Beko ICQFDB155 Instruction Manual

EN
Instruction of use
Frost Free Combi Built-In Fridge / Freezer
ICQFDB155

Please read these instructions first before using your appliance
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance, to
ensure you know how to safely operate the controls and functions. Carefully
follow all unpacking and installation instructions to ensure the appliance is
correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this user
manual, and store in a safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences
between models will be listed.
If you have any questions or concerns, please call our contact centre or find
help and information online at www.beko.co.uk.
Explanation of symbols used throughout this User Manual
- The terminal in the plug is marked with the symbol.
- The freezer compartment is marked with the symbol.
-Some installation steps in furniture are marked with the symbol
of attention.
-Important information or useful usage tips.
Contents

C
Introduction & safety warnings...........................................................................2
Electrical requirements......................................................................................3
Transportation instructions.................................................................................4
Important installation instructions ......................................................................5
Getting to know your fridge / freezer..................................................................6
Suggested arrangement of food in the fridge / freezer......................................7
Temperature control and adjustment.................................................................8
Starting.................................................................................................. .............9
Storing frozen food..................................................................................... ........9
Freezing fresh food............................................................................... ........... ...9
Making ice cubes................................................................................................9
Defrosting.........................................................................................................10
Cleaning and care............................................................................................11
Replacing the interior light bulb........................................................................11
Do's and don'ts.................................................................................................12
Energy saving tips............................................................................................13
Problem solving ...............................................................................................13
Installation instructions detailed step by step...................................................14
Reversing the doors.........................................................................................21
Standard manufacturer guarantee terms and conditions................... ...............26
How to obtain service for your appliance............................................. .............28
Please keep this handbook for future reference, or for anyone else who may use the appliance.
Installation of high levelling foot........................................................................23
Built-in appliances guarantee terms and conditions...................... ............. .......27


Congratulations on your choice of a quality Appliance which has been designed to give you service for
many years.
WARNING !
IMPORTANT !
DO NOT connect your appliance to the electricity supply until all packing and transit protectors have been
removed.
•Leave to stand for at least 4hours before switching on to allow compressor oil to settle if transported
horizontally.
r, disable the lock/latch,
ensure that it is left in a safe condition to prevent the entrapment of young children.
•This fridge/freezer must only be used for its intended purpose i.e.the storing and freezing of edible
an ongoing commitment. This appliance which is among the latest range introduced is particularly
environment friendly. Your appliance contains non CFC / HFC natural substances in the cooling
transpor
ignition source and immediately ventilate the room where the appliance is situated.
•We suggest you contact your local authority for disposal information and facilities available
•See Installation Instructions on page 5for information on suitable location.
•To obtain the best possible performance and trouble free operation from your appliance it is very
important to carefully read these instructions.
•On delivery, check to make sure that the product is not damaged and that all the parts and accessories
are in perfect condition.
•Ensure that the plug remains readily accessible. Do not use a multiple adapter bar or extension cable.
•Failure to observe these instructions may invalidate your right to free service during the guarantee
period.
WARNING- Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING- Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING- Do not damage the refrigerant circuit.
WARNING- Do not use electrical appliances inside the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
•We suggest you keep these instructions in a safe place for easy reference.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•If there is a blue light on the refrigerator, do not look at the blue light with optical tools.
PERFORMANCE
Energy ef
Energy consumption - Kwh/year
Net storage - vol fresh food ltrs (cu. ft.)
Total net vol - ltrs (cu. ft.)
Frozen food compartment rating
Conservation time from failure
Freezing capacity fresh food - kg (lb) / 24 hrs.
Climate class
Operating noise level dB(A)
Net storage - vol frozen food ltrs (cu. ft.)
A+
163 (5.8)
254 (9.0)
13 h.
4.25 (9.4)
4 STAR
91 (3.2)
298
40
Frost Free Combi
Fridge Freezer
ICQFDB155
SN-ST


ELECTRICAL REQUIREMENTS
Before you insert the plug into the wall socket make sure that the voltage and the
frequency shown in the rating plate inside the appliance corresponds to your
electricity supply.
Rating label is on the left hand side of fridge inner liner.
We recommend that this appliance is connected to the mains supply via a
suitable switched and fused socket in a readily accessible position.
WARNING: When positioning the appliance ensure the supply cord is not trapped
or damaged.
Should the mains lead of the appliance become damaged or should it need
replacing at any time, it must be replaced by a special purpose made mains lead
which can only be obtained from a Beko Authorised Service Agent.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted moulded plug is not suitable for your socket, then the plug should be cut
off and an appropriate plug fitted. Destroy the old plug which is cut off as a plug with
bared cord could cause a shock hazard if inserted into a socket elsewhere in the
house.
The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse need
to be replaced an ASTABEAB approved BS 1362 fuse of the same rating must be
used. Do not forget to refit the fuse cover. In the event of losing the fuse cover the
plug must not be used until a replacement fuse cover has been fitted. Colour of the
replacement fuse cover must be the same colour as that visible on the pin face of
the plug. Fuse covers can be obtained from an authorised service agent.
IMPORTANT! FITTING A DIFFERENT PLUG
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug
proceed as follows (see diagram):
1. Connect the green-yellow or green (Earth) wire
to the terminal in the plug marked 'E' or with the
symbol or coloured green and yellow or green.
2. Connect the blue (Neutral) wire to the terminal
in the plug marked 'N' or coloured black.
3. Connect the brown (Live) wire to the terminal in
the plug marked 'L' or coloured red.
With alternative plugs a 13A fuse must be
fitted either in the plug or adaptor or in the main fuse
box. If in doubt contact a qualified electrician.
WARNING: Do not locate extension sockets or charging transformers/power
supplies or Lithium-Iron battery operated products adjacent to the compressor as
they could overheat.
