OPERATOR MANUAL
Basil®5700LSR
Cage and Rack Washer
(2009-12-10) P920512-768

WARNING — COPYRIGHT PROHIBITED
This manual is protected by Federal Copyright Law, which provides for damages of up to USD $20000,
as well as criminal fines and imprisonment, for unauthorized copying.

i
Introduction Operator Manual 920512-768
This manual contains important information on the proper use of this
equipment. Refer to SECTION 6, ROUTINE MAINTENANCE,for instruc-
tions in routine care of this washer. All personnel and department
heads are urged to carefully review and become familiar with the
Safety Precautions and instructions contained herein. These
instructions are important to protect the health and safety of person-
nel operating this Basil® 5700LSR Cage and Rack Washer and
should be retained in a conveniently accessible area for quick refer-
ence. This equipment is specifically designed only for the uses out-
lined in this manual.
Complete instructions for uncrating and connecting utilities, as well
as equipment drawings, have been provided. If they are missing,
contact STERIS for replacement copies, providing the serial and
model numbers of the unit.
Regarding utilization of VHP module, refer to the EQUIPMENT MANUAL
SUPPLEMENT (P129390-699 for the VHPM100-ABX BIODECONTAMINA-
TION SYSTEM or P129390-700 for the VHP1000-ARD BIODECONTAMINA-
TION UNIT) for further instructions.
Advisory IMPORTANT: A listing of the Safety Precautions to be observed
when operating this washer can be found in SECTION 1. Do not oper-
ate the equipment until you have become familiar with this informa-
tion.
STERIS does not intend, recommend or represent in any way that
this Basil 5700LSR Cage and Rack Washer be used for the steril-
ization of any animal care or other devices which have been contam-
inated with pathogenic microorganisms.
Any alteration of this equipment not authorized or performed by
STERIS which could affect its operation or safety features will void
the warranty, could adversely affect sanitization efficacy, could vio-
late national, state and local regulations and could jeopardize your
insurance coverage.
Articles processed in the Basil 5700LSR Cage and Rack Washer
must tolerate temperatures and chemicals specified in this manual.
Always follow item manufacturer recommendations for cleaning
instructions.
To help ensure operators are adequately trained in the safe use of
the equipment, STERIS recommends:
• all personnel who operate or maintain the equipment are trained
in its operation and in its safe use;
• personnel working with toxic chemicals and vapors (if
applicable) have comprehensive instructions in the washer
process, relevant health hazards and methods to detect the
escape of toxic materials;
©2009, STERIS Corporation. All rights reserved. Printed in Canada.
A WORD FROM STERIS CORPORATION

ii
920512-768 Operator Manual Introduction
• there is regular training of all personnel involved in the operation
and maintenance of the equipment; attendance records are
maintained; and that evidence of understanding is
demonstrated.
Indications For Use The Basil 5700LSR Cage and Rack Washer is intended for use in
the sanitization of soiled, reusable animal care devices (such as
cages, racks, debris pans, feeder bottles) and other miscellaneous
items by providing thorough washing and optimal drying.
This equipment is specifically designed to only process goods as
outlined in this manual. If there is any doubt about a specific material
or product, contact the manufacturer of the product for the recom-
mended cleaning technique.
Safety hazards may occur if unit is used for other purposes than
stated above.
Service Information A thorough preventive maintenance program is essential to help
ensure safe and proper equipment operation. Customers are
encouraged to contact STERIS concerning extended service mainte-
nance agreements to give the washer planned maintenance and
help ensure equipment performance according to factory specifica-
tions.
A global network of skilled service specialists can provide periodic
inspections and adjustments to help ensure low-cost peak perfor-
mance. STERIS can provide information regarding the annual main-
tenance program.
STERIS carries a complete line of accessories for use in this equip-
ment. Please contact STERIS for details.

iii
Introduction Operator Manual 920512-768
Certification This Basil 5700LSR Cage and Rack Washer complies with the fol-
lowing standards:
•Governing Directive for the Affixing of the CE Mark:
Machinery Directive (98/37/EC).
•Underwriters Laboratories, Inc. (UL)
UL 61010-1, Second Ed.
•Canadian Standards Association (CSA)
CAN/CSA C22.2 No. 61010-1, Second Ed.
•Conformity to Other Applicable Directives:
Electromagnetic Compatibility Directive (2004/108/EC) and
amendments (91/368/EEC, 93, 44, EEC);
Low Voltage Directive 2006/95/EC.
•Standards applied to demonstrate conformity to the
directives:
EN/IEC 61010-1, EN/IEC 61326-1.

iv
920512-768 Operator Manual Introduction
Manufactured by:
Corporation STERIS Canada
490, boulevard Armand-Paris
Québec (Québec)
G1C 8A3 CANADA
The base language of this document is
ENGLISH. Any translation must be made
from the base language document.
STERIS Limited
STERIS House
Jays Close
Viables
Basingstoke
Hampshire
RG22 4AX
United Kingdom
Sales and Service:
STERIS Corporation
5960 Heisley Road
Mentor, Ohio 44060
440-354-2600 • 800-444-9009
www.steris.com

v
920512-768 Operator Manual Table of Contents
TABLE OF CONTENTS
Section
Number Description Page
A WORD FROM STERIS CORPORATION ................................................................ I
Advisory ........................................................................................................................................................... i
Indications For Use ..........................................................................................................................................ii
Service Information ..........................................................................................................................................ii
Certification .....................................................................................................................................................iii
1 SAFETY PRECAUTIONS .....................................................................................1-1
2 INSTALLATION VERIFICATION ..........................................................................2-1
2.1 General .................................................................................................................................................. 2-1
2.2 Technical Specifications ........................................................................................................................ 2-1
2.2.1 Voltage, Amperage and Power Consumption ................................................................................ 2-1
2.2.2 Permissible Environmental Conditions ........................................................................................... 2-2
2.2.3 Noise Level ..................................................................................................................................... 2-2
2.2.4 Seismic Anchorage System ........................................................................................................... 2-2
2.3 Installation Checklist .............................................................................................................................. 2-2
2.4 Chemical Additives Specifications ........................................................................................................ 2-5
3 COMPONENT IDENTIFICATION ..........................................................................3-1
3.1 Component Identification ...................................................................................................................... 3-1
3.2 Operator Terminal .................................................................................................................................. 3-2
3.2.1 Login Passwords ............................................................................................................................ 3-2
3.2.2 Cycle Mode .................................................................................................................................... 3-2
3.2.3 Supervisor Mode ............................................................................................................................ 3-2
3.2.4 Service Mode ................................................................................................................................. 3-3
3.2.5 Operator Terminal Touch Screen ................................................................................................... 3-3
3.2.6 Audible Signal ................................................................................................................................ 3-4
3.3 Printer .................................................................................................................................................... 3-5
3.4 Typical Printouts .................................................................................................................................... 3-6
3.5 Sliding Doors ......................................................................................................................................... 3-7
3.6 Emergency Safety Features .................................................................................................................. 3-7
3.6.1 LOCK/UNLOCK/INIT Key Switch ................................................................................................... 3-7
3.6.2 EMERGENCY STOP Cables ........................................................................................................... 3-8
3.6.3 EMERGENCY STOP Pushbutton(s) ................................................................................................ 3-8
3.6.4 Safety Latches ................................................................................................................................ 3-8
3.6.5 Audible Alarm Signal ...................................................................................................................... 3-8
3.6.6 Safety Delay ................................................................................................................................... 3-8

vi
Table of Contents Operator Manual 920512-768
Section
Number Description Page
4 OPERATING INSTRUCTIONS .............................................................................4-1
4.1 Before Operating Washer ...................................................................................................................... 4-1
4.2 Door Operation ...................................................................................................................................... 4-2
4.3 How to Load Accessories ...................................................................................................................... 4-3
4.3.1 Uses and Capacities .......................................................................................................................... 4-3
4.3.2 How to Load Central Spray Header Manifold With Rodent Cage Modular Racks ............................. 4-5
4.3.3 How to Load Bottle Washing Cart ...................................................................................................... 4-7
4.4 Typical Cycle Operation ........................................................................................................................ 4-8
4.5 VHP Cycle (Option) ............................................................................................................................. 4-11
4.6 Review Cycle Values ........................................................................................................................... 4-13
4.7 Pause a Cycle ...................................................................................................................................... 4-13
4.8 Abort a Cycle ....................................................................................................................................... 4-14
4.9 Responding to an Alarm ...................................................................................................................... 4-15
4.10 Shutdown ........................................................................................................................................... 4-16
4.11 Purge Travelers ................................................................................................................................. 4-16
4.12 Drain Cycle ........................................................................................................................................ 4-16
4.13 Power Failure ..................................................................................................................................... 4-17
4.13.1 Opening Doors During a Power Failure ..................................................................................... 4-17
4.13.2 Resuming Cycle After a Power Failure ....................................................................................... 4-17
4.14 Opening Doors After EMERGENCY Features Were Activated .......................................................... 4-18
4.15 Resuming Washer Operation After EMERGENCY Features Were Activated .................................... 4-18
5 CYCLE AND CONTROL VALUE PROGRAMMING ................................................5-1
5.1 General .................................................................................................................................................. 5-1
5.2 Supervisor Mode ................................................................................................................................... 5-4
5.2.1 Accessing Supervisor Mode .......................................................................................................... 5-4
5.2.2 Supervisor Mode Menus ................................................................................................................ 5-5
5.2.3 Modify Cycles ................................................................................................................................. 5-5
5.2.4 Cycle Modification .......................................................................................................................... 5-6
5.2.5 Modifying Cycle Parameters .......................................................................................................... 5-8
6 ROUTINE MAINTENANCE ...................................................................................6-1
6.1 Preventive Maintenance Schedule ........................................................................................................ 6-2
6.2 Cleaning Procedures ............................................................................................................................. 6-5
6.2.1 Daily Cleaning ................................................................................................................................ 6-5
6.2.2 Weekly Cleaning ............................................................................................................................ 6-6
TABLE OF CONTENTS (Cont’d)
Continued...

vii
920512-768 Operator Manual Table of Contents
6 ROUTINE MAINTENANCE (Cont’d)
6.2.3 Horizontal Spray Headers and Spray Jets .....................................................................................6-7
6.2.4 Central Spray Header Manifold (Accessory) .................................................................................6-8
6.2.5 Rotary Spray Arms on Bottle Washing Cart (Accessory) .............................................................6-10
6.2.6 Supply-Line Strainers ...................................................................................................................6-10
6.2.7 Vertical Self-Cleaning Filter ..........................................................................................................6-11
6.3 DESCALER Cycle ................................................................................................................................ 6-13
6.4 Chemical Container Replacement ....................................................................................................... 6-14
6.5 Injection Pumps ...................................................................................................................................6-15
6.6 Change Printer Paper ..........................................................................................................................6-16
6.7 Changing Printer Ribbon Cartridge .....................................................................................................6-18
7 TROUBLESHOOTING ..........................................................................................7-1
8 REPLACEMENT PARTS AND PRODUCTS ...........................................................8-1
TABLE OF CONTENTS (Cont’d)
Section
Number Description Page

ix
920512-768 Operator Manual Table of Contents
TABLE OF CONTENTS
Section
Number Description Page
3 COMPONENT IDENTIFICATION
3-1 Basil 5700 LSR Cage and Rack Washer Components .................................................................3-1
3-2 Operator Terminal and Printer .......................................................................................................3-5
3-3 Sample Printout .............................................................................................................................3-6
3-4 Sample Alarm Printout ...................................................................................................................3-6
3-5 Emergency Safety Features ..........................................................................................................3-9
4 OPERATING INSTRUCTIONS
4-1 Pan Cart ........................................................................................................................................4-4
4-2 Universal Cage and Pan Wash Cart .............................................................................................4-4
4-3 Central Spray Header Manifold .....................................................................................................4-6
4-4 Rodent Cage Modular Rack ..........................................................................................................4-6
4-5 Bottle Washing Cart ......................................................................................................................4-7
4-6 Cycle Operation Flowchart (Typical) ...........................................................................................4-10
4-7 Resume or Abort a Cycle ............................................................................................................4-14
5 CYCLE AND CONTROL VALUE PROGRAMMING
5-1 Supervisor Mode Flowchart ..........................................................................................................5-5
5-2 Modifying a Cycle Flowchart .........................................................................................................5-7
6 ROUTINE MAINTENANCE
6-1 Horizontal Spray Headers and Spray Jets ....................................................................................6-7
6-2 Central Spray Header Manifold (Accessory) ................................................................................6-9
6-3 Bottle Washing Cart (Accessory) ..................................................................................................6-9
6-4 Vertical Self-Cleaning Filter .........................................................................................................6-12
6-5 Chemical Container .....................................................................................................................6-14
6-6 Open Printer Cover .....................................................................................................................6-17
6-7 Open Paper Cover Compartment ...............................................................................................6-17
6-8 Cut Paper Edge ...........................................................................................................................6-17
6-9 Install Paper Roll .........................................................................................................................6-17
6-10 Changing Printer Ribbon Cartridge ............................................................................................6-18
LIST OF ILLUSTRATIONS
Figure

xi
920512-768 Operator Manual Table of Contents
TABLE OF CONTENTS
Section
Number Description Page
1 SAFETY PRECAUTIONS
Table 1-1 Definition of Symbols on Unit .........................................................................................................1-4
Table 1-2 Definition of Symbols on Identification Nameplate ........................................................................1-5
5 CYCLE AND CONTROL VALUE PROGRAMMING
Table 5-1 Cycle Description Chart - Basil 5700 LSR Cage and Rack Washer .............................................5-2
6 ROUTINE MAINTENANCE
Table 6-1 Preventive Maintenance Guide ......................................................................................................6-2
7 TROUBLESHOOTING
Table 7-1 Troubleshooting Chart – No Alarm or Printout, Control Panel Problems........................................7-2
Table 7-2 Troubleshooting Chart – No Alarm or Printout, Electrical Problems ..............................................7-3
Table 7-3 Troubleshooting Chart – No Alarm or Printout, Mechanical Problems...........................................7-5
Table 7-4 Troubleshooting Chart – Alarm and/or Printout ..............................................................................7-9
8 REPLACEMENT PARTS AND PRODUCTS
Table 8-1 Replacement Parts.........................................................................................................................8-1
LIST OF TABLES
Table

1-1
Safety Precautions Operator Manual 920512-768
The following Safety Precautions must be observed when operating and servicing this Basil®5700LSR Cage and
Rack Washer. WARNING indicates potential for personal injury and CAUTION indicates potential for damage to
equipment. For emphasis, certain Safety Precautions are repeated throughout the manual. It is important to
review ALL Safety Precautions before operating and servicing the unit.
WARNING – PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD:
WARNING – PERSONAL INJURY HAZARD:
Before servicing or cleaning unit, always turn LOCK/UNLOCK/INIT key selector to LOCK position to
prevent cycle operation. Keep the key on yourself.
Ensure wash chamber is completely dry before processing a VHP cycle.
Only STERIS or STERIS-trained service technicians should make repairs and adjustments to this
equipment. Maintenance done by inexperienced, unqualified personnel or installation of unauthorized
parts could cause personal injury, invalidate warranty or result in costly damage. Contact STERIS
regarding service options.
Regularly scheduled preventive maintenance, in addition to faithful performance of minor maintenance
described in this manual, is required for safe and reliable operation of this equipment. Contact STERIS
to schedule preventive maintenance.
Always wear appropriate personal protective equipment (PPE), including gloves and faceshield, when
cleaning or removing debris from bottom of the wash chamber and from sump filters.
Always verify flap door sill is down before entering wash chamber.
If cycle has not been completed, contaminated debris or water may remain in the bottom of wash cham-
ber.
Keep hands/fingers away from closing doors to prevent crushing.
Never perform cleaning of wash chamber until full cycle has been completed. If cycle has not been
completed, contaminated debris or water may remain in the bottom of wash chamber.
To open door from inside wash chamber, pull emergency stop cable; then, pull emergency door handle.
Door may easily be open.
To prevent tipping, place biggest and heaviest items on the lower levels of accessory cart.
Cages and items in washing cart may move during processing and be filled with residual hot water or
protrude from cart at the end of the cycle. Always wear appropriate Personal Protective Equipment
(PPE) and carefully remove cages and items from cart.
1
SAFETY PRECAUTIONS

1-2
920512-768 Operator Manual Safety Precautions
WARNING – ELECTRIC SHOCK HAZARD:
WARNING – BURN HAZARD:
WARNING – CHEMICAL BURN HAZARD:
WARNING – SLIPPING HAZARD:
Always set building electrical-supply disconnect switch and console master power switch to OFF before
performing any preventive maintenance functions within the compartments. Electrical shock can cause
serious injury.
Disconnect all utilities to washer before servicing. Do not service washer unless all utilities have been
properly locked out. Always follow local occupational health and safety regulations, as well as electric
and plumbing codes.
After pressing STOP touch pad, wait until water flow stops before opening doors. Hot water/steam may
be sprayed through door opening if doors are opened too soon.
Before performing any service on unit, wait until chamber and piping cool to room temperature.
Except for emergency, do not open door when cycle is in progress. In an emergency, stop cycle by
pressing EMERGENCY STOP pushbutton and wait for safety delay to elapse before opening doors.
Hot water and steam could be sprayed through door opening if doors are opened too soon.
Inner surfaces of washer are very hot after cycle completion. Operator should wear appropriate per-
sonal protective equipment (PPE), including gloves and faceshield and avoid all contact with inner walls
when entering chamber to unload washer.
Pipes may be extremely hot.
Always use non-foaming chemical for effective cleaning and proper pump and water level control opera-
tion. Follow manufacturer's recommendations for amount of chemical to be used.
Washer chemicals are caustic and can cause adverse effects to exposed tissues. Do not get in eyes, on
skin or attempt to swallow. Read and follow precautions and instructions on chemical label and in Mate-
rial Safety Data Sheet (MSDS) prior to handling chemical, refilling chemical container or servicing
chemical injection pump or lines. Wear appropriate Personal Protective Equipment (PPE) whenever
handling chemical or servicing chemical injection pump and lines.
Wear appropriate personal protective equipment (PPE), including gloves and faceshield, when using a
descaling product. Avoid contact with eyes or skin. If spilled or splashed, flush with water for 15 min-
utes. If swallowed, DO NOT induce vomiting. Administer an alkali with plenty of water. Seek medical
attention immediately.
To prevent slips, keep floor dry. Promptly clean up any spills or condensation. If spilled liquids are deter-
gents or other chemicals, follow safety precautions and handling procedures set forth on detergent or
chemical label and/or Material Safety Data Sheet (MSDS).

1-3
Safety Precautions Operator Manual 920512-768
CAUTION – POSSIBLE EQUIPMENT DAMAGE:
Always use a silicone lubricant to lubricate squeeze tubes. Petroleum-based lubricants, such as
Vaseline®1 or grease, will cause squeeze tubes to melt.
Avoid product damage. Always select a cycle appropriate for the items being processed.
Before operating the unit, always position Bottle Washing Cart or Central Header Manifold over the
manifolded coupling system. If manifold is not positioned correctly, damage may result and unit will be
unable to effectively wash load.
Do not process load using Central Header Manifold or Bottle Washing Cart when Automatic Floor Tilting
is activated. If Automatic Floor Tilting is used, manifolded water inlet and washer will be damaged.
Failure to connect wires to proper terminals may result in damage to, or malfunction of unit when power
is applied.
Items processed in the washer must tolerate temperatures and chemicals specified in this manual.
Always follow item manufacturer's recommendations for cleaning instructions.
Remove all cellulose type bedding from cages and pans before processing. Cellulose bedding may clog
filters and piping.
Remove any items, accessories or racks from wash chamber before processing a drying treatment prior
to a VHP cycle. Items will be damaged by high temperature drying.
Repeated fuse burnouts indicate a short circuit or overload. Trouble should be located and corrected by
a fully trained technician.
Use nonabrasive cleaners when cleaning unit. Follow directions on containers and rub in a back-and-
forth motion, in same direction as surface grain. Abrasive cleaners will damage stainless steel. Clean-
ers rubbed in a circular motion or applied with a wire brush or steel wool on door and chamber assem-
blies will damage stainless steel. Do not use these cleaners on painted surfaces.
When choosing a chemical, select one with a low chloride content. Chloride is harmful to stainless steel
and will deteriorate washer.
1 Vaseline is a trademark of Cheseborough Pond’s Incorporated.

1-4
920512-768 Operator Manual Safety Precautions
Tables 1-1 and 1-2 contain symbols which may be on your Basil 5700LSR Cage and Rack Washer components:
Table 1-1. Definition of Symbols on Unit
Symbol Definition
Protective Earth (Ground).
Transfer of Heat, Hot Surface.
Warning! Risk of Electrical Shock.
Attention, Consult Manual For Further Instructions.
Warning! Do Not Step Here.
Fork Lift: Place Forks of the Fork Lift Here.
Rotation: Direction of Rotation Device.
Factory Adjustment: Do Not Adjust.
Unlock and Allow Cycle Operation.
Lock and Prevent Cycle Operation.
Reset.

1-5
Safety Precautions Operator Manual 920512-768
Table 1-2. Definition of Symbols on Identification Nameplate
Symbol Definition
MODEL Model Number of The Unit.
S/N Serial Number of The Unit.
YEAR Year of Manufacture of The Unit.
kVA Kilovolt-Ampere.
V_~ Volt, Number of Phase (3 or 1[blank]), Alternate Current.
AAmperage.
Hz Hertz – Frequency of The Unit.
WIRE Number of Wires In The Electrical Cable (Ground Not Included).

2-1
Installation Verification Operator Manual 920512-768
2.1 General Equipment drawing (920-512-757) showing all utility and space
requirements was sent after the order for the Basil®5700LSR Cage
and Rack Washer was received. The clearance space specified on
equipment drawing is necessary for proper installation, operation
and maintenance. Uncrating/Installation Instructions (P920512-767)
were provided with the washer. If these documents are missing or
misplaced, contact STERIS giving the serial, equipment and model
numbers of the unit. Replacement copies will be sent to you
promptly.
2.2 Technical
Specifications
These specifications are intended to describe the technical informa-
tion given on the identification nameplate of the washer and to state
other relevant information. Refer to equipment drawing or identifica-
tion nameplate located on frame of mechanical core, below main
electrical box, for proper voltage and amperage.
2.2.1 Voltage, Amperage and
Power Consumption
This unit operates either on:
• 208 V~, three-phase, 60 Hz;
• 380/400/415 V~, three-phase, 50 Hz;
• 480 V~, three-phase, 60 Hz.
A protective ground conductor is required (Class 1 Equipment).
Installation Category II (Overvoltage Category).
Refer to SECTION 3.9, ELECTRICAL CONNECTIONS, of Uncrating/Instal-
lation Instructions (P920512-767) for proper connection.
Maximum currents and power consumptions:
Amp kVA
208 V 37.0 13.3
380/400/415 V 18 15
480 V 18 15
IMPORTANT: A listing of the Safety Precautions to be observed when operating this Cage and Rack
Washer can be found in SECTION 1. Do not operate equipment until you have become familiar with this
information.
INSTALLATION VERIFICATION 2

2-2
920512-768 Operator Manual Installation Verification
2.2.2 Permissible
Environmental Conditions
This washer is designed to give optimal results under the following
conditions:
Indoor use only;
Altitude of operation up to: 6,267 ft (2,000 m);
Maximum relative humidity is 80% for temperatures up to: 88ºF
(31ºC) decreasing linearly to 50% relative humidity at 104ºF
(40ºC);
Pollution degree 2.
2.2.3 Noise Level Equivalent Sound Pressure Level at work station, measured 3 ft (1 m)
away from equipment and at 5 ft (1.6 m) from ground: 76.6 dB (A).
2.2.4 Seismic Anchorage
System
A Seismic Anchorage System is available for high risk seismic zones
(see Seismic Anchorage Report 920-512-776 for washer and 920-
512-769 for mechanical core).
2.3 Installation
Checklist
After installing the washer according to the Uncrating/Installation
Instructions (P920512-767), complete the following checklist to help
ensure complete and correct installation, or contact STERIS to
schedule a technician to test your installation and demonstrate
proper equipment operation.
❑Shutoff valves (not provided by STERIS), for maintenance pur-
poses and capable of being locked in OFF position only,
installed on steam, air and water lines and in compliance with
local occupational health and safety regulations, as well as elec-
tric and plumbing codes.
❑Disconnect switches (not provided by STERIS), for maintenance
purposes and capable of being locked in OFF position only,
installed in electrical supply lines near the unit and in compli-
ance with local occupational health and safety regulations, as
well as electric and plumbing codes. Disconnect switches must
bear the identification of the equipment to which they are con-
nected.
NOTE: If unit is installed next to other equipment, shutoff valves
and disconnect switches should be located so service can be
shut off to one piece of equipment at a time.
❑Washer is positioned as shown on equipment drawing, with
required clearance space and in relation to building supply
lines.
❑Washer is level. Remove cabinet panel and adjust leveling legs if
necessary.

2-3
Installation Verification Operator Manual 920512-768
❑Electrical supply for unit is as specified on equipment drawing.
❑Electrical connections between washer and mechanical core are
as specified in SECTION 3 of Uncrating/Installation Instructions
(P920512-767).
❑Verify electrical boxes. Ensure no foreign objects inside electri-
cal boxes. Also check for any unconnected wires.
❑Verify all electrical connections are plugged in and/or con-
nected.
❑Building hot water line supplies water to unit as specified on
equipment drawing.
❑If Drain Discharge Cool Down System with Cold Water Injec-
tion is present, building cold water line supplies water to unit as
specified on equipment drawing.
❑If Drain Discharge Cool Down System with Chilled Water and
pH Neutralizing System is present, building cold water line
supplies water to unit as specified on equipment drawing.
❑Building steam line provides steam to unit as specified on equip-
ment drawing.
❑Building condensate return line is connected to washer as spec-
ified on equipment drawing.
❑Building waste line is connected to washer as specified on
equipment drawing.
❑Piping connections between washer and mechanical core are as
specified in SECTION 3 of Uncrating/Installation Instructions
(P920512-767).
❑Building ventilation system is connected to washer as specified
on equipment drawing.
❑Building air line supplies air to unit as specified on equipment
drawing.
❑Air line connections between washer and mechanical core are
as specified in SECTION 3 of Uncrating/Installation Instructions
(P920512-767).
❑Verify all clamps and unions on washer and mechanical core.
Tighten if necessary.
❑All pneumatic connections and switches are properly installed,
adjusted and connected.
❑If Drying System option is present, drying system connections
between washer and mechanical core are as specified in SEC-
TION 3 of Uncrating/Installation Instructions (P920512-767).
❑Springs for emergency stop cables (on top of washer) are cor-
rectly installed on microswitch.
❑Switch(es) for EMERGENCY STOP pushbutton, located on con-
trol access panel on load side for single door units or on both
load and unload side, if double-door unit, are correctly installed.

2-4
920512-768 Operator Manual Installation Verification
❑Verify for any construction and/or installation debris, inside and
outside wash chamber, under floor gratings and on sump filters.
Clean or discard.
❑Verify spray headers and spray header cables. All cables are
properly tightened.
❑Verify headers travel to the top and bottom of the wash chamber
without touching top or bottom pulleys and guides. Verify proper
installation.
❑Inspect doors for alignment and smooth movement.
❑Verify all the protective paper has been removed from stainless
steel.
❑Floor underneath and surrounding unit has a noncombustible
and nonslip surface, or is covered with a metal sheet extending
to the outer edges of the unit.
❑If Ramp Accessory is present, ramp is correctly attached to
washer as specified in SECTION 3 of Uncrating/Installation
Instructions (P920512-767).
IMPORTANT: After a few weeks of operation, inspect unit for leaks.
Retighten all clamps and connections.
