GalaxyNW12
3D stereo, networkcentric, 12,000 lumens, WUXGA, threechip DLP projector
Barco’s Galaxy NW12 is the world’s first
active 3D stereo projector with a native
WUXGA (1920x1200) resolution. It’s the
perfect choice for any single or
multiprojectorcollaborativedisplaysystem.
Maximaleaseofuse
ThankstoitsfullcompatibilitywithBarco’sXDSControlCentersoftwaresuite,
theGalaxyNW12offersdirectaccesstoalllocalandnetworkedsourcesina
familiarWindowsdesktop.Youcandisplayyoursourcesinmultiplewindows
thatcanberesized,draggedandmadetooverlapanywhereonthescreen,in
anycombinationof2Dand3D.
Supreme stereoscopic quality With its strong 12,000 lumens light output,
Barco’s Galaxy NW12 was designed to operate in bright environments. Its
nativestereoscopiccapabilities,whichincludebothpassiveandactiveInfitec,
renderitaperfectchoiceforapplicationsthatrequirestereoscopicimagesof
thehighestdetail.
Maintenancefreedesign
TheGalaxyNW12isdesignedwithoneofthelowestnoiselevelsinitsclass,
and a guaranteed long system lifetime due to its fully sealed, liquidcooled
optical engine. This not only prevents dust from entering the projector’s
interior, it also eliminates routine maintenance procedures and strongly
reducespotentialsystemdowntime.

GalaxyNW12
3D stereo, networkcentric, 12,000 lumens, WUXGA, threechip DLP projector
Optimizedforsystemintegration
Barco’s Galaxy NW12 is optimized for multiprojector system integration
throughvariousfeatures:
• Edge blending technology creates one continuous image without blurry
overlapzoneswhereprojectionsconverge.
•DynaColorandlinkedconstantlightoutput(CLO)ensurethesamelight
andcolorlevelsacrosstheentirescreen.
• Warping (geometry correction) enables accurate projection from different
anglesandacrosssphericalorcurvedsurfaces.

Productspecifications GalaxyNW12
Lightoutput 12,000lumens
Contrastratio upto2,000:1
Resolution WUXGA(1920x1200px)
Chiptype ThreechipDLP
Lamp 2kWxenonlamp
Lampwarranty 750hrswarranted
Weight 70kg(154.2lbs)
Dimensions(WxLxH) 590x913x345mm(23.22x35.94x13.58")
LensShift Horizontalupto/+65%Verticalupto/+110%
Standardinputs TwinduallinkDVI
3stereosyncinputs(miniDIN)
OptionalInputs Twofreelayers(seeoptions)
CommunicationPort RS232(onD9)
10/100Mb/sEthernet(onRJ45)
Data Analogsourceswithapixelclockofupto270MHz
DVIsourceswithapixelclockofupto300MHz(includingWUXGA120Hz)
Safety ETL60950andEN60950
CEcompliant
CCCcompliant
ACpower 220V240V
Max.powerconsumption 2,800Watt/9,560BTU
Generatedon:25Jan2014
Technicalspecificationsaresubjecttochangewithoutpriornotice.
Pleasecheckwww.barco.comforthelatestinformation.
