Barton 95516 User manual

SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 95516
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST
HIGH PRESSURE PROPANE STOVE BURNER

1
GENERAL SAFETY WARNINGS
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator. Read
carefully and understand all instructions before operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.
IMPORTANT SAFETY INFORMATION

2
Sober adult operation ONLY! Read and understand this manual before using the product. The use of
alcohol, prescription or non-prescription drugs may impair your ability to properly assemble or safely
operate this appliance.
This cooker, like any gas appliance, can be extremely dangerous! It can burn you, scald you with hot
oil or water, or start a re. Misuse of an outdoor cooker can result in serious personal injury or property
damage. The warnings and safety instructions in this manual must be followed to provide reasonable
safety and efciency in using this unit.
LP (propane) gas is colorless, tasteless, heavier than air, and is both ammable and explosive. Combustion
of propane consumes oxygen and produces carbon monoxide (a poisonous gas). Therefore, never operate
an outdoor cooker inside a building or conned area where ventilation may be restricted. Make sure the
LP Cylinder and the appliance is placed in an open area. DO NOT obstruct the ow of combustion and
ventilation air.
Never leave cooker unattended. Most accidents occur as a result of leaving the cooker unattended.
When Frying; a cooker left unattended may eventually over heat, resulting in a serious grease re. When
Boiling;a cooker left unattended may eventually boil over. Water can splash down on the burner and
put out the re resulting in propane gas being released out into the cooking area. When Steaming; a
cooker left unattended may eventually evaporate all the water inside the steam pot. If water is allowed to
evaporate completely, the heat from this cooker will melt a hole into the bottom of the pot, resulting in a
loss of the pot and the food inside.
DO NOT leave this appliance unattended while heating oil, grease or water, cooking food or when hot
after use [oil, grease or water above 100°F(38°C)]. Heated liquid can remain at scalding temperatures
long after cooking has ended.
Use ONLY on a level, stable non-combustibles surface like brick, concrete or dirt. DO NOT use this
appliance on any surface that will burn or melt like wood, asphalt, vinyl, or plastic.
This appliance is for OUTDOOR use only. DO NOT use in a building, garage or any other enclosed area.
DO NOT use on wooden decks, under roof overhangs, on porches, carports or at garage door openings.
This appliance is NOT intended to be installed in or on recreational vehicles and/or boats. This appliance
is not intended for and should NEVER be used as a heater.
DO NOT locate this appliance under ANY overhead construction. Keep a minimum clearance of 10 feet
from the sides, front and back of the appliance to ANY construction. Keep the area clear and free of any
combustible material such as household chemicals, paint, gasoline and other ammable vapors and
liquids.
Keep the fuel supply hose away from any and all heated surfaces.
Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts
or leaks, the hose must be replaced prior to the appliance being put into operation.
Keep children and pets away from the appliance at all times. Avoid bumping of or impact with the appliance
to prevent spillage or splashing of hot liquid.
DO NOT move the appliance when in use. Allow the cooking vessel to cool to 115°F (46°C) before moving
or storing.
IMPORTANT SAFETY INFORMATION

ASSEMBLY
When cooking with oil or grease, the thermometer provided MUST be used. Follow instructions in this
manual for proper installation and use of thermometer. Follow instructions to make sure thermometer is
working properly.
NEVER let the oil or grease temperature get hotter than 350°F (177°C). If the temperature goes above
400°F (200°C) or if oil begins to smoke, IMMEDIATELY turn burner OFF. Wait for the temperature to
decrease to less than 350°F (177°C) before relighting burner. If there is a lid or cover, do not remove.
After reaching 450°F (230°C), oil or grease temperature can rapidly increase to its point of spontaneous
combustion or a serious grease re. Therefore, never leave cooker unattended, always monitor the
thermometer.
When cooking with oil or grease have a type BC or ABC re extinguisher readily available. In the event
of an oil or grease re DO NOT attempt to extinguish with water. Turn off the gas at the supply cylinder.
Immediately call the re department. A Type BC or ABC re extinguisher may, in some circumstances
contain the re.
NEVER overll the cooking pot with oil, grease or water. Follow instructions in this manual for establishing
proper oil, grease or water levels.
Failure to completely thaw and dry food may cause oil or grease to overow. When frying with oil or
grease, all foods products MUST be completely thawed and towel dried to remove excess water. Follow
instructions in this manual for frying foods.
In the event of rain, snow, hail,sleet or other forms of precipitation while cooking with oil or grease, cover
the cooking vessel immediately and turn off burner(s) and gas supply. DO NOT attempt to move the
appliance or the cooking vessel.
DO NOT place an empty cooking vessel on the appliance while in operation. The intense heat will melt
an empty pot. Use caution when placing anything on the cooking vessel.
NEVER use a cooking vessel larger than the capacity and diameter recommended by the manufacturer.
In sunlight or other bright light, the ame may be almost invisible. Use extreme caution keeping hands,
hair and clothing away from the cooker. Never put face or hands over burner while lighting. Make sure to
turn cooker off when not in use. Always wear cooking mitts when handling the cooker, cookware, cooking
utensils and accessories.
NEVER ll the Cylinder beyond 80% full. All LP Cylinders in excess of 2.2 lbs(1.0 Kg.) propane capacity,
must include a collar to protect the cylinder valve.
The valve on the propane tank is the “ON/OFF” valve. When nished cooking, or in case of an emergency,
turn the tank valve clockwise to the “OFF” position. Be sure to close the tank valve before disconnecting
the hose. Caution - The valve on the hose and regulator assembly controls the ame intensity only. It is
not an “ON/OFF” valve.
ALWAYS check for gas leaks before lighting.
Follow lighting procedures as stated in this manual. Use a replace match or gas appliance butane lighter.
This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection from hot
surfaces or splatter from hot cooking liquids. Always wear shoes while cooking.
Use Barton appliances only in accordance with state and local ordinances and codes. In the absence of
local codes, installation must conform with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage
and Handling of Liqueed Petroleum Gases, ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane
Installation Code.
3

PARTS and ATTRIBUTES
BURNER
TOP RACK
REGULATOR
CONNECTOR
HOLDERS
BOTTOM RACK
50,000 BTU
Heavy duty burner with weatherproof coating frame
CSA certied regulator, hose and connector included
Detachable holders for easy storage
4

OPERATION
1. The hose and regulator is a pre-assembled unit. DO NOT take apart. Simply
connect the hose and regulator assembly to the LP gas cylinder and to the cooker.
2. Make sure the valve on the LP cylinder is clean. Connect the hose to the
cylinder valve by turning the hand wheel to the right. Hand tighten.
CAUTION: The control valve controls the “volume” of gas only. Use the valve on
the propane tank to turn the gas supply on or off.
3. Connect the valve to the propane cylinder. Use the regulator valve to increase or decrease the amount
of gas needed. Closing the regulator valve on the hose will shut off the ow of gas to the burner.
NOTE: Using a small brush or spray bottle, splash on a soapy liquid (ex. Dish
washing liquid and water, or 50% non-ammonia soap and 50% water) on the
connections around the regulator and cylinder connection. Any bubbles that
appear indicate a gas leak. If so, turn off the gas and tighten the ttings some
more.
DO NOT use the cooker if a gas leak is detected and cannot be stopped.
4. After you are certain there are no leaks, turn tank valve and regulator valve to
“OFF” position. Wait 5 minutes for any gas fumes to go away before lighting the
burner.
5. When you are sure there are no leaks, turn cylinder valve and regulator control
valve on hose to the closed position.
6. Reopen cylinder valve fully.
7. Have a standard match, replace match or long-nosed propane lighter
lit and ready to place over the burner.
8. Before lighting, Turn air control shutter on the burner to an almost
closed position. After lighting, turn air control shutter to open position to
achieve a better ame.
5
9. Light the burner from the bottom, keeping hands and face away from
the top of the cooker.
10. Place lighter over the burner, then slowly open regulator valve until
burner ignites.
11. Adjust air shutter on burner for a blue ame. (In direct sunlight, ame
may appear clear.)
12. Adjust the regulator control valve for desired ame height.
13. When lighting for the rst time, you will smell paint burning at the top for a few minutes. This is normal.
14. When nished using the cooker, turn off gas from the cylinder valve rst. It will take a few seconds for
the re to go out and for the propane gas to “bleed” from the hose and regulator assembly. After the re is
completely out, turn regulator control valve to the “OFF” position.
15. If ame is accidentally extinguished, turn propane tank off. Wait 30 seconds, then repeat these steps.

OPERATION OPERATION
6
Intense heat from the cooker will burn away paint from parts of the frame and windscreen ashing. This will
cause a slight ‘odor’ for a few minutes during the initial use. The exposed steel will rust. Occasional care
must be taken to prolong the life of your cooker.
1. Store cooker in a cool dry place. DO NOT store outside exposed to weather. Storage of an appliance
indoors is permissible only if the cylinder is disconnected. If storing cooker indoors, detach and leave LP
cylinder outdoors. LP cylinders must NOT be stored in a building, garage or any other enclosed area.
2. For long term storage, cover the cast iron burner and the hose and regulator assembly in a plastic bag.
3. Spiders and small insects have been known to spin webs inside the tube of the cast iron burner.
Obstructions in the tube interfere with the ow of air and gas through the burner. A clogged tube may result
in a re beneath the appliance. If this happens, remove the cast burner from the frame and clean the tube
with a stiff, bent wire or screwdriver. We also advise cleaning inside the top ports as well.
4. DO NOT tamper with or attempt repairs on the burners, frames, valves, or LP cylinders.
5. Always close LP cylinder valve rst after use. Always use and store LP cylinder in an upright position.
Store out of the reach of children. Never store or transport LP cylinders in occupied enclosures. If storing
cooker indoors, detach and leave LP cylinder outdoors.
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
PLEASE READ THE FOLLOWING CAREFULLY
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PRODUCT MADE IN CHINA
