the process.
TO REINSTALL:
1. Ensure that the cone burr is installed properly.
2. Grip the two grind adjustment tabs and ensure that the grind adjustment ring is rotated fully counterclockwise.
3. Align the red burr lifting tab with the red mark on the grind adjustment ring. The three tabs protruding from the sides of the ring burr should
also align with the three slots in the top of the grind adjustment ring.
4. Press the ring burr down into place.
5. Ensure the hopper gasket is properly installed on the ring burr, with the thicker side of the gasket sitting within the plastic rim on top of the
ring burr.
REMOVING AND REINSTALLING THE CONE BURR
The Encore ESP is equipped with a quick-release knob on top of the cone burr, allowing for easy removal of the cone burr for cleaning or burr replacement.
TO REMOVE:
1. Twist the quick-release knob clockwise until removed.*There will be a small washer underneath the quick-release knob. Remove along with
the knob.
2. Lift the cone burr straight up and out of the grinder.
*If there is diiculty in removing the quick-release knob, we recommend using a thick cloth or a glove to hold the cone burr in place, as it will rotate freely,
but take care as it may be sharp. Pliers may also be used to get a better grip on the quick-release knob.
Note: There are several parts that sit below the cone burr that may also be removed for cleaning and maintenance, shown in order in the diagram on the
next page. If these parts are removed with the cone burr, keep them arranged in the order shown for reinstallation.
TO REINSTALL:
1. If the parts below the cone burr were removed for cleaning, place them back on the drive shaft in the order shown in the diagram.
2. When placing the cone burr back onto the metal drive shaft, make sure that the two protrusions on part Eare able to it into the holes on part
Dand the two divots on the bottom of the cone burr.
3. Place the quick-release knob onto the threaded part on top of the metal drive shaft and twist the knob counter-clockwise to tighten. Tighten
until the cone burr starts to rotate when the knob is turned.

®
January 2023 (v1.0) 9
ENCORE ESP™ OPERATIONS MANUAL
A
B
C
D
E
F
G
CONE BURR ASSEMBLY
A. Quick-Release Knob
B. Washer
C. Cone Burr
D. Paddle Wheel
E. Drive Shim
F. Washer Shims
G. Felt Ring

®
January 2023 (v1.0) 10
ENCORE ESP™ OPERATIONS MANUAL
CLEANING THE GROUNDS BIN, HOPPER AND BURRS
The grounds bin, hopper, hopper lid, and hopper gasket can be washed with warm, soapy water. Rinse and let air dry. Do not allow the burrs to get wet,
otherwise they will rust.
If the grinder is used daily, the burrs should be brushed o regularly (about once a month) with the included brush. The burrs do not need to be removed
from the grinder for cleaning, but it will allow for a more thorough cleaning. If dark, oily, or lavored coee is used often, grinder cleaning tablets may need
to be used in order to absorb the oils left behind by the coee. Is oil is left to build up in the grinder, it may become clogged, resulting in damage to the
grinder. Please follow grinder cleaning tablet manufacturer instructions for use. If a clog may have formed, see the following section for more information.
Do not grind any substance other than grinder cleaning tablets to clean the internals of the grinder.
A CLOGGED GRINDER
If coee is not falling into the grounds bin while grinding, and all parts are properly installed and functioning, a clog may be preventing the coee from
moving through the grinder. This can happen if coee is allowed to mound up past the maximum ill line on the grounds bin, or if dark, oily coee or
lavored coee is used often without periodically cleaning the grinder. Ground coee can stick to built-up coee oils in the grinder and cause a clog to
form. Regular cleaning and proper use can prevent a clogged grinder.
IN THE EVENT THAT A CLOG DOES FORM:
• Follow the steps on the previous page to remove the cone burr and parts underneath. This will allow for direct access to where the clog has formed.
• Empty out as much coee as possible in the grind chamber. The sides and bottom of the grind chamber are white plastic, and should be visible when
the coee has been cleaned out. Compacted coee can become very hard, so it is recommended that a sti tool, like a small hex wrench or the handle
of the provided cleaning brush, be used to chip away at the compacted coee.
• The center of the exit chute, where ground coee exits the grind chamber and falls into the grounds bin, is found directly underneath the red marker
on the grind adjustment ring when it is rotated fully counterclockwise. This chute must be completely clear for coee to exit into the grounds bin.
• If the unclogging attempt is unsuccessful, do not hesitate to contact Baratza support. Check the warranty section on the next page to ind out how to
contact Baratza support in your region.
SHIM KIT USE AND INSTALLATION
As the grinder is used, parts will settle into place, and the grind settings used may slowly shift so that a iner grind setting must be used. This is a normal
part of the wear process and will eventually stop as the parts are settled. However, in some cases, the inest grind settings may not be ine enough to
achieve the grind necessary. In this case, the shims provided in the original packaging may be used to shift the overall grind settings of the grinder. By
inserting one shim, the grind will shift by about ive settings. For example, if setting 10 was used before shim installation, setting 15 will be the rough
equivalent after shim installation.
TO INSTALL A SHIM:
1. Follow the instructions on previous pages to remove the hopper, ring burr, and cone burr.
2. After removing the cone burr, remove parts Dand Eas shown on the previous page.
3. Place one or two shims (as needed) on top of the other washer shims (Part F).
4. Reassemble.
If even after shim installation the grinder is not able to grind inely enough for espresso, there may be an issue with assembly or a part of the unit. See the
warranty page for information on how to contact Baratza support in your region for assistance.

®
January 2023 (v1.0) 11
ENCORE ESP™ OPERATIONS MANUAL
WARRANTY & SERVICE
U.S. & CANADIAN WARRANTY
INFORMATION
Limited Warranty for Baratza Grinders is 1 year from the original date of
purchase. This warranty covers all defects in materials and workmanship
(parts and labor) including free ground transportation to and from
our repair facility within the US and Canada. This warranty does not
applyto:improper use, lack of cleaning, abuse, normal wear and tear, lack
of proper adjustment, foreign objects (stones, screws, etc.) in the beans,
or uses outside the intended use of grinding whole roasted coee beans
(roasted beyond 1st crack). If the purchased grinder fails within one year,
email[email protected]or call [phone] or toll free 877-701-
2021. For additional warranty, support, or troubleshooting information, go
towww.baratza.com.
Please note: Grinders that are purchased in the US or Canada and shipped
or taken out of the country have a one-year warranty for parts only. If
the grinder fails within one year of date of purchase, simply email us at
[email protected] or call [phone]. Please have the following
information prior to contacting Baratza: 1) Proof of date of purchase and
2) Model and serial number (located on bottom of the grinder). A Baratza
representative will respond to determine the problem and suggest a
solution path. The customer is responsible for paying the freight charges
and any duties and taxes for replacement parts that Baratza may send. The
customer is also responsibleto provideany labor required to repair the
grinder.
INTERNATIONAL WARRANTY
INFORMATION
For all countries outside the US and Canada, the warranty, support and
serviceisprovided by the International Retailer the grinder was purchased
from. If the grinder was purchased from a retailer outside of the country
the customer resides in, the customer may be responsible for any shipping
costs to service the grinder, and may need to pay for service.
PROOF OF PURCHASE &
PRODUCT REGISTRATION
The grinder can be registered atwww.baratza.com/register-your-grinder.
Registration will enable us to contact the registrant in the unlikely event of
a product safety notiication and assist us in complying with the provisions
of the Consumer Product Safety Act. The serial number is located on the
bottom of the grinder. Please keep the sales receipt that shows the date of
purchase.
FOR REPAIRS OR QUESTIONS
Email: [email protected]
For Parts and Information go to: www.baratza.com
For Troubleshooting Help:
www.baratza.com/troubleshooting
