Behringer EURORACK MXB1002 User manual

Version 1.0 March 2001
Technical Specifications
ENGLISH
www.behringer.com
EURORACK® MXB1002

2
EURORACK MXB1002
MXB1002
EURORACK®
Professional 10-channel mixing console with optional batter operation and monitor plus effects paths
s10-channel mi ing console with two mono channels, three stereo channels and a separate stereo tape
channel
sOptional mains or battery operation (with alkaline batteries)
sSeparate gain controls for mic and line inputs on all stereo channels
sGold-plated XLR mic connectors on all mono and stereo channels
sUltra low-noise, discrete mic preamplifiers on all microphone inputs
sDedicated inserts on all mono channels
sBalanced 1/4" stereo jacks and balance controls on all stereo channels
sSeparate stereo tape channel with 1/4" and RCA jacks
sStereo output for recording applications
sUltra-musical, active 3-band EQ on all ten channels
sMonitor and effects paths as well as separate gain controls on all channels
sHigh-grade-sealed faders and potentiometers made by ALPS
sClip-LEDs on all input channels
sInsert option for e ternal effects devices
sMon Send and FX Send controls in the main section for optimal level adjustment
sHeadphones output with dedicated volume control
sBuilt-in phantom power for condenser mics
s19" rack-mounting kit included
sE tremely rugged construction ensures long life even under the most demanding conditions
sManufactured under ISO9000 certified management system

3
EURORACK MXB1002
SPECIFICATIONS
INPUT CHANNELS 1 & 2
Mic input electronically balanced, discrete input configuration
Frequency response 10 Hz to 200 kHz
Gain range +14 dB to +60 dB
SNR 120 dB E.I.N.
Line input electronically balanced
Frequency response 10 Hz to 130 kHz
Gain range -6 dB to +38 dB
SNR 95 dB E.I.N.
STEREO CHANNELS 3/4 - 7/8 & 9/10
Frequency response 10 Hz to 70 kHz
Gain range Line: -oo to +15 dB / Mic: +13 to +60 dB
SNR Line: 96 dB / Mic: 104 dB E.I.N.
EQUALIZATION
LOW 50 Hz, +/- 15 dB
MID 700 Hz, +/- 15 dB
HI 10 kHz, +/- 15 dB
MAIN MIX
Main Outputs +28 dBu balanced / +22 dBu unbalanced
Mon Send +22 dBu unbalanced
FX Send +22 dBu unbalanced
Tape Out +22 dBu unbalanced
Phones Output +15 dBu / 150 W
POWER SUPPLY
Mains voltage USA/Canada 115 V ~, 60 Hz, Power Supply MXUL4
U.K./Australia 240 V ~, 50 Hz, Power Supply MXUK4
Europe 230 V ~, 50 Hz, Power Supply MXEU4
Japan 100 V ~, 60 Hz, Power Supply MXJP4
Battery life app. 4 h (with Duracell* Alkaline Type MN1604 / 580 mAh)
PHYSICAL
Dimensions (H * W * D) app. 1 5/8" (40 mm) / 2 7/8" (73 mm) * 11 3/4" (298 mm) * 8 1/2" (216 mm)
Weight app. 2.5 kg (PSU not included)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to e isting products without further notice. Specifications and appearance may differ from those listed or shown.
