Beko DV 7120 User manual

DV 7120
Dryer

2960310865_EN/051213.1659

Read this manual prior to initial operation of the product!
Dear Customer,
We hope that your product, which has been manufactured in modern facilities and passed through a strict quality control
procedure, will give you very good results.
We advise you to read through this manual carefully before using your product and keep it for future reference.
This User Manual will
• Help you use your machine in a fast and safe way.
• Read the User Manual before installing and starting your product.
• In particular, follow the instructions related to safety.
• Keep this User Manual within easy reach for future reference.
• Please read all additional documents supplied with your product.
Remember that this User Manual is also applicable for several other models.
Explanation of symbols
A Important safety information. Warning for hazardous situations with regard to
life and property.
BCaution; Warning for supply voltage.
Caution; Warning for fire hazard.
Caution; Warning for hot surfaces.
Read the instructions.
C Useful information. Important information or useful hints about usage.

3EN
1Important safety information
This section includes safety information that will help
protection from risks of personal injuries or materialistic
damages. Failure to follow these instructions shall cause
any warranty and reliability commitment to become void.
General safety
• Never place the machine on a carpet-covered floor,
otherwise, lack of airflow beneath the machine may
cause electrical parts to overheat. This will cause
problems with your machine.
• If the power cable or mains plug is damaged, you
must call Authorised Service Agent for repair.
• The product should not be plugged in during
installation, maintenance and repair works. Such
works should always be made by the technical
service. Manufacturer shall not be held responsible
for damages arising from processes carried out by
unauthorised persons.
• Connect the product to a grounded outlet protected
by a fuse of suitable capacity as stated in the
technical specifications table.
• Operate your product at temperatures between
+5°C and +35°C.
• Do not use electrical devices in the product.
• Do not connect the air exit of the product to the
chimney holes which are used for the exhaust fumes
of the devices operating with gas or other types of
fuel.
• You must provide enough ventilation in order to
prevent gases exiting from devices operating with
other types of fuels including the naked flame from
accumulating in the room due to the back fire effect.
• Always clean the lint filter before or after each
loading.
• Never operate your dryer without the lint filter
installed.
• Do not allow fibre, dust and dirt accumulation
around the exhaust exit and at adjacent areas.
• Power cable plug must be within easy reach after
installation.
• Do not use extension cords, multi-plugs or adaptors
to connect the dryer to power supply in order to
decrease the risk of electric shock.
• Do not make any changes on the plug supplied with
the product. If it is not compatible with the socket,
have a qualified electrician change the socket with a
suitable one.
• Items cleaned or washed with gasoil/fuel oil, dry-
laundry solvents and other combustible or explosive
materials as well as the items that are contaminated
or spotted with such materials should not be dried in
the product since they emit flammable or explosive
vapor.
• Do not dry items cleaned with industrial chemicals in
the dryer.
• Do not dry unwashed items in the dryer.
• Items soiled with cooking oils, acetone, alcohol, fuel
oil, kerosene, stain remover, turpentine, paraffin and
paraffin removers must be washed in hot water with
plenty of detergent before being dried in the dryer.
• Garments or pillows bolstered with rubber foam
(latex foam), shower bonnets, water resistant
textiles, materials with rubber reinforcement and
rubber foam pads should not be dried in the dryer.
• Do not use fabric softeners and anti-static products
unless they are recommended by the manufacturers
of the fabric softener or the product.
• This product must be grounded. Grounding
installation decreases the risk of electric shock by
opening a path with low resistance for the electricity
flow in case of a malfunction or failure. Power
cable of this product is equipped with a conductor
and a grounding plug that allows for grounding the
product. This plug must be installed appropriately
and inserted into a socket which is grounded in
accordance with the local laws and regulations.
• Do not install the product behind a door with a lock,
sliding door or a door that has a hinge against the
hinge of the dryer.
• Do not install or leave this product in places where it
will be exposed to outdoor conditions.
• Do not tamper with the controls.
• Do not perform any repair or part replacing
procedures on the product even if you know or have
the ability to perform unless it is clearly suggested
in the operating instructions or the published service
manual.
• Inside and exhaust duct of the product must
be cleaned by the qualified service personnel
periodically.
• Wrong connection of grounding conductor of the
product can cause electric shock. If you have
any suspect about the grounding connection,
have it checked by a qualified electrician, service
representative or service personnel.
• Do not reach into the machine when the drum is
spinning.
• Unplug the machine when it is not in use.
• Never wash down the appliance with water! There
is the risk of electric shock! Always disconnect by
unplugging from the mains before cleaning.
• Never touch the plug with wet hands. Never unplug
by pulling on the cable, always pull out by grabbing
the plug only. Do not operate the machine if the
power cable or plug is damaged!
• Never attempt to repair the machine yourself,
otherwise, you will be putting your life and others’
lives in danger.
• For malfunctions that cannot be solved by following
the information given in the safety instructions:
Turn off the machine, turn off and contact an
authorised service agent.
• Do not stop the dryer before the drying cycle comes
to an end unless you will remove all laundry from
the dryer fast in order to lay them and dissipate the
heat.

4EN
• Remove the door of the drying compartment before
decommissioning or disposing of the product.
• The final step of the drying cycle (cool-down cycle)
occurs without applying heat to ensure that the
items are left at a temperature that will not damage
them.
• Fabric softeners or similar products should be used
as specified by the fabric softener instructions.
• Underwear that contains metal reinforcements
should not be placed in a dryer. Damage to the
dryer can result if metal reinforcements come loose
during drying.
• Check all garments for forgotten lighters, coins,
metal pieces, needles, etc. before loading.
• At times when your dryer is not in use or after the
laundry is taken out following the completion of
drying process, turn off by using the On/Off button.
In cases when the On/Off button is on (while the
dryer is energized), keep the door of the dryer
closed.
Intended use
• This product has been designed for domestic use. It
should not be used for other purposes.
• Use the product only for drying laundry that are
marked accordingly.
• Dry only those articles in your product that are
stated in this manual.
• This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children) unless they are attended by a person
who will be responsible for their safety or who will
instruct them accordingly for use of the product.
Children’s safety
• Electrical appliances are dangerous for the children.
Keep children away from the machine when it is
operating. Do not let them tamper with the machine.
• Packaging materials are dangerous to children.
Keep the packaging materials out of reach of
children or dispose them by classifying according to
waste directives.
• Do not allow children sit/climb on or enter in the
product.
• Children should be supervised to ensure that they
do not play with the product.
• Close the loading door when you leave the area
where the product is located.
Compliance with the WEEE Directive and
Disposing of the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product bears
a classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with
high quality parts and materials which can
be reused and are suitable for recycling.
Do not dispose of the waste product with
normal domestic and other wastes at the end of its service
life. Take it to the collection center for the recycling of
electrical and electronic equipment. Please consult your
local authorities to learn about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes.
Take them to the packaging material collection points
designated by the local authorities.

5EN
2Installation
Refer to the nearest Authorised Service Agent for
installation of your product.
CPreparation of location and electrical installation for
the product is under customer’s responsibility.
BInstallation and electrical connections must be carried
out by a qualified personnel.
APrior to installation, visually check if the product
has any defects on it. If so, do not have it installed.
Damaged products will cause risks for your safety.
Appropriate installation location
• Install the product in an environment which has no
risk of freezing and is in a stable and level position.
• Operate your product in a well ventilated, dust-free
environment.
• Do not block the air ducts in front of and under the
product with materials such as long pile rugs and
wooden bands.
• Do not place your product on a long pile rug or on
similar surfaces.
• Do not install the product behind a door with a lock,
sliding door or a hinged door which can strike the
product.
• Once the product is installed, it should stay at the
same place where its connections have been made.
When installing the product, make sure that the rear
wall of it does not touch anywhere (tap, socket, etc.)
and also pay attention to install the product at a
place where it will stay permanently.
BDo not place the product on top of the power cable.
• Keep at least 1.5 cm distance to walls of other
furniture.
Under counter installation
• A special part (Part no: 295 970 0100) replacing
the top trim must be provided and installed by
the Authorised Service Agent in order to use the
machine under a counter or in a cupboard. It should
never be operated without the top trim.
• Leave at least 3 cm of space between the side
and rear walls of the product and the walls of the
counter/cupboard when installing your product under
a counter or in a cupboard.
Mounting over a washing machine
• A fitting device should be used between the two
machines when installing above a washing machine.
The bracket (Part no. 296 280 0100 white/296
280 0200 grey) must be installed by the Authorised
Service Agent.
• Place the product on a firm floor. If it will be placed
on top of a washing machine, the approximate
weight of both machines may reach 180 kg when
they are full. Therefore, the floor must be capable of
carrying the load on it!
Ventilation hose and connection (for products
equipped with an outlet vent)
Ventilation hose allows exhaust air from inside the
machine
Vented dryer has 1 air outlet.
Stainless sheet metal or aluminum pipes can be used
instead of a hose. The pipe diameter should be minimum
10 cm.
Maximum hose and pipe lengths are given in the table
below.
Hose Pipe
Maximum length 4 m 5 m
1 elbow 45° -1.0 m -0.3 m
1 elbow 90° -1.8 m -0.6 m
1 elbow 90° short -2.7 m
1 wall passage -2.0 m -2.0 m
CEach elbow and other passages should be subtracted
from the maximum length stated above.
To connect a ventilation hose;
1. Connect the air outlet hose to the hose spacer piece
by turning it counterclockwise.
2. Make the hose passages as shown below.
CExhaust of humid air from the dryer into the room is
inconvenient. It may damage the walls and furniture
in the room.
CThe ventilation hose can be routed outdoors via a
window or it can be connected to the air outlet in the
bathroom.
CAir outlet hose must be routed directly to the
outdoors. There must be a limited number of elbows
as not to hinder ventilation.
CTo prevent water accumulation in the hose, make
sure that it is not folded on the floor.
BThe ventilation hose should not be connected to the
chimney of a stove or a fireplace.
BDo not operate your product at the same time with
heaters such as a coal or gas stove. Airflow may
cause the chimney to flare up.

6EN
Adjusting feet
In order to ensure that your product operates more silently
and vibration-free, it must stand level and balanced on its
feet. Front feet of your product can be adjusted. Balance
the machine by adjusting the feet.
1. Loosen the feet by hand.
2. Adjust the feet until the product stands level and firmly
on the floor.
C Do not use any tools to loosen the adjustable feet,
otherwise, they can be damaged.
C Never remove the adjustable feet from their
housings.
C You may supply 2 plastic pieces from an Authorized
Service with 2951620100 part number. These
parts prevent your machine from slipping when
the machine locates on wet and slippery surfaces.
You may assemble mentioned parts to the front
adjustable feet by fitting and pressing them to snap
into ground of feet.
Electrical connection
Connect the machine to a grounded outlet protected
by a fuse of suitable capacity as stated in the technical
specifications table. Our company shall not be liable for
any damages that will arise when the machine is used on
a circuit without grounding.
• Connection must comply with national regulations.
• If the current value of the fuse or breaker in the
house is less than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
• Power cable plug must be within easy reach after
installation.
• The voltage and allowed fuse or breaker protection
are specified in the “Technical Specifications”
section.
• The specified voltage must be equal to your mains
voltage.
• Do not make connections via extension cables or
multi-plugs.
• The main fuse and switches must have a contact
distance of minimum 3 mm.
BDamaged power cable must only be replaced by a
qualified electrician.
BIf the product is faulty, it must not be operated unless
it is repaired! There is the risk of electric shock!
First use
• To have the product ready for operation before
calling the authorised service agent, make sure
that its location and power supply installations
are appropriate. If they are not, call a qualified
electrician to have any necessary arrangements
carried out.
• Make sure that the power connections of the
product are in accordance with the instructions
given in relevant chapters of this manual.
Transportation of the machine
1. Unplug the machine from the mains.
2. Remove the water drain (if any) and chimney
connections.
3. Drain water remained in the machine completely
before transportation.

7EN
Technical Specifications
EN 2
Height (adjustable) 85.0 cm
Width 59.5 cm
Depth 54 cm
Capacity (max.) 7 kg
Weight (net) 31 kg
Voltage
See type label
Rated power input
Model code
Type label is located behind the loading door.

8EN
Laundry unsuitable for drying in the machine
• Laundry items with metal attachments such as belt
buckles and metal buttons can damage your dryer.
• Do not dry items such as woollens, silk garments
and nylon stockings, delicate embroidered fabrics,
laundry with metal accessories and items such as
sleeping bags in the dryer.
• Laundry made of delicate and valuable fabrics as
well as lace curtains can be creased. Do not dry
them in the dryer!
• Do not dry items made of hermetic fibres such as
pillows and quilts in the dryer.
• Laundry made of foam or rubber will be deformed.
• Do not dry laundry containing rubber in the dryer.
• Do not dry laundry exposed to petroleum, oil,
combustible or explosive agents in the dryer even if
they are washed beforehand.
• Overly wet laundry or laundry with dripping water
must not be put into the dryer.
• Items cleaned or washed with gasoil/fuel oil, dry-
laundry solvents and other combustible or explosive
materials as well as the items that are contaminated
or spotted with such materials should not be dried in
the product since they emit flammable or explosive
vapor.
• Do not dry items cleaned with industrial chemicals in
the dryer.
• Do not dry your unwashed laundry in the dryer.
• Items soiled with cooking oils, acetone, alcohol, fuel
oil, kerosene, stain remover, turpentine, paraffin and
paraffin removers must be washed in hot water with
plenty of detergent before being dried in the dryer.
• Garments or pillows bolstered with rubber foam
(latex foam), shower bonnets, water resistant
textiles, materials with rubber reinforcement and
rubber foam pads should not be dried in the dryer.
• Do not use fabric softeners and anti-static products
unless they are recommended by the manufacturers
of the fabric softener or the product.
• Do not dry the underwear reinforced with metal
parts in the dryer. If these metal reinforcements
loosen and break during drying, they will damage
your dryer.
Preparing laundry for drying
• Check all laundry items before loading them into
the product to make sure that there are no lighters,
coins, metal items, needles and etc. in their pockets
or on any part of them.
• Fabric softeners and similar products must be
used in accordance with the instructions of the
manufacturer of the relevant products.
• All laundry must be spun at the highest spin speed
that your washing machine allows for the laundry
type.
• Laundry may be tangled after washing. Separate
your laundry before placing them into your dryer.
Things to be done for energy saving:
•Make sure that you operate the product at its full
capacity but pay attention to not exceeding it.
• Spin your laundry at the highest speed possible
when washing them. Thus, the drying time is
shortened and energy consumption is decreased.
• Pay attention to dry same types of laundry together.
• Follow the instructions in the user manual for
programme selection.
• Make sure that sufficient clearance is provided at
the front and rear side of the dryer for air circulation.
Do not block the grill at the front side of the product.
• Do not open the door of the machine during drying
unless necessary. If you must certainly open the
door, pay attention not to keep it open for a long
time.
• Do not add new (wet) laundry during drying.
• Lint and fibres released from the laundry to the air
during the drying cycle are collected in the “Lint
Filter”. Make sure that you clean the filters before or
after each drying.
• In models with condenser, make sure that you clean
the condenser regularly at least once every month
or after every 30 drying cycles.
• In vented models, follow the chimney connection
rules in the user manual and pay attention to the
chimney cleaning.
• Ventilate the room, where the dryer is located, well
during drying.
• “For power saving in models with lamps, at times
when your dryer is not in use, keep the door closed
if the On/Off button is pressed (if the dryer is
energized).”
Laundry suitable for drying in the machine
CAlways follow the suggestions on the laundry labels.
Dry only the laundry having a label stating that they
are suitable for drying in a dryer and make sure that
you select the appropriate programme.
A B C
l mn
o p q
D
Low
3Initial preparations for drying

9EN
• Sort your laundry according to their types and
thicknesses. Dry the same type of laundry together.
E.g.: fine kitchen towels and table cloths dry faster
than the thick bath towels.
Correct load capacity
AConsider the information in the “Programme
Selection Table”. Always start the programme in
accordance with the maximum load capacity.
CAdding laundry to the machine more than the level
shown in the figure is not recommended. Drying
performance will degrade when the machine is
overloaded. Furthermore, your dryer and your
laundry can be damaged.
CPlace your laundry into the drum loosely so that they
will not get tangled.
CLarge pieces (E.g.: bed sheets, quilt covers, large
tablecloths) may bunch-up. Stop the dryer 1-2
times during drying process to separate bunched-up
laundry.
Following weights are given as examples.
Home articles Approximate
weights (g)
Cotton quit covers (double) 1500
Cotton quit covers (single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Garments Approximate
weights (g)
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10 pieces) 100
T-Shirts 125
Loading
• Open the loading door.
• Place laundry items loosely into the dryer.
• Push the loading door to close. Ensure that no items
are caught in the door.

10 EN
4Selecting a Programme and Operating Your Machine
Control panel
56
12 3 4
End/anti-
creasing
Timer
program
mes
Cottons Synthetics Freshen up Iron dry Ekstra
dry
Cupboard
dry plus
Cupboard
dry
Drying
Buzzer/
cancel
On/Off Start
pause
cancel
Filter
cleaning
Child-proof
lock
Tank
full
Jeans Shirts Delicates Xpress
35’
1. Filter cleaning warning light
Warning light turns on when the filter is full.
2. Program follow-up indicator
Used to follow-up the progress of the current
programme.
3. Cancel audio warning
Used to cancel the audio warning given at the end of
the programme.
4. On/Off button
Used to turn on and off the machine.
5. Programme selection knob
Used to select a programme.
6. Start/Pause/Cancel button
Used to start, pause or cancel the programme.

11 EN
Preparing the machine
1. Plug in your machine.
2. Place the laundry in the machine.
3. Press the “On/Off” button.
C Pressing the “On/Off” button does not necessarily
mean that the programme has started. Press “Start/
Pause/Cancel” button of the machine to start the
programme.
Programme selection
Decide the appropriate programme from the table below
which includes drying temperatures in degrees. Select the
desired programme with the programme selection button.
Extra dry
Dry at high temperature only for
cotton laundry. Thick and multi
layered laundry (E.g.: towels, linens,
jeans) are dried in a way that they do
not require ironing before placing in
the wardrobe.
Cupboard dry
Normal laundry (E.g.: tablecloths,
underwear) are dried in a way that
they do not require ironing before
placing in the drawers.
Cupboard dry
Plus
Normal laundry (E.g.: tablecloths,
underwear) are dried in a way that
they do not require ironing before
placing in the drawers, but more than
those in the ready to wearoption.
Iron Dry Normal laundry (E.g., Shirts, dresses)
are dried ready to be ironed.
C For further program details, see, “Program
Selection Table”
Main programmes
Depending on the type of laundry, the following main
programmes are available:
•Cottons
You can dry your durable laundry with this programme.
Dries at high temperature. It is recommended to use
for your cotton items (such as bed sheets, quilt cover,
underclothing, etc.).
•Synthetics
You can dry your less durable laundry with this
programme. It dries at a lower temperature compared
to the cottons programme. It is recommended for your
synthetic laundry (such as shirts, blouses, synthetic/cotton
blended laundry, etc.).
C Do not dry curtains and lace in your
machine.
•Anti-creasing
A 2-hour anti creasing programme to prevent laundry from
creasing will be activated if you do not take the laundry out
after the programme is over. This programme rotates the
laundry in 10-minute intervals to prevent creasing.
Special programmes
For special cases, there are also extra programmes
available:
CAdditional programmes may differ according to the
model of your machine.
•Mini
You can use this programme to dry the cottons that are
spun at high speeds in your washing machine. It can dry
your 1,2 kg Cotton laundry (3 Shirts / 3 T-Shirts) within 30
minutes.
C In order to obtain better results from the dryer
programs, your laundry must be washed with
suitable program and spun at the recommended
spin speeds in your washing machine.
•Shirts
Dries the shirts in a more sensitive way so that they are
less creased and ironed easily.
CShirts may contain little amount of dampness at the
and of the program. It is advised not to leave the
shirts in the dryer.
•Jeans
You can use this program to dry the jeans that are spun at
high speeds in your washing machine.
C Review the relevant part of the program table.
•Delicates
You can dry at a lower temperature your very delicate
laundry (silk blouses, fine underwear, etc.) that are suitable
for drying or laundry which is advised to be hand-washed.
C It is recommended to use a cloth bag to avoid certain
delicate garments and laundry from getting creased
or damaged. Take your garments immediately out of
the dryer and hang them after the programme ends
in order to prevent them being creased.
•Freshen Up
Only ventilation is performed for 10 minutes without
blowing hot air. You can air your clothes that have been
kept at closed environments for a long time thanks to this
program to deodorize unpleasant odors.
•Timer programmes
You can select one of the 10 min., 20 min., 40 min. and
60 min. timer programmes to achieve the desired final
drying level at low temperatures. Programme dries at the
selected time regardless of the drying temperature.

12 EN
Program selection and consumption table
* : Energy Label standard program (EN 61121:2012)
All values given in the table have been fixed according to EN 61121:2012 Standard. These values may
deviate from the table according to the laundry type, laundry spin speed, environmental conditions and
voltage fluctuations.
EN 2
Programmes Capacity
(kg)
Washing machine spin
speed (rpm)
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
ACupboard Dry
71200-1000 60% 140
900-800 70% 150
3.5 1200-1000 60% 75
900-800 70% 90
ACupboard Dry Plus
71200-1000 60% 150
900-800 70% 160
3.5 1200-1000 60% 85
900-800 70% 100
AIron dry
71200-1000 60% 100
900-800 70% 115
3.5 1200-1000 60% 60
900-800 70% 75
Mini 1.2 1200-1000 50% 30
Shirts 1.5 1000-800 50% 49
Jeans 4 1200-1000 50% 100
Synthetics
BCupboard Dry
3.5 800 40% 55
600 50% 70
1.75 800 40% 35
600 50% 45
Delicates
BCupboard Dry 1.5 600 50% 40
Energy consumption values
Programmes Capacity
(kg)
Washing machine spin
speed (rpm)
Approximate
amount of
remaining
humidity
Energy consumption
value kWh
Cottons Linen Cupboard Dry* 7 1000 60% 4.2
Cottons iron dryn 7 1000 60% 3.1
Synthetics Cupboard Dry 3.5 800 40% 1.6

13 EN
Auxiliary function
Cancel audio warning
Your dryer will give an audio warning when the programme
comes to an end. If you do not want to hear the audio
warning, press “Cancel Audio Warning” button. The
relevant light will turn on when this button is pressed and
an audio warning will not be given when the programme
comes to an end.
CYou can select this function either before or after the
programme starts.
Warning indicators
CWarning indicators may differ according to the model
of your dryer.
Filter cleaning
A warning light will turn on to remind filter cleaning after
the programme finishes.
CIf the filter cleaning warning light lights up
continuously, please refer to, “Suggested solutions
for problems”.
Starting the programme
1. Press “Start/Pause/Cancel” button to start the
programme.
2. Light of the “Start/Pause/Cancel” button will turn on
to indicate that the programme has started.
Progress of program
Progress of a running program is shown through the
program follow-up indicator.
At the beginning of every program step, the relevant
indicator LED will light up and light of the completed step
will turn off.
“Drying”:
Drying level will be illuminated during the whole drying
process until the drying degree reaches “iron dry”.
“Iron Dry”:
Starts to illuminate when the drying degree reaches “iron
dry” step and remains illuminated until the next step.
“Ready to wear”:
Starts to illuminate when the drying degree reaches
“Ready to wear” step and remains illuminated until the
next step.
“Final / Anti-creasing”:
Illuminates when the program comes to an end and anti-
creasing function is activated.
C If more than one LED light up or flash concurrently,
it means there is malfunctioning or a failure (please
see, Solution suggestions for problems).
Changing the programme after it has started
You can use this feature to dry your clothes under higher
or lower temperatures after your dryer has started.
For example;
1. Press and hold the “Start/Pause/Cancel” button for
about 3 seconds to “Cancel” the programme in
order to select “Extra Dry” programme instead of
“Iron Dry” programme.
2. Select the “Extra Dry” programme by rotating the
programme selection button.
3. Press “Start/Pause/Cancel” button to start the
programme.
CPress “Start/Pause/Cancel” button for 3 seconds
to cancel the programme or turn the programme
selection knob in any direction to end the
programme while the machine is running. Water
tank and filter cleaning warning lights turn on to
warn the user when the programme is cancelled
by pressing the “Start/Pause/Cancel” button for 3
seconds. However, the warning lights do not turn
on when the programme is cancelled by turning the
programme selection knob. Only the drying light
turns on and the machine remains in hold until a
new programme is selected and the “Start/Pause/
Cancel” button is pressed. Child-proof lock of the
machine should not be active in order to perform
these two operations. If the child-proof lock is active,
deactivate it before performing these operations.
Adding/removing laundry in standby mode
In order to add or remove laundry after the programme
starts:
1. Press the “Start/Pause/Cancel” button to switch the
dryer to “Pause” mode. Drying process will stop.
2. Open the door at “Pause” position and close it again
after adding or taking out laundry.
3. Press “Start/Pause/Cancel” button to start the
programme.
CAny laundry added after the drying process has
started may cause the dried clothes in the machine
intermingle with wet clothes and the result will be
wet laundry after the drying process is over.
CLaundry may be added or taken out as much as
desired during a drying process, but this process will
extend the programme duration and increase energy
consumption since the drying will be interrupted
continuously. Therefore, it is recommended to add
laundry before the drying programme has started.
Child-proof lock
There is a child-proof lock to prevent any programme
interruption due to the pressing of button while the
programme is running. The loading door and all buttons
except the “On/Off” button on the control panel are
deactivated when the child-proof lock is active.
Press the “Start/Pause/Cancel” and “Cancel audio
warning” buttons simultaneously for 3 seconds to activate
the child-press lock.
To start a new programme after the programme is over or
to interrupt the programme, the child-proof lock should be
deactivated. Press the same buttons for 3 sec. again to
deactivate the child-proof lock.
C Child-proof lock is deactivated when the machine is
restarted by pressing the On/Off button.

14 EN
C Press the relevant buttons for 3 seconds to activate
the child-proof lock. A long beep will be heard and
the child-proof lock will be activated. A double beep
will be heard if you press any button or turn the
programme selection knob while the child-proof
lock is active. Press the buttons for 3 seconds to
deactivate the child-proof lock. Single beep will be
heard and child-proof lock will be deactivated.
AA double beep will be heard if you turn the
programme selection knob when the machine is
running and the child-proof lock is active. If you
deactivate the child-proof lock without returning the
program selection knob to its previous position, the
programme will be terminated since the position
of the programme selection knob is changed. The
drying light turns on and the machine remains on
hold until a new programme is selected and the
“Start/Pause/Cancel” button is pressed.
Ending the programme through canceling
To cancel any selected program;
Press “Start/Pause/Cancel” button for about 3 seconds.
The “Filter cleaning”, “Water tank” and “End/ Anti-
creasing” warning lights will turn on at the end of this
period for reminding purposes.
If you change the position of programme selection knob
while your machine is running, then the machine stops,
and the current programme is cancelled.
A As the inside of the machine will be excessively hot
when you cancel the program while the machine is
running, activate the ventilation program to cool it
down.
End of programme
The “End/Anti-creasing”, “Filter cleaning” and “Water
tank” warning lights on the programme follow up indicator
will turn on when the programme comes to an end. The
door can be opened and the machine becomes ready for
a second cycle.
Press “On/Off” button to turn off the dryer.
CFinal step of the drying cycle (cooling step) is
performed without heat application in order to keep
the items at a temperature that would not harm
them.
CA 2-hour anti creasing programme to prevent laundry
from creasing will be activated if you do not take
the laundry out after the programme has come to
an end.
CIf you will not take the laundry out immediately, do
not stop the dryer before the drying process is
complete.
CClean the filter after each drying (please see, Filter
cleaning).
CDrain the water tank after each drying (please see,
Water tank)

15 EN
5Maintenance and cleaning
Lint filter
Lint and fibres released from the laundry to the air during
the drying cycle are collected in the “Lint Filter”.
CSuch fibre and lint are generally formed during
wearing and washing.
CAlways clean the filter after each drying process.
CYou can clean the filter and filter area by vacuum
cleaner.
Figure 1
Figure 2
To clean the filter:
1.Take out the cover.
2.a) If the product’s lint filter can be opened as shown in
Figure 1, remove the filter by pulling it up and open
the filter.
2.b) If the product’s lint filter is as shown in Figure 2,
remove the filter by pulling it up.
3. Clean lint, fibre, and cotton raveling on the filter and
in the filter housing by hand or with a soft piece of
cloth.
4. Close the filter and place it back into its seat.
CClogging may arise on the filter surface after using
your machine for some time; if this occurs, wash the
filter with water and dry it before using again.
Sensor (models with a sensor)
There are humidity sensors in your dryer that detect
whether the laundry is dry or not.
To clean the sensor:
1. Open the loading door of the dryer.
2. Allow the machine to cool down if drying has been
carried out.
3. Wipe the metal sensors with a soft cloth, dampened
with vinegar and dry them.
CClean metal sensors 4 times a year.
ANever use solvents, cleaning agents or similar
substances when cleaning since these materials
can cause fire and explosion!

16 EN
6Solution suggestions for problems
Drying process takes too much time
• Meshes of the filter may be clogged. Wash with water.
Laundry come out wet at the end of drying.
• Meshes of the filter may be clogged. Wash with water.
• Excessive laundry might have been loaded in. Do not overload the machine.
Machine does not switch on or the program does not start. Machine is not activated when set.
• It might have not been plugged in. Make sure that the machine is plugged in.
• The loading door may be ajar. Make sure that the loading door is properly closed.
• Program might have not been set or the «Start/Pause/Cancel» button might have not been pressed. Make sure
that the program has been set and it is not in “Pause” mode.
• «Childproof lock» might have been activated. Deactivate the childproof lock.
• The condenser cover on the models with a condenser might not be closed securely. Make sure that the
condenser cover and the red lock is closed securely.
Program has been interrupted without any cause.
• The loading door may be ajar. Make sure that the loading door is properly closed.
• Electricity may be cut off. Press «Start/Pause/Cancel» button to start the program.
• The condenser cover on the models with a condenser might not be closed securely. Make sure that the
condenser cover and the red lock is closed securely.
Laundry has shrunk, become felted or deteriorated.
• A program suitable for the laundry type might have not been used. Dry only the laundry which is suitable for
drying in your machine after checking the labels on your clothes.
• Select a program with suitable low temperature for the laundry type to dry your clothes.
Drum lightning does not come on. (for models equipped with a lamp)
• The machine might have not been started by using the On/Off button. Make sure that the machine is On.
• Bulb may have blown. Call the authorized service to replace the bulb.
• The condenser cover on the models with a condenser might not be closed securely. Make sure that the
condenser cover and the red lock is closed securely.
2 beeps heard when the buttons are pressed or the program selection knob is turned.
• Childproof lock» might have been activated. Deactivate the childproof lock.
• Program selection knob might be turned to an undefined position. Select one of the defined programs.
“Filter cleaning” light is flashing.
• Filter might have not been cleaned. Clean the cover filter.
“Final / Anti-creasing” LED is on.
• Program has come to an end. Turn off the machine and take out the laundry.
3 beeps are heard when you press the Start/Pause/Cancel button
• The loading door may be ajar. Make sure that the machine is plugged in.
• Make sure that the condenser cover and the red lock is closed securely.
Also for products equipped with a condenser:
“Water tank” warning LED is flashing.
• Water may be full.
• Drain the water in the water tank.
A Call an authorised service agent if the problem persists.

2960310865_TH/051213.1659

















 
C 
A 
B 
 
 

18 TH
1 






 




 


 



 


 



  









 








 



 




 

 



 




 

 






 


 



 







 




 

 



 





19 TH





A




 



 



  

 

 





 




 


 


 


 

 




 
 
 


 



 

 


 

 






 


 

 

 







 



 

 

 




20 TH


































