Barton 96802 Original instruction manual

SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST
FIRE PIT COLUMN WITH ROCKS
ITEM: 96802

IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions may
result in re and/or serious injury. Save all warnings and instructions for future reference.
SAFETY
WARNING DO NOT use this product or any available optional equipment without rst completely reading
and understanding these instructions and any additional instructional material such as owner’s manuals,
service manuals or instruction sheets supplied with this product or optional equipment. Basic precautions
MUST be followed to reduce the risk of re and personal injury.
1
EXPLOSION - FIRE HAZARD: Keep solid combustibles, such as building materials, paper or cardboard,
a safe distance away from the re pit as recommended by the instructions.
Provide adequate clearances around air openings into the combustion chamber.
NEVER use the re pit in spaces which do or may contain volatile or airborne combustibles, or products
such as gasoline, solvents, paint thinner, dust particles or unknown chemicals
During operation, this product can be a source of ignition. Keep re pit area clear and free from
combustible materials, gasoline, paint thinner, cleaning solvents and other ammable vapors and liquids.
Use a propane gas tank (sold separately). DO NOT attach to a remote gas supply. Propane gas is not
natural gas. Only use propane for this rebowl.
EXPLOSION - FIRE HAZARD: Never store propane near high heat, open ames, pilot lights, direct
sunlight, other ignition sources or where temperatures exceed 120 degrees F (49 C).
Propane vapors are heavier than air and can accumulate in low places. If you smell gas, leave the
area immediately.
NEVER install or remove propane cylinder while re pit is lighted, near ame, pilot lights, other ignition
sources or while re pit is hot to touch.
Store the propane cylinder outdoors in a well ventilated space out of reach of children. Never store the
propane cylinder in an enclosed area (house, garage, etc.). If re pit is to be stored indoors, disconnect
the propane cylinder for outdoor storage.
We cannot foresee every use which may be made of our re pit. Check with your local re safety
authority if you have questions about re pit use. Other standards govern the use of fuel gases and heat
producing products for specic uses. Your local authorities can advise you about these. If no local codes
exist, follow National Fuel Gas Code, ANSI Z223.1. In Canada, installation must conform to local codes.
If no local codes exist, follow the current National standards of CANADA CAN/CGA-B 149.2.
CARBON MONOXIDE HAZARD: This re pit is a combustion appliance. All combustion appliances
produce carbon monoxide (CO) during the combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used and maintained in accordance with all warnings
and instructions. DO NOT block air ow into or out of the re pit.
Carbon Monoxide (CO) poisoning produces u-like symptoms, watery eyes, headaches, dizziness,
fatigue and possibly death. You can’t see it and you can’t smell it. It’s an invisible killer. If these symptoms
are present during operation of this product get fresh air immediately!

2
IMPORTANT SAFETY INFORMATION
FOR OUTDOOR USE ONLY. Never use inside house, or other unventilated or enclosed areas. This re
pit consumes air (oxygen). DO NOT use in unventilated or enclosed areas to avoid endangering your
DO NOT store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
CARBON MONOXIDE HAZARD: This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a
camper, tent or home.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operation and maintenance instructions thoroughly before installing or
servicing this equipment.
California Proposition 65 Combustion by-products produced when using this product contain chemicals
known to the State of California to cause cancer, birth defects, and other reproductive harm.
BURN HAZARD: NEVER leave re pit unattended when hot or in use. Keep out of reach of children.
Certain materials or items, when stored under the re pit, will be subjected to radiant heat and could be
seriously damaged.
SERVICE SAFETY: Keep all connections and ttings clean. Make sure propane cylinder valve outlet is
clean. During set up, check all connections and ttings for leaks using soapy water. NEVER use a ame.
Use as a heating appliance only. NEVER alter in any way or use with any device.
CAUTION indicates an imminently hazardous situation which, if not avoided, may result in minor or
moderate personal injury, or property damage.
This product is fueled by propane gas. Propane gas is invisible, odorless, and ammable. An odorant is
normally added to help detect leaks and can be described as a “rotten egg” smell. The odorant can
fade over time so leaking gas is not always detectable by smell alone.
Propane gas is heavier than air and leaking propane will sink to the lowest level possible. It can ignite by
ignition sources including matches, lighters, sparks or open ames of any kind many feet away from the
original leak. Use only propane gas set up for vapor withdrawal.
Store or use propane gas in compliance with local ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use.
LP GAS WARNING: DO NOT exceed 1/4” depth of lava rocks directly above burner holes. Applying too
much media may result in unburned gas pooling in the rebowl. Ventilation is required to allow fresh air
into the enclosure and for any residual gas to escape.
The re pit should be inspected before use and annually by a qualied service person. More frequent
cleaning may be required as necessary. It is imperative that the control compartment, burners, and
circulating air passageway of the appliance be kept clean.
Lava rocks can hit someone in the face or eyes during the initial start of this unit. Keep away from the
rebowl for the rst 20 minutes after it has been ignited.
The max inlet supply pressure: Max gas supply 11”s.c. (2.74kPa)
DO NOT enlarge valve orices or burner ports when cleaning the valve or burner.
Remove the battery when not using the rebowl for an extended period of time
Remove the PVC cover before operating this appliance.
DO NOT use this rebowl on vehicles or boats. Always operate the appliance on a at surface outdoors.

3
IMPORTANT SAFETY INFORMATION
DO NOT replace the the PVC cover until the rebowl is cooled off.
Keep the gas tank a minimum of 5 feet away from the rebowl when lit.
The maximum gas supply pressure is 250psi.
The LP gas supply tank must be construxted and marked in accordance with the specications for LP
gas tanks of the US Department of Transportation (DOT) or the National Standard of Canada CAN/
CSA-B339, LP gas tanks spheres and tubes for the Transportation of Dangerous Goods; and commission
The LP gas tank must have a listed overlling prevention devise (OPD) and a QCCI or Type I, (CGA810)
LP gas tank connection.
DO NOT enlarge valve orices or burner ports when cleaning the valve or burner.
Clean the battery contacts prior to battery installation.
NEVER use charcoal or any other solid fuel in the rebowl.
If you see, smell or heat the hiss of escaping gas from the propane gas tank: 1. Disconnect propane
gas tank. 2. DO NOT attempt to correct the problem yourself. 3. Get to your gas supplier and/or the re
department for help.
NEVER use a ame to check for gas leaks.
DO NOT use this re table for cooking.
After a period of storage, and/or non use, the propane re table should be checked for gas leaks and
burner obstructions before use.

4
PRODUCT SPECIFICATIONS
LAVA ROCKS
BODY
DOOR
PVC
COVER BATTERY
1
4
11
10
9
8
7
14
2
12
3
5
6

5
ASSEMBLY AND OPERATION
STEP 1: Open the carton and turn it upside down, making sure the 5 pieces of the carton are pesent. Lift
the carton carefully, make sure no pieces fall away. Take all the packing materials away except for the paper
honeycomb board rounding the top of the rebowl.
STEP 2: Turn the rebowl heads up on a at ground. Remove all the paper honeycomb material rounding
the rebowl.
STEP 3: (I) Check each part before using the product. Make sure the gas supply system is turned “OFF”
before assembling. (II) Put the gas tank in the metal stand. Make sure the gas tank sits on the metal stand
completely. Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tightly.
(III) Locate the battery and remove the plastic cover rst. Unscrew the rubber cap of the Electric Ignitor,
place the AAA battery into the battery case. Make sure the positive pole (“+”) towards the cap. Screw the cap
back to the battery case tightly. (IV) Evently distribute the pumice stones on the top of the rebowl.
DO NOT COVER THE IGNITION SCREEN when
placing the pumice stones into the re table.
Always keep Ignition Screen visible. Connect
the Pressure-Regulating Valve to the gas tank.
1) Turn the cylinder valve clockwise to close the
gas supply on the gas tank. 2) Screw Regulator
coupling clockwise by hand only. Make sure it is
fastened.
WARNING: This screen must be clear and free of obstructions at all times to insure proper operation.
WARNING: The burner of the rebowl must be
covered by lava rocks completely. Otherwise the
ame may extinguish. Make sure lava rock pacement
is even and not built up in corners.
Perform leak test in a well-ventilated area outside and where no source of spark can occur. Remove battery
from igniter. Open tank valve fully (counter-clockwise). Turn the on/off valve at the unit to the “OFF” position
to pressurize the hose assembly. Use a soapy water solution to check all the connections for leaks before
attempting to light the appliance. If a leak is found, turn the tank valve off and do not use the appliance
until repairs can be made.

6
OPERATION and MAINTENANCE
Before each use, inspect the hose. Replace hose if there are any
signs of cutting, wear or abrasion.
(1) Turn the cylinder valve on the gas tank counter-clockwise to open the
gas supply.
(2) Close the storage door on the rebowl for the gas tank.
(3) Light the re table shown in the image
A: Press and hold the Electric Ignitor. Meanwhile, push and turn the control
knob counter-clockwise to the ‘PILOT’ position. Keep pushing the control
knob to light the pilot burner.
B: After ignition, release the Electric Ignitor. Continue to push and hold the
control knob for 45 seconds.
C: If ignition does NOT immediately take place on pilot burner in seconds, push and turn the control knob
clockwise to ‘OFF’. Wait 5 minutes, and then repeat the lighting procedure as above.
D: After light the pilot burner, turn Control Knob to LO or HI position. Main Burner will light immediately. If not,
repeat the lighting procedure as above.
CAUTION: If the burner does not ignite with the valve open, gas will continue to ow out of the burner and
could accidently ignite with risk of injury, repeat the lighting procedure as above.
Observe ame height when lit: Flame should possibly be a yellow/blue color
between 2 to 10 inches high.
Push the control knob and turn it clockwise to the OFF position.
Turn the cylinder valve on the gas tank clockwise to close off the gas
supply if not in use for a long time.
TO EXTINGUISH
ROUTINE CARE
Keep your re table free and clear from combustible materials.
• Visually inspect burner from obstructions and keep replace free and clear from debris.
• After the burner and pumice stones are completely cooled down, use a soft brush to get rid of the mild
stains, loose dirt and soil. Wipe with a soft cloth.
• Stubborn stains, discoloration and possibly rust pitting can occur from exposure to harsh outdoor conditions.
• Be careful not let any powder or solvent come in contact with painted or plastic components as damage may
occur
MAINTENANCE
• Store the re table in a cool dry place away from direct sunlight.
• The propane cylinder must be disconnected and removed from the re table before the appliance can be
stored indoors.
• Make sure both the gas and the re table is turned off before changing battery. Please refer to the process
of assembling battery.
• Use Manufacturer approved or supplied replacement parts and accessories only. Otherwise this may void
the warranty of this product and result in a hazardous condition.
• Please contact the Manufacturer for information regarding replacement hoses, thermocouples, ignitors,
pumice stones, etc

13
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
