Beko DH 8534 CSRX User manual

DH 8534 CSRX
Dryer
User Manual
2960311990_EN/251218.1612
EN

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product.
We hope that your product which has been
manufactured with high quality and technology
will give you the best results. We advise you
to read through this manual and the other
accompanying documentation carefully
before using your product and keep it for
future reference. If you transfer the product
to someone else, give its manual as well. Pay
attention to all details and warnings specified
in the user manual and follow the instructions
given therein.
Use this user manual for the model indicated on
the cover page.
• Read the instructions.
Explanation of symbols
Throughout this user manual the following
symbols are used:
BDANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
AWARNING!
• Warning for hazardous situations with regard
to life and property.
This product was manufactured using the latest technology in environmentally friendly conditions.
WARNING!
• Warning against hot surfaces.
WARNING!
• Warning against scalding hazard.
CNOTE
• Important information or useful hints about
usage.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging wastes with
the domestic waste or other wastes, discard
them to the dedicated collection points
designated by the local authorities.

3
Dryer / User Manual
1 Important instructions for safety and environment
CNOTE
• This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
1.1 General safety
AWARNING!
The dryer can be used by children
at and above 8 years old and by
persons whose physical, sensory
or mental capabilities were not fully
developed or who lack experience
and knowledge provided that they
are supervised or trained on the
safe usage of the product and the
risks it brings out. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
Children of less than 3 years should
be kept away unless continously
supervised.
• Adjustable feet should not be
removed. The gap between the
dryer and the floor should not be
reduced with materials such as
carpet, wood and tape. This will
cause problems with the dryer.
AWARNING!
Always have the installation and
repairing procedures carried
out by the Authorized Service.
Manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorized persons.
• Never wash the dryer by spraying
or pouring water onto it! There is
the risk of electric shock!
For the products with a steam
function:
AWARNING!
• Use only distilled water or water
condensed in the water tank of the
machine in steam programs. Do
not use mains water or additives.
When using condensed water in the
water tank, it should be filtered and
cleared of fibres.
• Do not open the door when steam
programs are running. Hot water
may be expelled.
• Before putting laundry in a steam
program, stains on it should be
removed.
• You may only put laundry that is not
dirty or stained but permeated with
unpleasant odour in steam (odour
removal) program.
• Do not use any dry cleaning sets
or additional materials in a steam
program or in any program.

4 Dryer / User Manual
1.1.1 Electrical safety
BDANGER!
• Electrical safety instructions
should be followed while electrical
connection is made during the
installation.
• The appliance must not be
supplied through an external
switching device, such as a timer,or
connected to a circuit that is
regularly switched on and off by
utility.
• Connect the dryer to a grounded
outlet protected by a fuse at the
value specified on the type label.
Have the grounding installation
performed by a qualified electrician.
Our company shall not be liable for
any damages that will arise when
the dryer is used without grounding
in accordance with the local
regulations.
• The voltage and allowed fuse
protection is stated on the type label
plate.
• The voltage specified on the type
label must be equal to your mains
voltage.
• Unplug the dryer when it is not in
use.
• Unplug the dryer from the mains
during installation, maintenance,
cleaning and repair works.
• Do not touch the plug with wet
hands! Never unplug by pulling
on the cable, always pull out by
grabbing the plug.
BDANGER!
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Power cable plug must be easily
accessible after installation.
• Damaged mains cable should be
changed notifying the Authorized
Service.
• If the dryer is faulty, it must not be
operated unless it is repaired by an
authorized service agent! There is
the risk of electric shock!
1.1.2 Product safety
DANGER!
• Superheating of the clothes inside
of the dryer can occur if you cancel
the programme or in the event of
a power failure whilst the dryer is
running, this concentration of heat
can cause self-combustion and fire
so always activate the ventilation
programme to cool down or quickly
remove all laundry from the dryer in
order to hang them up and dissipate
the heat.

5
Dryer / User Manual
DANGER!
Points to be taken into
consideration for fire hazard:
Below specified laundry or items
must not be dried in the dryer
considering fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone,
alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or
paraffin removers must be washed
in hot water with plenty of detergent
before being dried in the dryer.
For this reason especially the items
containing the above specified
stains must be washed very well,
to do this use adequate detergent
and choose a high washing
temperature.
Below specified laundry or
items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads.
Clothing cleaned with industrial
chemicals.
Items such as lighter, match,
coins, metal parts, needle etc. may
damage the drum set or may lead
to functional problems. Therefore
check all the laundry that you will
load into your dryer.
Never stop your dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to dissipate the
heat.
DANGER!
• Clothes that are washed
inadequately may ignite on their
own and even may ignite after
drying ends.
• You must provide enough ventilation
in order to prevent gases exiting
from devices operating with other
types of fuels including the naked
flame from accumulating in the
room due to the back fire effect.
AWARNING!
• Underwear that contains metal
reinforcements should not be dried
in the dryer. Dryer may be damaged
if metal reinforcements come loose
and break off during drying.
CNOTE
• Use softeners and similar products
in accordance with the instructions
of their manufacturers.
Always clean the lint filter before or
after each loading. Never operate
the dryer without the lint filter
installed.

6 Dryer / User Manual
AWARNING!
• Never attempt to repair the dryer
by yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others’ lives in
danger.
• There must not be a lockable, sliding
or hinged door that may block the
opening of the loading door in the
place where your dryer is to be
installed.
• Install your dryer at places suitable
for home use. (Bathroom, closed
balcony, garage etc.)
• Make sure that pets do not enter the
dryer. Check the inside of the dryer
before operating it.
• Do not lean on the loading door of
your dryer when it is open, otherwise
it may fall over.
• The lint must not be allowed to
accumulate around the tumble dryer
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
• Fabric softeners, or similar products.
should be used as specified by the
fabric softener instructions.
• Exhaust air must not be discharged
into a flue which is used for
exhausting fumes from appliances
burning gas or other fuels.
1.2 Mounting over a washing machine
• A fixing device should be used between
the two machines when installing the
dryer above a washing machine. The
fitting device must be installed by the
authorized service agent.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms. Place
the products on a solid floor that has
sufficient load carrying capacity!
AWARNING!
• Washing machine cannot be placed on
the dryer. Pay attention to the above
warnings during the installation on your
washing machine.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm < 50 cm
54 cm Can be installed Cannot be
installed
60 cm Can be installed Cannot be installed
1.3 Intended use
• Dryer has been designed for domestic
use. It is not suitable for commercial
use and it must not be used out of its
intended use.
• Use the dryer only for drying laundry that
are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect usage
or transportation.
• The service life of the dryer that you
purchased is 10 years. During this period,
original spare parts will be available to
operate the dryer properly.
1.4 Child safety
• Packaging materials are dangerous for
the children. Keep packaging materials
away from children.

7
Dryer / User Manual
• Electrical products are dangerous for the
children. Keep children away from the
product when it is operating. Do not let
them tamper with the dryer. Use the child-
proof lock in order to prevent the children
to tamper with the dryer.
CNOTE
Child-proof lock is on the control panel.
(See Child lock)
• Keep loading door closed even when the
dryer is not in use.
1.5 Compliance with the WEEE
regulation and disposing of the waste
product
This product complies with EU
WEEE Directive (2012/19/EU). This
product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be reused and
are suitable for recycling. Do not dispose of
the waste product with normal domestic and
other wastes at the end of its service life. Take
it to the collection center for the recycling of
electrical and electronic equipment. Please
consult your local authorities to learn about
these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 58,9 cm
Capacity (max.) 8 kg**
Net weight (± 4 kg) 44 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading
door.
CNOTE
• Technical specifications of the dryer are
subject to specification without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.

8 Dryer / User Manual
2 Your Dryer
2.1 Overview
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In models where the tank is placed below,
the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the
tank is placed above)
11. Power cord
2.2 Package Contents
1. Water
drain
hose *
5. Drying
basket
user
manual*
2. Filter
drawer
spare
sponge*
6. Water
Filling
Container*
3. User
Manual
7. Pure
Water*
4. Drying
basket*
8.
Fragrance
Capsules
Group*
*Optional - may not be included, depends on
model.
3 Installation
Before the calling the nearest Authorized
Service for the installation of the dryer, ensure
that electrical installation and water drain is
appropriate referring to the user’s manual.
If they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
CNOTE
• Preparation of the dryer’s location
as well as the electrical and waste
water installations is under customer’s
responsibility.
AWARNING!
• Prior to installation, visually check if the
dryer has any defects on it. If the drier
is damaged, do not have it installed.
Damaged products cause risks for your
safety.
• Let your dryer wait for 12 hours before
starting to use it.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer will

9
Dryer / User Manual
be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall
be placed against a wall.
BDANGER!
Do not place the dryer on the power cable.
3.2 Removing the transportation
safety assembly
AWARNING!
• Remove the
transportation
safety assembly
before using the
dryer for the first
time.
• If the door swing
side of your
appliance can
be modified, see
the reversible
door mounting
instructions.
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining the
water collected in the water tank.
Connecting the water drain hose
1
3 4
2
1-2 Pull hose at
the behind of
the dryer by
hand in order
to disconnect
it from where it
is connected.
Do not use
any tools to
remove the
hose.
3Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose of
the product in previous step.
4Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
CNOTE
• Water drain hose should be attached to a
height of maximum 80 cm.
• Make sure that the water drain hose is not
stepped on and it is not folded between
the drain and the machine.
• If there is an accessories pack supplied
with your product, please see the detailed
description.
3.4 Adjusting the feet
• Turn the feet to
left or right until
the dryer stands
level and firmly.
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
AWARNING!
• We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.6 Warnings about sounds
CNOTE
• It is normal to
hear a metallic
noise from the
compressor
sometimes during
operation.
• Water collected during operation is
pumped to water tank. It is normal to
hear pumping noise during this process.
3.7 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this
lamp is to assist the user to place laundry in
the tumble dryer in a comfortable way. The
lamps used in this appliance have to withstand
extreme physical conditions such as vibrations
and temperatures above 50 °C

10 Dryer / User Manual
4 Preparation
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying
in a dryer and make sure that you select the
appropriate programme.
Do not dry with
dryer
At high
temperature
At medium
temperature
At low
temperature
4.2 Laundry not suitable for drying in
the dryer
CNOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dries earlier than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
• For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• Clean the filter periodically when there
is visible air collection on it or when the
symbol lights up, if there is a filter drawer
cleaning warning symbol available.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating.
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry Approximate
weights (g)* Laundry Approximate
weights (g)*
Cotton
quilt covers
(double)
1500 Blouses 150
Cotton quilt
covers (single) 1000 Cotton shirts 300
Bed sheets
(double) 500 Shirts 250
Bed sheets
(single) 350 Cotton dresses 500
Large
tablecloths 700 Dresses 350
Small
tablecloths 250 Jeans 700
Tea napkins 100 Handkerchiefs
(10 pieces) 100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.

11
Dryer / User Manual
5 Operating the product
5.1 Control Panel
1 2
45678
3
1. Program Selection button
2. Display
3. On-Off button
4. Start/Stand-by button
5. End Time button
6. Time Programs Adjusting button
7. Audio Warning Level button
8. Dryness Settings Selection button
5.2 Screen symbols
Volume up
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Filter drawer /
Heat exchanger
cleaning
End/anti-
creasing
On/O Timer
Delay
Drying Cupboard
Dry
Iron Dry
Express
14’
Delicates
Jeans BabyProtect Extra dry Cupboard
dry plus
Sport Freshen Up
Start
pause
cancel
Cottons
Synthetics
Mix
Express
30’
Drying Rack/
TimeDry
Daily Bedding
Duvet/
DownWear
Express
Shirt 30'
Wool Refresh Hygiene
(BabyProtect+)
Shirts Cottons Eco
Refreshment

12 Dryer / User Manual
5.3 Preparing the dryer
Plug in the tumble dryer
Open device door.
Place the laundry into the tub in a slight loosely.
Close the door by pushing.
CNOTE
• Make sure there is nothing door and the
device while closing the door.
Press and hold On/Off/Cancel button for
1 second.
• When dryer is used for the first time,
declaration program (cupboard dry
cottons) is selected.
CNOTE
• Program doesn’t start immediately only
by pressing the On/Off/Cancel button.
Start the program with the On/Off/Cancel
button after program selection.
5.4 Program selection
Your dryer has 16 different programs.
Mix
Mix
Verluchten
Rafraîchir
Hemden 30’
Chemises 30’
• Select the desired program by turning the
program selection button..
• Displayed program selection and
consumption chart are based on sorting
by preferences of majority of users.
Rem aining time indicator*
Clean filter drawer warning symbol
Filter cleaning warning symbol Child lock warn in g sym bol
Clo set - dry
Wat er t an k warn in g sym bol
End t im e
An t i- crease
End of cycle
Start/hold sym bol
Steam symbol
Dryness level
Iron-dry
* Tim e displayed indicat es t h e rem ain in g t im e t o t h e end of t h e cycle and t h is
t im e varies as per t h e hum idit y of t h e laundry.
Buzzer level sym bol

13
Dryer / User Manual
5.5 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg) Spin speed in washing machine (rpm) Drying Time (minutes)
Cottons Iron Dry
You may dry your cotton laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
8 1000 150
Cottons Eco
You may dry all your cotton laundry in this
program. (T-shirt, pants, pyjamas, baby clothes,
underwear, linen, etc.) You can put your laundry in
the wardrobe without ironing.
8 1000 209
Cottons Cupboard Dry
You may use this program for extra dryness in
thick laundry such as pants, tracksuit. You can put
your laundry in the wardrobe without ironing.
8 1000 219
Cottons Extra Dry
You may dry your thick cotton laundry in this
program such as towels, bathrobe, etc. You can
put your laundry in the wardrobe without ironing.
8 1000 229
Synthetics Iron Dry
You may dry your synthetic laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
4 800 55
Synthetics Cupboard Dry
You may dry all your synthetic laundry in this
program. (Shirt, T-shirt, underwear, tablecloth,
etc.) You can put your laundry in the wardrobe
without ironing.
4 800 75
Drying Rack/ TimeDry
You may select from time programmes between
10 and 160 minutes to achieve the desired drying
level at low temperature. In this programme,
tumble drier’s operation lasts for the set time
independently from the dryness of laundry. This
product is available to be used with a drying
basket as option. For products that are sold
without a basket, you can obtain a basket from an
authorized service and use the drying programs
specified above. For details of use, see the drying
basket user guide.
- - -
Refresh (Wool Refresh)
Ventilates for 10 minutes without blowing hot air.
You can ventilate the cotton and linen clothes
that have been enclosed for a long time with this
program to remove their odour. You can use this
program to ventilate and soften wool laundry that
can be washed in a washing machine. Do not use
for full drying.
- - 10
Delicates
You may dry your delicate laundry or laundry with
hand wash symbol (silk blouses, thin underwear,
etc.) at low temperature in this program.
1,5 1200 65
Jeans You may dry denim pants, skirts, shirts or jackets
in this program. 4 1200 130
Outdoor/Sports (Goretex)
Use it to dry your clothes made of synthetics,
cotton or mixed fabrics or waterproof products
such as functional jacket, raincoat etc. Turn them
inside out prior to drying.
2 1000 135

14 Dryer / User Manual
Mix(Daily)
You can dry both cotton and synthetic laundry with
this programme.Sports and fitness clothes may be
dried with this program.
4 1000 125
Gentle Care / Shirts It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing. 1,5 1200 50
Hygiene (BabyProtect+)
It is a long-term program that you can use for the
clothes (baby clothes, towels, underwear, etc.
cotton) you require hygeine. Hygiene is provided
with high temperature. It is especially suitable for
durable fabrics.
5 800 215
Bedding/Feather
You can dry your feather or fibre filled textile that
bears can be dried in drier label as a single piece
of laundry. You can dry king size quilt, pillow or
coats as single piece of laundry. Dry your cloths
such as coats and jackets turned inside out.
- 800 165
Express Super Short Use this program to have 2 shirts ready for ironing. 0,5 1200 30
Energy consumption values
Programmes Capacity (kg)
Spin speed in washing
machine (rpm)
Approximate amount of
remaining humidity
Energy consumption value
kWh
Cottons Eco * 8 1000 60% 1,48
Cottons Iron dry 8 1000 60% 1,15
Synthetics cupboard dry 4 800 40% 0,51
Contains fluorinated greenhouse gases. Hermetically sealed R450a / 0,36 kg - GWP:604 - 0,217
tCO2e
“Cottons Eco programme” used at full and partial load is the standard drying programme
to which the information in the label and the fiche relates, that this programme is suitable for
drying normal wet Cottons laundry and that it is the most efficient programme in terms of
energy consumption for Cottons.

15
Dryer / User Manual
Volume level low
Volume level high
Dryness settings selection
Dryness settings button is used for
adjusting to desired dryness. Program time
may change depending on the selection.
CNOTE
• You can activate this function only prior to
start of program.
CNOTE
• When the program ends for not having
wrinkles on your delicate laundry, take out
your laundry immediately and hang them.
CNOTE
• To get better results from drying machine
programs, your laundry should be washed
with suitable program in your washing
machine and wrung with recommended
wringing speed.
• Shirt might remain slightly damp at the end
of the program. It is recommended not to
leave the shirts inside the drying machine.
* : Energy Label standard program (EN
61121:2012)
All the values on the chart are identified
according to EN 61121:2012 standard.
Consumption values may vary from the
valued in the chart depending on laundry
type, wringing speed, ambient conditions and
voltage levels.
5.6 Auxiliary functions
Audible warning
Machine makes an audible warning when
the program is completed. To adjust the sound
level, use the Sound Warning Level button.
CNOTE
• You can change the sound level before
the program starts or while the program
continues..

16 Dryer / User Manual
Drying level damp
Drying level normal
Drying level extra
5.7 Warning symbols
CNOTE
• Warning symbols may vary depending on
the model of your machine.
Fibre filter cleaning
When the program is completed, the warning
symbol for filter cleaning turns on.
CNOTE
• For detailed information, See 6
Maintenance and cleaning.
• If filter cleaning symbol constantly flashes
See.7 Troubleshooting.
Emptying the water tank
When the program is completed, the warning
symbol to empty the water tank turns on.
CNOTE
• For detailed information, See 6
Maintenance and cleaning.
If the water tank fills up while the program
continues, the warning symbol starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning symbol turns off and program
resumes.
Cleaning the filter drawer
Warning symbol flashes periodically to remind
that filter drawer must be cleaned.
CNOTE
• For detailed information, See 6
Maintenance and cleaning.
Loading cover is open
If loading cover of the dryer is open while
drying, Stand-by symbol turns on and program
progress symbol flashes.
End time
You can delay the end time of the program up
to 24 hours with end time function.

17
Dryer / User Manual
• Open the loading door and place the
laundry.
• Select drying program, spin cycle and if
needed, additional functions.
• Press the End Time selection button and
set the delay time you wish. End Time
symbol turns on. (When pressed and hold
the button, End Time proceeds non-stop).
• Press the Start / Stand-by button. End
time countdown starts and Start symbol
turns on. “:” Separator in the middle of
displayed delay time flashes.
CNOTE
• You can add or remove laundry within
end time. End Time symbol will turn off at
the end of countdown, drying starts and
duration of program is displayed. Displayed
time is the sum of normal drying time and
end time.
Changing the end time
If you want to change the duration during the
countdown:
• Press the On/Off/Cancel button for 3
seconds to cancel the program. Turn on
the machine again and repeat the Delay
Setting process for the duration you wish.
• When your machine is turned on for the
first time, it turns on with the declaration
program (cotton wardrobe dry).
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
• Press the On/Off/Cancel button for 3
seconds to cancel the program.
• Press the On/Off/Cancel button to start
you previously selected program.
5.8 Starting the program
Press the Start/Stand-by button to start the
program.
Indicating start of the program, Start symbol
turns on, “:” separator in the middle of
remaining time keeps flashing. Program
Progress Symbol turns on.
5.9 Program progress status
5.10 Child Lock
The machine has a child lock which prevents
the program flow from being interrupted when
the buttons are pressed during a program. To
activate the child lock
• Press and hold time programs and audio
warning buttons for 3 seconds.
• When the child lock is activated, the lock
symbol on the screen turns on.
• When the child lock is activated, all
buttons on the panel except the On/
Off/Cancel and Child Lock buttons are
deactivated.
• When the child lock is activated, indicator
symbols don’t change if the position of
Program Selection button is changed.
When Program Selection button is turned
and function buttons are pressed, the
letters “CL” flashes on the screen.

18 Dryer / User Manual
• The child lock has to be deactivated to
be able to start a new program after the
current program is finished or to be able
to interfere with the program.
To Deactivate The Child Lock:
• Press and hold the child lock button for 3
seconds.
• Child lock deactivates when the dryer is
turned off and on by the On/Off/Cancel
button.
5.11 Changing the program after it is
started
You can change the program you selected to
dry your laundry with a different program after
the machine starts running.
• For example, to select Extra Dry instead
of Iron Dry, pause the program by
pressing the Start / Stand-by button.
• Select the Extra Dry program using the
Program Selection button.
• Press the Start/Stand-by button to start
the program.
Adding and removing clothes during
stand-by
• If you want to add or remove clothes
to/from the machine after the drying
program starts:
• Press the Start/Stand-by button to put
the machine in Stand-by state. The drying
operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.
CNOTE
• Adding laundry after the drying operation
starts may cause the dried laundry inside
the machine to mix with wet laundry and
leave the laundry damp at the end of
operation.
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases program duration and energy
consumption. So, it is recommended to
add laundry before the program starts.
• If a new program is selected by turning the
program selection knob while the machine
is in stand-by; the running program
terminates and new program information is
displayed on the screen.
WARNING!
• Do not touch the inner surface of the drum
while adding or removing clothes during a
continuing program. The drum surface is
hot.
5.12 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any
reason after the machine starts running,
keep the On/Off/Cancel button pressed
for 3 seconds.
AWARNING!
• The inside of the machine shall be
extremely hot when you cancel the
program during machine operation, so run
the ventilation program to allow it to cool
down.

19
Dryer / User Manual
5.13 End of program
When the program ends, the Fibre Filter
Cleaning and Water Tank warning symbols
on the program observation indicator turn on.
Loading door may be opened and machine
becomes ready for another run.
To turn off the machine, press the On/Off/
Cancel button.
CNOTE
• Wrinkle Prevention function activates the 2
hour-Wrinkle Prevention program if laundry
isn’t taken out of machine after completion
of the program.
• Clean the fibre filter after each drying. See
6.1 Cleaning Lint Filter / Loading Door Inner
Surface
• Empty the water tank after each drying.
See 6.3 Draining the water tank
5.14 Odor Feature
Read the ProScent manual for the use of
this feature if your dryer has odor application
capability.

20 Dryer / User Manual
6 Maintenance and cleaning
6.1 Loading Door Inner Surface
The hair and fibres that are separated from the
laundry during drying process is collected by
the Fibre Filter.
CNOTE
• Fibres are formed during wearing and
washing clothes.
• You can clean the filter slot with a
vacuum cleaner.
AWARNING!
• After each drying cycle, clean the fibre
filter and the inner surface of the loading
door.
To clean the fibre filter:
• Open the loading door.
• Hold the first part (inner filter) of the two
part fibre filter and remove it by pulling it
upwards.
• Collect the hair, fibres and cotton balls with
hand or with a soft cloth.
• Remove the second part (outer filter) by
pulling it upwards.
CNOTE
• Ensure that hair, fibre and cotton balls do
not fall into the slot where the filters are
installed.
• Open both fibre filters (inner and outer
filters) remove the hair, fibre, cotton balls
with your damp hand or a vacuum cleaner
or a cloth.
• Clean both filters under water running in
reverse direction of fibre accumulation
or with a soft brush. Dry the filter before
placing it back.
• Insert the fibre filters
on one another and
place it back in its
place.
• Clean the loading door interior and its
washer with a soft damp cloth.
6.2 Cleaning the sensor
There are
dampness sensors
in the dryer that
detect whether
the laundry is dry
or not.
To clean the
sensors:
