Baroness SP05 Setup guide

V o l.4
Assembly and installation manual

Thank you for purchasing this Baroness product.
This manual describes how to handle this product and make adjustments.
Please be sure to carefully read and fully understand the owner’s manual and this manual before
use.
This machine was shipped after a thorough inspection. However, the performance of the machine is
greatly affected by handling and daily maintenance, such as inspection and adjustments before and
after operation. Please handle this machine properly and perform necessary inspection and
adjustments before and after operation in order for the product to fulfill its original function and
ensure safe operation.
For operation and inspection, refer to the owner’s manual. For necessary parts, refer to the parts
catalogue.
KYOEISHA Co., Ltd.
Caution
The information described in this manual is subject to change without prior notice for improvement.
When replacing parts, be sure to use genuine Baroness parts or parts designated by Kyoeisha. Note
that the Baroness product warranty may not apply to defects caused by the use of parts from other
companies.
This symbol is accompanied by the word "Danger," "Warning," or "Caution." All labels with this symbol
describe important safety precautions, so please read such labels carefully and only operate the machine
after you have understood them completely. Failure to adequately follow these safety precautions may cause
an accident.
Danger：
This symbol indicates that serious injury or death will occur if the warning is ignored.
Warning：
This symbol indicates that serious injury or death may occur if the warning is ignored.
Caution：
This symbol indicates that injury or damage to property may occur if the warning is ignored.

1. Before installation, removal, adjustments, etc., park the machine on a level surface. Set the parking brake,
stop the engine, and remove the key. Ensure that all the parts have come to a complete stop.
2. Keep your hands and feet away from moving parts.Avoid performing work with the engine running. Keep
other people away from the machine during work.
3. If necessary, use appropriate chain blocks, hoists, or a jack. If the machine is lifted up, ensure that it is
supported by jack stands or appropriate blocks.
4. When replacing parts or installing accessory parts, use genuine BARONESS parts.
5. Never start the engine in a closed room. Doing so could cause carbon monoxide poisoning.
When installing, removing, and adjusting optional equipment and attachments, observe the
following safety instructions to ensure safe operation.

SP05----AM02USC
1
Installing Optional Equipment for the SP05
Sand Cultivator
Intended use: The sand cultivator section is used to loosen the bunker surface and soften the sand.
Operating width: 116 cm (46 in.)
Check that all parts are included. The following parts are included in the package.
Should any part be missing or damaged, please contact the dealer you purchased it from.
SAND CULTIVATOR ASSY
SP05---0930B0
1
LEVER, CULTIVATOR
Qty:1
2
SAND CULTIVATOR
Qty:1
3
WASHER,M8
K5000080002
Qty:1
4
WASHER, SPRING M10
K0200100002
Qty:7
5
BOLT, M10-30
K0000100302
Qty:4
6
WASHER, M10
K5000100002
Qty:7
7
BOLT, M10-25
K0000100252
Qty:3
8
PIN, ROUND HEAD M8-25.6
K6041080258
Qty:1
9
PIN, COTTER M2.5-20
K0300025202
Qty:1

SP05----AM02USC
2
Tightening torque
Required tightening
torque Nominal diameter Appropriate tightening torque [General bolts Strength class: 4.8]
N-m kgf-cm lb-in
- M6 7–9
71.38~91.77
61.96~79.66
- M8 14–19 142.76~193.74 123.91~168.17
M10 29–38
295.71~387.49
256.68~336.34
Caution
When tightening bolts, refer to the above table. We will not be held responsible for any damage
resulting from improper or excessive tightening, etc.

SP05----AM02USC
3
SP05
Installing the Sand Cultivator Section
Steps Illustrations Descriptions
1
The lever portion of the packaged
Cultivator
Lever(1) is out of alignment.
Align the center(B) of the lever with A line.
2
Set Sand Cultivator(2) under the machine.
3
Secure the right fulcrum(D) to the right
frame mounting portion(C) with
Washer(6), S Washer(4) and Bolt(5).
Secure the left fulcrum to the left frame
mounting portion with Washer(6), S
Washer(4) and Bolt(5).
4
Secure the slotted hole(E) of the right
fulcrum(D) to the right frame mounting
portion(C) with Washer(6), S Washer(4)
and Bolt(5).
Secure the slotted hole of the left fulcrum to
the left frame mounting portion with
Washer(6), S Washer(4) and Bolt(5).

SP05----AM02USC
4
SP05
Installing the Sand Cultivator Section
Steps Illustrations Descriptions
5
Secure Cultivator Lever(1) to Sand
Cultivator(2) with Washers(6), S Washers(4)
and Bolts(7).
5
Secure
the gas spring(F) to the right
fulcrum(G) with Pin(8), Washer(3), Cotter
Pin(9) and cover the rod.
6
In the case that the
rod length of the gas
spring does not meet the fitting distance of
Cultivator, adjust the
rod length of the gas
spring according to the following procedure.
<<Place the rod end(H) of the gas spring in
contact with the block surface of the rear tire
of the machine and push Cultivator Lever(1)
toward the rear tire with gripping t
he lever
portion of the Cultivator Lever
to adjust the
rod length of the gas spring to
be within the
range of 40-70mm（15.7-27.5inch）and then
release the lever portion.>>

SP05----AM02USC
5
7
Ensure that the cultivator moves smoothly and does
not interfere with the other parts.

SP05----AM02USC
6
Removing Sand Cultivator Assy (See the illustrations for installing procedures)
1. Remove the Bolt(5), S Washers(4) and Washers(6) on the right and left frame mounting portions
of the machine fitted with Sand Cultivator(2).
2. Remove Sand Cultivator Assy from under the machine.

MEMO

MEMO
