Beanrush Beverages MyEspressino User manual

1
MyEspressino Coee Machine
Instruction Manual
Item MyEspressino
Voltage AC220-240V, 50Hz
Power 1450W
Water tank 1.7L
Pressure 15Bar

2 3
IMPORTANT SAFEGUARDS
Before using machine always carefully read and comply with all these instructions. We cannot
accept any responsibility for the consequences of improper use.
1. Check voltage to be sure that the voltage indicated on the name plate agrees with
your voltage.
2. This appliance has been incorporated with a grounded plug. Please ensure the wall
outlet in your house is well earthed.
3. Close supervision is necessary when the appliance is used by people. Place the
machine out of the reach of children and persons with limited capabilities.
4. Do not place on or near a hot gas or electric burner or in a heated oven.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting
or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or adjustment.
7. The use of accessory attachment not recommended by the appliance manufacturer
may result in fire, electric shock, or injury to persons.
8. Be careful to ensure that the power cable does not become trapped and does not rub
against sharp edges.
9. Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
10. Do not touch any hot parts. Use the handle of the funnel.
11. To protect against fire, electric shock and injury to persons, do not immerse cord,
plugs, or body of machine in water or other liquid.
12. It must be protected against freezing conditions.
13. Please fill up no more than 1.7L to upper MAX mark, when pure water in water tank.
14. Once the fault, defect or machine drop caused by suspicious defect, unplug the power
plug immediately, do not operate on the problem machine.
15. Do not use outdoors.
16. SAVE THESE INSTRUCTIONS FOR YOUR REFERENCE.
Home/Domestic use only
Power indicator
Power button
Coee Button
Steam Button
Steam Indicator
Coee indicator
Drip tray
Barometer
Stem/Hot water knob
Steam nozzle
Tamper
Coee Spoon
Water tank
Warning: The machine must use a grinding Coee powder and is composed
of a central structure for obtaining espresso and steam/hot water.

4 5
C. FROTHING MILK/ MAKE CAPPUCCINO
1. Prepare espresso rst with a large enough cup according to part “B. MAKE
ESPRESSO COFFEE’’;
2. Use whole, fresh cold milk out of the fridge(8˚C-10˚C), and pour 1/3 milk in
cup;
Note: Use a stainless steel cup, and cup diameter should not less than 70 ±
5mm, due to the volume of milk will increase after frothing.
3. Press steam button, it starts preheating, and steam indicator is ashing,
then wait for lamp lights on;
4. Put a stainless steel cup under steam nozzle;
5. Open knob, release steam, make the steam nozzle oating on the surface
of milk, and adjust the height of steel cup to froth milk;
6. Remove product when nished, turn o the knob, and Pour the frothed
milk into the espresso prepared; now the cappuccino is ready.
Note: Purge steam to clean steam nozzle after use, warning hot surface.
A. FOR THE FIRST USE
1. Move the coee maker from the package, and check the accessories
according to the list;
2. Clean all the detachable components;
3. Operation the appliance according to the section of “B” and “C” (no coee
powder in lter). Repeat 2-3 times.
B. MAKE ESPRESSO COFFEE
1. Open the lid, take out water tank, and pour appropriate water into tank.
Do not exceed the MAX capacity;
2. Put back the water tank and close the lid;
3. Connect power plug, press power button, then machine will automatically
pump water about 2s, and coee indicator and steam indicator always
light on, then coee indicator is ashing and the machine start preheating,
coee indicator will light on and then preheating nished after 2min;
4. Take out lter holder, pour appropriate coee powder into the lter with
coee spoon, then press the coee powder tightly;
5. Lock the lter holder into the group head;
6. Put cup(s) under coee outlet;
7. Start brewing by pressing coee button;
8. Remove lter holder, knock it out and clean it with hot water immediately,
and lock it again for next use.
Note: Check frequently the water level in the tank. Rell if necessary. Do not touch the hot
surfaces of the machine with hands, especially brewing outlet, steam nozzle when use
machine.

6 7
D. MAKE HOT WATER
1. Put a stainless steel container under steam nozzle;
2. Open knob after coee indicator always lights on, and then hot water is
ejected from the steam nozzle;
3. Close knob when the desired amount is reached.
Note: Check frequently the water level in the tank. Rell if necessary. Do
not touch the hot surfaces of the machine with hands, especially brewing
outlet, steam nozzle when use machine.
E. HEATING LIQUID
1. Use a stainless steel cup, pour cold liquid to 1/2 cup;
Note: Cup diameter should not less than 70 ± 5mm.
1. Press steam button, it start preheating, and steam indicator is ashing,
then wait for lamp lights on;
2. Put cup under steam nozzle;
3. Turn on the knob, release steam, let the steam nozzle is inserted into the
liquid;
4. Turn o the knob when the desired temperature is reached.
Note: When steam is stopped, clean the steam nozzle immediately, and
release the liquid in the pipe, to prevent the liquid scaling, because the
surface temperature of steam pipe is very high when in use, be careful not
to be scalded.
Coee Indicator Steam Indicator Cause Solution
Flashing Lights on Power on /
Flashing Lights o Pre-heating coee /
Lights on Lights o Coee Pre-heating
nished /
Lights o Flashing Pre-heating Steam /
Lights o Lights on Pre-heating
nished /
Flashing Lights o Temperature is too
high
Wait
temperature
naturally fall
or press coee
button boil
water to cooling
Flashing Flashing NTC is open circuit
or short circuit
Please contact
with the
authorized
service facility
for repairing.
Flashing Lights o Making coee for
too long
Turn o coee
button
Flashing Lights o Making hot water
too long
Turn o the
knob
Lights o Flashing Making coee for
too long
Turn o the
knob
*INDICATOR TIPS

8 9
Problem Cause/Result Solution
No water comes out
Water tank is empty Pour water in water tank
The input voltage or
frequency is inconsistent
with nameplate
Make sure the voltage and
frequency is consistent with
the nameplate
Machine malfunctions Please contact with the
authorized service
No steam is generated
Steam nozzle clogged Clean steam nozzle
Water tank is empty Pour water in water tank
Machine malfunctions please contact with the
authorized service
Coee runs out around the
edge of the lter holder
Too much coee in lter clean the lter, then pour
appropriate coee powder
There is coee in the seal
under group head
Clean the seal under group
head
Implementation of the
above operation problems
still exist
Please contact with the
authorized service
Coee comes out too slow
or no coee comes out
Coee powder is too ne,
and clogged lter With thicker coee powder
Filter holes are blocked Brush / clean the lter
Water tank is not inserted Insert the water tank in
place
Water leakage on the
bottom of machine
Drip tray is lled up Please clean the drip tray
Machine malfunctions Please contact with the
authorized service
Machine is not working
The power outlet is not
plugged well.
Please contact with the
authorized service
NTC is short circuit Plug the power cord into a
wall outlet correctly
Machine malfunctions Please contact with the
authorized service
The steam cannot froth.
Steam indicator is ashing Wait steam indicator lights
on.
The container is too big or
the shape is not t
Use high and narrow cup or
garland cup
Used skimmed milk Use whole milk
*TROULBE SHOOTING
*CLEAN AND MAINTENANCE
1. The machine has to be switched o and cooled down;
2. Clean housing with damp cloth;
Note: Do not use abrasive sponges and detergents or solvents.
Do not immerse the machine into water.
3. Clean steam outlet, conrm there is no blockage;
4. Brush the outlet and the seal under the group head;
5. Rinse with hot water to dissolve any coee bean oil residue;
6. Clean all the detachable attachments in the water and dry thoroughly.
*CLEANING MINERAL DEPOSITS
1. The machine builds up lime scale deposits over time, and you need
descale the machine 2-3 months;
2. Pour water and descale in water tank up to MAX capacity (water and
descale ratio is 4:1, follow the instruction of descale. Please use“household
descale”, or you can use the citric acid replace descale (water and citric acid
ratio is 100:3);
3. Lock the lter holder (no coee powder) into the group head. According to
part “B” MAKE ESPRESSO COFFEE;
4. Press coee button, then make about 150ml coee after coee indicator
always lights on, turn o coee button and turn on steam button, then
open knob after steam indicator always lights on, release steam about
2 min and turn o the knob, then make descales deposit in the machine at
least 15 min;
5. Repeat the steps 4 for 3 times;
6. Press coee button to brew coee until there is no descale left;
7. Make coee again(no coee powder), repeat the steps 4 for 3 times (no
need wait for 15 min), then brewing until no water is left in the boiler;
8. Repeat the step 7 at least 3 times to make sure the piping is cleanly.

10 11
*DISPOSAL
Please dispose of old machines in an environmentally neutral way.
Old machines contain valuable materials which should be salvaged
for recycling. Please therefore dispose of old machines via your
regional collection system.

12
BEANRUSH BEVERAGES PRIVATE LIMITED
Registered Office: A-3, Mezzanine Floor, Naraina Industrial Area, Phase-I,
New Delhi-II 0028
Contact No [phone] Email: [e-mail];
Website: www.myespressino.com
