Camon C2000 User manual

C2000 Tiller
Operating Instructions
Before commissioning the machine, read operating instructions and
observe warning and safety instructions.

Manufacturer Details
Tracmaster Ltd
Sovereign Centre
Victoria Road
Burgess Hill
West Sussex
RH15 9LR
UNITED KINGDOM
Tel: [phone]
Fax: [phone]
www.tracmaster.co.uk
[e-mail]
Machine Details
Model: CAMON C2000 Tiller
Serial Number: ..................................................
Engine Serial No: ..................................................
Date of Purchase: ..................................................
Supplier: ..................................................

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 1
Table of Contents
1.0 Designation of Machine............................................................................................................ 2
1.1 Applications..................................................................................................................... 2
2.0 Specifications........................................................................................................................... 3
3.0 Unpacking and Assembly......................................................................................................... 4
3.1 Major Components Diagram............................................................................................ 4
3.2 Unpacking Instructions .................................................................................................... 4
4.0 Safety Instructions ................................................................................................................... 5
4.1 Basic Safety Instructions ................................................................................................. 5
4.2 Main Components and Operating Elements.................................................................... 5
4.3 Engine and Drive............................................................................................................. 5
4.4 Operating Lever............................................................................................................... 5
4.5 Drag Bar.......................................................................................................................... 5
4.6 Transport Wheel.............................................................................................................. 6
4.7 Throttle Lever.................................................................................................................. 6
4.8 Commissioning................................................................................................................ 6
4.9 General Safety Instructions ............................................................................................. 6
4.10 Engine Specific Safety Instructions.................................................................................. 7
5.0 Safety Instructions Starting and Operating................................Error! Bookmark not defined.
5.1 To Start the Engine.......................................................................................................... 8
5.2 To Stop the Engine .......................................................................................................... 9
5.3 Safety Equipment ............................................................................................................ 9
5.4 Operation......................................................................................................................... 9
5.5 Procedure for Unexpected Shut Down ............................................................................ 9
5.6 Residual Risks of the C2000 Tiller................................................................................... 9
6.0 Maintenance .......................................................................................................................... 10
6.1 Schedule........................................................................................................................ 10
6.2 Basic Maintenance........................................................................................................ 10
6.3 Engine .......................................................................................................................... 10
6.3.1 Check Engine Oil Level..................................................................................... 10
6.3.2 Change Engine Oil............................................................................................ 10
6.3.3 Air Filter .............................................................................................................11
6.3.4 Spark Plug..........................................................................................................11
6.4 Cleaning .........................................................................................................................11
6.5 Troubleshooting............................................................................................................. 12
6.5.1 Machine............................................................................................................ 12
6.5.2 Engine............................................................................................................... 12
6.5.3 Lubricants ......................................................................................................... 12
7.0 Transportation, Storage and Handling.................................................................................... 13
7.1 Transportation................................................................................................................ 13
7.2 Storage.......................................................................................................................... 13
7.3 Handling ........................................................................................................................ 13
8.0 Service Record ...................................................................................................................... 14
EC Declaration of Conformity......................................................................................................... 15

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
2 For parts diagrams visit www.tracmaster.co.uk
1.0 What the Machine is Designed For
1.1 Applications
The CAMON C2000 Tiller has been designed by Tracmaster for cultivating soil for planting
of vegetables, plants and flowers.
The benefit of using a C2000 Tiller is the ease and efficiency with which the machine is able
to dig the ground, saving the operator substantial time and effort.
!IMPORTANT – READ CAREFULLY
The tines of the CAMON C2000 Tiller are designed to be used only on soil
where there is no grass present.
DO NOT use the CAMON C2000 Tiller for any alternative use other than
cultivating soil.
Operating the machine on non-grass surfaces such as concrete or tarmac
will cause damage to the C2000 Tiller.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 3
2.0 Specifications
ENGINE
Engine Manufacturer Honda
Engine Model GX160
Engine Type 4-stroke OHV, single cylinder
Net Engine Power 3.6kW (4.8hp) @ 3600rpm
Engine Shaft Size ¾” straight
Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO)
Spark Plug Gap 0.70 - 0.80mm
Engine Ignition Type Recoil
Cold Start System Choke
Fuel Tank Capacity 3.1 litres
Fuel Type Unleaded
Fuel Consumption 1.4 litres per hour @ 3600rpm
Air Filter Paper
Rated Engine Speed 3600rpm
Engine Oil 10w/30 API SJ or later
Engine Oil Capacity 0.6 litres
Dry Weight 15.1kg
The power rating of the engine indicated in this table is the net power output tested on a production engine for the engine
model and measured in accordance with SAE J1349 at a specified rpm.
MACHINE
Model
C2000
Working Width
64cm
No of Blades
16 [8 left / 8 right]
Wheel Types
Solid rubber
Handlebar Feature
Foldable
Noise Level
86db(A)
Vibration Acceleration Value
6.9ms2
Max Gradient for Operation on Slope
20 degrees
Weight
69kg
Dimensions (l x w x h)
80 x 64 x 60cm

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
4 For parts diagrams visit www.tracmaster.co.uk
3.0 Unpacking and Assembly
3.1 Major Components Diagram
1 Engine On/Off Switch
2 Top Handlebar
3 Handlebar Pin & R-Clip
4 Operating Lever
5 Engine
6 Belt Guard
7 Lifting Handle
8 Drag Bar
9 Digging Tines
10 Transport Wheel
3.2 Unpacking Instructions
Open the top of cardboard box.
Cut the box open by using a sharp knife to cut down through the four corners of the box.
Swivel the folded top handle bar until the holes at the bottom of the top handlebar are over
the locating hole on the bottom handlebar.
Insert the pin located on a chain to fix handlebars into position. Secure the pin with R-Clip.
Push the machine forward safely and gently out of the box.
Dispose of the cardboard box and other padding material.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 5
4.0 Safety Instructions
4.1 Basic Safety Instructions
Before starting the machine, read and understand these operating instructions.
4.2 Main Components and Operating Elements
Below is a description of the main components of the C2000 Tiller and how they operate.
4.3 Engine and Drive
The Honda GX160 is fitted with a red ON/OFF switch that is the main operating control for
the engine. Rotating the switch to the “I” position allows the engine to be started and run.
Rotating the switch to the “0” position will stop the engine.
The Honda GX160 is a four stroke engine that runs on standard unleaded fuel.
The engine is air cooled and therefore it is important that the grille covering the recoil rope is
kept clear from debris.
The engine air filter cleans the air drawn in by the engine. A clogged air filter will reduce
performance.
The engine is fitted with a choke lever. Read the engine operating instructions to
understand the operation of these levers.
4.4 Operating Lever
The drive to digging tines is controlled by the operating lever located under the grip on the
left handlebar.
Pulling upwards on this lever engages the drive to the tines which will start rotating and
digging into the ground.
4.5 Drag Bar
Located at the rear of the machine, the drag bar is used to control the depth and speed at
which the C2000 will dig into the ground.
The depth is controlled by varying the position at which the drag bar is held into its location
at the rear of the C2000. The drag bar has a choice of holes through which its locating pin
can be positioned. The lower the hole used on the drag bar to hold it in its position, the
deeper the machine will dig.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
6 For parts diagrams visit www.tracmaster.co.uk
Forward speed is controlled by the drag bar as during operation of the tiller downward
pressure is applied on the handlebars by the operator that forces the drag bar into the
ground. This acts as an anchor holding the tiller in place whilst it digs down to its required
depth. Releasing downward pressure on the drag bar allows the tiller to walk itself forward
into its new cultivating position.
4.6 Transport Wheel
The transport wheel is used solely for moving the C2000 Tiller to its designated digging
location.
NB: The transport wheel is not required at any point during actual ground cultivation.
The transport wheel is held in its downwards travel position using a spring mechanism. By
pulling on the wheel it is possible to overcome the tension of the spring and rotate the wheel
180 degrees upwards and around to a location where it is held out of the way of the digging
tines.
4.7 Throttle Lever
The throttle lever controls the engine speed that in turn controls the speed of the digging
tines.
A faster throttle speed will result in an increased rotational speed of the digging tines.
4.8 Commissioning
Prior to operation it is necessary to check the engine oil level and add engine oil level to the
levels indicated in the table in section 5.1.
The engine fuel tank will not contain fuel so will need filling to the recommended level before
use.
4.9 General Safety Instructions
Be aware of all the safety requirements for the machine.
Visually check the machine for operational safety, complete components and fixed guarding
prior to each use.
Read and be aware of the warning and instruction signs located on the machinery.
Cordon off the work area to access from the general public.
Before starting work clear the area of any objects that may cause damage to the machine.
Do not operate the machine if you are under the influence of alcohol or drugs. This
equipment must only be operated by persons who are medically fit both physically and
mentally.
Only work in good light and visibility.
Wear the correct personal protection equipment as instructed by this manual.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 7
Operator clothing should not be loose and footwear should offer good grip.
Know how to stop the machine in an emergency.
4.10 Engine Specific Safety Instructions
Always ensure the engine is turned off and the fuel tap is turned off when transporting the
machinery, cleaning the machinery and making adjustments.
Always start the engine in open air. Starting an engine within a confined space can lead to
the inhalation of toxic substances.
Do not smoke or use a naked flame when refueling.
Use only unleaded petrol from fuel containers designed for this purpose. Refuel outdoors
only and replace the fuel tank cap securely.
Do not mix oil with the fuel.
Leave one inch of space in the fuel tank during refilling.
Clear up any petrol spillages immediately.
Avoid contact with the engine during operation as it will become hot. Leave the engine to
cool prior to contact.
Never interfere with the control settings of the engine.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
8 For parts diagrams visit www.tracmaster.co.uk
5.0 Safety Instructions Starting and Operating
5.1 To Start the Engine
Using the dipstick provided,
check the engine oil level. Top
up with 10w/30 oil if the dipstick
is clear of oil.
Check the fuel level. Refill as
necessary and as determined by
the fuel tank type – see diagram.
Switch the engine ignition switch
to the ON position.
Turn the fuel tap located on the
engine carburetor to the ON
position. If the engine is cold or
has not been operated recently
set the choke lever on the
carburetor to the ON position.
Pull the engine recoil handle slowly until it engages then pull briskly to start the engine.
After the start, return the recoil handle gently. Do not let it snap back.
Once the engine has started, if the choke lever has been used, return this its OFF position
after the engine has run for a few seconds.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 9
5.2 To Stop the Engine
Release the operating lever.
Switch the engine ON/OFF switch to the “0” OFF position.
Turn the fuel tap lever to the OFF position.
WARNING: THE EXHAUST COVER MAY BE HOT – DO NOT TOUCH.
5.3 Safety Equipment
The C2000 operator must be wearing:
•Ear Defenders
•Gloves
•Protective Footwear
•Safety Glasses
5.4 Operation
Before cultivation can be carried out, the ground must be cleared of long grass and any
objects such as stones or bricks that would damage the Tiller.
WARNING: USING THE TILLER ON LONG GRASS WILL QUICKLY CAUSE DAMAGE TO
COMPONENTS OF THE MACHINE.
When safety checks have been completed, start the engine following the correct procedure.
Position the Tiller in the direction you wish to cultivate
Ensure the transport wheel has been located in its upright digging position.
5.5 Procedure for Unexpected Shut Down
Release the operating lever.
Turn the engine operating switch located on the engine to the OFF position.
Ensure the tines have stopped rotating prior to moving the machine.
5.6 Residual Risks of the C2000 Tiller
The C2000 Tiller is designed to be pushed by the operator during transportation. It has no
brake system and therefore the operator must hold firmly onto the machine at all times when
the machine is on sloped areas.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
10 For parts diagrams visit www.tracmaster.co.uk
6.0 Maintenance
6.1 Schedule
Operation
Daily
Every
Week
Every
Month
Engine
Check engine oil level 10W/30
See separate engine manual
X
X
Machine
Check condition of tines
X
Check belt condition
X
Check operating lever and cable
X
Check protection cover condition
X
Check bearings
X
Lubricate wheel bearings
X
Tighten all nuts and bolts
X
6.2 Basic Maintenance
Check that all guards are fitted securely.
Ensure the cable connecting the drive lever to the engine is securely fastened at both ends
and shows no sign of wear.
Ensure the wheel is held securely.
6.3 Engine
6.3.1 Check Engine Oil Level
This is to be checked prior to each use and every 8 hours during operation.
Check only when the engine is off and in a horizontal position.
Clean the oil filler plug and its surrounding parts.
Remove the oil filler plug. Clean the dipstick with a clean cloth and put the oil filler
plug all the way back into the engine. Remove the oil filler plug and check the oil
level.
Re fill the oil if indicator shows more is required. For the Honda GX160 the
recommended oil is SAE 10w/30.
6.3.2 Change Engine Oil
Refer to the engine manufacturer's manual for location of components and more
detailed assistance.
Do not change the oil if the engine is hot.
The first oil change is after 50 hours of work.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 11
Subsequent oil changes should be made after each 100 hours of work.
At extreme temperatures or conditions change the oil after every 50 hours. Drain the
oil when the engine is warm, as it will drain quickly and completely when warm.
Open the drain plug on the engine and the filling plug and drain the oil into a suitable
container or use a suction pump to remove oil through filler neck.
Ensure the waste oil is disposed of properly.
Re-fit the drain plug and tighten.
Fill fresh engine oil through the oil filling opening. Use a funnel or similar device for
ease of filling.
Replace the oil filler plug and tighten.
6.3.3 Air Filter
Inspection Check:
Remove the air cleaner cover and inspect the filter elements.
Cleaning:
See diagram below containing information provided by Honda.
6.3.4 Spark Plug
Clean and replace.
6.4 Cleaning
After cleaning, particularly if a pressure washer has been used, ensure any lubrication points
are re-lubricated.
Clean the engine with a cloth only. Avoid spraying the engine with jets of water as this may
leak into the fuel and ignition systems.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
12 For parts diagrams visit www.tracmaster.co.uk
6.5 Troubleshooting
6.5.1 Machine
Have all serious malfunctions on the machine and engine repaired by an authorised
Tracmaster or Honda agent.
Problem Possible Cause Remedy
No drive to blades Broken belt Replace belt
Broken spring tensioner Replace spring
Poor depth Drag bar set incorrectly Adjust drag bar
6.5.2 Engine
Problem Possible Cause Remedy
Engine
does not
start
Spark plug connector not connected Connect spark plug connector
Choke lever is not actuated Actuate choke lever
Fuel tank empty Fill fuel tank
Fuel line clogged Clean fuel line
Defective spark plug Clean or replace spark plug
Engine has too much fuel
Dry and adjust spark plug and
start engine on full throttle
Engine
overheats Low engine oil Refill immediately
Impaired cooling Clean cooling fan grille
Air filter clogged Clean air filter
6.5.3 Lubricants
Use the specified 10w/30 oil specified by Honda for the engine oil.
To lubricate the roller bearings in the wheels we recommend using bio-lubricating
grease.

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 13
7.0 Transportation, Storage and Handling
7.1 Transportation
Use ramps where possible to manoeuvre the Tiller into a transportation vehicle.
The C2000 Tiller must be fixed securely using straps and by placing chocks behind the
wheels.
Always transport the C2000 Tiller horizontally and not tilted at an angle.
Ensure that the fuel control lever on the engine is moved into the OFF position so fuel does
not leak into the carburetor during transportation.
7.2 Storage
Always clean the machine and thoroughly dry prior to storage and ensure all lubrication
points have been re-greased.
For periods of long storage, change the engine oil.
Either drain the fuel completely or fill the fuel tank and add fuel stabilizer.
Do not store the Tiller in wet rooms, where fertiliser is stored, or in stables as heavy
corrosion may occur.
Always store the machine in a horizontal position.
7.3 Handling
Do not attempt to lift the machine alone. At least two people is the minimum required.
Gloves must be worn when lifting the C2000 Tiller.
Do not tilt the machine so that fuel can leak into the air filter of the engine.
When performing maintenance on the Tiller when it is situated on a work bench, ensure that
the machine is firmly held in position at all times.
Do not lift the machine solely by the engine at any point.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
14 For parts diagrams visit www.tracmaster.co.uk
8.0 Service Record
To ensure your machine is kept in peak condition we recommend that your Scarifier is serviced
regularly.
Contact Tracmaster on 01444 247689 to find out who your local Authorised Agent is.
Company:__________________________
Date:______________________________
Company:__________________________
Date:______________________________
Company:__________________________
Date:______________________________
Company:__________________________
Date:______________________________
Company:__________________________
Date:______________________________
Company:__________________________
Date:______________________________

Tracmaster Ltd CAMON C2000 Tiller
_______________________________________________________________________________________________
For parts diagrams visit www.tracmaster.co.uk 15
Warranty Registration
To validate your warranty please complete the form below and return it to:
Tracmaster Ltd, Sovereign Centre, Victoria Road, Burgess Hill, RH15 9LR
Alternatively visit www.tracmaster.co.uk and complete the online form.
CUSTOMER DETAILS
Name: ...............................................................................................................
Company (if applicable):...............................................................................................................
Address: ...............................................................................................................
...............................................................................................................
............................................... Postcode: .........................................
Email: ...............................................................................................................
Phone: ...............................................................................................................
MACHINE DETAILS
Machine: CAMON Tiller
Model: C2000
Serial Number: ...............................................................................................................
Engine Serial Number: ...............................................................................................................
Purchase Date: ...............................................................................................................
SUPPLIER DETAILS (if not supplied directly by Tracmaster)
Dealer Name: ...............................................................................................................
Dealer Address: ...............................................................................................................
...............................................................................................................
............................................... Postcode: .........................................
We will never pass your details to any third party, however, we may occasionally send you emails with offers
and promotions, if you do not want us to do this, please tick this box.

CAMON C2000 Tiller Tracmaster Ltd
_______________________________________________________________________________
16 For parts diagrams visit www.tracmaster.co.uk
