Beko DH 8544 RX User manual

Dryer
User Manual
DH 8544 RX
2960311602_EN/251017.0906
EN
Sušln stroj
Navodla za uporabo
SL

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been manufac-
tured with high quality and technology will give you the best results. We advise you to read
through this manual and the other accompanying documentation carefully before using your
product and keep it for future reference. If you transfer the product to someone else, give its
manual as well. Pay attention to all details and warnings specied in the user manual and fol-
low the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against re hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN
Dryer / User Manual
1Important safety and
envronmental nstructons
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
•The dryer can be used by chldren at and above 8
years old and by persons whose physcal, sensory or
mental capabltes were not fully developed or who
lack experence and knowledge provded that they are
supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth
the product. Cleanng and mantenance works should not
be performed by chldren unless they are supervsed by
someone.
•Chldren of less than 3 years should be kept away unless
contnously supervsed.
•Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced wth
materals such as carpet, wood and tape. Ths wll cause
problems wth the dryer.
•Always have the nstallaton and reparng procedures
carred out by the Authorsed Servce. Manufacturer
shall not be held lable for damages that may arse from
procedures carred out by unauthorsed persons.
•Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!

4 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.1.1 Electrcal safety
AElectrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
AThe applance must not be suppled through an
external swtchng devce, such as a tmer,or
connected to a crcut that s regularly swtched on
and off by utlty.
•Connect the dryer to a grounded outlet protected by a
fuse at the value specfed on the type label. Have the
groundng nstallaton performed by a qualfed electrcan.
Our company shall not be lable for any damages that
wll arse when the dryer s used wthout groundng n
accordance wth the local regulatons.
•The voltage and allowed fuse protecton s stated on the
type label plate.
•The voltage specfed on the type label must be equal to
your mans voltage.
•Unplug the dryer when t s not n use.
•Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
•Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
•Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.
•Power cable plug must be easly accessble after
nstallaton.
BDamaged mans cable should be changed by an
Authorsed Servce agent.

5 / EN
Dryer / User Manual
Important instructions for safety and
environment
BIf the dryer s faulty, t must not be operated unless
t s repared by an authorsed servce agent! There s
the rsk of electrc shock!
1.1.2 Product safety
Superheatng of the clothes nsde of the dryer can
occur f you cancel the programme or n the event
of a power falure whlst the dryer s runnng, ths
concentraton of heat can cause self-combuston
and fre so always actvate the ventlaton
programme to cool down or quckly remove all
laundry from the dryer n order to hang them up and
dsspate the heat.
Ponts to be taken nto consderaton for fre
hazard:
Below specfed laundry or tems must not be dred
n the dryer because of fre hazard.
•Unwashed laundry tems
•Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
solvents must be washed n hot water wth plenty
of detergent before beng dred n the dryer.

6 / EN
Dryer / User Manual
Important instructions for safety and
environment
Below specfed laundry or tems must not be
dred n the dryer due to the fre hazard:
•Garments or pllows bolstered wth rubber foam
(latex foam), shower caps, water resstant textles,
materals wth rubber renforcement and rubber
foam pads.
•Clothng cleaned wth ndustral chemcals.
Items such as lghters, matches, cons, metal parts,
needle etc. may damage the drum set or may lead
to functonal problems. Therefore check pockets off
the laundry that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.
•You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.
AClothng that contans metal renforcements should
not be dred n the dryer. Dryer may be damaged
f metal renforcements come loose and break off
durng dryng.
CUse softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
CAlways clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.

7 / EN
Dryer / User Manual
Important instructions for safety and
environment
•Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others’ lves n
danger.
•There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
•Install your dryer n a sutable place that s dry, well
ventlated and unlkely to get below 5 degrees Centgrade.
•Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
•Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
•The lnt must not be allowed to accumulate around the
tumble dryer.
•The tumble dryer s not to be used f ndustral chemcals
have been used for cleanng.
•Fabrc softeners, or smlar products.should be used as
specfed by the fabrc softener nstructons.
•Exhaust ar must not be dscharged nto a flue whch s
used for exhaustng fumes from applances burnng gas or
other fuels.
1.2 Mountng over a washng machne
•A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce can be obtaned through spare part supplers.
•Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other

8 / EN
Dryer / User Manual
Important instructions for safety and
environment
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
AWashng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be stacked Can be
stacked Cannot be
stacked
60 cm Can be stacked Cannot be
stacked
1.3 Intended use
•Dryer has been desgned for domestc use. It s not sutable
for commercal use and t must not be used out of ts
ntended use.
•Use the dryer only for dryng laundry that are marked
accordngly.
•The manufacturer waves any responsblty arsen from
ncorrect usage or transportaton.
•Orgnal spare parts wll be avalable to repar the dryer for
a perod of 10 years.
1.4 Chld safety
•Packagng materals are dangerous for the chldren. Keep
packagng materals away from chldren.
•Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.

9 / EN
Dryer / User Manual
Important instructions for safety and
environment
CChld-proof lock s on the control panel.
(See Chld lock)
•Keep loadng door closed even when the dryer s not n
use.
1.5 Complance wth the WEEE regulaton
and dsposng of the waste product
Ths product comples wth EU WEEE Drectve
(2012/19/EU). Ths product bears a classfcaton
symbol for waste electrcal and electronc equpment
(WEEE).
Ths product has been manufactured wth hgh
qualty parts and materals whch can be reused and are
sutable for recyclng. Do not dspose of the waste product
wth normal domestc and other wastes at the end of ts
servce lfe. Take t to the collecton center for the recyclng
of electrcal and electronc equpment. Please consult your
local authortes to learn about these collecton centers.
1.6 Complance wth RoHS Drectve:
The product you have purchased comples wth EU RoHS
Drectve (2011/65/EU). It does not contan harmful and
prohbted materals specfed n the Drectve.
1.7 Package nformaton
Packagng materals of the product are manufactured
from recyclable materals n accordance wth our Natonal
Envronment Regulatons. Do not dspose of the packagng
materals together wth the domestc or other wastes. Take
them to the packagng materal collecton ponts desgnated
by the local authortes.

10 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.8 Techncal Specfcatons
* Mn. heght: Heght wth adjustable feet are closed.
Max. heght: Heght wth adjustable feet are opened
maxmum.
** Dry laundry weght before washng.
*** For the locaton of the type label on the dryer
CTechncal specfcatons of the dryer are subject to
specfcaton wthout notce to mprove the qualty of
the product.
CFgures n ths manual are schematc and may not
match the product exactly.
C
Values stated on markers on the dryer or n the other
publshed documentaton accompanyng wth the
dryer are obtaned n laboratory n accordance wth
the relevant standards. Dependng on operatonal and
envronmental condtons of the dryer, these values
may vary.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 60,9 cm
Capacity (max.) 8 kg**
Net weight (plastic front door
usage) 48,5 kg
Net weight (glass front door
usage) 51 kg
Voltage
See type label***Rated power input
Model code

11 / EN
Dryer / User Manual
2Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

12 / EN
Dryer / User Manual
3 Installaton
Before the calling the nearest Authorized
Service for the installation of the dryer, en-
sure that electrical installation and water
drain is appropriate referring to the user’s
manual. (See 3.3 Connecting to the drain
and 3.5 Electrical connection) If they are
not suitable, contact a qualied electrician
and technician to make necessary arrange-
ments.
CPreparation of the dryer's location
as well as the electrical and waste
water installations is under cus-
tomer's responsibility.
APrior to installation, visually check
if the dryer has any defects on
it. If the drier is damaged, do not
have it installed. Damaged prod-
ucts cause risks for your safety.
ALet your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer
will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
BDo not place the dryer on the
power cable.
3.2 Removing the
transportation safety
assembly
ARemove the transportation safety
assembly before using the dryer
for the rst time.
• Open the loading door.
• There is a nylon bag inside the drum that
contains a piece of styrofoam. Hold it
from its section marked with XX XX.
• Pull the nylon towards yourself and
remove the transportation safety
assembly.
ACheck that no part of the trans-
portation safety assembly re-
mains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser unit,
water accumulates in the water tank during
the drying cycle. You should drain accumu-
lated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.

13 / EN
Dryer / User Manual
Installation
Connecting the water drain hose
1-2Pull hose at the behnd of the dryer
by hand n order to dsconnect t from
where t s connected. Do not use any
tools to remove the hose.
3Connect one end of the dran hose
suppled wth the dryer to the
connecton pont from where you
removed the hose of the product n
prevous step.
4Connect the other end of the dran hose
drectly to the wastewater dran or to
the washbasn.
1
3 4
2
AHose connection should be made
in a safe manner. Your drain
house will be ooded if the hose
comes out of its housing during
water discharge.
CWater drain hose should be at-
tached to a height of maximum
80 cm.
CMake sure that the water drain
hose is not stepped on and it is
not folded between the drain and
the machine.
3.4 Adjusting the feet
• In order to ensure that the dryer
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet.
• Turn the feet to left or right until the
dryer stands level and firmly.
CNever unscrew the adjustable
feet from their housings.
3.5 Electrical connection
For specic instructions for electrical connec-
tion required during installation (see 1.1.1
Electrical Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the
dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the dryer
in upright position. If it is not pos-
sible to carry the machine in the
upright position, we recommend
carrying it by tilting towards the
right side when looked from the
front.

14 / EN
Dryer / User Manual
Installation
3.7 Warnings about sounds
CIt is normal to hear a metallic
noise from the compressor some-
times during operation.
CWater collected during operation
is pumped to water tank. It is nor-
mal to hear pumping noise during
this process.
3.8 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance is not suit-
able for household room illumination. The
intended purpose of this lamp is to assist the
user to place laundry in the tumble dryer in a
comfortable way. The lamps used in this ap-
pliance have to withstand extreme physical
conditions such as vibrations and tempera-
tures above 50 °C

15 / EN
Dryer / User Manual
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label
stating that they are suitable for drying in a dryer and make sure that you select the appropri-
ate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
4.2 Laundry not suitable for
drying in the dryer
CDelicate embroidered fabrics,
woolen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-ecient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and table clothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.
4Preparaton

16 / EN
Dryer / User Manual
Preparation
• Do not add wet laundry while the dryer is
in operation
• Clean the lint filter before or after each
drying cycle. (See 6.1 Cleaning Lint
Filter / Loading Door Inner Surface)
• Clean the filter drawer periodically when
there is visible air collection on it or
when the symbol lights up, if there is a
filter drawer cleaning warning symbol «
» available. (See 6. 4 Cleaning the
filter drawer)
• Ventilate the room, where the dryer is
located, well during drying.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
CIt is not recommended to load
the dryer with laundry exceeding
the level indicated in the figure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry Approximate
weights (g)*
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

17 / EN
Dryer / User Manual
5Operatng the product
5.1 Control Panel
1. Program Selection button
2. Display
3. On-O button
4. Start/Stand-by button
5. End Time button
6. Rapidry button
7. Buzzer button
8. Dryness Settings Selection button
1 2
45678
3
5.2 Screen symbols
Rem aining tim e indicat or*
Evaporator cleaning warning symbol
Filter cleaning warning symbol Child lock warning symbol
Clos et - dry
Wat e r t an k warn i n g s ym b ol
End tim e
An t i- cr eas e
End of cycle
St art /hold sym bol
Steam symbol
Dryness level
Iron-dry
*Tim e displayed indicates the rem aining t im e to the end of the cycle and t his
time varies as per the humidity of the laundry.
Buzzer level sym bol
Daily
Timer
programmes
Cottons Synthetics Freshen Up Anti
Creasing
Iron Dry Extra dry Cupboard Dry
Dryness
Level
Buzzer On/O Start
pause
cancel
Filter
cleaning
Child-proof
lock
Tank
full
Express
Jeans Shirts
Night
Shirts 30’
BabyProtect Sport Spin Mix
Buzzer
cancel
Delicates
Wool Refresh Drying
Rack
Timer
Delay Wool
Protect
Cupboard
dry plus
Dryness
Level
End/anti-
creasing
Volume
Up
Audible
warning
cancellation
Bedding

18 / EN
Dryer / User Manual
Operating the product
5.3 Preparing the dryer
Plug in the tumble dryer
Open device door.
Place the laundry into the tub in a slight
loosely.
Close the door by pushing.
CMake sure there is nothing
door and the device while closing
the door.
Press and hold On/O/Cancel button for 1
second.
• When dryer is used for the first time,
declaration program (cupboard dry
cottons) is selected.
CProgram doesn’t start
immediately only by pressing the
On/Off/Cancel button. Start the
program with the On/Off/Cancel
button after program selection.
5.4 Programme selection
Your dryer has 16 dierent programs.
Delicates
Freshen Up
• Select the desired program by turning the
program selection button..
• Displayed program selection and
consumption chart are based on sorting
by preferences of majority of users.

19 / EN
Dryer / User Manual
Operating the product
5.5 Programme selection and consumption chart
Programme Programme Description Capacity
(kg)* Spin Speed in Washing Machine (rpm) Drying Time (Min.) RapiDry (Min.)
Cottons
Cupboard Dry
You may dry all your cotton laundry
in this program. (T-shirt, pants,
pyjamas, baby clothes, underwear,
linen, etc.) You can put your laundry
in the wardrobe without ironing.
8 / 4 1000 152 / 95 115
Cottons Iron
Dry
You may dry your cotton laundry to
be ironed in this program to have
them slightly damp for ease of iron-
ing. (Shirt, T-shirt, tablecloth, etc.)
(Hemden, T-Shirts, Tischdecken
usw.)
8 1000 124 95
Cottons Extra
Dry
You may dry your thick cotton laun-
dry in this program such as towels,
bathrobe, etc. You can put your
laundry in the wardrobe without
ironing.
8 1000 165 130
Synthetics
Cupboard Dry
You may dry all your synthetic laun-
dry in this program. (Shirt, T-shirt,
underwear, tablecloth, etc.) You can
put your laundry in the wardrobe
without ironing.
4 800 75 50
Synthetics
Iron Dry
You may dry your synthetic laundry
to be ironed in this program to have
them slightly damp for ease of iron-
ing. (Shirt, T-shirt, tablecloth, etc.)
4 800 59 34
Jeans You may dry denim pants, skirts,
shirts or jackets in this program. 4 1200 117 85
Sport Use for drying laundry made out of synthetic, cotton or mixed type of
fabrics. 4 1000 105 70
Shirts 30’ Use this programme to make 2 shirts ready for ironing in 30
minutes. 0,5 1200 30 23
BabyProtect This programme is used for baby clothes that bear machine dryable
approval on its label. 3 1000 95 71
Mix Use this programme to dry non-
pigmenting synthetic and cotton
laundry items together.
4 1000 110 75

20 / EN
Dryer / User Manual
Operating the product
* Weight of dry laundry before washing
Bedding
Dry fiber quilts with
‘machinedryable’ label only. Make
sure you are loading the quilt in the
correct way to avoid damages on
the machine and the quilt. Take out
the quilt cover before loading the
quilt in the machine. Fold the quilt
in two before loading. - Do not load
more than 1 doublesize fiber quilt
(200x200 cm). Do not dry items
containing cotton such as quilts,
pillows and etc. - Do not dry items
other than quilts such as carpets,
rugs or mats. Permanent damage
may arise in your machine.
2,5 1000 120 -
Night
In this programme the level of
noise emitted to the environment
will be the lowest. Volume level will
be fifty percent lower with respect
to the ‘wardrobe dry for cottons’
programme.
8 1000 240
Delicates
You may dry your delicate laundry
or laundry with hand wash symbol
(silk blouses, thin underwear, etc.)
at low temperature in this program.
2 600 50
WoolProtect
Use this programme to dry woolen
garments such as jumpers that
are washed according to the
instructions. It is recomended that
garments would be removed at the
end of the programme.
1,5 600 148
Freshen Up
It just provides airing for 10
minutes without any hot air. You
can air the cotton and linen laundry
that are kept closed for a long time ,
and eliminate the odour in them.
- - 10
Timer
programmes
You may select from time programs
between 10 and 160 minutes to
achieve the desired drying level at
low temperature. In this program,
tumble drier’s operation lasts for
the set time independently from
the dryness of laundry.
In order to select any drying
time, you need to press the timer
selection “ “key.
- - -
