Crux 14542 User manual

15-Bar Pump Espresso Maker
Instruction Manual
Styled for Life
Designed & Engineered in New York City

Important Safeguards.....................................................................................................................2
Additional Important Safeguards..............................................................................................4
Notes on the Cord ............................................................................................................................6
Notes on the Plug .............................................................................................................................6
Plasticizer Warning...........................................................................................................................6
Electric Power.....................................................................................................................................6
Guide to the Perfect Espresso ....................................................................................................7
Getting to Know Your CRUX 15 Bar Pump Espresso Maker ..........................................8
Before Using for the First Time ................................................................................................10
Brewing Fresh Espresso................................................................................................................ 11
Frothing Milk ..................................................................................................................................... 13
User Maintenance Instructions.................................................................................................. 15
Care & Cleaning Instructions ..................................................................................................... 15
Descaling ............................................................................................................................................ 16
Storing Instructions........................................................................................................................ 17
Recipes ................................................................................................................................................ 18
Troubleshooting.............................................................................................................................. 23
Warranty......................................................................................................................................24-25
Table of Contents

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surface. Use handles or knobs only.
3. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
4. Close supervision is necessary when any appliance is used
by or near children.
5. In order to minimize the risk of property damage, never place
the Espresso Maker under cabinets. Make sure the area several feet
above the Espresso Maker is clear from all furniture or cabinetry.
6. Do not open the water tank top lid while coffee is brewing.
Scalding may occur if the cover is lifted or removed during
the brewing cycle.
7. Do not use outdoors.
8. Unplug unit from outlet when not in use and before cleaning.
Allow unit to cool before putting on or taking off parts,
and before cleaning.
9. To protect against fire, electrical shock, do not immerse cord, plugs,
or appliance in water or other liquids.

3
10. Do not operate any appliance with a damaged cord or plug, or after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to the nearest authorized service facility for
examination, repair or adjustment.
NOTE: DO NOT ATTEMPT TO REPAIR THE UNIT YOURSELF.
THIS WILL VOID THE WARRANTY.
11. The use of accessory attachments not recommended by
the appliance manufacturer may result in fire, electric shock
or injury to persons.
12. Never move the appliance by pulling the cord. Do not let the cord
hang over the edge of a table or counter or touch hot surfaces.
13. Stand the appliance on a table or flat surface.
14. Never use your Espresso Maker without water in it.
15. Do not place appliance on or near a hot gas or electric burner
or in a heated oven.
16. Press the ON/OFF button on the side of the unit to turn the
appliance OFF. Unplug the power cord from the electrical outlet
when the appliance is not in use, left unattended, or when the
carafe is empty.
17. Do not use this appliance for other than its intended use.
18. To reduce the risk of fire, do not mount unit over or near any
portion of a heating or cooking appliance.
19. To reduce the risk of electric shock, do not mount over a sink.
20. To reduce the risk of fire, do not store anything directly on top of
the appliance surface when the appliance is in operation.

4
FOR HOUSEHOLD
USE ONLY
ADDITIONAL IMPORTANT
SAFEGUARDS
WARNING: This appliance generates heat and escaping steam during
use. Proper precautions must be taken to prevent the risk of burns,
fires, or other injury to persons or damage to property.
1. All users of this appliance must read and understand this Instruction
Manual before operating or cleaning this appliance.
2. The cord to this appliance should be plugged into a 120V AC
electrical outlet only.
3. Use water only in this appliance! Do not put any other liquids
or food products in this appliance. Do not mix or add anything
to the water placed in this appliance, except as instructed in
the User Maintenance Instructions to clean the appliance.
4. DO NOT attempt to move an appliance containing hot liquids.
Allow appliance to cool completely before moving.
5. Keep appliance at least 4 inches away from walls or other objects
during operation. Do not place any objects on top of appliance
while it is operating. Place the appliance on a surface that is
resistant to heat.

5
6. If this appliance begins to malfunction during use, immediately
unplug the cord. Do not use or attempt to repair
the malfunctioning appliance.
7. If this appliance falls or accidentally becomes immersed in water or
any other liquid, unplug it immediately. Do not reach into the water!
Do not use this appliance after it has fallen into or has become
immersed in water.
8. The appliance must be left to cool down sufficiently before adding
more water to avoid exposure to steam.
9. Always use fresh, cool water in your appliance. Warm water or
other liquids, except as listed in cleaning section, may cause
damage to the appliance.
SAVE THESE
INSTRUCTIONS

6
NOTES ON THE CORD
The provided short power-supply cord should be used to reduce the
risk resulting from becoming entangled in or tripping over a longer
cord. Do not use an extension cord with this product. Always plug
directly into a wall outlet/receptacle.
NOTES ON THE PLUG
This appliance has a grounded 3-prong plug. Connect to a properly
grounded outlet only. If the plug does not fit fully into the outlet,
contact a qualified electrician. Do not attempt to modify the plug
in any way.
PLASTICIZER WARNING
CAUTION: To prevent Plasticizers from migrating to the finish of
the counter top or table top or other furniture, place NON-PLASTIC
coasters or place mats between the appliance and the finish of the
counter top or table top. Failure to do so may cause the finish to
darken; permanent blemishes may occur or stains can appear.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.

7
Guide to the Perfect Espresso
Water
• Make sure to use clean, cold water when filling the removable water tank.
Water Flow
• If you are making an espresso, ensure that the water flows through the espresso filter at
the correct speed. If it is too slow, the espresso will be over extracted – too dark and
bitter, with a blotchy and uneven crema on top. If it flows too quickly, the espresso will
be under-extracted – the proper flavor won’t have had time to develop and there may
not be a crema or it will be thin and only around the edges.
• You can alter the water flow by adjusting the strength of your tamp or by changing the
coarseness of your grind. If the flow is too fast, press down firmly, or choose a finer
grind. If the flow is too slow, ease the pressure of your tamp or choose a coarser grind.
Coffee
• Grinding beans just before use will generate the optimum flavor. They can keep for
a very long time provided they are stored in an airtight container kept out of sunlight,
in a cool, dry spot.
Grind
• If using pre-ground espresso, make sure that you select a grind specifically
for espresso/cappuccino machines.
• If grinding the beans at home, make sure that you select a fine espresso grind.

8
Getting To Know Your 15-Bar Pump Espresso Maker
Product may vary slightly from illustration
1. Removable
Water Tank
2. Water Tank Handle
3. Warming Plate
4. Removable Drip Tray
5. Removable Drip Tray
Cover
6. Steam Wand
with removable
Frothing Tip
7. Filter Holder
8. Brew Head
10. ON/OFF Button
1
2
6
7
8
10
3
4
5
Fig. 1

9
Fig. 1a
Fig. 2
HEATING
READY
1. ESPRESSO/STEAM
Button
2. Function Control
Knob
3. STEAM position
4. OFF position
5. ESPRESSO position
6. Red HEATING
Indicator Light
7. White READY
Indicator Light
1. 1 Cup Filter
Basket
2. 2 Cup Filter
Basket
3. Filter Holder
with 2-Spout
Brew Head
4. Measuring
Spoon/Coffee
Tamp
Control Panel
Accessories
1
1 2 3
4
2
3
4
5
6
7

10
Before Using for the First Time
1. Before brewing your first cup of espresso, we suggest
you pre-clean the machine and prime the pump.
Place the Espresso Maker on a level surface.
2. Make sure the Espresso Maker is turned to the OFF position.
3. Grasp the water tank handle at the back of the Espresso
Maker and lift it up and off the unit. (See Figure 3.)
4. Fill the water tank to the MAX indicator line.
NOTE: Never fill the water tank past the MAX indicator line.
Ensure water level is above the MIN indicator line.
WARNING: Never operate the Espresso Maker without water
in the tank.
5. Replace the water tank to its original position. Fold the lid
and then the handle back over the water tank.
6. Place an empty (do not add coffee) 2-cup filter basket into
the filter holder. Insert and lock into the Espresso Maker
following the detailed description in the section: Brewing
Fresh Espresso.
7. Place a wide-mouth spouted container or cup under the 2-spout brew head.
8. Plug the unit into a 120V AC electrical outlet.
9. Brew 2 containers of water without coffee grounds, following the procedures outlined in
the Brewing Fresh Espresso section of this instruction manual. This will thoroughly clean
the unit.
10.Empty the container or cup and the water collected in the drip tray. You are now ready
to brew a delicious cup of fresh espresso.
MAX
MIN
Fig. 3

11
Pre-Warming Cups
For the optimal espresso temperature, it is recommended to warm the espresso cups.
Simply place them on the warming plate on top of the unit when the machine is in use.
Brewing Fresh Espresso
1. Press the ESPRESSO/STEAM button to the highest ESPRESSO position ( ).
2. Make sure the I/O button is in the OFF position (O) and the function control knob is
in the OFF ( ) position. Plug the Espresso Maker into a 120V AC electrical outlet.
All indicator lights should be OFF.
1. Grasp the water tank handle at the back of the Espresso Maker and lift it up
and off the unit. (See Figure 3.)
2. Fill the water tank with cold water. Never fill the water tank past the MAX indicator line.
Ensure water level is above the MIN indicator line.
3. Replace the water tank to its original position.
4. If the filter holder is locked into the Espresso Maker, grasp the handle firmly and turn it
to the left until the handle faces the ▲position to remove. The filter holder handle will
drop down and out of the Espresso Maker.
5. Place the 1 or 2 cup filter into the filter holder depending on how many shots of espresso
you would like.
Fig. 4
2 cup
filter
1 cup
filter
Fig. 5

12
6. To change or remove filter basket, line the notch in the filter holder with the indicator on
the 1 or 2 cup filter basket. (See Figure 4.) Pull basket up and out of the filter holder.
7. Use the measuring spoon to measure ground espresso coffee and add to the filter basket.
(See Figure 5.) Use the flat side of the measuring spoon to gently tamp the coffee and
pack it. Wipe any loose coffee grounds from the rim of the filter holder to assure a proper
fit into the Espresso Maker.
FOR BEST RESULTS: Use freshly ground MEDIUM to FINE (espresso) coffee.
8. Place the filter holder underneath the brew head so that the filter holder handle is aligned
with ▲ (See Figure 6.)
9. Turn handle to the right until the filter holder handle is facing front and lined up with the
LOCK () and it is securely locked. (See Figure 7.)
10.Place 1 or 2 espresso cups under the 2-spout brewing head.
11. Press the ON/OFF (I/O) button. The red HEATING indicator light will illuminate.
12. Make sure the ESPRESSO/STEAM button is in the highest ESPRESSO position ( ).
13. After approximately 2 minutes, the white READY light will illuminate. Turn the function
control knob to the Espresso position ( ) and 2 spouts of espresso will begin to flow
into the cup or cups
HEATING
READY

HEATING
READY

Fig. 6 Fig. 7

13
NOTE: To prepare cappuccino, refer immediately to the Frothing Milk section in this
instruction manual.
CAUTION: To avoid scalding or burns, do not remove the filter holder handle during
the brewing process, or when either the red HEATING or white READY indicator light is
illuminated.
14. When the desired amount of espresso coffee has been brewed, turn the function control
knob to the OFF position ( ). Coffee will cease dripping after several seconds.
15. Before removing the filter holder press the ON/OFF (I/O) button to OFF (O).
CAUTION: Make sure to turn the machine OFF when not in use, as this Espresso Maker will
continue to heat water under pressure until the water tank is empty
Frothing Milk
REMINDER: To avoid splattering and causing large, aerated bubbles, the frothing tip must
remain just under the surface of the milk.
IMPORTANT: When frothing milk, the volume of milk will double. The top portion will be
foam and the bottom portion will be milk.
1. Press the ESPRESSO/STEAM button to the lowest STEAM position ( ).
2. Make sure the water level in the water tank is above the MIN indicator line
3. Fill a short, wide metal pitcher or tall cup half full with fresh, cold milk and place it next to
the Espresso Maker.
4. Swing the steam wand to the side of the Espresso Maker. (See Figure 8.)
5. Press the ON/OFF (I/O) button if the unit is not already ON. The red HEATING indicator
light will illuminate.
6. Make sure the ESPRESSO/STEAM button is in the lowest STEAM position ( ).
7. After approximately 2 minutes the white READY light will illuminate.
8. Place the pitcher under the steam wand. The tip of the steam wand should be just below
the surface of the milk. Turn the function control knob to the STEAM position ( ).

14
9. Angle the metal pitcher or cup so that the tip of the steam wand is sitting right below
the surface of the milk. This will cause the milk to begin to create a whirlpool affect.
10.Then fully submerge the steam wand into the milk to continue to heat it up.
11. Once the pitcher or cup has fully heated, turn the function control knob to
the OFF position ( ).
12. Remove the pitcher from the steam jet.
13. Let the milk rest.
14. Wipe the steam wand with a damp cloth to clean.
15. Swing the steam wand so that it is facing towards the drip tray. Turn the function control
knob to the STEAM position ( ) once more. Let the steam run until a small amount of
water has run through the unit to fully clean out the steam wand of any excess milk.
NOTE: If you want to brew Espresso straight after frothing milk, make sure the ESPRESSO/
STEAM button is in the highest ESPRESSO position ( ). Turn the function control knob to
the Espresso position ( ) to run a small amount of water through the Brew Head for
a few seconds without the Filter Holder in place until the white READY light turns off.
This will prepare the system for optimal brewing temperature. Then follow the Brewing
Fresh Espresso instructions.
Having the ESPRESSO/STEAM button in the lowest STEAM position ( ) when brewing
Espresso could result in a burned coffee taste because of the required higher temperature
for steam.
HEATING
READY

HEATING
READY

Fig. 8 Fig. 9

15
User Maintenance Instructions
This appliance requires little maintenance. It contains no user-serviceable parts.
Any servicing requiring disassembly other than cleaning must be performed by
a qualified appliance repair technician.
Care & Cleaning Instructions
1. Always make sure Espresso Maker is unplugged and allow to cool before attempting
to clean. To avoid burns on fingers or hands, always make sure the POWER light is off.
NEVER touch the filter basket holder or steam wand immediately after brewing
or steaming. Allow all parts to cool thoroughly before touching.
2. To protect against electrical shock, do not immerse cord, plug or unit in water
or other liquid.
3. After every use, remove the filter holder and filter basket, discard used coffee grounds.
4. Wash the filter holder and filter basket in hot, sudsy water. The stainless steel filters
and filter holder should be rinsed under water immediately after use to remove all
coffee particles.
5. If necessary, clean the filter basket with a kitchen brush. A pin may be used to clear
clogged holes of either filter basket or the steam wand. Dry thoroughly.
6. The inside of the brew head should be wiped with a damp cloth to remove any coffee
particles
7. Remove the drip tray cover. Empty water or coffee from drip tray. Dry with a clean cloth.
8. Wipe the exterior of the Espresso Maker with a damp cloth to remove superficial stains.
For stubborn stains, use a nylon or plastic pad with a non-abrasive cleanser. Do not use
metal scouring pads or abrasive cleansers.
9. Dry and replace disassembled parts.

16
Descaling
Special cleaning of your Espresso Maker is recommended at least once a month, depending
on frequency of use and quality of water used in the unit. If water in your area is especially
hard, the following cleaning procedure should be performed every 2 weeks, since minerals in
water can detract from the flavor of the coffee and possibly lengthen brew time.
1. Before cleaning your Espresso Maker, make sure the function control knob is on the OFF
position ( ) and the appliance has been disconnected from the wall outlet.
2. Fill the water tank with 1 part white vinegar to 3 parts cold water.
3. Attach empty coffee filter basket and holder.
4. Place a large container under both the Group Head and the Steam Wand.
5. Plug the Espresso Maker into 120V AC electrical outlet. Make sure the ESPRESSO/STEAM
button is on the higher ESPRESSO position ( ).
6. Press the ON/OFF (I/O) button if the unit is not already ON. The red HEATING indicator
light will illuminate.
7. When the white READY indicator light turns on, turn the function control knob to the
ESPRESSO position ( ) and let half the mixture of white vinegar and water run through
the Group Head, then turn the function control knob to the OFF position ( ).8. Press the
ESPRESSO/STEAM button to the lowest STEAM position ( ). When the white READY
indicator light turns on, move the function control knob to the STEAM position
() and allow the remaining liquid to run through the Steam Wand to clean any residue
left in the tube from the milk steaming process, then turn the function control knob to
the OFF position ( ).
9. After decalcifying, remove the water tank and rinse thoroughly then re-fill with fresh
cold water.
10.Repeat above steps 2 or 3 times using cold water to rinse any residual vinegar.
11. Unplug the Espresso Maker from the wall outlet.

17
Storing Instructions
1. Unplug unit and allow to cool.
2. Store Coffee Maker in its box or in a cool, dry place.
3. Never store unit while it is still plugged in.

18
Recipes
Cappuccino
Makes 1 serving (3.5 oz)
• 2 ounces milk
• 1 measured scoop of finely ground espresso or 1 espresso pod
• Cinnamon (optional)
Make sure the I/O button is in the OFF position (O) and the function control knob is in the
OFF position ( ). Plug the Espresso Maker into a 120V AC electrical outlet. All indicator
lights should be OFF. Grasp the water tank handle at the back of the Espresso Maker and
lift it up and off the unit. Fill the water tank with cold water and replace it to its original
position. Place the 1 cup filter into the filter holder. Use the measuring spoon to measure
1 scoop of ground espresso coffee and add to the filter basket. Use the flat side of the
measuring spoon to gently tamp the coffee and pack it. Wipe any loose coffee grounds
from the rim of the filter holder to assure a proper fit into the Espresso Maker. Place the
filter holder underneath the brew head. Turn handle into locked position.
Place an espresso cup under the brewing head. Press the ON/OFF (I/O) button to the
ON (I) position. The red HEATING indicator light will illuminate. Press the ESPRESSO/
STEAM button to the highest ESPRESSO position ( ).
Wait until the white READY light illuminates. Turn the function control knob to the
ESPRESSO position ( ) and 2 spouts of espresso will begin to flow into the cup.
When the desired amount of espresso coffee has been brewed, or if water has stopped
flowing, turn the function control knob to the OFF position ( ).
Fill a short, wide metal pitcher or tall cup with 2 ounces of fresh, cold milk. Swing the steam
wand to the side of the Espresso Maker. Press the ESPRESSO/STEAM button to the lowest
STEAM position ( ). After approximately 2 minutes the white READY light will illuminate.
Place the pitcher under the steam wand. The steam wand should be submerged in the milk.
Turn the function control knob to the STEAM ( ) position.
Move the pitcher in a slightly circular motion to froth the milk. After frothing, remove the
pitcher from the steam jet. Spoon 2-3 tablespoons of steamed milk on top of the espresso.
Sprinkle cinnamon on top as desired.
Enjoy
