BCP SKY6467 User manual

SKY6467 + SKY6468 + SKY6469 + SKY6470 + SKY6471 + SKY6472Ver. 1
2-Tier Square LED Cantilever
Umbrella with Fillable Base
INSTRUCTION
MANUAL

Do not use without
umbrella base weights.
Recommended Weight:
>200 lbs.
bestchoiceproducts.com
LBS

| 3
•Umbrella base weights are not included. Do not use without umbrella base weights (recommended
weight: >200 lbs.).
•Place umbrella on a stable and level surface.
•Umbrella is suitable for rain showers and light wind.
•Do not use umbrella in inclement weather, such as snow, heavy rain, thunderstorms, or strong wind.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
HARDWARE
1
1 PC
M6 x 9mm
BOLT 5
8 PCS
M10 WASHERKNOB
2
1 PC
M10 x 25mm
SCREW
3
4 PCS
M10 x 20mm
SCREW
4
4 PCS
TOOLS REQUIRED
UP TO 30 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
PARTS
1 PC
CROSSBAR I
A
1 PC
CROSSBAR II
B
1 PC
POLE ADAPTER
C
Please retain these instructions for future reference.
NOTICE
S10 ALLEN WRENCH
(PROVIDED)
S5 ALLEN WRENCH
(PROVIDED)

4|
PARTS
D
1 PC
ROTATOR BASE
1 PC
ROTATOR PLATE
F
E
1 PC
FOOT PEDAL
J
1 PC
CRANK HANDLE
1 PC
ADAPTER COLLAR
G
1 PC
UMBRELLA
H
1 PC
UMBRELLA COVER
L
K
1 PC
COVER SUPPORT
M
2 PCS
BASE WEIGHT I N
2 PCS
BASE WEIGHT II
1 PC
SOLAR PANEL
I

| 5
BEFORE FIRST USE
1. Hold the part H umbrella upside down and shake gently to separate the umbrella ribs. If necessary,
carefully pull the ribs apart to free them.
2. Insert and secure the part J crank handle into the crank mechanism on the part H umbrella.
3. Slowly turn the crank to open the umbrella. Make sure that the ribs are not stuck together.
PRODUCT ASSEMBLY
1Insert the part A crossbar into the part B
crossbar and set aside. 2Locate the part D rotator base and attach the part E foot pedal with one part 1 bolt.
NOTE: the bolt attaches through the
bottom of the foot pedal.
A
B
H
J
1
D
E

6|
PRODUCT ASSEMBLY
4
3
Attach the part C pole adapter to the part D rotator base with four part 4 screws and four part
5 washers.
Place the G adaptor collar onto the pole adapter.
Press down on the pedal to rotate the base and expose the lower mounting holes. Overlay the
rotator base with the crossbars.
Attach the part D rotator base to the part A & B crossbars with four part 3 screws and four part
5 washers.
3
5
x4
x4
4
x4
5
C
x4
G

| 7
PRODUCT ASSEMBLY
6
5
Place the base weights over the crossbar assembly, place the part N weights closest to the part
D rotator base and the part M weights on the outside.
Slide the part F rotator plate over the part C adapter.
NOTE: Make sure the pedal can articulate through the plate opening
Fill the part M & N base weights with your choice
of sand or water. (DO NOT MIX sand with water)
M N
x2 x2
M
M
N
N
F
CAPACITY PER WEIGHT:
220LBS WATER OR 308LBS SAND
LBS

PRODUCT ASSEMBLY
8
7
Firmly insert the part H umbrella onto the part G adapter collar. Insert and tighten the part 2
knob to secure.
Insert the battery connector from the part H umbrella into the part I solar panel. Screw the solar
panel onto the top of the pole.
8|
I
2

OPENING THE CANOPY
| 9
1. Grip and squeeze the handle to engage the release. Move the arm up.
2. Release the handle to lock the canopy in your desired position.
3. Slowly turn the crank to open the canopy.
ADJUSTING THE TILT
1. Grip and squeeze the handle and move the arm up/down to adjust the tilt angle of the umbrella.
2. Lock it in your desired position by releasing the handle.
3. Step firmly onto the part E foot pedal to rotate the canopy as needed

10 |
•Press the power switch on the canopy to turn on LED lights.
TURNING ON THE LIGHTS
•Turn the crank counterclockwise to close the canopy.
CLOSING THE CANOPY
