Baumatic BBC460SS User manual

He
BBC460SS Blast
chiller

USER MANUAL FOR YOUR BAUMATIC
BBC460SS Blast
chiller
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference. for
you or any person not familiar with the operation of the appliance.
GS 03/02/11
2

3
Contents
Environmental note 4
Important safety information 5–6
Specifications of your blast chiller 7-8
Product and aperture dimensions 7
Electricaldetails 8
Using your Baumatic blast chiller 8-10
Beforeswitchingon 8
Storing blast chilled or frozen products 8-9
Loadingtheblastchiller 9
Usingthecoreprobe 9-10
Switching on the appliance and setting a chiller cycle 11-24
Controlpanel 11
Switching the appliance on 11-12
3°C blast chiller cycle with core probe 12
-18°C standard foods deep-freezing cycle with core probe 13
-18°C non-standard foods deep-freezing cycle with core probe 13-14
3°C blast chiller time cycle 15
Food class table 15-18
-18°C standard foods deep-freezing time cycle 18
Food class table 19-20
-18°C non-standard foods deep-freezing time cycle 20-21
Food class table 21-22
Bottlescycle 22-23
Cans cycle 23-24
Cleaning and Maintenance 25-26
Installation 26-28
Electrical connection 26-27
Positioning 27
Installing your blast chiller 28
Troubleshooting 29-30
Contactdetails 31

Environmental note
Note : Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
4

Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Baumatic Advice Line.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.
Use of the appliance
oYour appliance is only designed to be used in the
home. It is suitable for rapidly lowering
temperatures, rapidly freezing foods and rapidly
cooling drinks. If it is used for any other purpose or
it is not used correctly, then Baumatic Ltd. will
accept no liability for any damage or injury that
might be caused.
oAltering the specification of the appliance must not be attempted
for reasons of safety.
oThe blast chiller has NOT been designed to be used
continuously. Therefore, for it to function correctly and
efficiently, it is advisable to switch the appliance off after a
maximum of two cycles and leave the door open for around 30 –
40 minutes so that any ice which has formed can evaporate.
Before using your appliance
oCheck the appliance for any signs of transport damage. If you
notice any damage, then you should not connect your appliance
to your mains supply and should contact your supplier.
Child safety
5
oPackaging material should be kept away from
children.
oChildren should not be allowed to touch the
controls or play with the appliance.

General safety
oDo not pull on the power supply cable to remove the plug from
your mains supply socket.
oDo not pull out or insert the plug with wet hands.
6
oDo not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
oBefore cleaning the appliance or performing
maintenance work, ensure that the appliance has been
disconnected from your mains supply.
oNever allow the back coils of the appliance to come into contact
with the wall surface.
oAlways ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
oNever block the ventilation openings of the appliance, either on
the inside or its exterior.
oIt is vital to keep your appliance well ventilated,
so that there is proper air flow between the
bottom of the unit and the plinth/kick plate
which it is sitting on.
oDo not place electrical devices inside of the appliance, such as
mixers and electric ice cream makers.
oThis appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Service
You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Customer Care Department.

Specifications of your blast chiller
o5 x chiller cycles
o10 x display icons
oDoor open indicator
oLow performance indicator
oCore probe device
o3 x Programmable chiller time cycles
oBottles cycle
oCans cycle
oThermal maintenance mode
Dimensions of appliance
Height: 460 mm
Width: 598 mm
Depth: 566 mm
Dimensions of aperture*
Height: 450 mm
Width: 560 mm
Depth: 570 mm (min)
7

8
Net capacity: 27 litres
Electrical details
Rated Voltage: 220 - 240 Vac 50 Hz
Max Rated Inputs: 0.44 kW
Standard accessories
Core probe device
Glass tray
* Please refer to the installation instructions for more specific
information on the size of aperture that you will require.
IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.
Using your Baumatic blast chiller
Before switching on
oMake sure that it has been installed by a suitably qualified
person, as per the information contained in Baumatic’s
installation instructions.
oAfter delivery, wait for eight hours before connecting the
appliance to your mains supply. This will allow any refrigerant
gasses that may have been disturbed during the transportation
process to settle.
oThe outside of the appliance and the removable accessories
contained within it, should be cleaned with a solution of liquid
detergent and water.
oThe interior of the appliance should be cleaned with a solution of
sodium bicarbonate dissolved in lukewarm water. The interior
and accessories should be thoroughly dried, after the cleaning
process has been completed.
oThere can be an odour when you first switch on the appliance. It
will lessen as the appliance starts to cool.
Storing blast chilled or frozen products
oBlast chilled and / or rapidly frozen food MUST NOT be kept
inside the blast chiller. It must be accurately covered and
protected (with cling film, a hermetic seal etc.) in the fridge or
freezer.

oBlast chilled food must be kept in a fridge at a constant
temperature of 3°C.
oFrozen food must be kept in a freezer at a constant temperature
of -18°C.
Loading the blast chiller
oAvoid keeping chilled and / or rapidly frozen food at room
temperature for long. If kept at room temperature, the foods will
undergo the following negative transformations: loss of
moisture, loss of initial quality and an increase in the possibility
of contamination.
oFor these reasons, it is advisable to start the chosen cycle as
soon as the preparation and / or cooking of the food is finished.
oTo load the blast chiller, always use the supplied grills, basket
and drip-tray in order to avoid blocking the airflow hitting the
product, which is located at the back of the blast chiller.
oEnsure that the products to be blast chilled are not stacked
incorrectly by inserting them individually or in small pieces when
they are large.
Using the core probe
oThe core probe is a device which can be found within the blast
chiller refrigerator and is used for reading the temperature at the
centre of the food which is to be rapidly chilled or frozen.
oWARNING: Take extra care when using the core probe as
it is very sharp and there is a risk of injury if handled
incorrectly.
9

oWhile in use, the core probe must be inserted into the food to be
chilled or frozen before the cycle begins.
oTo guarantee that the probe works correctly in the blast chiller
and deep-freeze cycle, insert it as in the diagram below. Insert
the tip right into the centre of the food, being careful that it does
not come out of the other side.
oAt the end of the cycle, clean the probe with a soft cloth and
warm water.
REMEMBER: The blast chiller and deep-freezing periods vary a
great deal depending on the physical characteristics and the
size of the food being used. For best use, it is advisable to put
foods into the appliance with a thickness of less than 2 cm,
which are defined as STANDARD foods.
For foods in basins which are thicker than 2 cm or for foods
which are not in bowls but are thicker than 2 cm (NON-
STANDARD foods), it is advisable to choose a -18°C non-
standard foods chiller cycle.
10

Switching on the appliance and setting a chiller cycle
Control panel
1 = +3°C blast chiller cycle with core probe button
2 = -18°C standard foods deep-freezing cycle with core probe button
3 = +3°C blast chiller time cycle button
4 = -18°C standard foods deep-freezing time cycle button
5 = Bottles cycle button
6 = Cans cycles button
7 – +3°C blast chiller icon
8 = -18°C deep-freezing icon
9 = Core probe icon
10 = First stage cycle icon
11 = Second stage cycle icon
12 = Third stage cycle icon
13 = Time cycle icon
14 = Bottles cycle icon
15 = Cans cycle icon
16 = Ignition icon
17 = ON / OFF button
Switching the appliance on
oTo switch on the appliance, press and hold the ON / OFF
button (17) for a few seconds.
oThe ignition icon (16) will remain on for the whole
length of time that the appliance is in use.
oAt the end of each cycle, press the ON / OFF button
(17) again to switch off the appliance.
oWithin the first three minutes after the start of the chosen cycle,
it is possible to modify it or switch the appliance off.
oIf there is five minutes of inactivity after the appliance is
switched on, the appliance will automatically switch off.
11

oAll the blast chiller and deep-freezing cycles indicated in
this user manual are defined based on a starting food
temperature of between 70°C and 90°C.
oAt the end of any cycle, it is possible to
keep the food stuff in the appliance for
longer by simply not opening the door
immediately. All three chiller cycle stage icons (10, 11 and 12)
will flash during this period.
3°C Blast chiller cycle with core probe
oThe weight of the food must NEVER be more than 1 kg.
oThe temperature reading takes place in the central part of the
food by inserting the core probe.
oCarefully put the hot food into the blast chiller, slide in the probe
ensuring that the tip is in the centre of the food. To guarantee
that the probe works correctly in the blast chiller and deep-
freezing cycle, insert it as the ‘Using the core probe’ section
directs.
oClose the door and press the 3°C blast chiller cycle with
core probe button (1).
oThe display will show the 3°C blast chiller icon
(7) and the core probe icon (9), which are lit at
the same time, indicating that the chosen cycle
has started correctly.
12
.
oThere are three icons which light to show
the progression of the cycle (10, 11 and
12). They will switch off in turn and flash
in order
oAt the end of the cycle, the progression
icons (10, 11 and 12) will flash together
with a buzzer which will sound for around
twenty seconds. To end the cycle, open the door.
oAt the end of the cycle, the chill blaster will switch into
maintenance mode until the door is opened. The product will
remain in a thermal range of 1°C - 5°C.

-18°C Standard foods deep-freezing cycle with core probe
oThe weight of the food must NEVER be more than 1 kg.
oThe temperature reading takes place in the central part of the
food by inserting the core probe.
oPut the hot food into the blast chiller, slide in the probe ensuring
that the tip is in the centre of the food. To guarantee that the
probe works correctly in the blast chiller and deep-freezing cycle,
insert it as the ‘Using the core probe’ section directs.
13
(2).
oClose the door and press the -18°C standard foods
deep-freezing cycle with core probe button
oThe display will show the -18°C deep-freezing
icon (8) and the core probe icon (9) which are lit
at the same time, indicating that the chosen cycle
has started correctly.
oThe cycle progression icons (10, 11 and
12) show the different stages of the cycle
and will switch off in turn and flash in
order. oAt the end of the cycle, the progression
icons (10, 11 and 12) will flash together
with a buzzer which will sound for
approximately twenty seconds. To end the cycle, open the door.
oAt the end of the cycle, the chill blaster will switch into
maintenance mode until the door is opened. The product will
remain in a thermal range of -16°C - -20°C.
-18°C Non-standard foods deep-freezing cycle with core probe
ATTENTION: Before beginning this cycle, the food must have a
temperature of 3°C. Therefore, if necessary, chill the food using
the 3°C blast chiller cycle with the core probe first.
oA non-standard food is classified as a product with a thickness
larger than 2 cm or foods in basins or bowls which are thicker
than 2 cm.
oThe weight of the food must NEVER be more than 1 kg.
oThe temperature reading takes place in the central part of the
food by inserting the core probe. To guarantee that the probe

oCheck that the blast chiller is empty and that the door is closed.
oPress the 3°C blast chiller cycle with core probe
button (1) and the -18°C standard foods deep-
freezing cycle with core probe button (2)
simultaneously to select this cycle.
14
rrectly.
oThe display will show the 3°C blast chiller
icon (7), -18°C deep-freezing icon (8)
and the core probe icon (9) which
indicates that the chosen cycle has started co
oAfter a few minutes, a buzzer will signal the best time to put the
food to be deep-frozen into the appliance.
oPut the food into the appliance within five minutes otherwise the
appliance will be switched off and it will be necessary to start
the procedure again from the beginning.
oInsert the probe, ensuring that the tip is at the centre of the
product and close the door.
oOn the display, the progression icons (10,
11 and 12) show the different stages of
the cycle and will switch off in turn and
flash in order. oAt the end of the cycle, the progression
icons (10, 11 and 12) will flash together
with a buzzer which will sound for
approximately twenty seconds. To end the cycle, open the door.
oAt the end of the cycle, the chill blaster will switch into
maintenance mode until the door is opened. The product will
remain in a thermal range of -16°C - -20°C.

3°C Blast chiller time cycle
oThe weight of the food must NEVER be more than 1 kg.
oPlace the hot food into the blast chiller. Close the door
and press the 3°C blast chiller time cycle button (3)
repeatedly until the desired food class icon has been
chosen. For food class icon details see the table below.
Icon 10 Class 1 30 minutes
Icon 11 Class 2 60 minutes
Icon 12 Class 3 90 minutes
Icons 10 + 11 Class 4 120 minutes
Icons 11 + 12 Class 5 150 minutes
Icons 10 + 12 Class 6 180 minutes
oApproximately five seconds after selecting the desired food class,
the cycle will start automatically.
oThe display will show the 3°C blast chiller icon
(7) and the time cycle icon (13) which are lit at
the same time, indicating that the chosen cycle
has started correctly.
oThe cycle progression icons (10, 11 and
12) show the different stages of the cycle
and will switch off in turn and flash in
order.
oAt the end of the cycle, the progression
icons (10, 11 and 12) will flash together
with a buzzer which will sound for
approximately twenty seconds. To end the cycle, open the door.
oAt the end of the cycle, the chill blaster will switch into
maintenance mode until the door is opened. The product will
remain in a thermal range of 1°C - 5°C.
oFor a general guideline for food classes and chiller times please
refer to the table below.
Please note the following table should be used as a guideline
only. Chiller times can vary depending on the type and size of
the food.
Class 1 foods (g) for blast chiller times of
less than ½ an hour (icon 10)
Short-crust pastry biscuits 500
Yoghurt biscuits 500
15

16
Spinach 500 – 1000
Asparagus 500 – 1000
Swiss chard stalks 500 – 1000
Courgettes 500 – 1000
Cauliflower 500 – 1000
Fennels 500
Carrots 500
Broccoli 500 – 1000
Peppers 500 – 1000
Leeks 500 – 1000
Celery 500 – 1000
Brussels sprouts 500
Potatoes 500
Class 2 foods (g) for blast chiller times of
between ½ hour and 1 hour (icon 11)
Short-crust pastry biscuits 1000
Yoghurt biscuits 1000
Custard 500
Fennels 1000
Potatoes 1000
Carrots 1000
Brussels sprouts 1000
Rare T-bone steak core
temperature 55°C
500 - 1000
Class 3 foods (g) for blast chiller times of
between 1 hour and 1 and a ½ hours (icon
12)
Plum cake 500
Apple pie 500 – 1000
Sponge cake 500
Custard 500
Neck of pork core temperature
72°C
500
Medium – well done T-bone steak
core temperature 65°C
500
Roast beef core temperature
58°C
500
Ricotta and spinach cannelloni
core temperature 75°C
500
Lasagne Bolognese core
temperature 78°C
500
Courgette flan core temperature
70°C
500
Savoury flan core temperature
72°C
500
Class 4 foods (g) for blast chiller times of
between 1 and ½ hours and 2 hours (icons

17
10 and 11)
Custard 1000
Plum cake 1000
Sponge cake 1000
Tomato sauce 500
White sauce 500
Meat sauce 500
Trout 500
Mussels and clams 500 – 1000
Prawns and flat lobster 500
Plaice fillet 500 – 1000
Scorpion fish fillet 500
Roast pork core temperature
70°C
500
Roast turkey breast core
temperature 68°C
500
Class 5 foods (g) for blast chiller times of
between 2 hours and 2 and a ½ hours (icons
11 and 12)
Tomato sauce 1000
Meat sauce 1000
White sauce 1000
Trout 1000
Prawns and flat lobster 1000
Scorpion fish fillet 1000
Braised shoulder of beef core
temperature 75°C
500
Class 6 foods (g) for blast chiller times of
between 2 and ½ hours and 3 hours (icons
10 and 12)
Roast pork core temperature
70°C
1000
Neck of pork core temperature
72°C
1000
Medium – well done T-bone steak
core temperature 65°C
1000
Roast beef core temperature
58°C
1000
Roast turkey breast core
temperature 68°C
1000
Ricotta and spinach cannelloni
core temperature 75°C
1000
Courgette flan core temperature
70°C
1000
Savoury flan core temperature
72°C
1000
Braised shoulder of beef core
temperature 75°C
1000

Lasagne Bolognese core
temperature 78°C
1000
If the food being used is not shown in the above table, it is
advisable, for the first few times that the appliance is used, to
use the 3°C blast chiller cycle with the core probe and to
manually check the time taken so that the food can then be
classified.
-18°C Standard foods deep-freezing time cycle
oThe weight of the food must NEVER be more than 1 kg.
oPut the hot food into the blast chiller and close the door.
oPress the -18°C standard foods deep-freezing time cycle
button (4) repeatedly until the desired food class icon
has been selected. For food class icon details please see
the table below.
Icon 10 Class 1 60 minutes
Icon 11 Class 2 120 minutes
Icon 12 Class 3 180 minutes
Icons 10 + 11 Class 4 240 minutes
oApproximately five seconds after selecting the desired food class,
the cycle will start automatically.
oThe display will show the -18°C deep-freezing
icon (8) and the time cycle icon (13) which are
lit at the same time, indicating that the chosen
cycle has started correctly.
oThe cycle progression icons (10, 11 and
12) show the different stages of the cycle
and will switch off in turn and flash in
order.
oAt the end of the cycle, the progression
icons (10, 11 and 12) will flash together
with a buzzer which will sound for around
twenty seconds. To end the cycle, open the door.
oAt the end of the cycle, the chill blaster will switch into
maintenance mode until the door is opened. The product will
remain in a thermal range of -16°C - -20°C.
oFor a general guideline for food classes and deep-freezing times,
please refer to the table on the next page.
18

19
Please note the following table should be used as a guideline
only. Chiller times can vary depending on the type and size of
the food.
Class 1 foods (g) for deep-freezing times of
less than 1 hour (icon 10)
Short-crust pastry biscuits 500 – 1000
Yoghurt biscuits 500 – 1000
Spinach 500
Asparagus 500
Swiss chard stalks 500
Courgettes 500
Cauliflower 500
Fennels 500
Carrots 500
Broccoli 500
Peppers 500
Leeks 500
Celery 500
Brussels sprouts 500
Class 2 foods (g) for deep-freezing times of
between 1 and 2 hours (icon 11)
Plum cake 500
Apple pie 500
Custard 500
Sponge cake 500
Spinach 1000
Asparagus 1000
Courgettes 1000
Cauliflower 1000
Fennels 1000
Carrots 1000
Broccoli 1000
Peppers 1000
Leeks 1000
Celery 1000
Brussels sprouts 1000
Potatoes 500 – 1000
Swiss chard stalks 1000
Class 3 foods (g) for deep-freezing times of
between 2 and 3 hours (icon 12)
Plum cake 1000
Apple pie 1000
Sponge cake 1000
Custard 1000
White sauce 500 – 1000
Meat sauce 500
Tomato sauce 500

Class 4 foods (g) for deep-freezing times of
between 3 and 4 hours (icons 10 and 11)
Tomato sauce 1000
Meat sauce 1000
If the food being used is not shown in the above table, it is
advisable, for the first few times that the appliance is used, to
use the -18°C standard food deep-freezing cycle with the core
probe and to manually check the time taken so that the food
can then be classified.
-18°C Non-standard foods deep-freezing time cycle
ATTENTION: Before beginning this cycle, the food must have a
temperature of 3°C. Therefore, if necessary, chill the food using
the 3°C blast chiller cycle with the core probe first.
oA non-standard food is classified as a product with a thickness
larger than 2 cm or foods in basins or bowls which are thicker
than 2 cm.
oThe weight of the food must NEVER be more than 1 kg.
oEnsure that the blast chiller is empty and that the door is closed.
oPress the 3°C blast chiller time cycle button (3)
and the -18°C standard foods deep-freezing time
cycle button (4) repeatedly until the desired food
class icon has been chosen. For food class icon details please see
the table below.
Icon 10 Class 1 120 minutes
Icon 11 Class 2 180 minutes
Icon 12 Class 3 240 minutes
oApproximately five seconds after selecting the desired food class,
the cycle will start automatically.
oThe display will show the 3°C blast chiller
icon (7), the -18°C deep-freezing icon
(8) and the time cycle icon (13) which
indicates that the chosen cycle has started
correctly.
st time to put the
product to be deep-frozen into the appliance.
oAfter a few minutes, a buzzer will signal the be
20
