Baumatic B25SE Operator's manual

说明书递交文档
设 计
DESIGN
许婷婷
2012.7.9
校 对
CO.BY 袁晓娟
图号/物料编码 PART NO.
标准化
S
TANDARD 马凯
李宇
1. 即日起更改说明书页码3、5、39、40、41内容
删除原先说明书40页 2014.4.11 周凤霞
图纸名称 PART NAME
材
料 MATERIAL
业务
seller
图样
标记
REL
版本号
REV.NO
.
重量
(g)
WEIGHT
比例
scale
批 准
A
UTHORIZ
E
于清 0 1:1
美的冰箱事业部
MIDEA REFRIGERATION
DIVISION
共 页
TOTAL
SHEETS
第 页
NO. OF SHEETS
技术要求
1、 尺寸：32K
2、 说明书印刷颜色：封面彩印,内页黑白印刷。
3、 样板需送设计部门封样。
标记
MARKER 变更内容 修改日期 签名
BAUMATIC
B25SE(CE-BCD515WE-S)
说明书
50200101B858
80g双胶纸

s
B25SE
Side by side frost free
fridge freezer

2
USER MANUAL FOR YOUR BAUMATIC
B25SE
545 Litre side by side
frost free fridge freezer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
JW 06/07/12

3
Contents
Environmental note 4
Important safety information 5-6
Specifications of your fridge freezer 7-10
Description of the appliance 8
Fridge section (including door) 8
Freezer section (including door) 8
Using your Baumatic fridge freezer 12-17
Before switching on 11
During first use 11
Control panel 12
Switching on the appliance 12
Setting the temperature manually (freezer section) 12
Setting the temperature manually (fridge section) 13
Switching on fast freeze mode 13
Switching on rapid cooling mode 14
Switching on holiday mode 14
Switching on energy saving mode 15
Returning the appliance to normal operation 15
Switching on the control panel lock 15
Using the ice/water dispenser 16-19
Arranging and storing food in the fridge section 20
The **** freezer section 21
Freezing fresh food 22
Tips on freezing 23
Storing commercially frozen food 24
Defrosting frozen food 24
Normal operating noises 24
Important user information 24
Saving energy when using your fridge-freezer 24-25
Cleaning and maintenance 26-29
General cleaning 26-28
The defrost drain hole 28
Defrosting the freezer section 29
Replacing the light bulb 29
Installation 30-36
Electrical connection 30
Positioning 31
Installation preparation 32
Removing the fridge and freezer doors 33-34
Installing the decorative plinth 35
Connecting the water inlet hose 36
Troubleshooting 37-39
40
41
Contact details
Technical data

4
Environmental note
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
IMPORTANT: Any installation work must be carried
out by a qualified electrician or competent person.
Use of the appliance
oYour appliance is only designed to be used in the
home. It is suitable for storing food that needs to
be chilled and refrigerated. If it is used for any
other purpose or it is not used correctly, then
. will accept no liability for any
damage that is caused.
oAltering the specification of the appliance must not be attempted
for reasons of safety.
Before using your appliance
oCheck the appliance for any signs of transport damage. If you
notice any damage, then you should not connect your appliance
to your mains supply and should contact your retailer.
Refrigerant
oYour appliance contains R600a refrigerant, which is a natural gas
that does not contain CFCs that can damage the environment.
However it is a flammable substance, therefore care should be
taken:
During the transportation and installation of the
appliance, make sure that the refrigeration pipe-
work does not get damaged.
If it does become damaged then sources of ignition
and open flames should be avoided. Also the room
that the appliance is situated in should be thoroughly
ventilated.
oDo not place any objects on top of the appliance,
as this may damage the table top.
Baumatic

6
Child safety
oPackaging material should be kept away from
children.
oChildren should not be allowed to touch the
controls or play with the appliance.
General safety
oDo not pull on the power supply cable to remove the plug from
your mains supply socket.
oDo not pull out or insert the plug with wet hands.
oDo not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
oBefore cleaning the appliance or performing maintenance work,
ensure that the appliance has been disconnected from your
mains supply.
oNever allow the back coils of the appliance to come into contact
with the wall surface.
oAlways ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
oNever block the ventilation openings of the appliance, either on
the inside or its exterior.
oIt is vital to keep your appliance well ventilated, so
that there is proper air flow between the bottom of
the unit and the plinth/kick plate which it is sitting
on.
oDo not place electrical devices inside of the appliance, such as
mixers or ice cream makers.
oDo not store aerosol cans with a flammable propellant in this
appliance.
Service
You should not attempt to repair the appliance yourself,
as this could cause injury or a more serious malfunction.
If you require a service call then please contact the
Baumatic Customer Care Department.

7
Specifications of your fridge freezer
Dimensions of your appliance
oHeight: 1760 mm
oWidth: 902 mm
oDepth: 750 mm (Including doors and handles)
Energy efficiency class
oEnergy class: A+
Cubic capacities
oTotal gross/net capacity: 545/515 litres
oGross capacity (fridge/freezer): 347/198 litres
oNet capacity (fridge/freezer): 340/175 litres
Specifications of the appliance
oFrost free fridge and freezer
oStar rating **** (freezer door racks **)
oMulti airflow cooling system
oElectronic temperature control
oDigital control panel
oAdjustable thermostat
oFast cooling switch
oFast Freeze switch
oFast freeze indicator light
oDoor open warning indicator
oTemperature rise warning indicator
oAutomatic motor-driven ice maker
oWater dispenser
oAdjustable feet
o3 Adjustable fridge safety glass shelves
o1 Salad crisper shelf (Safety glass)
o4 Bottle racks
o2 Salad crispers
oButter and cheese compartment
oEgg rack
o3 Freezer safety glass shelves
o2 Transparent freezer drawers
o4 Freezer door racks

8
IMPORTANT: When you install your appliance it is important to bear
in mind its climatic rating.
In order to find out the climatic rating of your appliance, you should
check the rating plate. The rating plate is located inside of the fridge
section, on the left side. You will need to open the door of the fridge
section and you may need to remove one of the middle safety glass
shelves. The rating plate will indicate the ambient temperature range
that your appliance will function correctly within.
Description of the appliance
1) Bottom beam/decorative plinth
2) Freezer drawer (x2)
3) Freezer shelf (x3)
4) Ice dispenser
5) Freezer door rack (x4)
6) Ice maker
7) Fridge light
8) Butter/cheese compartment
9) Adjustable safety glass shelves (x3)
10) Bottle racks (x 4)
11) Salad crisper drawer (x2)
12) Digital control panel
13) Ice/water dispenser

9
Description of product features (fridge)
Safety glass shelves
oThe shelves may be placed in any of the guide slots within the
interior of the appliance. They are protected from sliding out.
oTo remove a shelf: Take off all of the
items that are stored on the shelf that
you want to remove. Pull the shelf
forwards (a), then lift the front of the
shelf (b) towards 90° and carefully
pull it out of the grooves (c).
oThe upper shelves should be used to store pasta, canned food,
milk etc.
oThe lower shelf should be used to store cooked meats and
sausage etc.
Salad crispers
oThese drawers are suitable for storing fruits, salad and
vegetables. They are designed to keep the contents fresh for as
long as possible.
oCare should be taken when storing tropical fruit (bananas and
pineapples etc) and tomatoes. As these types of items can easily
deteriorate at a lower temperature.
Butter and cheese compartment
oThis rack should be used to store eggs, butter, cheese, yogurts
etc.
Bottle racks
oThese racks should be used for storing reasonably sized bottles.
These racks can also be used to store smaller cans, packages
and tubes, etc.
oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE
SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS
THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.
