Bauhn ATV32HDG-1021 User manual

[email protected]
MODEL: ATV32HDG-1021 PRODUCT CODE: 707390 10/2021
AUS
User Manual
ATV32HDG-1021
AFTER SALES SUPPORT
1300 002 534
32”
Android TV™

2
Welcome
Congratulations on your purchase!
This manual tells you all you need to know about using your new BAUHN®product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by BAUHN®are manufactured to the highest standards of performance and safety and,
as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty.
Domestic use only: This product is intended for indoor domestic use only. It is not suitable for commercial, industrial
or outdoor use. Do not use this product for anything other that its intended purpose, and only use it as described in
this manual.
We hope you will enjoy using your purchase for many years to come.

3
Contents
Welcome 2
Contents 3
Unpack and Prepare 4
What's in the Box 4
Important Tips 5
Attaching the Stand 6
Wall-Mounting the TV 7
Connect to Power 8
Connect your Antenna 8
Controls and Connections 9
Get to Know your TV 9
Control Joystick on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Remote Pairing 13
Remote Overview 14
On-Screen Set Up 16
How to access other devices
connected to the TV 17
How to turn on/off subtitles
in live TV mode 17
How to play personal photos
and music 17
How to set up Android TV
Remote Control app 18
Smart TV 19
Download or Delete Apps 20
Stream using Chromecast-
enabled Apps 21
Connect To Google Home 21
TV Setting Menus 22
Picture 24
Sound 26
Channel 27
Network & Internet 28
Accounts and Sign-in 30
Google Assistant 30
Apps 31
Retail Mode 31
About 32
Date & Time 33
Inputs 34
Power 35
Screen Saver 36
Location 36
Accessibility 37
Reset 37
Remotes & Accessories 38
TV Guide 39
Recording 40
Recording Live TV 41
Scheduled Recording 41
Playback 41
Pause Live TV (Time-shift) 42
Troubleshooting 43
Specications 46
Compliance and
Responsible Disposal 47
Warranty lnformation 48
Repair and Refurbished Goods
or Parts Notice 49

4 | UNPACK AND PREPARE
Unpack and Prepare
What's in the Box
Before installing your new TV, check you have everything
needed.
In the box you will find:
A. 32" HD Android TV
B. Remote Control
C. AAA Activ Energy Batteries (2)
D. TV Stands
E. Screws for the TV Stand (4)
F. Warning Sheet
G. TV Toppling Safety Message
H. Quick Start Guide
I. Warranty Certificate
J. General Safety Warnings
K. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
• Google account
• Internet connection (to access Smart TV apps and
functionality)
• Antenna cable (to watch live TV)
DE
F
GHIJK
See the box flap for how
to handle the TV without
damaging it!
D
FG
H
IJKL
M
E

UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.

6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match the stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit).
Attaching the Stand
• Unplug the TV from the power outlet before
installing or removing the stand.
• DO NOT place the TV standing upright without
its stand attached; it could damage the remote
sensor at the bottom of the TV.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.

UNPACK AND PREPARE | 7
200mm
Back of the TV
200mm
Wall-Mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M4*5mm screws (or longer,
depending on the mounting bracket) to wall-mount this
TV (screws are not included).
• Unplug the TV from the power outlet
before wall-mounting.
• Contact a professional for assistance with
wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M4*5mm
screws (or longer
as required)
The screws in the package are for securing the TV stand
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.

8 | UNPACK AND PREPARE
Free-to-air TV in HD (High Denition)
High Definition (HD)
channels provide the best
viewing quality and are
available with a digital
antenna connection.
Connect to Power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your Antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in the TV
to the power outlet. Leave
the power switched off until
installation is finished.

CONTROLS AND CONNECTIONS | 9
1. : Select the next channel or move up.
2. + : Increase the volume level or move right.
3. - : Decrease the volume level or move left.
4. : • When TV is on standby, press to turn on.
5. : Select the previous channel or move down. See next page for more info on the connections.
Controls and Connections
Control Joystick on the TV
Get to Know your TV
On/Standby light and
Remote sensor
• When TV is on, press to enter the menu.
Use the joystick to navigate around the interface
and press to enter the highlighted item.
• When TV is on, press and hold to put TV on
standby.
1
2
3
4
5
Bottom View

10 | CONTROLS AND CONNECTIONS
1USB
STORAGE
• Plug in a USB stick to PVR record and pause live TV.
• Play media files stored on your USB storage device (supported file codecs
and extensions may vary).
• Update the TV software via USB.
2
HDMI IN
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND
COMPUTER
All-digital connection between the TV and any HDMI device. Supports HD
resolution. Requires a high-speed HDMI cable (not included).
3
Headphone
Jack
SOUND
Connect to your headphones, amplifier, soundbar or audio device, using an
AUX cable (not included).
Ports on the TV
HDMI IN 1
(ARC)

CONTROLS AND CONNECTIONS | 11
4LAN
INTERNET
Connect to your broadband modem using a network cable (not included) for
best steaming experience. However, the TV also has built-in WiFi.
5
DIGITAL
OPTICAL
OUT
SOUND
Connect an external digital audio device. Use an Optical cable (not included) to
connect the unit with an amplifier, soundbar or other audio decoding device for
digital audio signal output.
6VIDEO IN
You can use this to connect your DVD player. Supports Standard Definition (SD)
picture quality. Requires an AV cable (not included).
7AUDIO IN
SOUND
You can use this to connect Audio to your TV for AV inputs. Requires an AV
cable (not included).
8ANTENNA IN
FREE-TO-AIR
TV
Connect your antenna for live TV. (Antenna cable not included).
45 1 6 82 7
DIGITAL
OPTICAL OUT
LAN HDMI IN 3
( )
ANTENNA
IN
HDMI IN 2 (CVBS)
VIDEO IN AUDIO IN
L R

12 | REMOTE CONTROL
Setup
Insert two AAA size batteries according to the polarity
markings (+ / -) inside the compartment. Make sure the
batteries are correctly aligned and properly pushed into
place.
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.
• Remove the batteries from the remote if you do not
intend to use it for a long time.
• When discarding used batteries, follow any
guidelines for recycling and disposal of batteries
that apply in your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them to
extreme heat.
Remote Control
Image is for illustration purposes only.
Position of battery cover/clip and polarities of batteries on
your remote control may vary.
AAA size
batteries
included
1
2
3

REMOTE CONTROL | 13
Using the Remote Control
To use the remote, point it towards the remote sensor
at the front of the TV. The remote will not operate if its
path is blocked.
The remote has a range of up to about 5 metres from
the TV at an angle of up to 30 degrees to either side of
the sensor, as illustrated below.
Image is an example only.
Remote sensor location on your TV may vary.
Remote Pairing
This remote control uses IR (infrared) to send its
commands to the TV.
• You can use this remote control via IR for
most operations.
5m
Remote Hints and Tips
• Do not drop, step on or otherwise
impact the remote control. This
may damage the parts or lead to
malfunction.
• Do not place objects between the
remote control and the remote
sensor.
• Do not use this remote control while
simultaneously operating a remote
control for other devices.

14 | REMOTE CONTROL
INPUT: Switch between input signal
sources
: Launch the YouTube app
(MUTE): Mute or restore sound
: Fast forward
MENU :Enter on-screen menu
/ / / : Press the UP/DOWN/
LEFT/RIGHT buttons to navigate
OK: Confirm your selection; access
live TV Channel list
/ APPS LIST:Access installed
apps list
Remote Overview
(ON): Switch the TV to On or Standby
: Launch the Netflix app
/REC: Record a TV program
: Stop
: Rewind
: Play/pause
TEXT :Teletext (not available in Australia)
GUIDE: Launch the TV Guide
(BACK) : Return to the previous
screen
: Android TV home screen

REMOTE CONTROL | 15
CH : Go to the next or
previous channel
: Jump to last viewed channel
/ / / RED/GREEN/
YELLOW/BLUE BUTTONS: Functions
are according to the on-screen
display
VOL : Turn the volume up or down
: Open the search interface
NUMBER BUTTONS (0-9): Press to select
a TV channel directly when watching TV
INFO: Display additional information
Note: The remote control is used across a range
of TV models with different operations. Hence
some functions may not be applicable for this TV.

16 | ON-SCREEN SET UP
First Time Setup Menu
When you turn the TV on for the first time, the First Time Setup Menu
will appear.
Follow the prompts using the / / / / OK buttons to select
your preferences. You will be guided through:
1. Remote Pairing
6. Location
12. TV Mode
8. Google Assistant
13. Chromecast built-in always available 14. Channel Scan
7. Help Improve Android 9. Country 10. Password
11. Timezone
5. Terms Of Service2. Language 3. Quick Setup 4. WiFi Setup
If you make an error, you can update your preferences in the settings
menu later.
On-Screen Set Up
Make sure equipment is properly connected (as shown on page
10-11) before connecting the TV to power.
On/Standby light is OFF
when the TV is on.
NOTE: To use your Android TV, you will need a Google
Account.
There are 3 options to set up your TV:
1. Quick Start using an Android phone: Your Android TV will
automatically connect to the Wi-Fi network and Google
account that the Android phone is connected to.
2. Set up with your remote: Use the remote to manually enter
Google account and connect to Wi-Fi.
3. Set up with a phone or computer: Make sure your phone
or computer is on the same Wi-Fi network as the TV is
connecting to.
3. Quick Setup
On/Standby light is RED
in standby mode.
NOTE:
The remote provided with this TV does
not support Bluetooth®and Google
Assistant. Please press the (BACK)
button to skip the Bluetooth®pairing
process.
GUIDE
+
OK
P.MODE
+

ON-SCREEN SET UP | 17
How to access other devices connected to the TV
1. Press the INPUT button on the remote control, select your desired input sources and press OK.
2. (OR) select the icon from the Android TV home screen.
You can rename the inputs to easily identify the device connected to it by going to:
Settings > Device Preferences > Inputs
How to turn on/off subtitles in live TV mode
1. To turn off subtitles, press the MENU button on the remote, select Advanced Options and select Subtitle. From
here change digital subtitle to "off."
2. To turn on subtitles, press the MENU button on the remote, select Advanced Options and select Subtitle. From
here change digital subtitle to "on."
How to play personal photos and music
You can view your photos or play your music from a connected USB flash drive.
1. Plug in a USB flash drive to one of the USB connections.
2. Press the button and select the MMP (Multi-Media Player) app from the favourite apps list and press OK.
Alternatively, you may use other apps available on the Google Play Store.

18 | ON-SCREEN SET UP
How to set up Android TV Remote Control app
You can navigate your Android TV using your phone or tablet with the Android TV Remote Control app.
Note: You need an Android device running Android 4.3 or higher to use the app.
1. On your smart phone, search and download the Android TV Remote Control app from the Play Store/App
store (alternatively, scan the QR code below):
2. After app has downloaded and installed, open up the app . Ensure that both your
smart phone and Android TV are using the same Wi-Fi network.
3. Tap the name of your Android TV.
4. A PIN will appear on your TV screen, enter the PIN on your smart phone and tap Pair.
You can now use your smart phone as a remote for your Android TV.
For Android For iOS

SMART TV | 19
Smart TV
Before you start using apps, your TV must be
connected to the internet.
The speed of your internet connection determines
the quality of your audio/video experience when you
watch streaming content.
Accessing internet content may count towards your
download limit and may incur fees from third parties
such as your internet service provider (ISP).
Function Remote Button
Display the Android TV home
screen
Change the order of apps /
remove an app from favourites Press and hold
Open your desired App
Netflix is a streaming service that offers unlimited
viewing of a wide variety of award-winning TV shows,
movies and documentaries.
A paid subscription is required.
This TV can play Netflix content in HD resolution,
however the playback resolution may vary depending on
your subscription level and your network speed.
Streaming Netflix content will count towards the data
usage of your broadband plan.
NotificationsVoice search/on-
screen keyboard
Access all apps Favourite apps
Settings
Change inputs Internet
connectivity
status

20 | SMART TV
Download or Delete Apps
You can download apps and games for your Android TV through the Google Play Store app.
Download apps
1. From the Android TV Home screen, Select the Google Play Store app.
2. Browse or search for apps and games.
To browse: Move up or down to view different categories. When you find a category you’re
interested in, move to the right to view items.
To search: Scroll to the right at the top of the screen and select Input .
3. Select the app or game you want.
4. Select Install.
Delete an app
1. From the Android TV Home screen, select Settings.
2. Select Apps.
3. Under "Recently Opened Apps" or "See All Apps", choose the app you want to remove.
4. Select Uninstall and then press OK.
