Beko RCF582W User manual
RCF582W
Frost Free Combi
Fridge/Freezer
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in in a 1st class
manufacturing facility and checked under the most meticulous quality control
procedures, will provide you with many years of good service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future reference.
This manual
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
EN
3
1 Your refrigerator 4
2 Warnings 5
Electrical requirements........................... 7
Warning! This appliance must be
earthed.......................................................... 7
Energy saving tips.....................................8
Compliance with WEEE Directive and
Disposing of the Waste Product: .......9
Compliance with rohs directive: .........9
Package information..............................10
3 Installation 11
................ 11
.................................................... 11
....................... 11
....13
.............................14
...............................16
4 Before operating 17
Final Check ................................................. 17
5 Using your refrigerator 18
Temperature Control And
Adjustment................................................18
.................................19
.............................. 20
.............................. 20
.................................... 20
Defrosting ..................................................21
6 Maintenance and
cleaning 22
7 Do's and Don'ts 23
Problem Solvıng ...................................... 24
8 Guarantee Details 25
9 How To Obtain Service 26
EN
4
1Your refrigerator
Congratulations on your choice of a Beko quality Appliance which has been
designed to give you service for many years.
Figures that take place in this instruction manual are schematic and may not
the product you have purchased, then it is valid for other models.
1. Temperature setting control
2.
3. Cabinet shelves
4. Defrost water collection
channel
5. Salad crisper
6.
7.
8.
9.
10. Adjustable feet
11. Dairy compartment
12. Egg tray
13. Door shelves
14. Fridge compartment
15.
10
11
13
12
14
6
7
9
15
EN
5
2Warnings
Do not connect your
appliance to the
electricity supply until
all packing and transit
protectors have been
removed.
stand upright for at
least 4 hours before
switching on to allow
compressor oil to settle
old refrigerator with a
lock or latch fitted to the
door, disable the lock/
latch, ensure that it is
left in a safe condition to
prevent the entrapment
of young children.
must only be used for its
intended purpose i.e the
edible foodstuff.
Do not dispose of the
appliance on a fire.
At Beko, the care
and protection of our
environment is an
ongoing commitment.
This appliance which is
among the latest range
introduced is particularly
environment friendly.
Your appliance
contains non CFC / HFC
natural substances
in the cooling system
in the insulation
which are potentially
flammable if exposed
to fire. Therefore, take
care not to damage,
the cooling circuit /
pipes of the appliance
in transportation
damage do not expose
the appliance to fire
or potential ignition
source and immediately
ventilate the room
where the appliance is
situated.
We suggest you contact
your local authority for
disposal information
and facilities available.
8 for information on
suitable location.
EN
6
To obtain the best
possible performance
and trouble free
operation from your
appliance it is very
important to carefully
read these instructions.
On delivery, check to
make sure that the
product is not damaged
and that all the parts
and accessories are in
perfect condition.
Ensure that the
plug remains readily
accessible. Do not use
multiple adapter or
extension cable.
Failure to observe
these instructions may
invalidate your right to
free service during the
guarantee period.
openings, in the
appliance enclosure or
in the built-in structure,
clear of obstruction.
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
Do not damage the
refrigerant circuit.
Do not use electrical
appliances inside
the food storage
compartments of
the appliance, unless
they are of the type
recommended by the
manufacturer.
We suggest you keep
these instructions in
a safe place for easy
reference.
This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe
way and understand
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.
EN
7
Children should be
supervised to ensure
that they do not play
with the appliance.
Electrical
requirements
the plug into the wall
socket make sure that
the voltage and the
frequency shown on the
rating plate inside the
appliance corresponds to
your electricity supply.
hand side of fridge inner
liner.
We recommend that this
appliance be connected
to the mains supply
via a suitable switched
and fused socket. The
appliance must be
positioned so that the
plug is accessible.
WARNING:
When positioning the
appliance ensure the
supply cord is not trapped
or damaged.
Should the mains lead
of the appliance become
damaged or should it
need replacing at any
time, it must be replaced
by a special purpose
made mains lead which
can only be obtained
from a Beko authorised
service agent.
Warning! This
appliance must be
earthed
plug is not suitable for
your socket, then the
plug should be cut off
and an appropriate plug
fitted. Destroy the old
plug which is cut off as
a plug with bared cord
could cause a shock
socket elsewhere in the
house.
Themouldedplugonthis
appliance incorporates
a 13 A fuse. Should the
fuse need to be replaced
rating must be used. Do
not forget to refit the
losing the fuse cover the
plug must not be used
until a replacement fuse
cover has been fitted.
EN
8
Colour of the
replacement fuse cover
must be the same colour
as that visible on the pin
face of the plug. Fuse
covers are available from
any good electrical store.
Important! Fitting A
Different Plug
1. As the colours of the
wires in the mains
lead of this appliance
may not correspond
with the coloured
markings identifying the
terminals in your plug
proceed as follows: (See
2.Connect the green-
wire to the terminal
in the plug marked ‘E’
or with the symbol
or coloured green and
yellow or green.
3.Connect the blue
terminal in the plug
marked ‘N’ or coloured
black.
4.Connect the brown
terminal in the plug
red.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP
5.With alternative plugs a
13 A fuse must be fitted
either in the plug or
adaptor or in the main
contact a qualified
electrician.
Energy saving tips
1. Ensure your appliance
is installed in a well
ventilated area.
2.Ensure the time
between buying chilled/
them in your appliance
is kept at minimum,
particularly in summer.
We recommend you use
a cool bag or a special
carrier bag to carry
perishable food.
3.
of your appliance open
longer than necessary
EN
9
and ensure they are
closed properly after
each opening.
4.
food in the fridge
compartment, so that
ice pack to assist cooling
in the fridge.
5.Energy consumption
of this appliance is
compartment is loaded
without use of top shelf
lid and the drawers
except the bottom
is loaded without use
of drawers except the
bottom drawer in order
to achieve maximum
loading capacity.
Compliance with
WEEE Directive and
Disposing of the
Waste Product:
This product
complies with EU
WEEE Directive
This product
bears a classification
symbol for waste
electrical and electronic
product has been
manufactured with high
quality parts and
materials which can be
reused and are suitable
for recycling. Do not
dispose of the waste
product with normal
domestic and other
wastes at the end of its
service life. Take it to the
collection center for the
recycling of electrical and
electronic equipment.
Please consult your local
authorities to learn
about these collection
centers.
Compliance with rohs
directive:
The product you have
purchased complies
not contain harmful and
prohibited materials
specified in the Directive.
EN
10
Package information
Packaging materials
of the product are
manufactured from
recyclable materials in
accordance with our
National Environment
dispose of the packaging
materials together
with the domestic or
other wastes. Take
them to the packaging
material collection points
designated by the local
authorities.
EN
11
3Installation
Transportation
Instructions
1. The appliance should be
transported only in a vertical upright
position. The packing as supplied
must be intact during transportation.
2.
transport the appliance has to be
be laid on its right hand side when
standing in the front of the appliance.
After bringing it to upright position,it
must not be operated for at least 4
hours to allow the system to settle.
3. Failure to comply with the
above instructions could result in
damage occurring to the appliance.
The manufacturer will not be held
responsible if these instructions are
disregarded.
4. The appliance must be
protected against rain, moisture and
other atmospheric influences.
5. When positioning your
appliance take care not to damage
your flooring, pipes, wall coverings
etc. Do not move the appliance by
pulling by the door or handle.
6. Empty any water in the drain
tray before moving. See section
‘Defrosting’ and ‘Care & cleaning’ for
further information.
7. Make sure that the defrost
water pipe at the back of the product
is fixed to the plastic evaporating pan
on the top of the compressor, to avoid
defrost water spillage on the floor.
Important :
Care must be taken while cleaning
/ carrying the appliance to avoid
touching the bottom of the condenser
metal wires at the back of the
appliance as you might injure your
fingers and hands.
Do not attempt to sit or stand on top
of your appliance as it is not designed
for such use. You could injure yourself
or damage the appliance.
Important:
Make sure that mans cable s not
caught under the applance durng and
after carryng / movng the applance,
to avod the mans cable becomng cut
or damaged.”
Important:
Ths applance s not desgned for
stackng wth any other applance.
When postonng your applance,
take care not to damage your floorng,
ppes,wall coverngs etc.
Do not allow chldren to play wth
the applance or tamper wth the
controls. Beko declnes to accept any
lablty should the nstructons not be
followed.
Important
Installation Instructions
1. The space in the room where
the appliance is installed must not be
smaller than 10 cubic metres.
2. This appliance has been
designed to operate in ambient
temperatures up to 32 degrees C
EN
12
at the advised setting [4 - four on
ambient temperature falls as low as
-15 °C. So you may then install your
appliance in a garage or an unheated
room without having to worry about
spoilt. However at low ambient
temperatures mentioned above,
so check and consume food in the
fridge accordingly. When the ambient
temperature returns to normal, you
may change the setting to suit your
needs.
3. Do not place the appliance near
cookers, radiators or in direct sunlight
as this will cause your appliance
maintain the following minimum side
clearances:
4. Make sure that sufficient room
is provided around the appliance to
ensure free air circulation. Fit the two
plastic wall spacers supplied with the
appliance onto the condenser on the
back of the appliance by rotating 1/4
5.
be located on a smooth surface.
The two front feet can be adjusted
as required. To ensure that your
appliance is standingupright adjust
the two front feet by turning
clockwise or anti-clockwise, until
the product is in firm contact with
the floor. Correct adjustment of feet
avoids excessive vibration and noise.
6.
section to prepare your appliance for
use.A special receptacle is supplied to
store the mains plug during transit.
The receptacle is fixed at the back
of the cabinet, on the side of the
remove the plug from the receptacle.
Never pull the mains cord, you may
of transportation, ensure you locate
the plug in the receptacle provided to
avoid transit damage.
WARNING
Do not locate extension sockets
or charging transformers/power
operated products adjacent to the
compressor as they could overheat.
EN
13
Replacing The Interior
Light Bulb
Should the lght fal to work, proceed
as follows.
1. Switch off at the socket outlet
and pull out the mains plug.
2. You may find it useful to
remove shelves for easy access.
3. Use a flat tipped screwdriver
to remove the light diffuser cover by
inserting the blade in each of the two
recesses to prise off each side.
4. First check that the bulb
hasn’t worked loose by ensuring it
is screwed securely in the holder.
bulb works, replace the light cover by
inserting the rear lug and pushing up
to locate the front two lugs.
5.
switch off at the socket outlet and
6. Carefully dispose of the
burnt-out light bulb immediately.
obtained from a good local electrical
EN
14
Reversing The Doors
We recommend that you reverse
doors before switching on for the first
time.
flat and cross-headed screwdrivers, a
pair of pliers.
Spare Parts supplied in the plastic
bag: The following parts, which are
exclusively for left hand side fitted
hinge operation are supplied in a
plastic bag with the appliance:
- Upper door top trim hinge covers
– there are 2 different parts, one for
each side of top trim.
- Upper door middle hinge bushing/
door stopper assembly.
We suggest you keep all the parts
supplied in the plastic bag and also
parts, which have been removed
when reversing doors, in a safe place
for possible future, re-use.
IMPORTANT:
We suggest you ask somebody to
help you when moving the appliance
around and to hold doors when
removing / re-fitting hinges and doors
to avoid any injury and damage to the
product.
Please refer to diagrams supplied.
To follow numbers in brackets below,
refer to the main diagram.
1. Switch off the appliance at the
socket outlet and pull out the mains
plug.
2.
fittings and food, if any, from inside
the appliance and door racks.
3.
cover of upper door top trim and
hinge covers on both sides of front
top panel using a small flat-headed
4.
against a strong wall on its rear side
sufficiently to allow the lower hinge
to be removed. Take care to protect
the appliance, your wall and floor
coverings. You can utilise the original
packaging to do this. Once you tilt the
appliance back, check to make sure
the appliance is completely stable and
5. Unscrew and remove the
lower hinge using a cross-headed
screwdriver while holding the lower
6.
off the middle hinge and stand door
7. Open upper door and unscrew
and remove the middle hinge while
holding the upper door firmly. Use a
flat-headed screwdriver. Middle hinge
will need to be rotated 180 degrees
before re-fitting on the opposite side.
8.
off the upper hinge and stand door
9. Unscrew and remove the
upper hinge using a flat-headed
10.
degrees and then unscrew and
remove the hinge pin using a pair of
pliers and re-fit to opposite side of
11.
pin bushings on top of doors on the
opposite side of both doors. Use small
flatheaded screwdrivers to remove
plugs and bushings. Take care not to
EN
15
12.
Unscrew and remove the bottom
door hinge pin bushing/door
stopper using a cross-headed
screwdriver. (11)Unscrew and
remove the upper door middle
hinge pin bushing/door stopper
using a cross-headed screwdriver.
IMPORTANT:This part cannot be
used on the opposite side; left hand
side middle hinge pin bushing/door
stopper part is supplied in the plastic
13.
left hand side using flat-headed
14. Fit upper door left hand side
middle hinge pin bushing/door
stopper supplied in the plastic bag
15.
plugs on the left hand side, which are
covering middle hinge holes, on the
opposite side to cover holes left
16.
upper hinge and hold the door firmly.
17.
to middle hinge pin bushing of upper
door on the left hand side and re-fit
left screw when the door is closed
and then fit the right screw after
opening the door for access.
18.
lower hinge hole on the left hand side
at the bottom of the cabinet on the
19.
to middle hinge pin and then re-fit
the lower hinge on the left hand side.
20. Carefully stand the appliance
upright and adjust the two front feet
if necessary.
21. Check that doors open and
close easily, they are aligned correctly
and that there are no gaps allowing
between the door seal and the
cabinet, adjust the door seal by gently
pulling away from the door using
fingers.
22. Check that all the hinge screws
are tightened. Avoid over tightening
the screws.
23. Put all items, fittings back in
the appliance.
24.Fit upper door top trim and
front top panel plastic hinge covers.
Upper door top trim hinge covers are
25. Wait for at least 4 hours to
allow the system to settle before
switching on.
26. Once the correct storage
temperatures have been reached in
the appliance, put back all the food.
EN
16
1
17
1
20
11
13 9
6
2
10
5
14
3
20
20
8
12
18
16
17
19
180°
(8) (13)
45°
15
4
Reversing the doors
Proceed in numerical order
EN
17
4Before operating
Final Check
1. The feet have been adjusted
for perfect levelling.
2. The interior is dry and air can
circulate freely at the rear of the
cabinet.
3. Clean the interior as
4.
socket and switch on the electricity
supply.
5. When the door is open the
fridge interior light will come on.
6. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
whether the compressor is running
or not which is quite normal.“Due
to operation of the fan inside the
overall noise level is slightly higher
in comparison to non-frost free
appliances. This is quite normal and is
not a fault.”
7. Set the setting half way
between min and max.
8. Front edges of the cabinet may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
9. “Do not load the appliance
immediately it is switched on. Wait
until the correct storage temperature
has been reached. We recommend
that you check the temperature
with an accurate thermometer
(see; Temperature Control and
10.
the noise will be louder when the
11. Avoid spillage of food
particularly small items like rice,
peas, beans through the fan guard as
they may cause the cooling system
to block and therefore operate less
efficiently.
EN
18
5Using your refrigerator
Temperature Control And Adjustment
Operating temperatures are
controlled by the thermostat (see
fridge compartment. Settings may be
made from min, 1 ... 6, max, max being
the coldest position.
When the appliance is switched on
for the first time, the setting should
be adjusted so that after 24 hours,
the average fridge temperature is
recommend you set the thermostat
half way between the min and max
setting and monitor to obtain the
desired temperature i. e. towards
max you will obtain a colder fridge
temperature and vice versa. Some
sections of the fridge may be cooler or
warmer ( such as the salad crisper and
quite normal.
The normal storage temperature
by adjusting setting towards max
position.
We recommend that you check
the temperature with an accurate
thermometer to ensure that the
storage compartments are kept to the
desired temperature.
reading very quickly since the
thermometer temperature will rise
very rapidly after you remove it from
the appliance.
Please remember each time the
door is opened cold air escapes
and the internal temperature rises.
Therefore never leave the door open
and ensure it is closed immediately
after food is put in or removed.
the fridge compartment, reduce the
thermostat setting to 1, monitoring
at the same time that the fridge
temperature is maximum +5
degreesC [41 degrees F]. Once the
ice build up disappears and the
appliance starts auto defrosting again
as normal,then you may increase the
thermostat setting, if required.
EN
19
Suggested Arrangement
Of Food In The Fridge/
Freezer
recommendation for storage
as stated on the food packaging
should be observed at all times.
3. Cooked dishes must be stored
in airtight covered containers.
4. Fresh wrapped produce can be
placed on the shelf. Fresh fruit and
vegetables should be cleaned and
stored in the crisper bins.
5.
door section.
6. To store raw meat, wrap in
polythene bags and place on the
lowest shelf. Do not allow to come
into contact with cooked food to avoid
contamination. For safety, only store
raw meat for two to three days.
7.
or covered. Allow hot food and
beverages to cool before placing them
in the fridge. Do not store explosive
substances. High proof alcohol
must be stored upright in sealed
should not be stored in the can.
8.
water ices should not be consumed
too cold.
9. Some fruit and vegetables
suffer damage if kept at
temperatures near 0°C. Therefore
wrap pineapples, melons, cucumbers,
tomatoes and similar produce in
polythene bags.
10. Place chilled cooked food and
similar food near the rear of the
fridge inner liner where the cold wall
is located.
11. Shelves, racks, crisper bins,
drawers, flaps, bottle grippers are all
removable.
Arrangement Examples (See
1.
dairy products, cans.
2. Meat, sausages, cold cuts.
3. Fruit, vegetables, salads.
4. Making, storing ice cubes.
5.
6.
fresh food.
7.
8. Small bottles, cans, tubes.
9. Eggs.
10.
The followng gudelnes and
recommendatons are suggested to
obtan the best results and storage
hygene.
1. The fridge compartment is for
the short term storage of fresh food
and drinks.
2.
is rated and suitable for
10
7
1
3
4
6
9
2
8
5
EN
20
12.
room temperature to thaw; the best
way to defrost food is to put it in the
fridge to thaw slowly. Make sure you
avoid defrosting food or food juices
drip onto other food.
13. For hygiene reasons, always
wrap food using a suitable packaging
material before storing in your
appliance to avoid contact with the
appliance surface.
Storing Frozen Food
food should be stored n accordance
nstructons for a
storage compartment.
To ensure that the hgh qualty
manufacturer and the food retaler s
mantaned, the followng should be
remembered:
1.
quickly as possible after purchase.
2. Ensure that contents are
labelled and dated.
3.
not be affected f the falure lasts for
then the food should be checked and
ether eaten mmedately or cooked
Freezing Fresh Food
Please observe the followng
nstructons to obtan the best results.
any one tme. The qualty of the food
rght through to the core as quckly as
possble.
of your applance n 24 h whch s 4 kg
compartment causes the refrgeraton
compressor to operate contnuously
temporarly lead to excessve coolng
of the refrgeraton compartment.
thermostat towards MAX. Small
the temperature control.
Take specal care not to mx already
Making Ice Cubes
Fll the ce - cube tray 3/4 full wth
of a spoon, never use sharp edged
objects such as knves, forks. Store
not consumed for several weeks
dsappear completely.
Table of contents
Other Beko Freezer manuals
Beko
Beko FROST FREE COMBI CDA 563 F Installation instructions
Beko
Beko C467-HC User manual
Beko
Beko RFNES312T35X User manual
Beko
Beko CDA 645 F Owner's manual
Beko
Beko FSA13000 User manual
Beko
Beko HSM10440 Instruction Manual
Beko
Beko FSA 716 User manual
Beko
Beko HSA24540N User manual
Beko
Beko RFNK290E23W User manual
Beko
Beko HSA37520 User manual
Beko
Beko CF1300APW User manual
Beko
Beko BC502 Assembly instructions
Beko
Beko BVF290PX User manual
Beko
Beko RFNE320L24W User manual
Beko
Beko RFNE 312E35 W User manual
Beko
Beko HSA11500 User manual
Beko
Beko RCNA460SX User manual
Beko
Beko TZS 492 User manual
Beko
Beko FSE13040N User manual
Beko
Beko HSA 29530 User manual
