Beckhoff CU8110-0060 User manual

Manual | EN
CU8110-0060
Uninterruptible Power Supply (Capacitive)
2024-01-23 | Version: 1.0

Table of contents
CU8110-0060 3Version: 1.0
Table of contents
1 Notes on the documentation....................................................................................................................5
1.1 Representation and structure of warnings ........................................................................................6
1.2 Documentation issue status ..............................................................................................................7
2 Safety .........................................................................................................................................................8
2.1 Intended use .....................................................................................................................................8
2.2 Staff qualification...............................................................................................................................8
2.3 Safety instructions.............................................................................................................................8
3 Transport and storage ............................................................................................................................10
4 Product overview ....................................................................................................................................11
4.1 Structure..........................................................................................................................................11
4.2 Name plate......................................................................................................................................12
4.3 Block diagram .................................................................................................................................13
4.4 Holding times ..................................................................................................................................14
5 Interfaces .................................................................................................................................................15
5.1 USB 2.0 interface (X101) ................................................................................................................15
5.2 Power supply (X102).......................................................................................................................16
6 Commissioning .......................................................................................................................................17
6.1 Assembly.........................................................................................................................................17
6.1.1 Fastening to the DIN rail .................................................................................................. 18
6.1.2 Installing the mounting plate (optional) ............................................................................ 19
6.2 Power supply...................................................................................................................................20
6.3 Communication ...............................................................................................................................22
6.3.1 Connection via UPS-OCT ................................................................................................ 22
6.3.2 Connecting additional devices ......................................................................................... 23
6.3.3 Connection via USB .........................................................................................................24
6.3.4 Connection via digital I/O ................................................................................................. 25
7 Configuration...........................................................................................................................................26
7.1 Install UPS software........................................................................................................................26
7.2 System behavior .............................................................................................................................27
7.3 UPS configuration dialogs...............................................................................................................30
7.3.1 Device configuration dialog .............................................................................................. 31
7.3.2 Alarm configuration dialog................................................................................................ 33
7.4 Configuring the UPS .......................................................................................................................36
7.5 TwinCAT interface...........................................................................................................................38
7.5.1 FB_GetUPSStatus ...........................................................................................................38
7.5.2 ST_UPSStatus .................................................................................................................40
7.5.3 E_BatteryStatus ...............................................................................................................43
7.5.4 E_UpsCommStatus.......................................................................................................... 43
7.5.5 E_UpsPowerStatus .......................................................................................................... 44
8 Error handling and diagnostics .............................................................................................................45
9 Care and maintenance............................................................................................................................46
10 Decommissioning ...................................................................................................................................47

Table of contents
CU8110-00604 Version: 1.0
10.1 Dismantling the UPS .......................................................................................................................47
10.2 Disposal ..........................................................................................................................................48
11 Technical data .........................................................................................................................................49
12 Appendix..................................................................................................................................................51
12.1 Accessories.....................................................................................................................................51
12.2 Support and Service........................................................................................................................52

Notes on the documentation
CU8110-0060 5Version: 1.0
1 Notes on the documentation
This description is intended exclusively for trained specialists in control and automation technology who are
familiar with the applicable national standards.
For installation and commissioning of the components, it is absolutely necessary to comply with the
documentation and the following notes and explanations.
The qualified personnel is always obliged to use the currently valid documentation.
The responsible staff must ensure that the application or use of the products described satisfies all safety
requirements, including all the relevant laws, regulations, guidelines, and standards.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without notice.
No claims to modify products that have already been supplied may be made on the basis of the data,
diagrams, and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, TwinCAT/BSD®, TC/BSD®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®,
Safety over EtherCAT®, TwinSAFE®, XFC®, XTS® and XPlanar® are registered and licensed trademarks of
Beckhoff Automation GmbH.
If third parties make use of designations or trademarks used in this publication for their own purposes, this
could infringe upon the rights of the owners of the said designations.
Patents
The EtherCAT Technology is covered by the following patent applications and patents, without this
constituting an exhaustive list:
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702
and similar applications and registrations in several other countries.
EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The distribution and reproduction of this document, as well as the use and communication of its contents
without express authorization, are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event that a patent, utility
model, or design are registered.

Notes on the documentation
CU8110-00606 Version: 1.0
1.1 Representation and structure of warnings
The following warnings are used in the documentation. Read and follow the warnings.
Warnings relating to personal injury:
DANGER
Hazard with high risk of death or serious injury.
WARNING
Hazard with medium risk of death or serious injury.
CAUTION
There is a low-risk hazard that can result in minor injury.
Warnings relating to damage to property or the environment:
NOTICE
There is a potential hazard to the environment and equipment.
Notes showing further information or tips:
This notice provides important information that will be of assistance in dealing with the product or
software. There is no immediate danger to product, people or environment.

Notes on the documentation
CU8110-0060 7Version: 1.0
1.2 Documentation issue status
Version Modifications
1.0 First version.

Safety
CU8110-00608 Version: 1.0
2 Safety
Read the chapter on safety and follow the instructions in order to protect from personal injury and damage to
equipment.
Limitation of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Unauthorized modifications and changes to the hardware or software configuration, which go
beyond the documented options, are prohibited and nullify the liability of Beckhoff Automation GmbH & Co.
KG.
In addition, the following actions are excluded from the liability of Beckhoff Automation GmbH & Co. KG:
• Failure to comply with this documentation.
• Improper use.
• Assignment of untrained personnel.
• Use of unauthorized replacement parts.
• Use of the devices in a damaged condition.
2.1 Intended use
The CU8110-0060 UPS is intended for mounting on a DIN rail in an industrial control cabinet or terminal box.
Alternatively, the UPS can be equipped with a mounting plate and mounted on the rear panel of the control
cabinet. The UPS supports in particular Industrial PCs, Embedded PCs, Panels and Panel PCs in case of
voltages fluctuations or failures and this way ensures a safe shutdown of the system.
The UPS has been developed for a working environment that satisfies protection class IP20. This involves
finger protection and protection against solid foreign objects up to 12.5 mm, but not protection against water.
Operation of the devices in wet and dusty environments is not permitted. The specified limits for electrical
and technical data must be adhered to.
The CU8110-0060 UPS is maintenance-free. The energy module (EDLC) does not need to be replaced even
after several decades.
Improper use
The UPS is not suitable for operation in the following areas:
• Potentially explosive atmospheres.
• In areas with an aggressive environment that is enriched, for example, with aggressive gases or
chemicals.
• Living areas. In living areas, the relevant standards and guidelines for interference emissions must be
adhered to, and the devices must be installed in housings or control boxes with suitable attenuation of
shielding.
2.2 Staff qualification
All operations involving Beckhoff software and hardware may only be carried out by qualified personnel with
knowledge of control and automation engineering. The qualified personnel must have knowledge of the
administration of the Industrial PC and the associated network.
All interventions must be carried out with knowledge of control programming, and the qualified personnel
must be familiar with the current standards and guidelines for the automation environment.
2.3 Safety instructions
Follow the safety instructions for protection against injuries and prevention of damage to equipment or
property.

Safety
CU8110-0060 9Version: 1.0
Assembly
• Never work on live equipment. Always switch off the power supply for the device before installation,
troubleshooting or maintenance. Protect the device against unintentional switching on.
• Avoid polarity reversal of the data and supply cables, as this may cause damage to the equipment.
• Observe the relevant accident prevention regulations for your machine (e.g. the BGV A 3, electrical
systems and equipment).
• Note the temperature limit values for operation. If the UPS is operated outside of these temperature
limit values, electrolyte can escape, heat up or in the worst case explode.
• The UPS location must be adequately ventilated. In case of a fault, the UPS can release flammable
gases that could cause an explosion.
• Do not store the UPS in an airtight container or bag. The battery pack can release gases that could
explode if the UPS is kept in an airtight enclosure.
• If you come into contact with electrolyte, rinse the affected body part immediately with water.
Firefighting
Extinguish the battery pack with dry powder, halon or CO2.
• Do not extinguish with water.
• Disconnect the power supply.
• During firefighting wear self-contained respiratory protective equipment and protective clothing.
• Air the room after you have extinguished the UPS.
Safety labels on the UPS
The following safety labels are attached to the name plate of the UPS:

Transport and storage
CU8110-006010 Version: 1.0
3 Transport and storage
NOTICE
Short circuit due to moisture
Moisture can form during transport in cold weather or in the event of large temperature fluctuations. Leave
the device to adjust to room temperature slowly. If condensation has occurred, wait at least 12 hours before
switching on the device.
Transport
Despite the robust design of the unit, the components are sensitive to strong vibrations and impacts.
Therefore, during transport please protect your device from:
• mechanical stress and
• use the original packaging.
Table1: Dimensions and weight
CU8110-0060
Dimensions (W x H x D) 50 mm x 100 mm x 90 mm
Weight approx. 425g
Storage
Observe the following storage conditions, in order to maintain the service life of the UPS:
• Store the UPS at room temperature or below.
• Do not store the UPS in a dusty environment, at high humidity or in location with strong vibrations.

Product overview
CU8110-0060 11Version: 1.0
4 Product overview
UPS-OCT availability
UPS-OCT should be available from Q2 2024 (new hardware required).
The CU8110-0060 is a capacitive uninterruptible power supply (UPS) based on double-layer capacitors
(EDLC) with a maximum energy of 0.3 Wh and a maximum power output of max. 55W.
In the event of a fault or the failure in the 24 V DC input voltage, the UPS takes over the supply of power to
the connected devices with a controlled and buffered 24 V DC output voltage. All Beckhoff components or
components from third parties, especially industrial PCs, embedded PCs, panels and panel PCs, can be
equipped with the CU81xx UPS series. The UPS has a total of two 24-V outputs. In addition to the industrial
PC, a panel or terminal segment can be supplied with uninterrupted power on the second output.
OCT (One Cable Technology), USB 2.0, and digital signals are available for communication between the
UPS and the industrial PC. A special feature of OCT is that the connecting lines (+24 V, 0 V) between the
industrial PC and UPS are used not only to supply power to the industrial PC, but also for bidirectional,
modulated data transmission.
4.1 Structure
3
4
1
2
Fig.1: Structure of a CU8110-0060 UPS.
Table2: Key for the structure.
No. Component Description
1Power supply (X102)
[}16].
Interface for power supply to the UPS (Uin) and the devices being
supported (U1out and U2out). The wiring is done via a 9-pin push-
in connector.
2Control inputs and control
outputs (X102) [}16].
Interface for digital control inputs (UPS EN, P SHDN) and digital
status outputs (UPS RDY, P FAIL).
3USB 2.0 interface (X101)
[}15].
Communication interface between UPS and industrial PC for
devices without UPS-OCT. Status queries, device status, or
shutdown are possible.
4Diagnostic LED [}45] Indicate the state of the input voltage, output voltage, and errors.

Product overview
CU8110-006012 Version: 1.0
4.2 Name plate
Fig.2: Name plate example.
Table3: Information on the name plate.
No. Description
1 Model designation of the UPS.
2 Serial number for the unambiguous identification of the product.
3 Date of manufacture.
4 Maximum power consumption and power output of the UPS.
5 UPS capacity.
6 Hardware and software version.
7 Power supply 24VDC.
8 CE approval.
9 Machine-readable information in the form of a Data Matrix Code (DMC, code scheme
ECC200) that you can use for better identification and management.

Product overview
CU8110-0060 13Version: 1.0
4.3 Block diagram
The block diagram for the CU81xx UPS is described in this chapter. The input voltage Uin typically comes
from a single-phase (230V) or three-phase (400V) AC power supply, the secondary side of which provides
the 24 V DC operating voltage for the UPS. The charging electronics takes the energy for charging the
energy carrier, i.e. the batteries or capacitors, from this input voltage. The charging electronics ensures that
all parameters of the energy carrier (e.g. maximum charge or discharge currents, temperatures, minimum
energy) remain within the permitted limits.
Fig.3: CU81x0-x00x block diagram.
If the input voltage is at least 24V -15% (20.2V), the UPS, which is connected between the AC power
supply and the load to be supported, always supplies at least 24V at the output due to a step-up converter.
If the input voltage drops below this value, operation is switched to UPS mode and the output is supplied by
the energy storage device (UPS mode). The UPS then continues to supply exactly 24V. In the case of an
input voltage from 24V to 24V+20% (28.8V), this is present directly at the output due to the bypass
circuit. If the input voltage exceeds the threshold of 28.8V, a transition to UPS mode takes place in order to
protect the end devices. At the same time, an overvoltage warning is output. Therefore, less than 24V and
more than 28.8V can never be present at the UPS output.
The complete control of the UPS is handled by the central UPS controller, which orchestrates the interaction
of all other microcontrollers (UPS-OCT communication, charge controller).

Product overview
CU8110-006014 Version: 1.0
4.4 Holding times
Table4: Capacity and switch-off times at different discharge currents.
Discharge current [A] Time to switch-off [s] Usable energy [Wh]
0.25 155 0.26
0.5 86 0.29
0.75 57 0.29
1 45 0.30
1.25 35 0.29
1.5 30 0.30
1.75 24 0.28
2 22 0.29
2.25 19 0.29
2.5 17 0.28
0
20
40
60
80
100
120
140
160
0,25 0,5 0,75 1 1,25 1,5 1,75 2 2,25 2,5
Hold-up time [s] = f( ) [A]Output current
Fig.4: Hold time without temperature and ageing effects.
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,25 0,5 0,75 1 1,25 1,5 1,75 2 2,25 2,5
Withdrawable e y = f(nerg [Wh] ) [A]Output current
Fig.5: Usable energy without temperature and ageing effects.

Interfaces
CU8110-0060 15Version: 1.0
5 Interfaces
5.1 USB 2.0 interface (X101)
The USB interface is a communication interface between the UPS and Industrial PC. Die USB interface can
be used especially by devices without UPS-OCT. These include, for example, older Beckhoff Industrial PCs
but also components supplied by third-party providers.
Fig.6: USB 2.0 interface X101.
The USB interface is of type B and corresponds to the USB 2.0 specification.
Table5: USB interface (X101), PIN assignment.
Pin Connection Typical assignment
1 VBUS Red
2 D- White
3 D+ Green
4 GND Black
Shell Shield Drain Wire

Interfaces
CU8110-006016 Version: 1.0
5.2 Power supply (X102)
Fig.7: Power supply X102.
To supply the CU81x0 UPS, two 9-pin connectors with push-in connection are used. For the 9-pin
connectors, cables with a cross-section of 0.5 mm² to 1.5 mm² or AWG20 to AWG16 are required. With
cable end sleeve max. 1 mm2 or AWG 17 are permissible.
Table6: Power supply X102, connection on left side.
No. Pin Description
1 Uin,
0V,
PE
+24 V DC input, power supply for UPS.
2 U1out,
0V,
PE
+24 V DC UPS output with UPS-OCT support, interface for the
device being supported.
3 U2out,
0V,
PE
+24 V DC UPS output, interface for a second device being
supported e.g. control panel (display).
The U1out and U2out interfaces together must not exceed the maximum output current of the UPS.
Table7: Power supply X102, right-hand connection.
No. Pin Description
4 UPS RDY,
0V,
PE
+24V DC output. This output is switched to 24V when the UPS
charging is above a set threshold (e.g. 80 %).
5 P FAIL,
0V
+24 V DC output for power-fail-signal. This output is switched
to 24 V if the power supply fails or if P SHDN is activated. This
output can be connected with the PC_ON input on a Beckhoff
Industrial PC or any PLC input.
6 NC
NC
Reserved.
7 UPS EN +24 V DC input. A falling edge from 24 V to 0 V signals the
UPS to switch off the outputs U1out and U2out immediately.
This input can be connected with the PC_STATUS output on a
Beckhoff Industrial PC or any PLC output.
8 P SHDN +24 V DC input. A rising edge from 0V to 24V at this input
triggers an immediate shutdown of the operating system. If
there is 24V at P_SHDN on startup, the PC will first be started
with a falling edge from 24V to 0V.

Commissioning
CU8110-0060 17Version: 1.0
6 Commissioning
6.1 Assembly
48,8 87,8
100
65,5
Fig.8: CU8110-0060 dimensions.
48,8
100
83
115
39
M4
Fig.9: CU8110-0060 with mounting plate (optional), dimensions.

Commissioning
CU8110-006018 Version: 1.0
6.1.1 Fastening to the DIN rail
For optimal dissipation of heat, mount the UPS horizontally in the control cabinet on a DIN rail. The housing
is designed so that the UPS can be held against the DIN rail and snapped onto it.
Requirements:
• DIN rail of the type TS35x15 2.3 according to EN 60715.
Fasten the UPS to the DIN rail as follows:
1. First, place the UPS against the lower edge of the DIN rail.
2. Tilt the upper part of the UPS towards the DIN rail.
3. Lightly press the UPS against the DIN rail and upwards.
1
2
ðAs soon as you press the UPS upwards, the lower springs of the DIN rail adapters give way. In this
manner, the UPS can be attached on the upper edge of the DIN rail.
4. Attach the UPS to the upper edge of the DIN rail.
ðYou have successfully mounted the UPS. Check again that the mounting is correct and that the UPS is
engaged on the DIN rail.

Commissioning
CU8110-0060 19Version: 1.0
6.1.2 Installing the mounting plate (optional)
In this chapter, we show you how to install a mounting plate on the UPS. With the mounting plate, the UPS
can subsequently be fastened to the rear panel of a control cabinet. To do this, the two DIN rail adapters and
the grounding springs on the rear side of the UPS have to be dismounted. The mounting plate is not included
in the scope of delivery (see: Accessories [}51]).
Requirements:
• C9900-M675 mounting plate made of black anodized aluminum.
• Screwdrivers.
Install the mounting plate as follows:
1. Loosen the six M4 screws and remove the DIN rail adapter.
2. Loosen the M3 screws and remove the grounding springs from the UPS.
3. Fasten the mounting plate to the rear panel of the UPS with four M4 screws.

Commissioning
CU8110-006020 Version: 1.0
6.2 Power supply
An external power supply unit is required for the supply of power to the UPS, which provides a 24V DC
voltage (-15% / +20%). Connect the external power supply unit to the Uin input of the UPS.
Fig.10: Schematic wiring of a CU8110-0060 UPS.
The cabling of the UPS in the control cabinet must be done in accordance with the standard EN
60204-1:2006 PELV = Protective Extra Low Voltage:
• The "PE" and "0 V" conductors of the voltage source for a UPS must be on the same potential
(connected in the control cabinet).
• Standard EN 60204-1:2006, section 6.4.1:b stipulates that one side of the circuit, or a point of the
energy source for this circuit must be connected to the protective earth conductor system.
Selecting the appropriate power supply unit
Dimension the power supply unit according to the maximum power consumption of the connected devices
including the current consumption when charging the UPS. For example, if a CX9020 with a power
consumption of 5W (= 0.21A) is connected, the calculation looks as follows: 0.21A + 2.2A = 2.41A. In this
calculation example, at least a 2.41A power supply unit is required for the CX9020.
Table8: Technical data, electrical currents and internal fuses.
Technical data CU8110-0060
Current consumption
during charging (without
load)
max. 2.2A
Output current max. 2.5A
Fuse (internal, input) electronic 10A
Fuse (internal, output) electronic 3A
