Baroness LM2700 Operation manual

5-Unit Reel Mower
Serial No.11185-
Owner's Operating Manual
Original lnstructions Ver.3.3
Read this manual and the Owner's Manualfor the engine before using the machine.
Required reading

Contents
Greeting........................................................................................................................1
Keeping the owner's operating manual....................................................................1
Introduction...................................................................................................................1
Warning Symbols.....................................................................................................2
Precautionary Statement .........................................................................................2
Purpose....................................................................................................................2
Safety ..........................................................................................................................3
Safety Precautions...................................................................................................3
Training................................................................................................................3
Preparation..........................................................................................................3
Operation.............................................................................................................4
Maintenance and Storage ...................................................................................5
Disposal .......................................................................................................................6
Recycle and Waste Disposal ...................................................................................6
About Recycle .....................................................................................................6
About The Waste Disposal ..................................................................................6
Product Overview .........................................................................................................7
1. Specifications.......................................................................................................7
Specifications ..................................................................................................7
Sound Pressure Level.....................................................................................7
Sound Power Level .........................................................................................7
Vibration Level.................................................................................................7
2. Names of Various Sections..................................................................................8
3. Regulation Decals................................................................................................9
3-1 Positions of Regulation Decals ..................................................................9
3-2 Description of Regulation Decals...............................................................9
4. Safety Decals and Instruction Decals ................................................................11
4-1 About Safety Signs and Instruction Signs ................................................11
4-2 Positions of Safety Decals and Instruction Decals...................................11
4-3 Description of Safety Decals and Instruction Decals ...............................12
Handling Instructions .................................................................................................13
5. Inspection Before Use........................................................................................13
5-1 Inspection and Cleaning of Radiator and Oil Cooler................................13
5-2 Inspection and Supply of Coolant ............................................................13
5-3 Inspection and Supply of Hydraulic Oil ....................................................14
5-4 Inspection and Cleaning of Air Cleaner....................................................14
5-5
Inspection of Battery and Supply of Battery Fluid ....................................15
5-6
Inspection of Tires....................................................................................15
5-7
Inspection of Brake ..................................................................................16
5-8
Inspection of Belt .....................................................................................16
5-9
Inspection of Wire ....................................................................................16
5-10
Inspection of The Engine and Its Surroundings.......................................16
5-11
Inspection and Supply of Engine Oil ........................................................16
5-12
Inspection and Supply of Fuel..................................................................17
5-13
Air Bleeding of Fuel System.....................................................................17
5-14
Inspection of Fuel Filter............................................................................18
5-15
Inspection of Oil Leakage ........................................................................18
5-16
Inspection of Reel Cutter (Cutting Cylinder) and Bed Knife (Bottom Blade) .......18
6. Fastening of Each Portion..................................................................................19
6-1 Standard Tightening Torques ...................................................................19
6-2 Tightening Torque by Model.....................................................................20
7. Adjustment Before Operating.............................................................................21
7-1 Adjustment of Steering Wheel..................................................................21
7-2 Adjustment of Seat...................................................................................21
7-3 Adjustment of Blade Engagement............................................................21
7-4 Cutting Height Adjustment .......................................................................22
7-5 Adjustment of Cutter Adjustment Spring ..................................................23
7-6 Adjustment of Reel Cover ........................................................................23
7-7 Adjustment of Groomer ............................................................................23
7-8 Adjustment of Groomer Spring.................................................................24
7-9 Adjustment of CR Brush...........................................................................24

8. Start / Stop of Engine.........................................................................................25
8-1 Procedure to Start Engine........................................................................25
8-2 Procedure to Stop Engine........................................................................25
8-3 Safety Mechanisms..................................................................................26
8-4 Warning Mechanisms...............................................................................26
9. Operation Method of Each Part .........................................................................27
9-1 Precautions for Operating The Machine ..................................................27
9-2 Cautions when Leaving The Machine......................................................27
9-3 Positions and Descriptions of Operation Panel Marks.............................27
9-4 Switch and Levers on The Operation Panel ............................................28
9-5 Travelling-Mowing Changeover Switch....................................................28
9-6 2WD - 4WD Changeover Switch..............................................................28
9-7 Reel Rotation Switch................................................................................29
9-8 Reel Reverse Switch................................................................................29
9-9 Throttle Lever...........................................................................................29
9-10 Mower Unit Raise / Lower Lever..............................................................30
9-11 Diff-Lock Switch .......................................................................................30
9-12 Brake Pedal .............................................................................................30
9-13 Parking Brake Lever ...............................................................................30
9-14 Forward / Backward Pedal ......................................................................31
9-15 Pedal Stopper .........................................................................................31
9-16 Mower Lock Lever (Latch) ......................................................................31
9-17 Reel Rotation Adjusting Valve..................................................................31
9-18 Reel Rotation / Stop Switching Lever ......................................................32
9-19 Groomer Clutch Lever..............................................................................32
9-20 Hood ........................................................................................................32
9-21 Underseat Cover......................................................................................32
10. Measuring Instrument ......................................................................................33
10-1 Instruments of Operation Panel ...............................................................33
10-2 Tachometer & Hour Meter........................................................................33
10-3 Water Temperature Gauge.......................................................................33
10-4 Fuel Gauge ..............................................................................................33
10-5 Charge Lamp ...........................................................................................33
10-6 Thermo-Start Lamp (Glow Lamp) ............................................................33
10-7 Oil Pressure Lamp (Engine Oil Pressure Lamp)......................................34
11. Moving The Machine........................................................................................34
12. Towing..............................................................................................................35
13. Cutting Work ....................................................................................................36
14. Transportation ..................................................................................................36
15. Long-Term Storage ..........................................................................................36
16. Maintenance ....................................................................................................37
16-1 Maintenance Precautions ........................................................................37
16-2 Maintenance Schedule ............................................................................37
17. Jacking Up The Machine .................................................................................38
17-1 About Jacking Up The Machine ...............................................................38
17-2 Jack-Up Points.........................................................................................38
18. Greasing ..........................................................................................................39
18-1 About Greasing ........................................................................................39
18-2 Greasing Points (Main Vehicle)................................................................39
18-3 Greasing Points (Mower Units) ................................................................40
19. Maintenance Work ...........................................................................................40
19-1 Swiveling Mower Units #2 and #3............................................................40
19-2 Cleaning of Mower Unit............................................................................41
19-3 Back Lapping of Reel Cutter ....................................................................41
19-4 Sharpening of Reel Cutter (Cutting Cylinder) ..........................................43
19-5 Replacement of Reel Cutter (Cutting Cylinder)........................................44
19-6 Replacement of Bed Knife (Bottom Blade) ..............................................44
19-7 Removing/Installing Tires.........................................................................45
19-8 Adjustment of Brake.................................................................................45
19-9 Adjusting The Neutral Position of The Piston Pump ................................47
19-10
Change of Coolant ...................................................................................47
19-11
Change of Hydraulic Oil ...........................................................................48
19-12
Change of Hydraulic Oil Filter ..................................................................49
19-13
Change of Air Cleaner..............................................................................50
19-14
Change of Engine Oil...............................................................................50
19-15
Change of Engine Oil Filter......................................................................51
19-16
Change of Fuel Filter ...............................................................................51
19-17
Change of Fuses......................................................................................52

−1−
Greeting
Thank you for purchasing the Baroness product.
This manual describes the proper handling, adjustment, and inspection of your product.
We hope you will use the product safely, and take advantage of its best performance.
Keeping the owner's operating manual
Keep this Manual in the box located in the rear of the seat.
Introduction
Read this manual carefully to ensure that you thoroughly understand how to properly
operate and maintain the product, and to avoid causing injury to yourself or others.
The operator is responsible for operating the product properly and safely.
Maintenance should only be performed by a certified specialist.
If you have any questions concerning maintenance or genuine parts, please contact your
local Baroness dealer or Kyoeisha.
When making inquiries about the product, please specify the product's model designation
and serial number.
When loaning or transferring the product, please also provide this manual together with the
product.
Kyoeisha Co., Ltd.
Box

−2−
Warning Symbols
This manual uses the following warning symbols for handling precautions that are important
for your safety.
Warning symbol
This symbol indicates the articles regarding “Danger,” “Warning,” or “Caution.”
Those articles describe important safety precautions and so read them carefully to
understand completely before operating the machine.
Failure to adequately follow these safety precautions may cause an accident.
Danger
This symbol indicates that serious injury or death will occur if the warning is ignored.
Warning
This symbol indicates that serious injury or death may occur if the warning is ignored.
Caution
This symbol indicates that injury or damage to property may occur if the warning is
ignored.
Important
This symbol indicates precautions on the mechanism of the machine.
Precautionary Statement
Caution
The information described in this manual is subject to change for improvement without
prior notice.
When replacing parts, be sure to use genuine Baroness parts or parts designated by
Kyoeisha.
Note that the Baroness product warranty may not apply to defects caused by the use of
parts from other companies.
Prior to use, carefully read the following manuals to thoroughly understand the contents
for safe and correct operation.
•Baroness Owner's Operating Manual
•The Engine's Owner's Manual
•The Battery's Owner's Manual
Purpose
This product is intended for cutting turf grass at golf courses.
Do not use this product in any way other than its intended purpose, and do not modify
this product.
Operating this product for other purposes and modifying it may be very dangerous and
may cause damage to the product.
In addition, this product is not authorized for operation as a special motor vehicle. Do not
operate it on public roads.

−3−
Safety
Failure to adequately follow these safety precautions may cause an accident resulting in
injury or death.
Danger
This product is designed to ensure safe operation and has been tested and inspected
thoroughly before shipment from the factory.
The product is equipped with safety devices to prevent accidents.
However, whether the product demonstrates its original performance level depends on
the manner in which it is operated and handled, as well as the manner in which it is
managed on a daily basis.
Inappropriate use or management of the product may result in injury or death.
Observe the following safety instructions to ensure safe operation.
Safety Precautions
Training
1.Read this manual and other training material carefully.Be familiar with the controls,
safety signs, and the proper use of the equipment.
2.If the operator or mechanic can not read English it is the owner’s responsibility to explain
this material to them.
3.All operators and mechanics should seek and obtain professional and practical
instruction. The owner is responsible for training the users. Such instruction should
emphasize:
[1] The need for care and concentration when working with ride-on machines.
[2] Control of a ride-on machine sliding on a slope will not be regained by the application
of the brake.
The main reasons for loss of control are
- Insufficient wheel grip
- Being driven too fast
- Inadequate braking
- The type of machine is unsuitable for its task
- Lack of awareness of the effect of ground conditions, especially slopes
- Incorrect hitching and load distribution
4.Never allow children or people unfamiliar with these instructions to use or service the
machine. Local regulations may restrict the age of the operator.
5.The owner/user can prevent and is responsible for accidents or injuries occurring to
themselves ,other people, or property.
6.Keep in mind that the owner, operator, and mechanic are responsible for accidents or
hazards occurring to other people or their property.
7.The ROPS is an integral and effective safety device. Do not remove or alter the ROPS.
8.Replace a damaged ROPS. Do not repair or alter.
9.You can find additional safety information where needed throughout this manual.
10.Determine the left and right sides of the machine from the normal operating position.
Preparation
1.Evaluate the terrain to determine what accessories and attachments are needed to
properly and safely perform the job. Only use accessories and attachments approved by
the manufacturer.
2.While operating, always wear substantial footwear, long trousers, hard hat, safety
glasses, and ear protection. Long hair, loose clothing, or jewelry may get tangled in
moving parts. Do not operate the equipment when barefoot or wearing open sandals.
3.Inspect the area where the equipment is to be used and remove all objects such as
rocks, toys and wire which can be thrown by the machine.
4.Keep children out of the operating area and under the watchful care of a responsible
adult other than the operator.
5.Exercise care in the handling of fuel.
Warning
Fuel is highly flammable. Take the following precautions.
[1] Store fuel in containers specifically designed for this purpose.
[2] Add fuel before starting the engine. Never remove the cap of the fuel tank or add fuel
while the engine is running or when the engine is hot.
[3] Refuel outdoors only and do not smoke while refueling.
[4] If fuel is spilled, do not attempt to start the engine but move the machine away from
the area of spillage and avoid creating any source of ignition until petrol vapours
have dissipated;
[5] Replace all fuel tanks and container caps securely.
6.Check that operator’s presence controls, safety switches and shields are attached and
functioning properly. Do not operate unless they are functioning properly.
7.If the brake operation is faulty or the parking brake lever has noticeable play, be sure to
adjust or repair them before operating the machine.
8.Replace faulty mufflers.
9.On multi-cylinder/multi-reel machines, take care as rotating one cylinder/reel can cause
other cylinders/reels to rotate.

−4−
Operation
1.Do not operate the engine in a confined space where dangerous carbon monoxide
fumes can collect.
2.Only operate in good light, keeping away from holes and hidden hazards.
3.Before attempting to start the engine, disengage all attachments, shift into neutral, and
engage the parking brake.
Only start engine from the operator’s position.
(Use seat belts if provided.)
4.Remember there is no such thing as a safe slope. Travel on grass slopes requires
particular care. To guard against overturning.
[1] Do not stop or start suddenly when going up or downhill.
[2] Engage clutch slowly, always keep machine in gear, especially when traveling
downhill.
[3] Machine speeds should be kept low on slopes and during turns.
[4] Stay alert for humps and hollows and other hidden hazards.
[5] Never operate across the face of the slope, unless the machine is designed for this
purpose.
[6] Never drive the machine on a slope with an angle of gradient that is greater than that
specified or in a place where there is a danger of the machine slipping.
5.Use extra care while operating machine with a grass catcher or other attachments. They
can affect the stability of the machine.
6.Never operate the machine with damaged guards, shields, or without safety protective
devices in place.
Be sure all interlocks are attached, adjusted properly, and functioning properly.
7.Do not change the engine governor settings or overspeed the engine. Operating the
engine at excessive speed may increase the hazard of personal injury.
8.Do the following before leaving the operator’s position.
[1] Stop on level ground.
[2] Disengage the power take-off and lower the attachments.
[3] Change into neutral and set the parking brake.
[4] Stop the engine and remove the key.
9.Disengage the drive to attachments, stop the engine, and remove the ignition key in the
following conditions.
[1] Before refuelling.
[2] Before removing the grass catcher.
[3] Before making height adjustment unless adjustment can be made from the operator's
position.
[4] Before clearing blockages.
[5] Before checking, cleaning or working on the machine.
[6] After striking a foreign object or if an abnormal vibration occurs.
Inspect the machine for damage and make repairs before restarting and operating
the equipment.
10.Keep hands and feet away from the cutting units and the rotating parts.
11.Do not mow in reverse unless absolutely necessary.
Always look down and behind before and while backing.
12.Do not carry passengers.
13.Never operate while people, especially children, or pets are nearby.
14.Slow down and use caution when making turns and crossing roads and sidewalks.
15.Stop the blades rotating before crossing surfaces other than grass.
16.Disengage drive to attachments when transporting or not in use.
17.When using any attachments, never direct discharge of material toward bystanders nor
allow anyone near the machine while in operation.
18.Do not operate the machine under the influence of alcohol or drugs.
19.Take care when loading or unloading the machine into a trailer or a truck. Load or unload
the machine in a flat and safe place. Before loading or unloading, set the parking brake
on the truck or trailer, stop the engine, and chock the wheels.
When transporting the machine on a truck or a trailer, set the parking brake, stop the
engine, and fasten the machine to the truck with a rope or other suitable restraining
device that has sufficient strength.
When using a running board, select one with sufficient strength, length, and width and
that will not cause the machine to slip.
20.Close the fuel valve before transporting the machine.
21.Use care when approaching blind corners, shrubs, trees, or other objects that may
obscure vision.
22.Do not take your eyes off the road ahead. Do not operate the machine with no hands.
23.Reduce the throttle setting during engine run-out and, if the engine is provided with a
shut-off valve, turn the fuel off at the conclusion of operation.
24.Do not operate the machine when there is the risk of lightning.

−5−
Maintenance and Storage
1.Disengage drives on level ground, lower the atattachments, set parking brake, stop
engine and remove key from ignition. Wait for all movement to stop before adjusting,
cleaning or repairing.
2.When machine is to be parked, stored, or left unattended, lower the cutting units unless
a positive mechanical lock is provided.
3.To reduce the fire hazard, keep the engine, silencer/muffler, battery compartment fuel
storage area, cutting units and drives free of grass, leaves, or excessive grease. Clean
up oil or fuel spillage.
4.Allow the engine to cool before storing in any enclosure.
5.Only cover the machine with a sheet after hot parts have sufficiently cooled down.
6.Never store the equipment with fuel in the tank inside a building where fumes may reach
an open flame or spark.
7.If the engine is provided with a shut-off valve,shut off valve while storing or transporting.
8.Do not store fuel near flames.
9.Never allow untrained personnel to service machine.
10.Allow the engine/muffler to cool before checking/maintenance.
11. Appropriately manage and correctly use the tools necessary for servicing or adjusting
the machine.
12.Use jack stands to support components when required.
13.Carefully release pressure from components with stored energy.
14.Be sure to depressurize the hydraulic system before performing maintenance operations
on it such as removing hydraulic equipment.
15.Check whether line connectors in the hydraulic system are properly tightened. Before
applying hydraulic pressure, check the connections of the hydraulic pressure lines and
the condition of the hoses.
16.When checking the hydraulic circuit for pinhole leaks or oil leakage from nozzles, do not
use your hands. Use items such as paper or corrugated cardboard to find leakage
points. Be extremely careful with high-pressure oil as it may pierce your skin, resulting in
an injury.
If fluid is injected into the skin it must be surgically removed within a few hours by a
doctor familiar with this form of injury or gangrene may result.
17.Disconnect battery before making any repairs. Disconnect the negative terminal first and
the positive last. Reconnect positive first and negative last.
18.Make sure that parts such as wires are not touching each other and that their covers
have not come off.
19.Use care when checking the cylinders/reels and bed knives.
[1] Wear gloves and use caution when servicing them.
[2] Be careful during adjustment of the machine to prevent entrapment of the fingers
between moving blades and fixed parts of the machine.
20.On multi-cylinder/multi-reel machines, take care as rotating one cylinder/reel can cause
other cylinders/reels to rotate.
21.Keep hands and feet away from moving parts. If possible, do not make adjustments with
the engine running.
22.Charge batteries in an open well ventilated area, away from spark and flames. Unplug
charger before connecting or disconnecting from battery. Wear protective clothing and
use insulated tools.
23.Keep all parts in good working condition and all hardware tightened. Replace all worn or
damaged decals.
24.Keep all nuts, bolts and screws tight to be sure the equipment is in safe working
condition.
25.Check the grass catcher frequently for wear or deterioration
26.If the fuel tank has to be drained, do this outdoors.
27.Swallowing engine coolant can cause injury or death; keep out of reach from children
and pets.

−6−
Disposal
Recycle and Waste Disposal
About Recycle
Recycling battery etc. is recommended for environmental conservation and economical use
of resources.
It may be required by local laws.
About The Waste Disposal
Make sure that waste generated when servicing or repairing the machine is disposed of in
accordance with local regulations.
(e.g. waste oil, antifreeze, rubber products, and wires etc.)

−7−
Product Overview
1. Specifications
■Specifications
■Sound Pressure Level
This machine was confirmed to have a continuous A-weighted sound pressure level of
88dB by measuring identical machines in accordance with the procedure specified in
ISO 5395-1:2013.
■Sound Power Level
This machine was confirmed to have a sound power level of 103dB by measuring
identical machines in accordance with the procedure specified in directive 2000/14/EC.
■Vibration Level
Hand-Arm Vibration
This machine was confirmed not to exceed a vibration level of 2.5 m/s2to hands and
arms by measuring identical machines in accordance with the procedure specified in
ISO 5349-1:2001, 5349-2:2001.
Whole Body
This machine was confirmed to transmit a vibration level of 0.52 m/s2to the whole body
by measuring identical machines in accordance with the procedure specified in ISO
2631-1:1997, 2631-2:2003
Model
Mower unit type
Dimensions
Total length
Total wi
dth
During operation
During transport
Roof
Total height Roof bar
Steering wheel
Weight
Machine
with ROPS
(empty fuel tank)
Minimum turning radius
Engine
Model
Type
Total displacement
Maximum output
Fuel tank capacity
Fuel consumption
Engine oil capacity
Coolant volume
Hydraulic tank capacity
Operating width (Mowing width)
Operating height (Mowing height)
Blades
Drive Traveling
Mowing
Speed(HST)
Forward
Reverse
Speed (Mechanical)
Efficiency
Maximum inclination for operation
Tire size
Front wheel
Rear wheel
Tire pneumatic pressure
Front wheel
Rear wheel
Battery
Engine plug

Maximum engine rpm is set up 2,600 rpm before shipment.
(*1) For 0.394 in (10 mm) or less mowing height, the optional bedknife is required
LM2700
26in 22in
118.11in 300cm ←
124.41in 316cm 115.35in 293cm
89.76in 228cm ←
86.61in 220cm ←
80.31in 204cm ←
59.06in 150cm ←
3,977.07lb 1,804kg 3,877.87lb 1,759kg
110.24in 280cm ←
Kubota V2203-M
←
Vertical water-cooled 4-cycle diesel engine
←
134.05cu.in.
2,197cm
3
㸦2.197L㸧
←
33.0kW44.9PS/2,600rpm ←
Diesel
12.42 U.S.gals Diesel 47.0dm
3
㸦47.0L㸧
←
184 g/PS࣭h (rated output) 250 g/kW࣭h (rated output)
←
2.56U.S.gals 9.7dm3㸦9.7 L㸧 ←
3.17 U.S.gals 12.0 dm3㸦12.0 L㸧←
11.36 U.S.gals 43.0 dm3㸦43.0 L㸧←
109.06in 277cm 100.00in 254cm
0.315-1.772in(*1) 8 - 45mm(*1) ←
9 ←
HST (2WD/4WD selectable) ←
Hydraulic ←
2WD: 0 - 13.67 mph 2WD:0 - 22.0km/h ←
4WD: 0 - 8.70 mph 4WD: 0 - 14.0km/h
0 - 4.97mph 0 - 8.0km/h ←
- ←
7.6acres/hour 31,024m2/h 7.0 acres/hour 28,448m2/h
PSK[PRZLQJZLGWK[ NPK[PRZLQJZLGWK[PSK[PRZLQJZLGWK[ NPK[PRZLQJZLGWK[
15 degrees ←
26.5×14.00 - 12 ←
20×12.00 - 10 ←
21.75psi 150kPa㸦1.5 kgf/
2
㸧 ←
20.30psi 140kPa㸦1.4 kgf/
2
㸧 ←
105D31R ←
- ←

−8−
2. Names of Various Sections
Parking brake lever
Brake pedal
Reverse pedal
Mower unit #4
Forward pedal
Hood Operation panel
Mower unit raise/
lower lever
Throttle lever
Tilt lever
Mower unit #2
Mower unit #1
Mower unit #5
Mower unit #3
Fuel filler hole
Muf
fler exhaust port
Roof
Radiator
Oil cooler
Oil level gauge
Light
Seat

−9−
3. Regulation Decals
3-1 Positions of Regulation Decals
3-2 Description of Regulation Decals
■Serial number plate
The serial number plate indicates the model
and serial number of the machine.
■Specification Decal
(For Europe)
The Specification decal indicates the CE
marking, model , and weight, etc.
■Noise Emission Decal
(For Europe)
The noise emission decal indicates the sound
power level determined by measuring identical
machines in accordance with the procedure
specified in the EC directives.
■Year of Manufacture Decal
(For Europe)
The year of manufacture decal indicates the
year when this machine was manufactured.
<Operation panel>
<Battery> Serial Number Plate
Specification Decal
Year of Manufacture Decal
Noise Emission
Decal
ROPS Compliance Decal
ROPS Caution Decal
Battery Capacity Decal
Recycle Decal
YEAR OF
MANUFACTURE

−10−
-,6
+5 $K
&&
$$
3E
■ROPS Compliance Decal
The ROPS compliance decal indicates the
manufacturer, model, etc., in accordance with
International Standard ISO 21299:2009.
■ROPS Caution Decal
ROPS caution decal describes the caution
messages compliant with ISO 21299:2009.
Replace damaged ROPS.
Do not repair or revise. (Only if equipped with
ROPS)
■Battery Capacity Decal
(For Europe)
The battery capacity decal indicates the
capacity by 20HR and CCA.
■Recycle Decal
(For Europe)
Recycle Decal illustrates Recycle Mark in
accordance with local regulation.

−11−
K4205001580
K4205001540
K4205001600
LM2700-0959Z0
K4205001840
K4205001950
9
.
K4205001900
K4205001580
K4209000980
<Operation panel>
<Inside the hood on the left side that can be seen from the rear>
<Rear right of the frame> <Arm lock part of both side>
* Attach on the left and right.
* Attach two labels to each mower.
* Put it on both
side.
12
11
K4205001970
10
K4205001970
K4205001530
K4209001000
K4205001940
<Front right of the frame>
* Low sulfur or ultra low sulfur
diesel fuel only.
4. Safety Decals and Instruction Decals
4-1 About Safety Signs and Instruction Signs
Part numbers for decals that need to be replaced are listed in the parts catalog.
Order them from a Baroness dealer or Kyoeisha.
4-2 Positions of Safety Decals and Instruction Decals
Safety decals and instruction decals are attached to this
product.
Make sure that they are preserved in their entirety. If they are
damaged, become dirty, or peel off, replace them with new
ones.
Important

−12−
4-3 Description of Safety Decals and Instruction Decals
Warning
Warning
Warning
Warning
Warning
Warning
: Read the Operator's manual.
: Leave the machine after setting the parking brake, turning the engine off, and
removing the engine key.
:
Flying objects - Be sure that people around the machine keep a safe distance away.
: Cutting hands or feet - Do not put near moving parts.
: Overturning - Do not operate the machine on a slop of 15 degrees or more to avoid
overturning.
When going down a slope, fasten the seat belt and operate the machine at slow speeds.
A
ttach the warning labels and operation labels in the locations that are close to
dangerous parts and in which the labels can be easily seen.
If a label is damaged or peels of
f, attach a new label to the machine.
Warning
: Read the Operator's manual
Engine starting-up procedure
(please read the Operator's manual.)
Take a seat.
Turn the key to the "Glow" position, and
wait until the "thermo-start" lamp goes out.
Turn to the "START" position.
Step on the brake pedal and release the
parking braking.
: Engine stop procedure
Turn off the reel rotation switch and raise
the mower.
Apply parking brake system.
Turn the key to the "STOP" position and
remove it.
9
K4205001900
K4205001900
10
11
12
K4205001600
K4205001530
K4205001540
K4205001580
K4209001000
K4205001950
K4205001940
K4209000980
K4205001970
K4205001970
: Cutting hands or feet
If you do not stop rotating the mower and the engine is not
turned off, you may get injured.
: High-pressure oil symbol
Read the Operator's manual.
: Cutting of Hand
Placing your hand near the fan and the belt while the engine is
running might result in injury.
Caution
Caution
Caution
Caution
: Hot surface
Do not touch. It can cause burns.
: Pinch
You can get pinched.
: Fuel filler port
(diesel fuel only)
Low sulfur or ultra low sulfur diesel fuel only.
: Mower lock lever
When storing the machines with raising #4 & #5
mowers, engage the mower locking lever.
: Be careful about blowout of coolant water
Do not open unless cooled down.
: Decal, caution to exhaust gas
Caution for exhaust gas.
: Decal, keep away from fire
Keep fire away.
Caution
Caution
LM2700-0959Z0
K4205001840

−13−
Do not touch the radiator or coolant during engine operation
or immediately after the engine has been turned off.
Supply coolant after the engine has well cooled down.
The radiator cap is pressurized.
If you remove the radiator cap while the engine is overheated,
hot steam will burst out, possibly resulting in burns.
Make sure that the water temperature and pressure are
reduced, and then grab the cap with a thick cloth and
gradually open the cap.
When you supply coolant, be sure to use clean water, such as
tap water.
Tightly close the radiator cap.
If the cap is loose or incorrectly installed, water may leak and
the engine may overheat.
An unclean radiator may cause overheating or damage to the
engine.
It may also cause malfunction of the hydraulic system.
Do not use solid objects, such as a spatula or screwdriver, or
high-pressure water to clean the radiator or oil cooler.
Otherwise, special fins or tubes may be damaged, possibly
resulting in reduced cooling performance or coolant leakage.
Important
Important
Important
Important
Caution
Caution
Caution
Handling Instructions
5. Inspection Before Use
Be sure to perform an inspection before you start using the machine so that you will be able
to take advantage of its optimum performance for a long period of time.
5-1 Inspection and Cleaning of Radiator and Oil Cooler
1) Make sure that there is no damage to the radiator.
2) Make sure that the radiator is not contaminated.
3) Make sure that there is no damage to the oil cooler.
4) Make sure that the oil cooler is not contaminated.
If the radiator, oil cooler and dust-proof mesh have been contaminated with dust, be sure to
clean it.
Especially after operating the machine in a dusty environment, it is important to remove dust
as soon as possible.
[1] Lift up the dust-proof mesh to remove it.
[2] Unlock the rubber catches on the left of the oil cooler, and then tilt the oil cooler.
[3] Carefully clean the front and back of the oil cooler and radiator with water or com-
pressed air.
Dustproof
net
Oil cooler Radiator
5-2 Inspection and Supply of Coolant
Make sure that the coolant level in the reserve tank is between "FULL" and "LOW".
If the coolant level in the reserve tank is lower than the "LOW" mark, open the reserve tank
cap and fill the tank with clean water up to the "FULL" mark.
[1] Open the radiator cap, and then supply
clean water up to the opening.
[2] Open the reserve tank cap, and then sup-
ply clean water up to the "FULL" mark.
Cap Reserve tank

−14−
Do not mix different types of oil.
Use Shell Tellus S2M46 (or equivalent) as hydraulic oil.
Important
Important
5-3 Inspection and Supply of Hydraulic Oil
The oil gauge is on the hydraulic tank.
Check with the mower units lowered on a level surface.
1) Make sure that the oil level is at the middle of the oil gauge.
2) Check underneath the machine for oil leakage.
If the hydraulic oil level is low, follow the steps below to supply oil.
[1] Open the tank cap, and then supply hy-
draulic oil through the oil filling port until
the oil level reaches the middle of the oil
gauge on the hydraulic tank.
[2] Tighten the tank cap securely.
[3] Start the engine, raise and lower the
mower units, and turn the steering wheel
right and left. Move forward and reverse
repeatedly several times
[4] Lower the mower units and maintain
that position on a level surface, and then
check to see if the oil level is at the mid-
dle of the oil gauge. If necessary, supply oil.
[5] Check underneath the machine for hydraulic oil leakage.
5-4 Inspection and Cleaning of Air Cleaner
Inspect the air cleaner by checking the vacuum indicator.
If the air cleaner element is contaminated, the vacuum indicator will display a red ring.
1) Make sure that there is no damage to the air cleaner.
2) Make sure that the air cleaner is not contaminated.
A contaminated air cleaner element may cause malfunction of the engine.
To maximize the life of the engine, clean the air cleaner properly.
[1] Remove the clips, remove the air cleaner
cap, and then remove the air cleaner ele-
ment.
[2] While paying close attention not to dam-
age the air cleaner element, tap a solid
portion of the air cleaner element or blow
compressed air from its inside to remove
dust and dirt.
If the air cleaner element is extremely
contaminated, replace it with a new one
.
[3] Attach the air cleaner element to the air
cleaner body.
[4] Re-place the air cleaner cap, and then af-
fix it securely using the clips.
[5] Press the reset button for the vacuum in-
dicator.
3) Replace the inner element every year.
Also replace it whenever it has become damaged or dirty.
Oil level gauge
Air cleaner
Reset button
Vacuum pressure indicator
The inner element cannot be cleaned.
Important

−15−
Implement after the engine and muffler etc. have well cooled
down.
Otherwise you may get burned.
Keep fire away while inspecting or charging the battery.
The battery may explode.
Be careful not to let your skin, eyes or clothes, etc., come into
contact with the battery fluid or accidentally swallow the fluid.
Should your skin or clothes come into contact with the battery
fluid, immediately wash them away with water.
When you supply battery fluid, wear protective garments and
safety glasses, etc.
●When removing the battery, remove the negative (-) cable
first, and positive (+) cable last. Install the battery, assemble
the positive (+) cable first and negative (-) cable last.
●When you connect the battery cables, connect the positive
and negative side correctly. When you mistake, the battery
and the electrical equipment may be damaged. (The red-color
cable is the positive side.)
●If a dry cloth is used to clean the battery, the static electricity
may occur and there is danger of fire or explosion.
Do not allow the battery fluid level to become lower than the
LOWER LEVEL (minimum fluid level line).
The battery may explode if it is used or charged while the
battery fluid level is at the LOWER LEVEL (minimum fluid
level line).
Warning
Danger
Danger
Danger
Danger
Caution
5-5
Inspection of Battery and Supply of Battery Fluid Before inspection of battery, clean the areas
around the battery fluid level lines with a cloth
dampened with water.
Make sure that the battery fluid level is between
the UPPER LEVEL (maximum fluid level line)
and the LOWER LEVEL (minimum fluid level
line).
If the battery fluid level is lower than halfway
between the UPPER LEVEL (maximum) line
and LOWER LEVEL (minimum) line, add puri-
fied water up to the UPPER LEVEL (maximum)
line.
5-6
Inspection of Tires
1) Check the pneumatic pressure of the tires.
2) Make sure that there are no cracks, damage or abnormal wear.
UPPER LEVEL
LOWER LEVEL
When filling the tires with air, do not fill the tires over the
specified maximum air pressure.
Otherwise, the tires may burst.
Important
Tire size Pneumatic pressure
Front wheel (26.5 x 14.00 - 12) 150kPa (1.5kgf/cm2)
Rear wheel (20.0 x 12.00 - 10) 140kPa (1.4kgf/cm2)

−16−
Securely tighten the oil level gauge and oil filler cap.
A slacking or damaged belt or damaged fan may cause
overheating or lack of a battery charge.
The engine must be stopped when the belt is inspected.
Important
Important
Warning
5-10
Inspection of The Engine and Its Surroundings
1) Check the parts of the fuel system for crack and leakage, and replace with new ones if
necessary.
2) When the grass, the leaf, etc. have jammed to the muffler and its surroundings, blow out
by air.
5-11
Inspection and Supply of Engine Oil
Stop the engine, wait for 10 to 20 minutes for
the engine to cool down, and then check the oil
level.
Position the machine so that the engine will be
level, and then insert the oil level gauge all the
way to check the oil level.
The appropriate oil level should be between the
upper and lower limit lines on the gauge.
5-7
Inspection of Brake
■Foot brake
While traveling, depress the brake pedal firmly to make sure that the brake is applied
effectively.
■Parking brake
1) Make sure that the parking brake is applied
after depressing the brake pedal and pulling
the parking brake lever.
2) Make sure that the parking brake is not
applied even slightly after depressing the
brake pedal to release the parking brake
lever.
5-8
Inspection of Belt
1) Press the middle of the belt with your finger to check the belt tension.
2) Make sure that there are no cracks, damage or abnormal wear.
5-9
Inspection of Wire
1) Make sure that the wire is not cracked or damaged.
2) If the wire is cracked or damaged, replace it with a new one immediately.
Parking brake lever When Pulling it,
brake functions
When releasing
it, brake does
not drag.
Oil level dipstick
Upper limit
Oil level dipstick
Lower limit

−17−
Do not supply fuel above F (FULL) level of the fuel gauge.
If you supply too much fuel, it might overflow from the fuel cap
when you travel or work on a slope.
Keep fire away while refueling.
Do not smoke while refueling.
Supply fuel after the engine is stopped and has well cooled
down.
●To prevent a fire, keep the machine clean and free of dust,
grease and oil.
●Clean up any spilled fuel.
●Don't oversupply the fuel. It may cause the fire, if the fuel
overflow from the fuel tank.
Warning
Warning
Warning
Warning
Do not supply too much engine oil. Otherwise, the engine may
be damaged.
The air-bleed plug should always be in the closed position
except during the air bleeding operation.
Using the machine with the air-bleed plug in the open position
may cause the engine to stall.
Do not mix different types of engine oil.
Securely tighten the oil level gauge and oil filler cap.
Be sure to use engine oil that is classified as API Service
Grade CF or higher, with an SAE Viscosity that is appropriate
for the operating environment (ambient temperature).
Important
Important
Important
Important
Important
If the engine oil level is lower than the lower limit line on the oil level gauge, supply engine
oil through the oil filling port.
[1] Remove the oil filler cap.
[2] Supply new engine oil until the oil reach-
es a level in between the upper and lower
limit lines on the oil level gauge.
[3] Replace the oil filler cap.
[4] It will take a while for the supplied engine
oil to descend into the oil pan.
Check the oil level again 10 to 20 minutes
after supplying the oil.
Oil filler cap
5-12
Inspection and Supply of Fuel
5-13
Air Bleeding of Fuel System
Air bleeding is not a required operation for this
machine since it occurs automatically.
With the machine on a level surface, observe
the fuel gauge in the operation panel to check
the fuel level.
If the fuel gauge located in the operation panel
indicates a level close to E (EMPTY), supply
fuel (diesel) at your earliest convenience.
The fuel tank capacity is approximately 47.0
dm3 (47.0 L).
EF
14
FUEL
1234
Air-bleed plug
