Bauhn apas-114 User manual

INSTRUCTION MANUAL
Model Number APAS-114
DJ System
With Bluetooth®Wireless Technology
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS

ii
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Congratulations on choosing to buy a BAUHN® product.
All products brought to you by BAUHN®are manufactured to the highest standards
of performance and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will
enjoy using your purchase for many years to come.
Welcome

iii
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Contents
Welcome ii
Warranty Details iv
General Safety Instructions 1
Product Overview 3
Controls and Connections 4
Getting Started 6
Instructions 8
Other Useful Information 12
Repair and Refurbished Goods or Parts Notice 15

iv
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
DJ System
with Bluetooth®Wireless Technology
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for
a period of 12 months from the date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded at
our discretion, solely at our option with no charge for parts and labour. The benefits
conferred by this warranty are in addition to all rights and remedies in respect of
the product that the consumer has under the Competition and Consumer Act 2010
and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and to compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.

1
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
General Safety Instructions
Electrical Safety and Cord Handling
• Power supply: This system can be powered three different ways: (a) by connection
to the mains power supply with the supplied power cord, (b) via the rechargeable 12V
4.5Ah in-built battery, or (c) via a DC power supply (not included). If connecting to a
DC power supply, make sure it provides a minimum of 50W.
• Voltage: Before connecting this equipment to the mains power supply, make sure
your outlet voltage corresponds to the voltage stated on the appliance rating label
(230V/50-60Hz).
• Mains power connection: When connecting this equipment to the mains power
supply, only use the cord and plug supplied. Align the plug properly and insert it fully.
Do not overload the power outlet.
• Protect from moisture: Do not expose this equipment, the power supply cord or the
plug to rain or moisture. Do not use it anywhere near water or where water splashes
or drips, such as in a wet basement or near a swimming pool. Do not touch the power
plug with wet hands.
• Damaged cord: When the power cord is damaged, it must be replaced by the
manufacturer or similarly qualified personnel in order to avoid a hazard.
• Protect the power cord: Do not let the cord hang over the edge of a table or counter,
or touch any hot surface. Do not allow anything to rest on or roll over the power cord.
Run any cords so no one steps on or trips over them. Do not run the cord near heat-
producing appliances such as radiators or stoves.
• Disconnect: Switch OFF and unplug the unit when it is not going to be used for a
while. Grasp the plug, not the cord, when disconnecting.
Read this manual thoroughly before first use and keep it in a safe place for future
reference, along with the warranty card, purchase receipt and carton. The safety
precautions enclosed herein reduce the risk of fire, electric shock and injury when
correctly adhered to. Follow all instructions and take notice of all warnings to
reduce the risk of fire or electric shock.
Important Warnings and Cautions!
• Do not open: To prevent contact with high voltage
components inside, do not attempt to open the
equipment. There are no user-serviceable parts inside.
• Do not repair: If the unit requires service, call our after
sales support line for advice. Do not attempt to repair
the unit yourself; only have it serviced by qualified
personnel.

2
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Usage Environment
• Location: When using the equipment, make sure to place it:
• In a well ventilated area, keeping a clearance of at least 20cm to the wall or other
equipment to ensure proper ventilation.
• Away from heat sources such as radiators, heat registers, stoves or other
equipment (including amplifiers) that produce heat.
• Away from areas with high temperatures, high humidity or direct sunlight.
• Away from excess dirt and dust.
• Away from open windows and any place where water or metal objects may get into
the equipment and damage it.
• Power connection: When using a power socket or appliance coupler as a power ON/
OFF device, please ensure that the power ON/OFF device can be easily accessed and
operated.
Usage Conditions and Restrictions
• Instructions: Follow the instructions in this manual when installing and adjusting this
equipment. Only adjust those controls that are covered in this instruction manual, as
improper adjustment of other controls may result in damage. If this happens, unplug
the equipment and have it serviced by appropriately qualified personnel.
• Usage restriction: The equipment is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children: Young children should be supervised to ensure they do not play with the
equipment. Close supervision is always necessary when an appliance is used by or
near children.
• Ventilation: Openings on the cabinet are provided for ventilation and to protect the
unit from overheating. To ensure proper operation, do not cover the openings with
things such as newspapers, tablecloths, curtains etc.
• Protect the equipment: Prevent metal objects falling onto or into the equipment. Do
not place heavy objects on top of the equipment or step on it. Do not place objects
filled with water (such as vases), or naked flame sources (such as candles), on top of
the equipment. If liquid or metal parts enter the system, unplug the power cable
immediately and call our after sales support centre to arrange a service before
further use.
• Cleaning: Unplug the equipment from the power outlet before cleaning. Clean the
equipment only with a dry, clean cloth. Do not use liquid or aerosol cleaners or volatile
solvents.
• Liability: We accept no liability for any damage or lost data caused by non-
compliance with these instructions or mishandling of the equipment.
General Safety Instructions (Cont.)

3
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Product Overview
Front View
Top View: Control Panel
See pages 4-5 for a description of all controls and connections.
A Telescopic Luggage
Handle
B Carry Handle
C Speaker Unit
D Sturdy Feet (2)
E Wheels (2)
A
C
B
DE

4
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Controls and Connections
Control Panel
1 5 Band Equaliser: Adjust the music play back to your preference.
2 Repeat Button: Press to repeat the current track, press again to repeat all.
3 USB/SD Indicator Light: Indicates USB/SD card mode.
4 SD Card Slot: Insert an SD card.
5 USB Port: Insert a USB device.
6 Bluetooth Indicator Light: Indicates Bluetooth mode.
7 Pause/Play Button: Press to play music track, press again to pause track.
8 Next Track Button: Press to play the next track / channel on FM radio mode.
9 Source Button: Select mode from AUX (default) / USB/ SD / FM radio or
Bluetooth mode.
10 Previous Track: Press to play the previous track / channel on FM radio mode.
11 Guitar Input Socket: Insert the guitar connector.
12 Guitar Volume Control: Adjust the guitar volume.
13 Microphone Echo Control: Adjust the microphone echo.
14 Microphone Volume Control: Adjust the microphone volume.
15 Karaoke Mode Button: While the speaker system is playing music:
Press the button (down) for the karaoke function, with music.
Release the button (up) for the microphone (voice only), without music.
16 Microphone Input Socket: Connect a wired microphone.
17 Power Indicator: Indicates that the power is ON.
18 Master Volume Control: Adjust the volume.
19 Battery Charging Indication Light: Indicates that the battery is charging.
1 2 3 4 5
7
11 12 13 14 15 16 1817 19
8
9
10
6

5
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Back Panel
Controls and Connections (Cont.)
20 3.5mm Signal Input Socket: Connect a computer, TV or portable music device.
21 RCA Input: Connect a TV, DVD or audio playback equipment.
22 RCA Output: Connect additional speakers if required.
23 DC input/Battery Charge/AC Input Switch: Power source switch.
24 AC Power Switch: ON/OFF switch for AC power.
25 DC Power Supply Input: Connect to the DC power supply source.
26 AC Power Input: Connect the power cable.
25
26
20
21
22
23
24

6
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Getting Started
Power Source
This system can be powered in three different ways:
(a) By connection to the mains power supply with the supplied power cord.
(b) Via the rechargeable 12V 4.5Ah built-in battery.
(c) Via an external DC power supply (not included).
AC Mode (mains power supply)
• Connect the power cable to the AC power input, then insert the plug into an
appropriate wall outlet.
• Set the AC POWER SWITCH to ON.
• Set the POWER SOURCE to AC mode. The system is now in operating mode and
will be powered by ~230V/50-60Hz.
DC Mode
• If the equipment is connected to the mains power supply, disconnect the power
cable.
• Set the AC POWER SWITCH to OFF.
• Set the POWER SOURCE to DC INPUT.
• External DC power supply
To power the unit via an external DC power supply, connect the external power
supply's positive pole to the red terminal and the negative pole to the black terminal.
The system will now be powered by the external DC power supply.
NOTE: The external DC power supply must be DC 12V-15V with a minimum output
power of 50W.
• Internal 12V 4.5Ah battery power supply
If no external power supply is connected, the system will automatically be powered
by the built-in 12V 4.5Ah battery when the power source is set to DC INPUT.
AC Power Switch
• Set to ON to use the equipment in AC mode, or to charge the built-in battery.
• Set to OFF to use the equipment in DC mode.
• To switch the system OFF, set the POWER SOURCE to AC mode and the AC POWER
SWITCH to OFF.

7
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Charging the Battery
This DJ System is equipped with a built-in 12V 4.5Ah rechargeable battery. Before the
first three times that you are going to use the system, this battery should be charged for
a minimum of 12 hours. To charge, proceed as follows:
• Set the AC POWER SWITCH to ON.
• Set the POWER SOURCE to BATTERY CHARGE. The built-in battery will now be
charged from the mains power supply. A full charge takes about 12-14 hours at this
stage.
• When the battery is fully charged, set the AC POWER SWITCH to OFF and disconnect
the power supply.
Important Notes Concerning the Battery
• When the battery is low or has run out, it is important to extend the recharging
time to 24 hours. Recharging it for a shorter time may reduce the battery life, damage
the battery and cause the battery to never be fully charged, which will result in a
shorter time of operation.
• Do not open the cover to the battery housing. Only professional technicians should
open this system if the battery needs to be replaced. In such a case, contact our
after sales support centre for advice. Only a battery with the same specifications may
be used to power this equipment. An unsuitable battery may damage the system or
cause malfunction.
• Do not use this battery in other equipment.
• If you are not going to use this system for a long period of time, please recharge the
battery at least once every 3 months to avoid letting your battery sit dormant for a
long period of time and risk battery failure.
Getting Started (Cont.)

8
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Instructions
Streaming Audio via Bluetooth®Wireless Technology
Pairing With a New Bluetooth Enabled Device
• Press the Source Button repeatedly until Bluetooth mode is selected. A beep will
sound and the Bluetooth indicator light will start flashing fast. The DJ System is now
ready for pairing.
• Turn on the Bluetooth function of your device and scan available Bluetooth enabled
devices nearby.
• Select “APAS-114” from the device list to pair. Enter ‘0000’ if your Bluetooth enabled
device prompts you for a passcode.
• If pairing is successful, the Bluetooth indication light will stop flashing. If you play a
song, the Bluetooth indication light will flash slowly.
• If you cannot pair the DJ System with your Bluetooth enabled device, turn both the DJ
System and your Bluetooth enabled device OFF and ON and then try again.
NOTE: If your Bluetooth enabled device does not support A2DP, you might not be able
to pair with the DJ system.
Connecting to Bluetooth Devices Stored in Memory
• Turn on the DJ System and press the SOURCE button to select Bluetooth mode. The
DJ System will start searching for the previously paired devices. If an available device
is found, the system will connect to the Bluetooth device automatically.
Playing Audio Via Bluetooth Wireless Technology
After successful connection you can play music from your Bluetooth enabled device
wirelessly on the DJ System.
• Press the button to play or pause music.
• Press the or button to skip to the previous or next track.
NOTES:
• Refer to the manual of your Bluetooth enabled device for more information about the
Bluetooth function on the device.
• If your Bluetooth enabled device does not support A2DP profile, it can be paired and
connected but will not play audio through the DJ System.
• When you pair and connect your computer to the DJ System, you may need to
change the sound setting on your computer.

9
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Audio Input Operation
This unit is equipped with 2 input sockets for audio playback from external devices: a
3.5mm input socket and a stereo RCA socket.
• If your audio device has a 3.5mm audio output socket (line-out or headphones), use
the included 3.5mm audio cable to connect the DJ System to your device.
• If your audio device has RCA output sockets, use RCA cables to connect the DJ
System to your device.
• Turn on both the DJ System and the external audio device.
• Adjust the volume according to the source you are using.
USB and SD Card Operation
This unit has a USB port and SD Card slot on the control panel at the top of the DJ
System. The ports accept standard USB drives and SD cards for playback of MP3 and
WMA files stored on them.
• Press the SOURCE button repeatedly until USB or SD Card mode is selected.
• Insert your USB device into the USB port (or the SD card into the card slot) and the
unit will start playing automatically.
• Press the or button to select the previous or next track.
• Press the button to temporarily pause the track.
• Press the REPEAT button to repeat the current track, press it again to repeat all
tracks.
NOTE: When you insert a USB device or SD card, the DJ System will automatically
select the appropriate mode and start playing. When you have both a USB
device and an SD card inserted, you will have to press the SOURCE button
repeatedly until the appropriate source is selected.
FM radio
In order to use FM radio press SOURCE repeatedly until you hear FM radio. Press the
button to activate auto search. Your Portable Entertainment System will search
for radio stations and save them on available channels. Use the or button to
navigate through saved channels.
Instructions (Cont.)

10
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Wireless Microphone
This DJ System comes with a wireless microphone for announcements or karaoke
entertainment. Before first use, you will have to install two AA batteries (not included).
Battery Installation
• Open the cover to the battery compartment at the back of microphone (Fig. 1).
• Insert 2 AA size batteries, making sure to match the polarity markings (+ / -) on the
batteries with those inside the compartment.
• Close the battery compartment.
Battery Precautions
• CAUTION: Danger of explosion! Ensure to insert batteries according to the polarity
markings inside the battery compartment.
• Replace all batteries at the same time with fresh batteries of the same size and
type.
• Do not mix old and new batteries, different types of battery (alkaline, carbon-zinc
or rechargeable), or rechargeable batteries of different capacities. Mixing different
types of battery could cause battery leaks or ruptures.
• Note that there are rechargeable and non-rechargeable batteries. Do not attempt to
charge non-rechargeable batteries.
• Remove the batteries when the microphone is not in use for a long time to avoid
leakage. Batteries can leak chemicals that can damage electronic parts.
• Dispose of batteries promptly and properly, observing any local hazardous waste
regulations. Do not burn or bury them.
• Keep batteries away from children. If you suspect a battery may have been
swallowed, seek immediate medical assistance.
Instructions (Cont.)
Fig. 1

11
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Microphone Operation
The microphone has one switch at the front, as illustrated in Fig.2.
• Push the switch up to the top to switch ON the microphone.
• For best reception, do not move the wireless microphone further than 15 meters away
from the DJ System.
• Push the switch to the middle position to mute the sound temporarily; the indicator
light will blink once.
• Push the switch down to switch OFF the microphone.
Important Notes
• While using the microphone, avoid being close to metal surfaces or walls, as they may
affect the wireless transmission.
• To get the best singing performance, keep the microphone within 5-15cm of the
mouth and at a 45 degree angle.
• When using the microphone, always pay attention to the battery. If the battery is low,
the indicator light will come on and the performance will progressively become poor.
Instructions (Cont.)
Fig. 2

12
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Other Useful Information
Cleaning and Maintenance
CAUTION!
• To prevent a fire or shock hazard, always switch OFF and disconnect the DJ
System from the AC power supply before cleaning.
• Never allow any water or other liquid to get inside the DJ System while
cleaning.
• The speaker cabinet may be cleaned with a soft, dry dust cloth.
• DO NOT use any of the following substances for cleaning the speaker cabinets or
tripods:
• NO wax or polish sprays.
• NO abrasive cloths or polishes.
• NO chemical cleaning agents.
• DO NOT remove the cover or the back of this equipment. There are no user-
serviceable parts inside.
• DO NOT attempt to repair or service the equipment yourself. All servicing should
be referred to qualified service personnel. Contact our after sales support centre for
advice on repair or service.

13
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Output Power 50W
Frequency Response 20Hz~22kHz
Distortion <0.15%
S/N Ration >85dB
Speaker Drivers
Woofer 8" x 1
Tweeter 2" x 1
Power Supply
Rechargeable 12V 4.5Ah battery
External DC power supply 12-15V (power >50W)
Built-in transformer ~230/50-60Hz, 50W
Product Size 293 x 263 x 460 mm (L x W x H)
Bluetooth Version 2.1, supports A2DP profile
USB and SD Card Support MP3 and WMA format files
Technical Specifications
Responsible disposal
At the end of its working life, do not throw this device out with your household
rubbish. Electrical and electronic products contain substances that can have a
detrimental effect on the environment and human health if disposed of inappropriately.
Observe any local regulations regarding the disposal of electrical consumer goods and
dispose of it appropriately for recycling. Contact your local authorities for advice on
recycling facilities in your area.
Other Useful Information (Cont.)

14
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
This page has been left blank intentionally.

15
1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
DJ System with Bluetooth®Wireless Technology
Repair and Refurbished
Goods or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to
be returned to the supplier for repair.
Please be aware that if your product is capable of retaining user-generated data
(such as files stored on a computer hard drive, telephone numbers stored on
a mobile telephone, songs stored on a portable media player, games saved on
a games console or files stored on a USB memory stick) during the process of
repair, some or all of your stored data may be lost. We recommend you save this
data elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them
with refurbished goods of the same type or use refurbished parts in the repair
process.
Please be assured though, refurbished parts or replacements are only used
where they meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may
escalate your complaint. Please telephone us on 1300 886 649 or write to us at:
Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086
Tempo Help Desk: 1300 886 649 (Aust)
(Operating Hours: Mon-Fri 08:30AM to 06:00PM EST)
Email: [email protected]g

1300 886 649 Model: APAS-114 Product Code: 47396 10/2015
www.tempo.org
AUS
Warranty returns
Should you for any reason need to return this product
for a warranty claim, make sure to include all accessories
with the product.
Product does not work?
If you encounter problems with this product, or if it fails
to perform to your expectations, make sure to contact
our After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
