Installation & Operations Manual
AirWerx 90X
Patented
Specification subject to change without notice.

Table of Contents
Warranty Registration
Safety Notes
Identification
Electrical Supply
Principle of Operation
Installation
Key Functions
Indicator Lights
Remote Control
Operating Instructions
Diagram
Maintenance
Dehumidifier Storage
Ducted Applications
Spare Parts
Troubleshooting
Warranty Information
2
2
3
3
3
3
4
5
6
7
7
8
9
9
10
11
12
1
......................................
...................................................
...................................................
..............................................
.......................................
......................................................
.................................................
...............................................
...............................................
......................................
.........................................................
...................................................
.......................................
.........................................
....................................................
...............................................
........................................

Warranty Registration
Congratulations on purchasing a new AirWerx 90X Dehumidifier. Your new dehumidifier comes with an
extensive warranty plan. To register, simply fill in and return the warranty card provided in your
dehumidifier box.
Be sure to note your dehumidifier serial number as you will need it for registration.
Safety Notes
The AirWerx Series Dehumidifier must always be connected using a grounded electrical connection
(as required for all electrical appliances ). If non-grounded wiring is used, all Iiability reverts to the
owner and the warranty is voided.
AirWerx Dehumidifiers should only be maintained and repaired by a qualified technician.
AirWerx Dehumidifiers are only intended for operation when oriented with the unit sitting on its feet and
level. Operating the unit in any other orientation could allow water to flood electrical components.
Always unplug dehumidifier before moving it to another location.
If there is a chance that water flooded the dehumidifier, it should be opened and allowed to dry
thoroughly before reconnecting to electrical power and restarting.
To ensure proper operation, neither the inlet nor discharge should be positioned against a wall. The
inlet requires a minimum of 12" clearance and the discharge requires a minimum of 36" clearance.
The best option for proper diffusion of air throughout the room is to have the discharge blowing away
from a wall and the inlet pulling air in parallel to a wall.
Do not insert your fingers or any object into the inlet or discharge.
All work on the dehumidifier should be done with the unit "off" and unplugged.
Do not use water to clean the exterior. To clean unit, unplug from power, then use a damp cloth to wipe
the exterior.
Do not stand on the machine or use it as a device to hang clothes.
2

Identification
For future reference, write down the model, serial number, and date of purchase for your dehumidifier.
This is extremely helpful if you need to seek assistance in the future. The data label on the side of your
unit has the key characteristics of your specific unit.
Model number: AirWerx 90X
Serial Number: ______________ Date of Purchase: _____________
For additional questions concerning your dehumidifier, the following options are available:
· Contact your installing contractor
· E-mail: [e-mail]
Electrical Supply
3
Power Supply: 220 V, 50 Hz AC, Single Phase
Outlet Requirement: 3-Prong, GFI
Circuit Protector: 15 Amp
WARNING: 120 Volts AC may cause serious injury from electric shock.
To reduce the risk of injury:
1. Disconnect electrical power before servicing.
2. Only plug unit into grounded electrical circuit.
3. Do not use an extension cord.
4. Do not use a plug adapter.
Principle of Operation
The AirWerx Series Dehumidifier utilizes its integral humidistat to monitor the conditioned space. When
the relative humidity goes above the selected set point, the dehumidifier will energize. Air is drawn
across an evaporator coil, which is cooler than the dew point of air. This means moisture will condense
out of the air. The air is then reheated through the condenser coil and distributed back into the room.
Step #1: Place dehumidifier on a level surface.
Do not place unit directly on vapor barrier. For example, use blocks or pavers to create a level surface.
If the unit is handled in such a manner that the compressor did not remain in the upright position, you will
need to place it on a level surface and wait a minimum of 2 hours before turning the unit "on".
Installation
The area to be controlled should be sealed with a vapor barrier. If the unit is installed in a crawlspace, all
vents should be sealed.
WARNING: Do not install your dehumidifier in a corrosive environment. Some liquid vapor barriers
dry via "solvent evaporation". Always make sure that barrier is completely dry and area is throughly
ventilated before installing dehumidifier.

4
Key Functions
1. Power Key
· Use this button to turn the dehumidifier on and off. Press once to turn the machine on. You will
hear two beeps and the light will illuminate red. Press the power button a second time and you
will hear one beep as the machine shuts down. Note that there is a one minute fan delay on
shutdown.
2. Arrow Buttons
· Use the up and down arrow buttons to set the desired humidity setpoint on the display screen.
The setpoint can be any number between 36-90%. Creating a setpoint means that when the
indoor humidity is lower than the set point, the machine will stop automatically. Conversely, when
the indoor humidity is higher than the set level, the unit will operate.
NOTE: The humidity levels displayed are approximate only
3. Continuous Mode
· To switch into continuous mode, set the humidity below 36%. At this point the Cont. light
should illuminate green on the display board to indicate you have successfully switched to
continuous mode. The display screen will show "CO”.
· When set to continuous, the dehumidifier will run constantly, regardless of the humidity level. To
stop the dehumidifier from running, turn the unit off or switch back to normal humidistat operation.
To switch back to normal humidistat operation, simply move the setpoint above 36%.
4. Central Control
· This mode is not applicable on the AirWerx 90X.
(+/-5%)
Step #2: Set Up Drain Line
The included drain line attaches to unit via a compression type fitting on the discharge end of the unit. To
attach drain line, remove the compression nut and slide it over the end of the house to be attached to
unit. Side compression nut side of house over the insert on the compression fitting completely. Tighten
compression nut.

5. Manual Drain Button
· For extended storage or movement of the machine, press the "Drain" button to remove water
from the integral pump’s reservoir.
6. Pump Trouble Warning
· When the pump reservoir water level is too high, the high water sensor will activate to prevent
overflow. When this occurs, the dehumidifier will stop the compressor automatically and the display will
show "E4" error. After a 1 minute delay, the fan motor will turn off and the machine will not operate until
the problem is resolved. To reset the unit after an “E4" error, check the pump to verify it is functioning,
then unplug the unit for two minutes.
7.Auxillary Terminals A5/A6
·The A5/A6 on the terminal strip can be used as a safety switch for external condensate pumps. It
should be set to N/O (normally open) at the dehumidifier. If an E4 error codes, switch the wiring to N/C
(normally closed).
5
Indicator Lights
1. Humidity Display Screen
·The display screen has two functions:
1. When the unit is powered on, it shows the humidity of the space.
2. While setting the desired humidity level, the screen will show the set humidity.
After a brief delay, the display will revert to the current humidity level.
2. Power Indicator Light
·This light indicates that the unit is properly powered on and ready to operate. Always make sure the is
"off" prior to performing any service.
3. Continuous Mode / AutoDefrost Light
·When this light illuminates green, it indicates that the dehumidifier is set to continuous operation mode.
·When the light glows red, it means the unit is in auto defrost mode and clearing the evaporator coil of
any ice buildup.

4. Compressor Light
·When the compressor light glows red, it indicates the compressor has been initiated but is currently
warming up.
·Once the compressor light switches to green, it indicates the compressor is in working status.
6
AirWerx Dehumidifiers can be controlled using an optional remote accessory. The AirWerx Remote
Control connects to your Airwerx Series Dehumidifier via a 25' CAT 5 cable. The remote control contains
an integrated sensor which gives you multiple options for remotely controlling your unit, in addition to
monitoring the conditions surrounding the dehumidifier.
One application for the remote control is to install the dehumidifier in one room with the conditioned air
ducted into a second room that contains the remote. For example, the dehumidifier could be installed in a
laundry room and ducted into a living room. The remote would then be mounted in the living room so the
remote sensor can control the humidity and provide easy controls for the user.
Another useful application for the remote control is if the dehumidifier is in area that's difficult to access on
a regular basis. For instance, if your dehumidifier is installed in your crawl space, the remote could be
mounted in your living space or garage. This provides you with an easy way to monitor the dehumidifier.
Remote Control Instructions
1. On/Off( Power) Button
Press the on/off button and the machine will start
running (two beeps). Press the button again to the
turn the machine off.
2. Up Button /Down Button
Use the Up and Down arrow buttons to adjust the
humidity level.
3. Mode M
Use the mode button to switch between
dehumidification and a ducted application.
The symbol on the display board indicates the sensor on the remote control is being utilized.
The symbol on the display board indicates the sensor on the dehumidifier is being utilized.
4. Temperature
Press the temperature button to display the current temperature on the screen. Press the button again to
turn off the display.
5.Continuous
Press this button to switch the unit into continuous mode. will appear on the display to indicate
continuous mode.

Operating Instructions
1. Start the machine
Press the power key to turn the machine on.
2. Adjust Settings
Use the up and down arrow keys to adjust your desired setpoint ( typically 50-55%) .
3. Stop the Machine
Press the power key again and the machine will stop. Note the fan will continue to operate for 1 minute
after the unit has shut off.
NOTE: Do not disconnect the power cord to force the unit to stop. Always use the power button.
4. Water Drainage
The AirWerx 90X has both automatic and manual draining. During normal operation, the AirWerx 90X
will automatically drain as required. If you would like to move or store the machine, you may press the
drain button to drain the water from the pump reservoir. The drain will operate for 15 seconds each time
the button is pushed. It may be necessary to push the drain button more than once to completely
empty the reservoir.
7
6. Drain Pump
Use this button if the unit will not be in use for an extended of time. Pressing the drain pump button will
remove water from the pump reservoir, so the unit can safely moved or stored.
NOTE: The symbols mentioned above will only appear when the dehumidifier is powered on.
Airwerx 90X Diagram
Front View
Back View
Power cord
Unit Cover
Inlet End Cap
Handle
Air Inlet Grille
Drain Hose
Unit Cover
Air Outlet Grille
Control panel
Discharge End Cap
Power cord
Remote control

8
Maintenance
Condensate Pump
Your AirWerx 90X is equipped with an integral condensate pump designed to pump water from your
dehumidifier out to the desired drain. This pump requires routine maintenance that is nor covered by
your 1-year parts warranty. Only a defective pump will be repaired or replaced during the warranty
period.
Preventative Maintenance
As with all pumps, preventative maintenance is necessary to prevent issues from dirt and slime that
may accumulate in the drain system. This includes the drain pan, hose to the condensate pump, pump
reservoir, pump head float assembly, and discharge tubing,
1. Unplug the unit.
2. Slide out the filter.
3. Clean the filter mesh by vacuuming or washing with warm
water ( no soap or solvents).
4. Be sure filter is completely dry
before restarting the unit.
Coil Maintenance
·Once per year, clean the coils with an approved coil cleaner.
·Coil cleaner should be a self-rinsing, foaming cleaner such as WEB® Coil
Cleaner.
Coil the filter
Electrical Access
1. Unscrew the 4 screw on the pump access panel.
2. Remove the screw on the pump.
3. Undo the 3 pump quick connects.
4. Insert a flathead screwdriver into the notch on the
side of the pump to help you gently lift the pump off
it's reservoir remains attached to the unit.
Pump maintenance
·Unscrew the 4 screws on the side panel to access the control board.
Cleaning/Didinfecting the Pump
Cleaning the machine body
Use a soft damp cloth to clean the exterior of unit. Do not use any soap or solvents.
At least once per year, clean your pump system
Basic Cleaning (Complete about once a year, depending on environment)
1. Open the end cap on the filter side of the unit. Press the frain the resevoir.
2. Disconnect power to the dehumifidier.
3. Mix a 16 oz solution of either (1 oz bleach + 15 oz water) OR (4 oz white vinegar + 12 oz water).
WARNING: Always unplug the unit before doing any maintenance.

9
4. Pour solution into the drain tray at the base of the coils. If any cleaning solutions gets on coils,
flush with water.
5. Allow solution to soak for 15 minutes.
6. Reconnect the dehumidifier to power.
7. Fill the reservoir with water and flush/cycle the pump at least two times.
8. If drain line is still filled with debris, repeat process. If still not cleaned, move on to Advanced
Cleaning.
9. Reassemble unit, unless moving on to advanced cleaning.
Advanced Cleaning (Complete as needed)
1. Press the drain button to drain the water from the reservoir (A wet-dry vacuum or towels can be
used to remove any remaining water).
2. Unplug the dehumidifier and remove the cover so you have access to the pump.
3. Remove the pump head from the reservoir by unscrewing the screw. Wipe reservoir clean with a
paper towel.
4. Mix a 16 oz solution of either (1 oz bleach + 15 oz water) OR (4 oz white vinegar + 12 oz water).
5. Fill the pump reservoir with cleaning solution.
6. Reassemble pump, then use manual drain button to flush mixture through discharge tubing.7.
Pour same cleaning solution slowly into drain tray under evaporator coils and let it clean hose from
pan to pump. This process can be stopped when the pump energizes one time.
NOTE: If you get any of the cleaning solution on the coils, flush with water.
8. Pour sufficient clean water through drain pan to allow the pump to turn on twice.
9. Reassemble the unit and return it to operational status.
Dehumidifier Storage
If the unit will be stored for an extended period of time, complete the following steps:
1. Turn off the unit and allow to dry.
2. Wrap and secure the power cord.
3. Cover the filter mesh.
4.Store in a clean, dry space.
Ducted Applications
Ducting the dehumidifier allows the unit to be in one room while conditioning an adjacent room. The
inlet/ return collar ( optional accessory, PN: W-103) is designed for 12" flex ducting while the supplt
grille is designed for 6" flex ducting.
Be sure to secure the ducting with tie wrap. Also, keep in mind, that the supply ducting can be
screwed into an adapter if necessary.
Ducting Installation
·Maximum total length of duct run= 10’
·Maximum length if only ducting inlet or outlet= 6'
·To connect 12"return ducting. it may be helpful to:
1. Remove inlet grille from end cap.
2. Connect duct to inlet grille.
3. Reconnect inlet grille to end cap.
Note: The supply duct adapter is standard on all units. Return duct is an optional accessory.

Installing Duct Adapter
To install adapter, line duct up with
holes on the side of unit push up
from the base of the adapter.
Removing Duct Adapter
If it is necessary to remove the adapter, place
hand at bottom of the adapter and use your
fingers to pull out and down. This will remove
the cover hooks from the machine.
Flex Duct Installation
Rotate the flex duct counter-clockwise.
Flex Duct Removal
Rotate flex duct clockwise or remove wire tie.
AirWerx 90X Spare Parts
All AirWerx Models-Parts
Part# Description
A-100 Remote Control Package ( cable+remote)
A-101
A-102
A-103
A-108
A-109
A-110
Remote Control
Remote Control Cable, 25’
Return Duct Collar Accessory
Main Control Board
Display Board
RH/Temperature Sensor
A-106 Duct Kit Assembly ( W-103+ W-100)
A-107 Flexible Supply Duct, 72"
A-915
A-916
A-917
A-918
Prefilter
Filter Assembly ( Cassette+Prefilter)
MERV- 8 Filter
HEPA Filter
AirWerx 90X-Filters
Part# Description
A-919 Carbon Filter
AirWerx 90X-Parts
Part# Description
A-900
A-901
A-902
Fan Motor
Complete Fan Assembly
Fan Capacitor
A-903
A-904
Compressor
Compressor Capacitor
A-905 Coil Assembly
A-906 Hot Gas Bypass Coil
Condensate Pump Assembly
A-907
A-908
A-909
A-910
A-913
RH/Temperature Sensor Cable
Display cable
CAT 5 Prot Internal Cable
Foot, adjustable
10

11
Troubleshooting
SolutionCause
Symptom
Power Supply Verify that there is power to the outlet and
that the plug is properly installed in outlet.
Room Temperature Over
105℉ (Display HI) or Below
33℉(Display LO)
The unit id outside the operating
temperature range. Modify the room
conditions so the temperature is between
33°-105℉ and operation will commence.
Trouble Code: HI or LO
Clean the filter mesh according to
instructions listed in manual.
Clear the blockage from inlet or outlet.
Air Filter is Clogged
Air Inlet or Outlet is Blocked.
Machine Won’t Run
Low Air Flow
Trouble Code E1:
Loud Noise
Filter Mesh is Blocked
E1=Humidity Sensor Issues
Room Temperature Over
105℉ or Below33℉( Display
LO)
Machine Is Not level Move the dehumidifier to flat, firm ground.
Clean the filter mesh according to
instructions listed in manual.
Check to ensure that wire is connected at
both ends. If no issues are visible, the
sensor may be faulty.
The unit is outside the operating
temperature range. Modify the room
conditions so the temperature is between
33°-105℉ and operation will commence.
If room conditions are within temperature
range, replace the defective sensor.
If a pump alarm is shown on the display, complete the following steps:
1. Reset the unit by disconnecting the power cord and then reconnecting it.
NOTE: UNIT WILL NOT FUNCTION UNTIL ERROR CODE HAS BEEN CLEARED.
2. Manually check to see if pump is operational by pressing the drain button. Check if the pump
energizes and de-energizes properly. Additionally, check to see if any water purged from the
system.
3. If you haven’t cleaned the system recently, check the discharge line for an obstruction, then clean
the balance of the pump system (see “Maintenance” on page 8 for details).
4. Replace the houses and/or pump, if maintenance alone isn’t sufficient.
Pump Alarm- Trouble Code E4

Limited Warranty
All warranty benefits apply to the original owner only. Warranty cannot be transferred or assigned.
1 YEAR ( FROM DATE OF PURCHASE): BaseAire warrants the dehumidifier will operate free of defects in
workmanship and materials. At its discretion, BaseAire will repair or replace any malfunctioning components, free
of charge (excluding transportation costs)
3 YEARS (FROM DATE OF PURCHASE): BaseAire warrants the refrigeration circuit (compressor, condenser and
evaporator) will operate free of defects in material or workmanship. At its discretion, BaseAire will replace
defective parts, including factory labor or refrigerant. This does not include transportation.
5 YEARS (FROM DATE OF PURCHASE): BaseAire warrants the compressor, condenser, and evaporator will
operate free of any defects in material or workmanship. At its discretion, BaseAire will repair or replace the
defective parts. This does not include labor, transportation, or refrigerant.
CUSTOMER RESPONSIBILITIES: In order to take advantage of the warranty service, the customer must do the
following:
1. Customer must provide normal care and maintenance (including, but not limited to cleaning filters, coils and
pumps)
2. Removal and re-installation of unit is the sole responsibility of owner.
3. If customer cannot return unit to certified repair center, all costs associated with freight shipment are borne by
the customer. In addition, all duties related to freight shipments, including but not limited to palletizing, wrapping,
labeling and pickup are associated with customer.
4. If shipped, customer is responsible for all risk of loss or damage.
BaseAire Warranty Steps:
1. Once receive the goods, customers must log in www.baseaire.com to fill out the warranty Registration form and
submit to BaseAire company. We will receive your purchasing and installation information and save it.
If no warranty registration is sent to us, warranty period will begin the day the shipment left the warehouse.
Please be sure to record serial # and date of installation. You will need this information to receive the RA number.
2. If warranty service is necessary, customers must contact BaseAire Tech Support by [e-mail] or
local technical service phone to receive a Return Authorization (RA number). Once an RA has been issued,
customers should bring the unit to a certified repair center. BaseAire will arrange the shipping to bring the unit
back to the BaseAire warehouse (at the expense of the customers) if customers are not available.
3. After the unit has been received by BaseAire (whether at a repair center or the warehouse), BaseAire will have
an initial inspection If it is determined to be invalid warranty claim (see exclusions below), customers have to pay
for all associated repair costs and shipping costs for units repair.
4. Customers can pick up the unit after repair at their own expense for shipping. Units will have a rigorous testing
before sending it back to customers.
5. If the unit can no longer be fixed, and it is in the warranty period and determined to be valid claim, we will ship
the customer a new unit within the same year warranty from the date of replacement.
6. After parts are repaired or replaced by BaseAire, the original warranty period continues to applies until meet its
deadline. No extensions to the original warranty period.
12

Limited Warranty Exclusions
EXCLUSIONS:
DAMAGE DUE TO THE FOLLOWING IS NOT COVERED UNDER WARRANTY
1. ACTS OF NATURE- INCLUDING BUT NOT LIMITED TO:
●FLOODING
●FIRE
●WATER DAMAGE
●HURRICANE STORM DAMAGE
2. IMPROPER USAGE-INCLUDING BUT NOT LIMITED TO:
●POOL/SPA/TUB APPLICATIONS
●MISUSE, ABUSE OR TAMPERING WHETHER INTENTIONAL OR ACCIDENTAL
●IMPROPER INSTALLATION OR DESIGN
●MPROPER VOLTAGE
●LACK OF NORMAL CARE
●FAILURE TO FOLLOW INSTRUCTIONS
3. CORROSION
4. FREEZING
5. ANY ADDITIONAL COSTS DUE TO CHANGES IN LAWS OR BUILDING CODES
6. FREIGHT CHARGES
7 ANY COSTS DUE TO LOST PROFIT OR DELAY
8. DAMAGE TO PROPERTY
9. CAUSE BEYOND CONTROL
10. CONSUMABLE PARTS INCLUDING BUT NOT LIMITED TO:
●FILTERS
●BATTERIES
●POWER CORDS
●VALVES
●SWITCHES
●RUBBER PARTS
11. DIRECT, INDIRECT, COLLATERAL OR INCONSEQUENTIAL DAMAGES OF ANY KIND
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED IN LAW OR IN FACT, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR PARTICULAR PURPOSE. BaseAire's total liability, regardless of nature of claim shall not
exceed original purchase exceed original purchase price of the product, if a product or component is replaced
while under warranty, the applicable warranty period shall not be extended beyond the original warranty time
period.
The foregoing shall constitute the total liability of seller in the case of defective performance of all or any of the
equipment or services provided to buyer. Buyer agrees to accept and hereby accepts the foregoing as the sole and
exclusive remedy for any breach or alleged breach of warranty by seller.
Any dishonesty or fraud in connection with BaseAire warranty thoroughly voids all warranty policies. BaseAire
expressly reserves the right to pursue legal action in the event of dishonesty, fraud, or attempted fraud.
13

Warranty/Registrate by scanning
