Behringer DYNAMICS COMPRESSOR DC9 User manual

Thank you for showing your condence in us by purchasing the BEHRINGER DYNAMICS COMPRESSOR DC9.
This ultimate eects pedal is specically designed to give a stable dynamics and an endless sustain to your
guitar by evening out the signal without degrading the original sound. You can also use the DC9 to boost
the overall volume of your instrument for solo parts.
A compressor limits the dynamic range of a signal by attenuating signal peaks exceeding a certain threshold level.
The amount of gain reduction is determined by the compression ratio. The result of compression is an attenuation
of the dierence between loudest and softest playing which achieves a more powerful and punchy tone.
1. Controls
(1) The SENSITIVITY control determines the compression ratio. The higher you set the
SENSITIVITY value, the more the compression intensies. In other words, as you increase
the SENSITIVITY, you reduce the level dierence between softest and loudest playing.
(2) The OUTPUT control adjusts the output level. Use it to compensate the gain reduction resulting
from the compression or to boost the output level of your instrument.
(3) The LED illuminates when the eect is activated. It also serves as a battery level indicator.
(4) Depress the footswitch to activate/deactivate the eect.
(5) Use this ¼" TS IN connector to plug in the instrument cable.
(6) The ¼" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
To install or replace the 9 V battery, remove the bottom side of the unit taking the four screws o.
◊ The DC9 has no on/o switch. As soon as you connect the jack to the in connector, the DC9
is switched on. When the DC9 is not being used, remove the jack from the in to extend
the battery life.
The SERIAL NUMBER is located on the bottom side of the device.
(2)
(6)
(1)
(5)
(3)
(4)
DYNAMICS COMPRESSOR DC9
Classic Dynamics Compressor

DYNAMICS COMPRESSOR DC9
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGEWITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE
MUSIC GROUP (MUSIC-GROUP.COM). ALLTRADEMARKS ARETHE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS
WHICH MAY BE SUFFERED BY ANY PERSONWHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.
COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS
ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR
IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM
OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUTTHE EXPRESS
WRITTEN PERMISSION OF MUSICGROUPIPLTD. ALL RIGHTS RESERVED. © 2012 MUSICGroupIPLtd.Trident Chambers,Wickhams Cay, P.O. Box 146, Road Town,
Tortola, British Virgin Islands
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories.
Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,
especially when power supply cord or plug is damaged.
3. Warranty
Please register your new BEHRINGER equipment right after your purchase by visiting
http://behringer.com and read the terms and conditions of our warranty carefully.
4. Specications
In
Connector ¼" TS
Impedance 1 M
Out
Connector ¼" TS
Impedance 1 k
Power Supply
9 V 𝌂 , 100 mA regulated
BEHRINGER PSU-SB
USA/Canada 120 V~, 60 Hz
Europe/U.K./ 230 V~, 50 Hz
Australia
China/Korea 220 V~, 50/60 Hz
Japan 100 V~, 50/60 Hz
Power connector 2 mm DC jack,
negative center
Battery 9 V type 6LR61
Power consumption 9 mA
Physical/Weight
Dimensions approx. 2 ⁄ x 4 ⁄ x 2 ⁄"
(H x W x D) approx. 56 x 113 x 69 mm
Weight approx. 0.53 lbs / 0.24 kg
BEHRINGER is constantly striving to maintain the
highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing
products without prior notice. Specifications and appearance
may therefore differ from those listed or shown.
