Becker MAP PILOT User manual

Instructions for use
Becker® MAP PILOT

1
>>> SAFETY MESSAGE HIERARCHY
> USE
> FR
> ES
Safety message hierarchy
This manual uses the following types of
safety messages to draw your attention to
important safety and other information
for use of the Becker® MAP PILOT.
Please review the symbols and content of
the boxes below. The information in the
DANGER, WARNING, CAUTION
and NOTICE boxes describes the poten-
tial consequence associated with disre-
garding the messages throughout the
manual. The information in the NOTE
boxes relates to use of the Becker® MAP
PILOT.
DANGER
The warnings contain safety information
regarding hazardous situations, which if
not avoided, will result in death or seri-
ous injury.
WARNING
These warnings contain safety informa-
tion regarding hazardous situations
which, if not avoided, could result in
death or serious injury.
CAUTION
These warnings contain safety informa-
tion regarding hazardous situations
which, if not avoided, could result in mi-
nor or moderate injury.
NOTICE
These warnings contain information re-
garding items or situations which may
cause damage to the unit or vehicle if dis-
regarded, information regarding unit
warranties and/or information pertinent
to traffic laws.
Note:
This provides information regarding use
of the unit.

2
CONTENTS >>>
> USE
> FR
> ES
Safety message hierarchy 1
Contents 2
Safety information 4
The Becker® MAP PILOT 6
Usage 6
Unpacking the Becker®
MAP PILOT 6
Checking the delivery 6
Delivery contents 6
Complaints 7
Dealing with the packaging 7
Description of unit 7
Battery 7
USB connecting cable 7
Map update/Additional functions 7
Registration 8
Repairs 8
Emissions and disposal 8
General operation 9
Maintenance and care 9
Battery quality declaration 10
Commissioning 10
Power supply 10
Memory card 10
Unit holder 11
Basic operation 11
Calling up navigation mode 11
Selecting/highlighting elements 11
Back function 12
Delete function 12
Menu basics 12
Main menu 12
Using the input menu 13
Entering characters 13
Selecting from a list 14
Selecting a character set/
special characters 14
Switching between upper and
lower case 14
Malfunctions 15
Content Manager Becker®
MAP PILOT 15
Installing the Content Manager
Becker® MAP PILOT 15
Starting the Content Manager 16
Navigation mode 17
What is navigation? 17
Last destinations 18
Using last destinations 18
Starting with existing destination 18
Displaying or editing a destination 18
Home address 19
Destination input 20
Structure of the destination input
menu 20
Entering an address 20
Selecting a country 21
Selecting a state/province 21
Selecting an address and starting
route guidance 21
Entering an address using speech 25
Points of interest 27
POI nearby/POI near destination 27
POI near address 28
Entering a POI directly by name 28
Entering a POI directly by phone
number 29
Selecting a destination from the map 29
Coordinate entry 29
Route planning 30
Creating a new route 31
Editing a route 32
Traffic announcements using TMC 32
Displaying TMC messages 33
Reading a message 33
Displaying the relevant road in
the map 33
Taking announcements into
consideration when calculating routes 34
Automatic recalculation 34
Manual recalculation 34
The map display 35
Calling up the map display 35
Structure of the map display 35
Map display without route guidance 35
Map display with route guidance 36
Split screen with route guidance 37
Route guidance with arrow display 37
Using the map display 38
Map zooming 38
Contents

3
>>> CONTENTS
> USE
> FR
> ES
Map toolbox 38
Route guidance 38
Canceling route guidance 38
Entering/deleting a stopover 39
Setting route options 39
Skipping a destination 39
Muting announcements 39
My Route 39
Displaying the entire route 40
TMC on the route 40
Point of interest on the route 41
Block ahead 42
Map display 43
Position display 44
Repeating an announcement 45
Settings 46
Route guidance settings 46
Route options 46
Reality view 47
Signposts 47
Lane recommendations 47
Announcements 48
Map settings 48
Autozoom 48
POIs on the map 48
Speed limits 49
Driver alerts 49
TMC settings 50
System settings 50
Language 50
Design variants 51
Pin protection 51
Map update reminder 51
Information 51
Factory reset 52
Glossary 53
Index 54
NOTICE 56
FCC Information 56
The type approval 56
CE declaration of conformity 57
Disposal 57
Disposal of the battery 58
Duty to supply information according
to battery legislation (BattV) 58
Removing the battery 58 The information and data contained in
this document is subject to change with-
out notice.
No part of this document may be repro-
duced or transmitted for any purpose
without the prior written permission of
HARMAN/BECKER Automotive
Systems GmbH. All technical data, draw-
ings etc. are protected by copyright law.
© Copyright 2012, HARMAN/BECKER
Automotive Systems GmbH
All rights reserved.

4
SAFETY INFORMATION >>>
> USE
> FR
> ES
Safety information
WARNING
• The unit may only be operated if the traffic situation permits and if you are absolutely certain that you, your fellow
passengers or other road users will not be put at risk, encumbered or distracted by it. This unit should not be used as a
substitute for the personal judgment of the driver.
• Applicable traffic regulations must be observed at all times. Destinations may only be input when the vehicle is stationary.
• The unit may only be used for its intended purpose. The volume of the navigational unit should be set so that noises
outside the vehicle can still be heard.
• The SD memory card can be removed. Small children could swallow it.
• Insufficient attention to the road, traffic controls or traffic conditions may result in traffic accidents. Accordingly, the
driver should not operate the unit while he/she is driving.

5
>>> SAFETY INFORMATION
> USE
> FR
> ES
NOTICE
• The navigational system is only an aid. The data/details provided may in some cases be incorrect. The driver must always
decide whether or not to follow the directions given. We accept no liability for incorrect details issued by the navigational
system. As a result of traffic routing changes and deviating data, inaccurate or incorrect instructions may be given. Drivers
should always pay attention to the actual road signs and traffic conditions. In particular, the navigational system cannot
be used as a means of orientation in cases of poor visibility.
• The unit should be switched off immediately if faults occur (e.g. development of smoke or smells).
• For safety reasons, the unit may only be opened by a specialist. Please refer to your dealer for repair.
• Never open the unit (with the exception of the battery compartment) or the rechargeable battery. Any modification to
the unit is also impermissible and renders the type approval invalid.
• Use only genuine Harman original accessories. This will ensure that all the relevant regulations are complied with and
damage to health and property is avoided. Dispose of defective units and the rechargeable battery according to the
applicable legal requirements.
• No warranty is granted in the case of improper use. These safety instructions also apply to genuine Harman original
accessories.

6
THE BECKER® MAP PILOT >>>
> USE
> FR
> ES
The Becker® MAP PILOT
Usage
The Becker® MAP PILOT is a high-per-
formance navigation module for use in
Mercedes-Benz vehicles. The Becker®
MAP PILOT can be used with the op-
tional equipment "Prefitting for Becker®
MAP PILOT" and "Becker® MAP
PILOT (incl. prefitting).
The unit and the accessories are to be pro-
tected against moisture and dirt.
With GPS = Global Positioning System
you no longer have to waste time looking
up road maps.
Your Becker® MAP PILOT is equipped
with TMC. TMC gives you the option of
receiving traffic announcements. You will
then be informed of any traffic problems.
The system plans an alternative route au-
tomatically or on request to avoid traffic
problems, depending on the setting.
Unpacking the Becker® MAP
PILOT
Checking the delivery
Before starting up the Becker® MAP
PILOT, the delivery contents must be
checked to ensure they are complete and
in good order.
>Carefully unpack the packaging con-
tents and check them.
Delivery contents
Becker® MAP PILOT
Leaflet with installation instructions
USB cable
Note:
Your Becker® MAP PILOT is delivered
in stable packaging. If the packaging or
its contents exhibit serious damage, the
unit must not be unpacked further. In
this case, please contact your dealer.
23
1
1
2
3

7
>>> THE BECKER® MAP PILOT
> USE
> FR
> ES
Complaints
Please check first on www.beckermappi-
lot.com (FAQs, software updates) for pos-
sible solutions. If this should not lead to
success, please contact your dealer.
Dealing with the packaging
The original packaging must be kept in a
dry place at least for the warranty period.
Description of unit
The Becker® MAP PILOT consists of the
basic Becker® MAP PILOT unit and the
supplied accessories in the delivery con-
tents.
Battery
The integrated rechargeable battery is
charged when the Becker® MAP PILOT
is placed in the holder and the vehicle ig-
nition is switched on.
USB connecting cable
You can connect the Becker® MAP
PILOT to a standard personal computer
having a USB interface using the USB
connecting cable provided. The 8 GB
flash memory of the Becker® MAP
PILOT and any SD card can then be ad-
dressed via the PC like a removable stor-
age medium.
Map update/Additional func-
tions
The road network is constantly changing,
but having a fresh map ensures you have
the wealth of information you need to
find your destination with ease.
It is also possible that in the course of fur-
ther development of your device new
functions will be available.
With the program described under “Con-
tent Manager Becker® MAP PILOT” on
page 15 you can easily keep your Becker®
MAP PILOT up to date.
Note:
It must be disposed of correctly in line
with the national regulations. The pack-
aging must not be burnt. The packaging
can be handed over to the dealer, depend-
ing on the country where delivered.
NOTICE
The basic unit and the accessories must
not be opened or modified in any way.
Note:
When the Becker® MAP PILOT is con-
nected to a PC, it is supplied with power
via the PC and does not consume battery
power.

8
THE BECKER® MAP PILOT >>>
> USE
> FR
> ES
Registration
You can register your product using our
software service. We will then inform you
of any new updates and other news.
You can register online on the Becker
homepage www.beckermappilot.com.
The “Map and Software update” menu
item is located under “Service”.
Repairs
The unit must not be opened in the event
of damage. Please contact your dealer.
Emissions and disposal
Information on emissions, electromagnet-
ic compatibility and disposal can be found
in “NOTICE” on page 56.

9
>>> GENERAL OPERATION
> USE
> FR
> ES
General operation
Maintenance and care
The unit is maintenance-free.
For proper care, a commercially available
cleansing fluid for electrical devices may
be applied using a soft damp cloth.
Your unit was designed and manufactured
with great care and should be treated with
equal care. You will enjoy your unit for a
long time to come if you observe the rec-
ommendations listed below:
• Protect your unit and the accessories
from water and moisture. If your unit
has been exposed to moisture, switch it
off immediately and disconnect the
power supply. Allow to dry at room
temperature.
• Do not store and operate your unit in a
dusty or dirty environment.
• Do not store your unit in hot environ-
ments. High temperatures can shorten
the service life of electronic components
in your unit, damage the rechargeable
batteries and cause certain plastics to
warp or melt.
• Do not store your unit in cold environ-
ments. During operation, when the
unit warms up to operating tempera-
ture, moisture may form internally,
causing damage to electronic compo-
nents.
• Do not drop your unit, protect it from
shocks and do not shake it. Improper
handling can damage components
within the unit.
• Never use corrosive or aggressive chem-
icals, cleaning solutions or aggressive
detergents for cleaning.
All the above information applies equally
to the unit, the rechargeable battery and
all accessories. Should one of these parts
not work properly, please contact your au-
thorised dealer.
DANGER
Danger to life by electrocution. Always
switch off the unit and disconnect the
mains power supply unit before clean-
ing the unit, supplied components or ac-
cessories.
Note:
Do not use any aggressive or abrasive
substances or cloths which may damage
the surface.
The unit must not be exposed to water.
