Behringer XENYX 1002B User manual

Premium 10-Input 2-Bus Mixer with
XENYX Preamps, British EQs and
Optional Battery Operation
Premium ultra-low noise
analog mixer with optional
battery operation
2 state-of-the-art XENYX Mic
Preamps comparable to
stand-alone boutique preamps
Neo-classic “British” 3-band EQs
for warm and musical sound
Optional battery operation
(with 9 V alkaline batteries)
allows for mobile operation
4 balanced, high-headroom stereo
inputs with 3 additional mic inputs
One FX send and one Monitor send
per channel for external FX devices
and monitor applications
Clip LEDs on all channels and
dedicated inserts on all
mono channels
Main output plus separate
Phones and CD/Tape outputs
Switchable phantom power for
condenser microphones
Long-wearing 60-mm logarithmic-
taper master fader and sealed
rotary controls
External power supply for
noise-free audio and superior
transient response
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
State-of-the-Art Goes Portable
Whether you plug it into the
wall or power it via 9 V batteries,
the XENYX 1002B comes equipped
with many of the features you’ve
come to expect from our larger mixers,
including XENYX mic preamps for
amazing sound quality, phantom
power for use with professional-grade
condenser mics, 2-Track inputs and
outputs, and 60 mm faders. The four
stereo channels accept left/right or
mono ¼" TRS/TR inputs, and three of
them also accommodate microphones
(with separate Trim controls).
The compact XENYX 1002B mixer also
features our highly musical 3-band
British EQ, plus an FX and monitor send
for each channel, making it a must-have
for any audio toolkit.
Superior mic preamps
The XENYX 1002B represents a
signicant milestone in the development
of mixer technology. Equipped with our
premium XENYX mic preamps, it can
easily hold its own against the most
expensive stand-alone mic preamps,
both in terms of sound quality and
available headroom. XENYX preamps
oer a staggering 130 dB of dynamic
range, with a bandwidth that extends
from below 10 Hz to well above 200 kHz.
XENYX mic pres provide such transparent,
crystal-clear performance you just might
think someone upgraded your mics.
Continued on next page
XENYX 1002
Small Format Mixers

Page 2 of 4
2-TRACK RCA
outputs to Tape/CD/
MD recording decks
PAN control
sets signal
placement in
stereo image
MID EQ control
adjusts midrange
content, ± 15 dB
@ 2.5 kHz
Sublimely musical British EQ
The British consoles of the 1960s and
‘70s changed the sound of rock and roll—
without them the British Invasion might not
have happened. Those legendary mixing
desks soon became the envy of engineers
and producers all over the world. The 3-band
EQ on the XENYX 1002B mixer is based
on that very same circuitry, allowing you
to imbue signals with incredible warmth
and detailed musical character. Even when
applied generously, these equalizers exhibit
sweet forgiveness and superb audio quality.
Applications and value
Don’t let the small footprint fool you—
the XENYX 1002B is built to the same
exacting standards as our larger-format
XENYX mixers and is housed in an equally
rugged steel chassis. It is the ideal choice
for keyboardists who need to mix down
multiple instruments or sound modules for
live or recording applications. Singers who
perform with backing tracks, as well as
instrumentalist/singers (acoustic guitar
or piano bar, for example) nd the
XENYX 1002B indispensable for patching
into “house” systems.
Field Operation
Its compact size and exible input
scheme also make it the natural choice
of sports announcers for calling play-by-play
game action. Likewise, radio and
TV reporters especially like the XENYX 1002B
for its ease-of-use, remarkable delity and
rugged reliability. And the 9 V battery option
allows newscasters and correspondents to
use the 1002B in remote locations where
power is hard to come by. (Two 9 V alkaline
batteries are required for normal operation,
three for phantom power).
From its state-of-the-art XENYX mic
preamps to its highly musical British-style
EQ and user-friendly layout, the XENYX
1002B is the solid leader for value and
sonic integrity in its class.
Stereo channel
Left and
Right inputs
INS (Insert) jack
provides path
to/from external
eects device
MIC Input
balanced
XLR socket
FX control sets
amount of
signal sent to FX
Send output
MON control
sets amount of
signal sent to
monitor(s)
LOW EQ control
adjusts bass
content, ± 15 dB
@ 80 Hz
LINE IN ¼" TRS
and TS jacks
LINE TRIM
adjusts level
of ¼" inputs
TRIM control
sets level of
input signal
HIGH EQ control
adjusts high
frequency content,
± 15 dB @ 12 kHz
Head phones
jack
Main outputs
2-TRACK ¼" &
RCA inputs from
Tape/CD/
MP3 decks
FX Send
output
Monitor Send
output
Phantom power
switch
MONITOR SEND
level control
FX SEND
level control
PHONES level
control
MAIN output
level fader
Stereo
channels
XENYX 1002

Page 3 of 4
Studio Monitors HPS5000
Rackmount Synth
FX Processor
Laptop
USB Audio Interface
Recording Setup
Field Recording Setup
UCA222
USB Audio Interface
UL2000M
Wireless Mic
Laptop
HPS3000
Electric
Guitar
Bass
Guitar
DI100
B412DSPDrum Machine
UCA222
USB Audio Interface
Laptop
F1220A Active Monitor Speaker
XM1800S
HPS3000
Live Performance
XENYX 1002

Page 4 of 4
For service, support or more information contact the BEHRINGER location nearest you:
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss
which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fullfillers and resellers only.
Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,
Tortola, BritishVirgin Islands. 985-10000-00392
Specications
Input Channels 1 & 2
Mic input electronically balanced,
discrete input conguration
Frequency response 10 Hz to 200 kHz
Gain range +14 dB to +60 dB
SNR 120 dB E.I.N.
Line input electronically balanced
Frequency response 10 Hz to 130 kHz
Gain range -6 dB to +38 dB
SNR 95 dB E.I.N.
Stereo Channels 3/4 - 7/8 & 9/10
Frequency response 10 Hz to 70 kHz
Gain range Line: -∞ to +15 dB
Mic: +13 to +60 dB
SNR Line: 96 dB / Mic: 104 dB E.I.N.
Equalization
LOW 50 Hz, +/- 15 dB
MID 700 Hz, +/- 15 dB
HI 10 kHz, +/- 15 dB
Main Mix
Main Outputs +28 dBu balanced,
+22 dBu unbalanced
Mon Send +22 dBu unbalanced
FX Send +22 dBu unbalanced
Tape Out +22 dBu unbalanced
Phones Output +15 dBu / 150 Ω
Power Supply
Mains voltage
USA/Canada 120 V~, 60 Hz,
Power Supply MXUL4
U.K./Australia 240 V~, 50 Hz,
Power Supply MXUK4
Europe 230 V~, 50 Hz,
Power Supply MXEU4
Japan 100 V~, 50 - 60 Hz,
Power Supply MXJP4
Battery life approx. 4 h
(with Duracell Alkaline Type MN1604/580 mAh)
Physical
Dimensions approx. 2.875 x 11.75 x 8.5"
(H x W x D) approx. 73 x 298 x 216 mm
Weight approx. 6.1 lbs/approx. 2.77 kg
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
XENYX 1002
