Beko DPS 7205W3 User manual

DPS 7205W3
Dryer
User Manual
Secador
Manual do utilizador
2960311007_EN/241214.2102

2960311007_EN/241214.2102
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been manufactured with high quality
and technology will give you the best results. We advise you to read through this manual and the other accompanying
documentation carefully before using your product and keep it for future reference. If you transfer the product to
someone else, give its manual as well. Pay attention to all details and warnings specified in the user manual and
follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about
usage.
AWarning for hazardous situations with
regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard them to the dedicated
collection points designated by the local authorities.

3 / 56 EN
Dryer / User Manual
1 Important instructions for safety and
environment
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
•The dryer can be used by children at and above 8 years old and by
persons whose physical, sensory or mental capabilities were not fully
developed or who lack experience and knowledge provided that they
are supervised or trained on the safe usage of the product and the risks
it brings out. Children should not play with the product. Cleaning and
maintenance works should not be performed by children unless they are
supervised by someone.
•Children of less than 3 years should be kept away unless continously
supervised.
•Adjustable feet should not be removed. The gap between the dryer and
the floor should not be reduced with materials such as carpet, wood and
tape. This will cause problems with the dryer.
•Always have the installation and repairing procedures carried out by the
Authorized Service. Manufacturer shall not be held liable for damages
that may arise from procedures carried out by unauthorized persons.
•Never wash the dryer by spraying or pouring water onto it! There is the
risk of electric shock!

4 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.1.1 Electrical safety
AElectrical safety instructions should be followed while electrical
connection is made during the installation.
•Connect the dryer to a grounded outlet protected by a fuse at the value
specified on the type label. Have the grounding installation performed by
a qualified electrician. Our company shall not be liable for any damages
that will arise when the dryer is used without grounding in accordance
with the local regulations.
•The voltage and allowed fuse protection is stated on the type label plate.
•The voltage specified on the type label must be equal to your mains
voltage.
•Unplug the dryer when it is not in use.
•Unplug the dryer from the mains during installation, maintenance,
cleaning and repair works.
•Do not touch the plug with wet hands! Never unplug by pulling on the
cable, always pull out by grabbing the plug.
•Do not use extension cords, multi-plugs or adaptors to connect the dryer
to power supply in order to decrease the risk of fire and electric shock.
•Power cable plug must be easily accessible after installation.
BDamaged mains cable should be changed notifying the Authorized
Service.
BIf the dryer is faulty, it must not be operated unless it is repaired
by an authorized service agent! There is the risk of electric shock!

5 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.1.2 Product safety
Points to be taken into consideration for fire hazard:
Below specified laundry or items must not be dried
in the dryer considering fire hazard.
•Unwashed laundry items
•Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or paraffin removers must be
washed in hot water with plenty of detergent before being dried
in the dryer.
For this reason especially the items containing the above
specified
stains must be washed very well, to do this
use adequate detergent and choose a high washing
temperature.
Below specified laundry or items must not be dried in the
dryer due to the fire hazard:
•Garments or pillows bolstered with rubber foam (latex foam),
shower bonnets, water resistant textiles, materials with rubber
reinforcement and rubber foam pads.
•Clothing cleaned with industrial chemicals.
Items such as lighter, match, coins, metal parts, needle etc.
may damage the drum set or may lead to functional problems.
Therefore check all the laundry that you will load into your dryer.
Never stop your dryer before
the programme completes. If you must do this, remove all
laundry
quickly and lay them out to dissipate the heat.
Clothes that are washed inadequately may ignite on their own
and even may ignite after drying ends.

6 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
•You must provide enough ventilation in order to prevent gases exiting from
devices operating with other types of fuels including the naked flame from
accumulating in the room due to the back fire effect.
AUnderwear that contains metal reinforcements should not be
dried
in the dryer. Dryer may be damaged if metal reinforcements come
loose and break off during drying.
CUse softeners and similar products in accordance with the
instructions of their manufacturers.
CAlways clean the lint filter before or after each loading. Never
operate the dryer without the lint filter installed.
•Never attempt to repair the dryer by yourself. Do not perform any repair
or replacement procedures on the product even if you know or have the
ability to perform the required procedure unless it is clearly suggested in
the operating instructions or the published service manual. Otherwise, you
will be putting your life and others’ lives in danger.
•There must not be a lockable, sliding or hinged door that may block
the opening of the loading door in the place where your dryer is to be
installed.
•Install your dryer at places suitable for home use. (Bathroom, closed
balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the inside of the dryer
before operating it.
•Do not lean on the loading door of your dryer when it is open, otherwise it
may fall over.
•The lint must not be allowed to accumulate around the tumble dryer

7 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.2 Mounting over a washing machine
•A fixing device should be used between the two machines when installing
the dryer above a washing machine. The fitting device must be installed
by the authorized service agent.
•Total weight of the washing machine and the dryer -with full load- when
they are placed on top of each other reaches to approx. 180 kilograms.
Place the products on a solid floor that has sufficient load carrying
capacity!
AWashing machine cannot be placed on the dryer. Pay attention
to the above warnings during the installation on your washing
machine.
Installation Table for Washing Machine and Dryer
Dryer Depth Washing Machine Depth
62cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be
installed
Can be
installed
Can be
installed
Can be
installed
Can be
installed
Can be
installed
Cannot be
installed
60 cm Can be
installed
Can be
installed
Can be
installed
Can be
installed
Can be
installed
Cannot be
installed
Cannot be
installed

8 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.3 Intended use
•Dryer has been designed for domestic use. It is not suitable for
commercial use and it must not be used out of its intended use.
•Use the dryer only for drying laundry that are marked accordingly.
•The manufacturer waives any responsibility arisen from incorrect usage or
transportation.
•The service life of the dryer that you purchased is 10 years. During this
period, original spare parts will be available to operate the dryer properly.
1.4 Child safety
•Packaging materials are dangerous for the children. Keep packaging
materials away from children.
•Electrical products are dangerous for the children. Keep children away
from the product when it is operating. Do not let them tamper with the
dryer. Use the child-proof lock in order to prevent the children to tamper
with the dryer.
CChild-proof lock is on the control panel. (See Child lock)
•Keep loading door closed even when the dryer is not in use.

9 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product complies with EU WEEE Directive (2012/19/EU). This
product bears a classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured with high quality parts and
materials which can be reused and are suitable for recycling. Do
not dispose of the waste product with normal domestic and other
wastes at the end of its service life. Take it to the collection center for the
recycling of electrical and electronic equipment. Please consult your local
authorities to learn about these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated
by the local authorities.
Please visit the following website to get more information on the product.
http://www.beko.com

10 / 56 EN
Dryer / User Manual
Important instructions for safety and environment
1.8 Technical Specifications
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
CTechnical specifications of the dryer are subject to specification
without notice to improve the quality of the product.
CFigures in this manual are schematic and may not match the
product exactly.
C
Values stated on markers on the dryer or in the other published
documentation accompanying with the dryer are obtained in
laboratory in accordance with the relevant standards. Depending
on operational and environmental conditions of the dryer, these
values may vary.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 54 cm
Capacity (max.) 7 kg**
Net weight (plastic front door usage) 46,5 kg
Net weight (glass front door usage) 48,5 kg
Voltage
See type label***Rated power input
Model code

11 / 56 EN
Dryer / User Manual
2 Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

12 / 56 EN
Dryer / User Manual
3 Installation
Before the calling the nearest Authorized Service for the
installation of the dryer, ensure that electrical installation
and water drain is appropriate referring to the user's
manual.(See 3.3 Connecting to the drain and 3.5
Electrical connection) If they are not suitable, contact
a qualified electrician and technician to make necessary
arrangements.
CPreparation of the dryer's location
as well as the electrical and waste
water installations is under customer's
responsibility.
APrior to installation, visually check if the
dryer has any defects on it. If the drier
is damaged, do not have it installed.
Damaged products cause risks for your
safety.
ALet your dryer wait for 12 hours before
starting to use it.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated, dust-free
environment.
• The gap between the dryer and the surface should
not be reduced by the materials such as carpet,
wood and tape.
• Do not cover the ventilation grills of the dryer.
• There must not be a lockable, sliding or hinged
door that may block the opening of the loading
door in the place where your dryer is to be
installed.
• Once the dryer is installed, it should stay at the
same place where its connections have been
made. When installing the dryer, make sure that
its rear wall does not touch anywhere (tap, socket,
etc.).
• Place the dryer at least 1 cm away from the edges
of other furniture.
• Your dryer can be operated at temperatures
between +5°C and +35°C. If the operating
conditions fall outside of this range, operation of
the dryer will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall be
placed against a wall.
BDo not place the dryer on the power
cable.
3.2 Removing the transportation
safety assembly
ARemove the transportation safety
assembly before using the dryer for the
first time.
• Open the loading door.
• There is a nylon bag inside the drum that contains
a piece of styrofoam. Hold it from its section
marked with XX XX.
• Pull the nylon towards yourself and remove the
transportation safety assembly.
ACheck that no part of the transportation
safety assembly remains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser unit, water
accumulates in the water tank during the drying cycle.
You should drain accumulated water after each drying
cycle.
You can directly drain accumulated water through the
water drain hose supplied with the product instead of
periodically draining the water collected in the water
tank.
Connecting the water drain hose
1-2 Pull hose at the behind of the dryer by hand in
order to disconnect it from where it is connected.
Do not use any tools to remove the hose.
3Connect one end of the drain hose supplied with
the dryer to the connection point from where you
removed the hose of the product in previous step.
4Connect the other end of the drain hose directly to
the wastewater drain or to the washbasin.

13 / 56 EN
Dryer / User Manual
Installation
1
3 4
2
AHose connection should be made in a
safe manner. Your drain house will be
flooded if the hose comes out of its
housing during water discharge.
CWater drain hose should be attached to a
height of maximum 80 cm.
CMake sure that the water drain hose
is not stepped on and it is not folded
between the drain and the machine.
3.4 Adjusting the feet
• In order to ensure that the dryer operates more
silently and vibration-free, it must stand level and
balanced on its feet. Balance the machine by
adjusting the feet.
• Turn the feet to left or right until the dryer stands
level and firmly.
CNever unscrew the adjustable feet from
their housings.
3.5 Electrical connection
For specific instructions for electrical connection
required during installation (see 1.1.1 Electrical
Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the dryer.
If direct water drain connection is made, then remove
the hose connections.
A
We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.7 Warnings about sounds
CIt is normal to hear a metallic noise
from the compressor sometimes during
operation.
CWater collected during operation is
pumped to water tank. It is normal to hear
pumping noise during this process.

14 / 56 EN
Dryer / User Manual
Installation
3.8 Changing the illumination lamp
In case an illumination lamp is used in your laundry
dryer
To change the Bulb/LED used for illumination of your
tumble dryer, call your Authorized Service.
The lamp(s) used in this appliance is not suitable for
household room illumination. The intended purpose of
this lamp is to assist the user to place laundry in the
tumble dryer in a comfortable way.

15 / 56 EN
Dryer / User Manual
4 Preparation
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are
suitable for drying in a dryer and make sure that you select the appropriate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
4.2 Laundry not suitable for drying in
the dryer
CDelicate embroidered fabrics, woolen, silk
garments, delicate and valuable fabrics,
airtight items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other after
washing. Separate the laundry items before
placing them into the dryer.
• Dry garments having metal accessories such as
zippers, inside out.
• Fasten the zippers, hooks and buckles and button
sheets.
4.4 Things to be done for energy
saving
Following information will help you use the dryer in an
ecological and energy-efficient manner.
• Spin your laundry at the highest speed possible
when washing them. Thus, the drying time is
shortened and energy consumption is reduced.
• Sort out the laundry depending on their type and
thickness. Dry the same type of laundry together.
For example thin kitchen towels and table clothes
dries earlier than thick bathroom towels.
• Follow the instructions in the user manual for
programme selection.
• Do not open the loading door of the machine
during drying unless necessary. If you must
certainly open the loading door, do not to keep it
open for a long time.
• Do not add wet laundry while the dryer is in
operation
• Clean the lint filter before or after each drying
cycle. (See 6. Maintenance and cleaning)

16 / 56 EN
Dryer / User Manual
Preparation
• Clean the filter drawer regularly either when the
Filter Drawer Cleaning warning symbol appears or
after every 5 drying cycles. (See 6. Maintenance
and cleaning)
• Ventilate the room, where the dryer is located, well
during drying.
4.5 Correct load capacity
Follow the instructions in the “Programme selection and
consumption table”. Do not load more than the capacity
values stated in the table.
CIt is not recommended to load the dryer
with laundry exceeding the level indicated
in the figure. Drying performance will
degrade when the machine is overloaded.
Furthermore, dryer and the laundry can get
damaged.
Following weights are given as examples.
Laundry Approximate weights
(g)*
Cotton quit covers (double) 1500
Cotton quit covers (single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10 pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

17 / 56 EN
Dryer / User Manual
5 Operating the product
5.1 Control panel
1. On/Off/Program selection button
2. Start/Pause button
3. Delay time button
4. Audio alarm level button
Daily
Start/
Wait/
Ready
Timer
programs
Cottons Synthetics Freshen
Up
End/anti-
creasing
Iron dry Extra
dry
Cupboard
dry
Cupboard
dry plus
Dryness
Level
Drying
Buzzer On/Off Start
pause
cancel
Filter
cleaning
Child-proof
lock
Ta n k
full
Xpress
Jeans Shirts
BabyProtect Sport Spin Mix Delicates
Volume up Mute
Timer
Delay
5.2 Screen symbols
1
23
4

18 / 56 EN
Dryer / User Manual
Operating the product
5.3 Preparation of Tumble Dryer
• Plug in the tumble dryer.
• Open the loading door.
• Place the laundry into the tumble dryer without
overloading.
• Push and close the loading door.
ATake care not to trap any laundry inside
the loading door.
• When you select the desired program by using
On/off/program selection button, the machine will
turn on.
1
23
4
CSelection of program by using On/off/
program selection button doesn’t mean
that the program has been started.
Press the Start/Pause button to start the
program.
5.4 Program selection
There are 15 programs included in your tumble drier.
1
23
4
• Program selection and consumption table have
been given in the order that might be mostly
preferred by users.

19 / 56 EN
Dryer / User Manual
Operating the product
5.5 Program selection and consumption table
Programs Program Description Capacity
(kg)
Spin Speed
in Washing
Machine
(rpm)
Drying Time
(min)
Cotton Cupboard Dry
You may dry all your cotton laundry in this program.
(T-shirt, pants, pyjamas, baby clothes, underwear, linen,
etc.) You can put your laundry in the wardrobe without
ironing.
7 1000 174
Cotton Cupboard Dry + You may use this program for extra dryness in thick laundry such as pants, tracksuit. You can put your laundry
in the wardrobe without ironing. 7 1000 180
Cotton Iron Dry You may dry your cotton laundry to be ironed in this program to have them slightly damp for ease of ironing.
(Shirt, T-shirt, tablecloth, etc.) 7 1000 140
Cotton Extra Dry You may dry your thick cotton laundry in this program such as towels, bathrobe, etc. You can put your laundry in
the wardrobe without ironing. 7 1000 185
Synthetic Cupboard Dry You may dry all your synthetic laundry in this program. (Shirt, T-shirt, underwear, tablecloth, etc.) You can put
your laundry in the wardrobe without ironing. 3.5 800 70
Synthetic Iron Dry You may dry your synthetic laundry to be ironed in this program to have them slightly damp for ease of ironing.
(Shirt, T-shirt, tablecloth, etc.) 3.5 800 60
Jeans You may dry denim pants, skirts, shirts or jackets in this
program. 4 1200 150
Xpress
You can use this program to dry your cotton laundry that
you have spun at high speeds in your washing machine.
This program dries 1 kg cotton laundry (3 Shirts/3T-
shirts) in 50 minutes.
1 1200 50
Shirts It dries the shirts in a more sensitive manner, and causes
less creasing and easier ironing. 1.5 1200 60
Sport You may dry your sports clothes that are appropriate for
tumble drying in this program. 4 1000 135
BabyProtect Program used for baby clothing with can be dried approval on the label. 3 1000 80
Delicates You may dry your delicate laundry or laundry with hand wash symbol (silk blouses, thin underwear, etc.) at low
temperature in this program. 2 600 70
Refresh It just provides airing for 10 minutes without any hot air. You can air the cotton and linen laundry that are kept
closed for a long time , and eliminate the odour in them. - - 10
Time programs
You may select from time programs between 30 and
45 minutes to achieve the desired drying level at low
temperature. In this program, tumble drier’s operation
lasts for the set time independently from the dryness of
laundry.
- - -

20 / 56 EN
Dryer / User Manual
Operating the product
* : Energy Label standard program (EN 61121:2012)
All values in the table have been specified as per the EN 61121:2012 standard. Consumption values may vary from
the values in the table depending on the variances in laundry type, spin speed, ambient conditions, and voltage
values.
„Cotton cupboard dry programme“ used at full and partial load is the standard drying programme
to which the information in the label and the fiche relates, that this programme is suitable for drying
normal wet cotton laundry and that it is the most efficient programme in terms of energy consumption
for cotton.
Energy consumption values
Programs Capacity(kg) Spin Speed in Washing
Machine (rpm) Approximate residual moisture content Energy consumption value (kWh)
Cotton Wardrobe Dryness 7 1000 60% 1.68
Cotton Iron Dryness 7 1000 60% 1.30
Synthetic Wardrobe Dryness 3.5 800 40% 0.59
Power consumption of the off-mode for the standart cotton programme at full load, PO (W) 0.5
Power consumption of the left-on mode for the standart cotton programme at full load, PL (W) 1.0
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed. R134a / 0,350 kg
