Beko RFNE448E41W User manual

RFNE448E45W - RFNE448E35W - RFNE448E41W
RFNE448E35XP - EX448E45W


Congélateur
Manuel d'utilisation
Diepvriezer
Gebruiksaanwijzing
EN / DE / FR / NL / AR
58 3697 0000 / AG
Kühlschrank/Gefrierschrank
Bedienungsanleitung
Freezer
User manual

Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in
modern facilities with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In
case the product changes hands, do not forget to hand the guide to its new owner
along with the product.
This guide will help you use the product quickly and safely.
 Please read the user guide carefully before installing and operating the product.
 Always observe the applicable safety instructions.
 Keep the user guide within easy reach for future use.
 Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide
clearly indicates any variations of different models.
CImportant information and
useful tips.
ARisk of life and property.
BRisk of electric shock.
The product’s packaging
is made of recyclable
materials, in accordance
with the National
Environment Legislation.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

3 / 22 EN
Refrigerator/User Manual
1- Safety Instructions 4
A 1.1 Intended Use ...................................4
A1.2 - Safety for children, vulnerable
persons and pets . . . . . . . . . . . . . . . . . . 4
A1.3 - Electrical safety . . . . . . . . . . . . . . 5
A1.4 - Transportation safety. . . . . . . . 5
A1.5 - Installation safety . . . . . . . . . . . . 5
A1.6- Operational safety . . . . . . . . . . . . 6
A1.7- Maintenance and cleaning
safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
A1.8- HomeWhiz . . . . . . . . . . . . . . . . . . . . 8
A1.9- Lighting . . . . . . . . . . . . . . . . . . . . . . . 8
2 Your Freezer 9
3 Installation 10
3.1 Appropriate Installation Location.10
3.2 Installing the Plastic Wedges..........11
3.3 Adjusting the Feet...............................11
3.4 Electrical Connection .........................11
3.5 Door Open Warning............................12
3.6 Changing the illumination lamp ... 12
3.7 Changing the door opening
direction ......................................................... 12
4 Preliminary preparation 13
5 Operating the product 15
5.1 Indicator panel...................................... 15
5.2 Freezing fresh food............................ 17
5.3 Recommendations for preservation
of frozen food ..............................................18
5.4 Deep-freeze information ................18
6 Maintenance and cleaning 19
6.1 Avoiding bad odours . . . . . . . . . . . . . . . 19
6.2 Protecting the plastic surfaces . . . 19
7 Troubleshooting 20

4 / 22 EN Refrigerator/User Manual
 This section contains safety
instructions that will help get
protected against risks of personal
injury or property damage.
 Our company shall not be responsible
for damages that may arise when
these instructions are not followed.
A Installation and repair procedures
must always be performed by the
manufacturer, authorised service agent
or a qualified person specified by the
importer.
A Only use original parts and
accessories.
A Do not repair or replace any part of
the product unless specified expressly in
the user manual.
A Do not make any technical
modifications to the product.
A 1.1 Intended Use
 This product is not suitable for
commercial use and it must not be
used out of its intended use.
This product is designed to be used in
houses and indoor places.
For example:
- Personnel kitchens in stores, offices
and other working environments,
- Farm houses,
- Areas used by customers at hotels,
motels and other types of accommoda-
tion,
- Bed&breakfast type hotels, boarding-
houses,
- Catering and similar non-retail applica-
tions.
This product should not be used outdo-
ors with or without a tent above it such
as boats, balconies or terraces. Do not
expose the product to rain, snow, sun or
wind.
There is the risk of fire!
A1.2 - Safety for child-
ren, vulnerable per-
sons and pets
 This product can be used by children
at and above 8 years old and by
persons with limited physical, sensory
or mental capabilities or who lack
experience and knowledge provided
that they are supervised or trained on
the safe use of the product and the
risks it brings out.
 Children aged from 3 to 8 years
are allowed to load and unload
refrigerating products.
 Electrical products are dangerous for
children and pets. Children and pets
must not play with, climb or enter the
product.
 Cleaning and user maintenance
should not be performed by children
unless they are supervised by
someone.
 Keep packaging materials away from
children. There is the risk of injury
and suffocation!
 Before disposing of the old or
obsolete product:
 Unplug the product by gripping from
the plug.
 Cut the power cable and remove it from
the appliance together with its plug
 Do not remove the shelves or drawers
so that it is harder for children to enter
the product.
 Remove the doors.
1- Safety Instructions

5 / 22 EN
Refrigerator/User Manual
Safety and environment instructions
 Keep the product in a way that it will
not tip over.
 Do not allow children play with the old
product.
 Never throw the product into fire
for disposal. There is the risk of
explosion!
 If there is a lock on the door of the
product, the key should be kept out
of the reach of children.
A1.3 - Electrical safety
 The product must be unplugged
during installation, maintenance,
cleaning, repairing and moving
procedures.
 If the power cable is damaged, it must
be replaced by a qualified person
specified by the manufacturer,
authorised service agent or importer
in order to avoid potential dangers.
 Do not squeeze the power cable
under or behind the product. Do not
place heavy objects on the power
cable. Power cable must not be bent
excessively, pinched or get in contact
with any heat source.
 Do not use extension cords, multi-
sockets or adapters to operate the
product.
 Portable multi-sockets or portable
power sources can overheat and
cause fire. Therefore, do not keep
any multi-sockets behind or near the
product.
 Plug must be easily accessible. If
this is not possible, the electrical
installation to which the product is
connected must contain a device
(such as a fuse, switch, circuit
breaker, etc.) which conforms to the
electrical regulations and disconnects
all poles from the grid.
 Do not touch the power plug with
wet hands.
 Remove the plug from the socket by
gripping the plug and not the cable.
A1.4 - Transportation
safety
 Product is heavy; do not move it
alone.
 Do not hold its door when moving the
product.
 Pay attention not to damage the
cooling system or the piping during
transportation. If the piping is
damaged, do not operate the product
and call the authorised service agent.
A1.5 - Installation safety
 Call the authorised service agent
for installation of the product. To
make the product ready for use,
check the information in the user
manual to make sure that the
electricity and water installations
are suitable. If they are not, call a
qualified electrician and plumber to
have the necessary arrangements
made. Otherwise, there is the risk of
electric shock, fire, problems with the
product, or injury!
 Prior to installation, check if the
product has any defects on it. If the
product is damaged, do not have it
installed.
 Place the product on a clean, flat
and solid surface and balance it
with adjustable feet. Otherwise,
the product may tip over and cause
injuries.
 The installation location must be
dry and well ventilated. Do not place
carpets, rugs or similar covers under
the product. Insufficient ventilation
causes the risk of fire!

6 / 22 EN Refrigerator/User Manual
Safety and environment instructions
 Do not cover or block the ventilation
openings. Otherwise, power
consumption increases and your
product may get damaged.
 Product must not be connected to
supply systems such as solar power
supplies. Otherwise, your product
may get damaged due to sudden
voltage changes!
 The more refrigerant a refrigerator
contains, the larger the installation
location must be. If the installation
location is too small, flammable
refrigerant and air mixture will
accumulate in cases of refrigerant
leakage in cooling system. The
required space for each 8 gr of
refrigerant is 1 m3minimum. The
amount of refrigerant in your
product is indicated on the Type
Label.
 Product must not be installed in
places exposed to direct sunlight
and it must be kept away from heat
sources such as hobs, radiators, etc.
If it is inevitable to install the product
close to a heat source, a suitable insu-
lation plate must be used in between
and the following minimum distances
must be kept to the heat source:
- Minimum 30 cm away from heat
sources such as hobs, ovens, heater
units or stoves,
- Minimum 5 cm away from electric
ovens.
 Protection class of your product
is Type I. Plug the product in a
grounded socket that conforms
the voltage, current and frequency
values stated on the type label of
the product. The socket must be
equipped with a 10 A – 16 A circuit
breaker. Our company shall not
be liable for any damages that
will arise when the product is used
without grounding and electrical
connection in accordance with the
local and national regulations.
 Product must not be plugged in
during installation. Otherwise, there
is the risk of electric shock and injury!
 Do not plug the product in sockets
that are loose, dislocated, broken,
dirty, greasy or bear the risk of
getting in contact with water.
 Route the power cable and hoses (if
any) of the product in a way that they
do not cause risk of tripping over.
 Exposing the live parts or power cable
to humidity may cause short circuit.
Therefore, do not install the product
in places such as garages or laundry
rooms where humidity is high or
water may splash. If the refrigerator
gets wet with water, unplug it and
call the authorised service agent.
 Never connect your refrigerator to
energy saving devices. Such systems
are harmful to your product.
A1.6- Operational safety
 Never use chemical solvents on
the product. There is the risk of
explosion!
 If the product malfunctions, unplug it
and do not operate until it is repaired
by the authorised service agent.
There is the risk of electric shock!
 Do not place flame sources (lit
candles, cigarettes, etc.) on or close
to the product.
 Do not climb on the product. There is
the risk of falling and getting injured!
 Do not damage the pipes of the
cooling system with sharp or
penetrating objects. The refrigerant
that might come out when the
refrigerant pipes, pipe extensions

7 / 22 EN
Refrigerator/User Manual
Safety and environment instructions
or surface coatings are punctured
causes skin irritations and eye
injuries.
 Unless recommended by the
manufacturer, do not place or
use electrical devices inside the
refrigerator/deep freezer.
 Be careful not to trap your hands or
any other part of your body in the
moving parts inside the refrigerator.
Pay attention not to squeeze your
fingers between the door and the
refrigerator. Be careful when opening
and closing the door particularly if
there are children around.
 Never eat ice cream, ice cubes or
frozen food right after removing
them from the refrigerator. There is
the risk of frostbite!
 When your hands are wet, do not
touch the inner walls or metal parts
of the freezer or the food stored
therein. There is the risk of frostbite!
 Do not place tins or bottles that
contain carbonated drinks or
freezable liquids in the freezer
compartment. Tins and bottles may
burst. There is the risk of injury and
material damage!
 Do not place or use flammable sprays,
flammable materials, dry ice, chemical
substances or similar heat-sensitive
materials near the refrigerator. There
is the risk of fire and explosion!
 Do not store explosive materials that
contain flammable materials, such as
aerosol cans, in your product.
 Do not place containers filled with
liquid onto the product. Splashing
water on an electrical part may cause
electric shock or the risk of fire.
 This product is not intended for
storing medicines, blood plasma,
laboratory preparations or similar
medical substances and products
subject to Medical Products Directive.
 Using the product against its
intended purpose may cause
the products stored inside it to
deteriorate or spoil.
 If your refrigerator is equipped with
blue light, do not look at this light
with optical tools. Do not stare at
UV LED lamp directly for a long time.
Ultraviolet light may cause eye strain.
 Do not overload the product. Objects
in the refrigerator may fall down
when the door is opened, causing
injury or damage. Similar problems
may arise if any object is placed onto
the product.
 To avoid injuries, make sure that you
have cleaned all the ice and water
that may have fallen or splashed on
the floor.
 Change the position of the shelves/
bottle holders on the door of your
refrigerator only when they are
empty. There is the risk of injury!
 Do not place objects that can fall
down/tip over onto the product. Such
objects may fall down when the door
is opened and cause injuries and/or
material damage.
 Do not hit or exert excessive force
on glass surfaces. Broken glass
may cause injuries and/or material
damage.
 Cooling system of your product
contains R600a refrigerant: Type of
the refrigerant used in the product
is indicated on the type label. This
refrigerant is flammable. Therefore,
pay attention not to damage the
cooling system or the piping while
the product is in use. If the piping is
damaged:

8 / 22 EN Refrigerator/User Manual
Safety and environment instructions
- Do not touch the product or the
power cable,
- Keep away potential sources of fire
that may cause the product to catch fire.
- Ventilate the area where the pro-
duct is located. Do not use fans.
- Call the authorised service agent.
 If the product is damaged and you
see refrigerant leak, please stay away
from the refrigerant. Refrigerant
may cause frostbite in case of skin
contact.
For products with a Water
Dispenser/Ice Machine
 Use only potable water. Do
not fill the water tank with
any liquids -such as fruit juice,
milk, carbonated beverages or
alcoholic drinks- that are not
suitable for use in the water
dispenser.
 There is the risk for health and
safety!
 Do not allow children play with
the water dispenser or ice
machine (Icematic) in order to
prevent accidents or injuries.
 Do not insert your fingers or
other objects into the water
dispenser hole, water channel
or ice machine container. There
is the risk of injury or material
damage!
A1.7- Maintenance and
cleaning safety
 Do not pull from the door handle
if you need to move the product
for cleaning purposes. Handle may
break and cause injuries if you exert
excessive force on it.
 Do not spray or pour water on or
inside the product for cleaning
purposes. There is the risk of fire and
electric shock!
 Do not use sharp or abrasive tools
when cleaning the product. Do not
use household cleaning products,
detergent, gas, gasoline, thinner,
alcohol, varnish etc.
 Only use cleaning and maintenance
products inside the product that are
not harmful for food.
 Never use steam or steam assisted
cleaners to clean or defrost the
product. Steam gets into contact with
the live parts in your refrigerator,
causing short circuit or electric shock!
 Make sure that no water enters
the electronic circuits or lighting
elements of the product.
 Use a clean and dry cloth to wipe the
foreign materials or dust on the pins
of the plug. Do not use a wet or damp
cloth to clean the plug. There is the
risk of fire and electric shock!
A1.8- HomeWhiz
 When you operate your product
through HomeWhiz application, you
must observe the safety warnings
even when you are away from the
product. You must also follow the
warnings in the application.
A1.9- Lighting
 Call the authorised service when it
is required to replace the LED/bulb
used for lighting.

9 / 22 EN
Refrigerator/User Manual
2Your Freezer
C
Figures that take place in this instruction manual are schematic and
may not correspond exactly with your product. If the subject parts are
not included in the product you have purchased, then it is valid for other
models.
 Control Panel
 Door shelf
 Glass shelves
 Drawers
 Adjustable front feet
1
2
3
4
5

10 / 22 EN Refrigerator/User Manual
3Installation
3.1 Appropriate
Installation Location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
Manufacturer shall
not be held liable for damages
that may arise from procedures
carried out by unauthorized
persons.
B
WARNINGProduct must
not be plugged in during
installation. Otherwise, there
is the risk of death or serious
injury!
A
WARNING:
If the door clearance of the
room where the product shall
be place is so tight to prevent
passing of the product, remove
the door of the room and pass
the product through the door
by turning it to its side; if this
does not work, contact the
authorized service.
 
surface to prevent jolts.
 
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.
 
direct sun light and kept in humid
places.
 
provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in
the wall, pay attention to leave at least
5 cm distance with the ceiling and side
walls.
 Your product requires adequate air
circulation to function efficiently.
If the product will be placed in an
alcove, remember to leave at least 5
cm clearance between the product
and the ceiling, rear wall and the side
walls.
 If the product will be placed in an
alcove, remember to leave at least 5
cm clearance between the product
and the ceiling, rear wall and the
side walls. Check if the rear wall
clearance protection component is
present at its location (if provided
with the product). If the component
is not available, or if it is lost or fallen,
position the product so that at least
5 cm clearance shall be left between
the rear surface of the product and
the wall of the room. The clearance
at the rear is important for efficient
operation of the product.

11 / 22 EN
Refrigerator/User Manual
Installation
3.2 Installing the
Plastic Wedges
Plastic wedges supplied with the
product are used to create the distance
for the air circulation between the
product and the rear wall.
 To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
 Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in
the figure.
3.3 Adjusting the Feet
If the product stands unbalanced after
installation, adjust the feet on the front
by rotating them to the right or left.
3.4 Electrical Connection
AWARNING: Do not make
connections via extension
cables or multi-plugs.
B
WARNING:Damaged
power cable must be
replaced by the Authorized
Service Agent.
C
If two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
 Our company shall not be liable
for any damages that will arise
when the product is used without
grounding and electrical connection
in accordance with the national
regulations.
 Power cable plug must be within easy
reach after installation.
 Connect your refrigerator to a
grounded outlet rated for a voltage
value of 220-240V /50 Hz. Outlet
shall have 10 to 16A fuse.
 Do not extension cords or cordless
multiple outlets between your
product and the wall outlet.

12 / 22 EN Refrigerator/User Manual
Installation
3.5 Door Open Warning
*May not be available in all models
An audio warning signal will be given
when the door of your product is left
open for at least 1 minute. This warning
will be muted when the door is closed
or any of the display buttons (if any) are
pressed.
3.6 Changing the
illumination lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in
the refrigerator/freezer in a safe and
comfortable way.The lamps used in this
appliance have to withstand extreme
physical conditions such as temperatures
below -20 °C.
(only chest and upright freezer)
3.7 Changing the door
opening direction
Door opening direction of your
refrigerator can be changed according
to the place you are using it. If this is
necessary, please call your nearest
Authorized Service.

13 / 22 EN
Refrigerator/User Manual
4Preliminary preparation
4.1. What to do for
energy saving
A
Connecting the product
to electronic energy-saving
systems is harmful, as it may
damage the product.
 For a freestanding appliance; ‘this
refrigerating appliance is not intended
to be used as a built-in appliance.
 Do not keep the refrigerator doors open
for long periods.
 Do not place hot food or beverages into
the refrigerator.
 Do not overfill the refrigerator; blocking
the internal air flow will reduce cooling
capacity.
 In order to load the maximum quantity
of food into the cooler compartment
of your refrigerator, the upper drawers
should be taken out and the food
should be placed onto the wire/glass
shelves. Net volume and energy
consumption information declared in
the energy label of your refrigerator
was tested by taking out the upper
drawers in the cooler department
and the ice bucket, which is easily
removable by hand.
 Food packages should not be in direct
contact with the heat sensor located
in the cooler compartment. The food
should be 10 cm away from the sensor.
In case of contact with the sensor,
energy consumption of the device may
increase.
10 cm
4.2. First Use
Before using your refrigerator, make
sure the necessary preparations are
made in line with the instructions in
"Safety and environment instructions"
and "Installation" sections.
 Keep the product running without
placing any food inside for 6 hours and
do not open the door, unless absolutely
necessary.
 The temperature change caused by
opening and closing of the door while
using the product may normally lead to
frost deposit, icing and condensation
on food placed on door/body shelves
and glass containers placed in the
product.

14 / 22 EN Refrigerator/User Manual
CA sound will be heard when
the compressor is engaged.
It is normal to hear sound
even when the compressor is
inactive, due to the compressed
liquids and gasses in the cooling
system.
CIt is normal for the front edges
of the refrigerator to be warm.
These areas are designed to
warm up in order to prevent
condensation.
CFor some models, indicator
panel turns off automatically 1
minutes after the door closes.
It will be reactivated when the
door is open or any button is
pressed.
 Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. Functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy under
these circumstances.

15 / 22 EN
Refrigerator/User Manual
CFigures in this user manual are schematic and may not match the product
exactly. If the subject parts are not included in the product you have
purchased, then those parts are valid for other models.
1.On/Off Indicator:
This icon ( ) come on when the freezer
is turned off. All the other icons turn off.
2.Economic Usage Indicator:
This icon ( ) (comes on when the
Freezer Compartment is set to -18°C
which is the most economical set value.
Economic Usage Indicator turns off when
the Quick Fridge or Quick Freeze function
is selected.
3.Freezer Compartment Temperature
Setting Indicator:
Indicates the temperature set for the
Freezer Compartment.
4.Power failure/High temperature /
error warning indicator :
This light ( ) illuminates during power
failure, high temperature failures and
error warnings. During sustained power
failures, the highest temperature that
the freezer compartment reaches will
flash on the digital display.
5.Eco Extra Indicator:
This icon ( ) lights up when this
Function is active.
6.Key Lock Indicator:
This icon ( ) lights up when the Key
Lock mode is activated.
5Operating the product
5.1 Indicator panel
1
7812 1011 9
14
235
4 6
13

16 / 22 EN Refrigerator/User Manual
Operating the product
7.Key Lock Mode:
Press Key Lock ( ) button continuously
for 3 seconds. Key lock icon will light
up and key lock mode will be activated.
Buttons will not function if the Key Lock
mode is active. Press Key Lock button
continuously for 3 seconds again. Key
lock icon will turn off and the key lock
mode will be exite.
8- Alarm off warning:
In case of power failure/high
temperature alarm, after checking the
food located in the freezer compartment
press the alarm off button ( ) to clear
the warning.
High Temperature Alarm may also be
cleared by other keys than the On/Off
key.
9.Eco Extra Function:
Press the Eco Extra button ( ) for 3
seconds to activate Eco Extra Function
when going on holday for instance.
Freezer will start operating in the most
economic mode at around 6 hours later
and the economic usage indicator will
turn on when the function is active.
10.Freezer Set Function:
This function ( ) allows you to change
the Freezer compartment temperature
setting. Press this button to set the
temperature of the freezer compartment
to -18, -19, -20, -21, -22, -23 and -24,
respectively.
11.Quick Freeze Function:
Quick Freeze indicator ( ) turns on
when the Quick Freeze function is on.
Press Quick Freeze button again to cancel
this function. Quick Freeze indicator will
turn off and normal settings will be
resumed.
Quick Freeze function will be cancelled
automatically 52 hours later if you do not
cancel it manually. If you want to freeze
plenty amount food, press Quick Freeze
button before you place the food into the
freezer compartment.
12.On/Off Function:
This function ( ) allows you to make
the Fridge turn off when pressed for 3
seconds.The fridge could be turned on
by pressing On/Off button for 3 seconds
again .
13.Energy Saving Indicator :
If the product doors are kept closed
for a long time energy saving function
is automatically activated and energy
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will turn
off. When the Energy Saving function is
activated, if any button is pressed or the
door is opened, energy saving function
will be canceled and the symbols on
display will return to normal.
Energy saving function is activated
during delivery from factory and cannot
be canceled.
14.Quick Freeze Indicator :
This icon ( ) comes on when the Quick
Freeze function is on.

17 / 22 EN
Refrigerator/User Manual
Operating the product
5.2 Freezing fresh food

them in .

temperature before putting them in the
refrigerator.

must be fresh and in good quality.

portions according to the family’s daily
or meal based consumption needs.

airtight manner to prevent them from
drying even if they are going to be kept
for a short time.

must be resistant to cold and humidity
and they must be airtight. The
packaging material of the food must be
at a sufficient thickness and durability.
Otherwise the food hardened due to
freezing may puncture the packaging.
It is important for the packaging to be
closed securely for safe storage of the
food.

immediately after they are thawed and
they should never be re-frozen.

instructions to obtain the best results.
 Activate the fast freezing function by
pressing the «Fast Freeze» button 24
hours before loading the food to be
frozen.
 24 hours after pressing the button,
place your hot food in the first and
second shelves of the product.
 The fast freezing function will be
automatically inactivated after 52
hours.
 Do not try to freeze a large quantity
of food at a time. Within 24 hours,
this product can freeze the maximum
food quantity specified as «Freezing
Capacity … kg/24 hours» on its type
label. It is not convenient to put more
unfrozen/fresh foods than the quantity
specified on the label.
 When you put unfrozen food in the
product, place them in a way that they
do not contact with frozen food. A cool-
pack may be placed on foods on the 3rd
shelf from top to bottom to prevent
heating.
 Ensure that raw food do not contact
with cooked food in the refrigerator.

18 / 22 EN Refrigerator/User Manual
Operating the product


Settings
Remarks
-20°C This is the default, recommended setting.
-21, -22, -23
or -24°C
These settings are recommended when the ambient temperature
is higher than 30°C or when you think the refrigerator is not cool
enough due to frequent opening and closing of the door.
Fast Freezing
Use when you want to freeze your food in a short time.
Recommended for maintaining the quality of meat and fish
products.
5.3 Recommendations for
preservation of frozen food

should be stored in accordance with the
frozen food manufacturer's instructions
in a frozen food storage compartment.

supplied by the frozen food
manufacturer and the food retailer is
maintained, following points should be
noted:
 Put packages in the freezer as
quickly as possible after purchase.
 Ensure that contents of the
package are labeled and dated.
 Do not exceed "Use By", "Best
Before" dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
5.4 Deep-freeze information
Food must be frozen as rapidly as
possible when they are put in the freezer
in order to keep them in good quality.
It is possible to preserve the food
for a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A
     
portions according to the family’s daily or
meal based consumption needs.
      
airtight manner to prevent them from
drying even if they are going to be kept
for a short time.
Materials necessary for packaging:




Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, dour, oils and
acids.
Foodstuff to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent their
partial thawing. Thawed out
food must be consumed and must not be
frozen again.

19 / 22 EN
Refrigerator/User Manual
6Maintenance and cleaning
Cleaning your fridge at regular inter-
vals will extend the service life of the
product.
BWARNING:
Unplug the product before cleaning it.
 Never use gasoline, benzene or
similar substances for cleaning
purposes.
 Never use any sharp and abrasive
tools, soap, household cleaners,
detergent and wax polish for
cleaning.
 For non-No Frost products,
water drops and frosting up to a
fingerbreadth occur on the rear wall
of the Fridge compartment. Do not
clean it; never apply oil or similar
agents on it.
 Only use slightly damp microfiber
cloths to clean the outer surface of
the product. Sponges and other types
of cleaning cloths may scratch the
surface
 Dissolve one teaspoon of bi-
carbonate in half litre of water. Soak
a cloth with the solution and wrung it
thoroughly. Wipe the interior of the
refrigerator with this cloth and the
dry thoroughly.
 Make sure that no water enters the
lamp housing and other electrical
items.
 If you will not use the refrigerator
for a long period of time, unplug it,
remove all food inside, clean it and
leave the door ajar.
 Check regularly that the door gaskets
are clean. If not, clean them.
 To remove door and body shelves,
remove all of its contents.
 Remove the door shelves by pulling
them up. After cleaning, slide them
from top to bottom to install.
 Never use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
6.1 Avoiding bad odours
 Materials that may cause odour
are not used in the production of
our refrigerators. However, due
to inappropriate food preserving
conditions and not cleaning the
inner surface of the refrigerator as
required can bring forth the problem
of odour. Pay attention to following
to avoid this problem:
 Keeping the refrigerator clean is
important. Food residuals, stains, etc.
can cause odour. Therefore, clean
the refrigerator with bi-carbonate
dissolved in water every few months.
Never use detergents or soap.
 Keep the food in closed containers.
Microorganisms spreading out from
uncovered containers can cause
unpleasant odours.
 Never keep the food that have
passed best before dates and spoiled
in the refrigerator.
6.2 Protecting the plas-
tic surfaces
Do not put liquid oils or oil-cooked meals
in your refrigerator in unsealed contai-
ners as they damage the plastic surfaces
of the refrigerator. If oil is spilled or sme-
ared onto the plastic surfaces, clean and
rinse the relevant part of the surface at
once with warm water.

20 / 22 EN Refrigerator/User Manual
7. Troubleshooting
Check this list before contacting the
service. Doing so will save you time
and money. This list includes frequent
complaints that are not related to faulty
workmanship or materials. Certain
features mentioned herein may not
apply to your product.
The refrigerator is not working.
 The power plug is not fully settled.
>>> Plug it in to settle completely
into the socket.
 The fuse connected to the socket
powering the product or the main
fuse is blown. >>> Check the fuses.
Condensation on the side wall of the
cooler compartment (MULTI ZONE,
COOL, CONTROL and FLEXI ZONE).
 The door is opened too frequently
>>> Take care not to open the
product’s door too frequently.
 The environment is too humid. >>>
Do not install the product in humid
environments.
 Foods containing liquids are kept
in unsealed holders. >>> Keep the
foods containing liquids in sealed
holders.
 The product’s door is left open. >>>
Do not keep the product’s door open
for long periods.
 The thermostat is set to too low
temperature. >>> Set the thermostat
to appropriate temperature.
Compressor is not working.
 In case of sudden power failure
or pulling the power plug off and
putting back on, the gas pressure
in the product’s cooling system is
not balanced, which triggers the
compressor thermic safeguard.
The product will restart after
approximately 6 minutes. If the
product does not restart after this
period, contact the service.
 Defrosting is active. >>> This
is normal for a fully-automatic
defrosting product. The defrosting is
carried out periodically.
 The product is not plugged in. >>>
Make sure the power cord is plugged
in.
 The temperature setting is incorrect.
>>> Select the appropriate
temperature setting.
 The power is out. >>> The product
will continue to operate normally
once the power is restored.
The refrigerator’s operating noise is
increasing while in use.
 The product’s operating performance
may vary depending on the ambient
temperature variations. This is normal
and not a malfunction.
The refrigerator runs too often or for
too long.
 The new product may be larger than
the previous one. Larger products will
run for longer periods.
 The room temperature may be high.
>>> The product will normally run
for long periods in higher room
temperature.
 The product may have been recently
plugged in or a new food item is
placed inside. >>> The product
will take longer to reach the set
temperature when recently plugged
in or a new food item is placed inside.
This is normal.
 Large quantities of hot food may have
been recently placed into the product.
>>> Do not place hot food into the
product.
 The doors were opened frequently or
kept open for long periods. >>> The
warm air moving inside will cause the
product to run longer. Do not open
the doors too frequently.
