1 Introduction
This Getting Started Guide considers the components that are
included in the starter kit for one ace 2 GigE camera. The components
are essential for camera operation and are designed for use with a
Basler ace 2 GigE camera only.
The Getting Started Guide informs about the scope of delivered
components and provides related precautions. The Getting Started
Guide does usually not include detailed specifications and information
about installing and using the components. This information is
available in the user documentation indicated in Chapter 4 of this
document.
2 Scope of Delivered Components
The scope of delivered components is as shown below. Some
components can also be ordered individually (see order numbers in
Table 1).
Fig. 1: Delivered Components; Not to Scale
3 Precautions
<
4 Specifications and Requirements
The Basler Product Documentation (BPD) provides Information for
using the starter kit’s components for camera installation and
operation. This documentation is available on: www.baslerweb.com.
Detailed information for the GigE Cat 6, S/FTP, 2 x RJ-45 cable and
the tripod mount adapter can be downloaded from the Basler website.
Specifications for the power-I/O cable and requirements for the power
supply to be used with the power-I/O cable, are given below.
4.1 Power-I/O Cable Specifications
The power-I/O cable includes an M8 6-pin plug on the camera end and
on the other end a coaxial power plug for the power supply (AUX
power) and an open end for I/O.
For detailed technical information, go to docs.baslerweb.com.
Component Order Number
Cable GigE Cat 6, S/FTP, 2 × RJ-45 (Data) 2000030284
Cable Power-I/O (I/O and AUX Power) N/A
Tripod Mount ace 2 - Camera Mount Adapter with
Three Screws
2200000314
This Getting Started Guide N/A
Table 1: Component Names and Related Order Numbers
NOTICE
A damaged cable can cause camera malfunction.
If the GigE data cable or power-I/O cable is damaged, the camera
may not operate as intended.
Avoid for instance the following:
Putting heavy mechanical loads on the cable
Bending to less than the minimum specified radius
Pulling a plug by pulling on the cable
If a cable or cable plug is damaged, stop camera operation and
replace the cable.
NOTICE
An incorrect component can cause camera malfunction.
Do not modify any of the supplied components.
Cable GigE Cat 6, S/FTP, 2 x RJ-45
Tripod mount ace 2
with three screws
Cable power-I/O
Getting Started Guide -
this document

AW00156301000 GigE Starter Kit ace 2 Getting Started Guide
Basler GigE Starter Kit ace 2 2
Fig. 2: Cable Overview with Dimensions [mm] and Plug Details; Not to Scale
4.2 Power Supply (AUX Power) Requirements
The power supply that you will use to supply AUX power via the
power- I/O cable, must meet the following requirements.
Pin Number Wire Color Function
1AUX power
2 White Opto-coupled I/O, Line 1
3 Blue Ground for opto-coupled I/O
4 Black GPIO I/O, Line 2
5 Gray GPIO I/O, Line 3
6 Ground for AUX power and GPIO
Table 2: Wiring Information and Pin Assignments
Category Specification
Max. Operating Voltage As required and allowed by the
camera: see BPD
Max. Rated Current 1.5 A
Operating Temperature Range 0 °C – 40 °C
Operating Relative Humidity Range;
Non Condensing
20 % – 80 %
Cable Diameter 5.0 mm
Min. Bending Radius (Outer Radius,
Static)
25 mm
Suitable for Drag Chain/Robotics
Applications
No
Connector on Camera Cable End M8 6-pin plug, male, A coding
Connector on Power Supply End
(AUX Power)
Coaxial power plug,
2.1×5.5×11 mm, female
I/O
Wires
Wires for Pin Numbers 2, 3, 4, 5 No connector, open end
Wire Diameter 0.25 mm2
Wire Insulation PP
Outer Jacket PUR, black
M8
Plug
Min. Number of Mating Cycles 100
Contact Plating Ni/Au
Insulation Material TPU
Co-
axial
Power
Plug
Inner Diameter of Shell 5.5 mm
Outer Diameter of Center Pin 2.1 mm
Table 3: Specifications for Power-I/O Cable and Plugs
3070
50
Label
3000
12
3
4
5
6
M8 6-pin male plug
Coaxial power plug
5.5
2.1
GND: shell pin
VDC: center pin

VDC: Coaxial power plug:
2.1×5.2×11 mm, female
Category Requirement
DC Output: Voltage 24 VDC
Max. Rated Power 30 W
Operating Temperature Range In accord with ranges of
camera and components.
Operating Relative Humidity Range In accord with ranges of
camera and components.
Receptacle (Interface with Power-I/O
Cable)
Compliant with coaxial power
plug, 2.1×5.5×11 mm female;
see above; center pin: VDC
Safety Must meet the SELV (Safety
Extra Low Voltage) and LPS
(Limited Power Supply)
requirements.
Protection Over current, over voltage,
short circuit
Table 4: Power Supply Requirements
