Beko RFNM200E20W User manual

EWWERQWEW
Морозильник
Посібник користувача
Морозильная камера
Руководство пользователя
RFNE200E20W
RFNE200E20S
EN UK RUS
Freezer
User manual

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe
way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
1 Your Freezer 3
2 Important Safety Warnings4
Intended use ...............................................4
General safety ............................................ 5
For products with a ..................................9
water dispenser;........................................9
Child safety ................................................10
Compliance with WEEE Directive and
Disposing of the Waste Product: .....10
Package information..............................10
HC warning.................................................10
Things to be done for energy saving11
3 Installation 12
Points to be paid attention to when the
relocation of the freezer ......................12
Electrical connection .............................13
Disposing of the packaging.................13
Disposing of your old freezer .............13
Placing and Installation.........................14
4 Preparation 16
5 Using your freezer 17
Freezing fresh food ................................18
Recommendations for preservation of
frozen food.................................................18
Placing the food.......................................18
Deep-freeze information.....................19
6 Maintenance and
cleaning 20
Protection of plastic surfaces .......... 20
7 Troubleshooting 21
CONTENTS

EN
3
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your Freezer
1. Thermostat
2. Flap (Fast-Freeze compartment)
3. Drawers
4. Adjustable front feet
* May not be available in all models
1
4
4
2
3
*

EN
4
2Important Safety Warnings
Please review the
following information.
Failure to observe this
information may cause
injuries or material
damage. Otherwise, all
warranty and reliability
commitments will
become invalid.
Original spare parts will
be provided for 10 years,
following the product
purchasing date.
Intended use
A
WARNING:
Keep ventilation
openings, in the
appliance enclosure
or in the built-in
structure, clear of
obstruction.
A
WARNING:
Do not use
mechanical devices
or other means
to accelerate the
defrostingprocess,
other than those
recommended by
the manufacturer.
A
WARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use
electrical
appliances inside
the food storage
compartments
of the appliance,
unless they
are of the type
recommended by
the manufacturer.
A
WARNING:
Do not store
explosive
substances such
as aerosol cans
with a flammable
propellant in this
appliance.
This appliance is
intended to be used in
household and similar
applications such as
– staff kitchen areas in
shops, offices and other
working environments;

EN
5
– farm houses and by
clients in hotels, motels
and other residential
type environments;
– bed and breakfast type
environments;
– catering and similar
non-retail applications.
General safety
• When you want to
dispose/scrap the
product, we recommend
you to consult the
authorized service
in order to learn the
required information
and authorized bodies.
• Consult your
authorized service
for all your questions
and problems related
to the refrigerator. Do
not intervene or let
someone intervene to
the refrigerator without
notifying the authorised
services.
• For products with a
freezer compartment;
Do not eat cone ice
cream and ice cubes
immediately after you
take them out of the
freezer compartment!
(This may cause
frostbite in your mouth.)
• For products with a
freezer compartment;
Do not put bottled
and canned liquid
beverages in the
freezer compartment.
Otherwise, these may
burst.
• Do not touch frozen
food by hand; they may
stick to your hand.
• Unplug your refrigerator
before cleaning or
defrosting.
• Vapor and vaporized
cleaning materials
should never be used in
cleaning and defrosting
processes of your
refrigerator. In such
cases, the vapor may
get in contact with the
electrical parts and
cause short circuit or
electric shock.
• Never use the parts on
your refrigerator such as
the door as a means of
support or step.

EN
6
• Do not use electrical
devices inside the
refrigerator.
• Do not damage the
parts, where the
refrigerant is circulating,
with drilling or cutting
tools. The refrigerant
that might blow out
when the gas channels
of the evaporator, pipe
extensions or surface
coatings are punctured
causes skin irritations
and eye injuries.
• Do not cover or block
the ventilation holes on
your refrigerator with
any material.
• Electrical devices must
be repaired by only
authorised persons.
Repairs performed by
incompetent persons
create a risk for the user.
• In case of any failure or
during a maintenance or
repair work, disconnect
your refrigerator’s mains
supply by either turning
off the relevant fuse
or unplugging your
appliance.
• Do not pull by the cable
when pulling off the
plug.
• Ensure highly alcoholic
beverages are stored
securely with the lid
fastened and placed
upright.
• Never store spray cans
containing flammable
and explosive
substances in the
refrigerator.
• Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
• This product is not
intended to be used by
persons with physical,
sensory or mental
disorders or unlearned
or inexperienced
people (including
children) unless they are
attended by a person
who will be responsible
for their safety or who
will instruct them
accordingly for use of
the product
• Do not operate a
damaged refrigerator.

EN
7
Consult with the service
agent if you have any
concerns.
• Electrical safety of your
refrigerator shall be
guaranteed only if the
earth system in your
house complies with
standards.
• Exposing the product
to rain, snow, sun and
wind is dangerous with
respect to electrical
safety.
• Contact authorized
service when there is a
power cable damage to
avoid danger.
• Never plug the
refrigerator into the
wall outlet during
installation. Otherwise,
risk of death or serious
injury may arise.
• This refrigerator is
intended for only
storing food items. It
must not be used for
any other purpose.
• Label of technical
specifications is located
on the left wall inside
the refrigerator.
• Never connect
your refrigerator to
electricity-saving
systems; they may
damage the refrigerator.
• If there is a blue light
on the refrigerator, do
not look at the blue light
with optical tools.
• For manually controlled
refrigerators, wait for at
least 5 minutes to start
the refrigerator after
power failure.
• This operation manual
should be handed in to
the new owner of the
product when it is given
to others.
• Avoid causing damage
on power cable when
transporting the
refrigerator. Bending
cable may cause fire.
Never place heavy
objects on power cable.
Do not touch the plug
with wet hands when
plugging the product

EN
8
• Do not plug the
refrigerator if the wall
outlet is loose.
• Water should not be
sprayed on inner or
outer parts of the
product for safety
purposes.
• Do not spray
substances containing
inflammable gases such
as propane gas near the
refrigerator to avoid fire
and explosion risk.
• Never place containers
filled with water on top
of the refrigerator; in
the event of spillages,
this may cause electric
shock or fire.
• Do not overload the
refrigerator with food.
If overloaded, the food
items may fall down and
hurt you and damage
refrigerator when you
open the door.
• Never place objects on
top of the refrigerator;
otherwise, these
objects may fall down
when you open or close
the refrigerator’s door.
• As they require a precise
temperature, vaccines,
heat-sensitive medicine
and scientific materials
and etc. should not be
kept in the refrigerator.
• If not to be used for a
long time, refrigerator
should be unplugged.
A possible problem in
power cable may cause
fire.
• Refrigerator may move
if adjustable legs are not
properly secured on the
floor. Properly securing
adjustable legs on the
floor can prevent the
refrigerator to move.
• When carrying the
refrigerator, do not hold
it from door handle.
Otherwise, it may be
snapped.
• When you have to place
your product next to
another refrigerator or
freezer, the distance
between devices
should be at least 8cm.
Otherwise, adjacent
side walls may be
humidified.

EN
9
• The product shall never
be used while the
compartment which
is located at the top or
back of your product
and in which electronic
boards are available
(electronic board box
cover) (1) is open.
1
1
For products with a
water dispenser;
• Pressure for cold water
inlet shall be maximum
90 psi (6.2 bar). If your
water pressure exceeds
80 psi (5.5 bar), use a
pressure limiting valve
in your mains system. If
you do not know how
to check your water
pressure, ask for the
help of a professional
plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment
in your installation.
Consult Professional
plumbers is you are not
sure that there is no
water hammer effect
in your installation.
• Do not install on the
hot water inlet. Take
precautions against
of the risk of freezing
of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum
and 100°F (38°C)
maximum.
• Use only potable water.

EN
10
Child safety
• If the door has a lock,
the key should be kept
away from reach of
children.
• Children must be
supervised to prevent
them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Therefore, do not dispose
the product with normal domestic
waste at the end of its service life.
Take it to a collection point for the
recycling of electrical and electronic
equipment. Please consult your
local authorities to learn the nearest
collection point. Help protect the
environment and natural resources by
recycling used products. For children’s
safety, cut the power cable and break
the locking mechanism of the door, if
any, so that it will be non-functional
before disposing of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and
our national asset wealth.
If you want to contribute to the
re-evaluation of the packaging
materials, you can consult to your
environmentalist organizations or the
municipalities where you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage
and transportation. In the event of
damage, keep your product away from
potential fire sources that can cause
the product catch a fire and ventilate
the room in which the unit is placed.
Ignore this warning if your
product's cooling system
contains R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.

EN
11
Things to be done for
energy saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is
not prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items
in the freezer when you remove
the shelf or drawer of the freezer.
Energy consumption value stated
for your refrigerator has been
determined by removing freezer
shelf or drawer and under maximum
load. There is no harm to use a shelf
or drawer according to the shapes
and size of food to be frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the food
quality.

EN
12
3Installation
BThe manufacturer will not be
liable for any event caused by
disregarding the information
supplied in this user manual.
Points to be paid attention
to when the relocation of
the freezer
1. Your freezer should be
unplugged.Before transportation of
your freezer, it should be emptied
and cleaned.
2. Before it is re-packaged,
shelves, accessories, crisper, etc.
inside your freezer should be fixed
with adhesive tape and secured
against impacts. Packaging should
be adequate and the transportation
rules on the package should be
strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the freezer,
Check the following before you
start to use your freezer:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges
are intended to keep the distance
which will ensure the air circulation
between your freezer and the
wall. (The picture is drawn up as
a representation and may not be
identical with your product.)
2. Clean the interior of the freezer
as recommended in the “Maintenance
and cleaning” section.
3. Connect the plug of the freezer
to the wall socket. When the freezer
door is opened,freezer internal lamp
will turn on.
The condenser of your appliance is located on the back as shown below. In order
to achieve better energy efficiency with lower energy consumption, please pull
the condenser towards yourself as illustrated in picture below.
*may not be available in all models
better energy
efficiency
2-b
initial position
PULL
PULL

EN
13
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give
rise to noise, even if the compressor
is not running and this is quite normal.
5. Front edges of the freezer may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in
compliance with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your freezer
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots designated
by the local authorities.
The packing of your freezer is
produced from recyclable materials.
Disposing of your old
freezer
Dispose of your old freezer without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your freezer.
Before disposing of your freezer,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.

EN
14
Placing and Installation
AIf the entrance door of the room
where the freezer will be installed is
not wide enough for the freezer to
pass through, then carefully remove
the doors of your freezer and pass it
sideways through the door.
1. Install your freezer to a place
that allows ease of use.
2. Keep your freezer away from
heat sources, humid places and direct
sunlight.
3. There must be appropriate
air ventilation around your freezer
in order to achieve an efficient
operation. If the freezer is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on the
materials such as rug or carpet.
4. Place your freezer on an even
floor surface to prevent jolts.

EN
15
Reversing the doors
Proceed in numerical order .
3
2
7
8
9
10
11
13
14
17
15
16
1
4
5
6
12

EN
16
4Preparation
• Your refrigerator should be installed
at least 30 cm away from heat
sources such as hobs, ovens, central
heater and stoves and at least 5
cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be
-15°C. Operating your refrigerator
under cooler conditions is not
recommended with regard to its
efficiency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigerators are to be
installed side by side, there should
be at least 2 cm distance between
them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the
initial six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
• Food contact with the temperature
sensor in the freezer compartment
may increase energy consumption
of the appliance. Thus any contact
with the sensor(s) must be avoided.
• In some models, the instrument
panel automatically turns off 5
minutes after the door has closed.
It will be reactivated when the door
has opened or pressed on any key.
• Due to temperature change as
a result of opening/closing the
product door during operation,
condensation on the door/body
shelves and the glass containers is
normal

EN
17
5Using your freezer
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1 2 3 4
1.Freezer Set Function
This function allows you to make the
freezer compartment temperature
setting.
Press this button to set the
temperature of the freezer
compartment to - (warmest), --, ---,
----, ----- (coldest) respectively.
2.High Temperature Error /
Warning Indicator
This light comes on during high
temperature failures and error
warnings.
3- Quick Frezee Indicator
This icon lits when the Quick Freeze
function is active.
4-Quick Frezee Function
When you press Quick Freeze button,
the temperature of the compartment
will be colder than the adjusted values.
This function can be used for food
placed in the freezer compartment
and required to be cooled down rapidly.
If you want to cool large amounts
of fresh food, it is recommended to
active this feature before putting the
food into the freezer.
Quick Freezer indicator will remain
lit when the Quick Freezer function is
enabled. To cancel this
function press Quick Freezer button
again. Quick Freezer indicator will turn
off and return to its normal settings.
If you do not cancel it, Quick Fridge
will cancel itself automatically
after 2 hours or when the freezer
compartment reaches to the required
temperature. This function is not
recalled when power restores after a
power failure.

EN
18
Freezing fresh food
• It must be preferred to wrap or cover
the food before placing them in the
refrigerator.
• Hot food must cool down to the
room temperature before putting
them in the refrigerator.
• The foodstuff that you want to
freeze must be fresh and in good
quality.
• Foodstuff must be divided into
portions according to the family’s
daily or meal based consumption
needs.
• The foodstuff must be packaged in
an airtight manner to prevent them
from drying even if they are going to
be kept for a short time.
• Materials to be used for packaging
must be tear-proof and resistant to
cold, humidity, odor, oils and acids
and they must also be airtight.
Moreover, they must be well closed
and they must be made from easy-
to-use materials that are suitable for
deep freeze usage.
• Frozen food must be used
immediately after they are thawed
and they should never be re-frozen.
• Please observe the following
instructions to obtain the best
results.
1. Do not freeze too large
quantities of food at one time. The
quality of the food is best preserved
when it is frozen right through to the
core as quickly as possible.
2. Placing warm food into
the freezer compartment causes
the cooling system to operate
continuously until the food is frozen
solid.
3. Take special care not to mix
already frozen food and fresh food.
Recommendations for
preservation of frozen food
• Prepacked commercially frozen food
should be stored in accordance with
the frozen food manufacturer's
instructions for a ( 4 star)
frozen food storage compartment.
• To ensure that the high quality
achieved by the frozen food
manufacturer and the food retailer is
maintained, the following should be
remembered:
1. Put packages in the freezer as
quickly as possible after purchase.
2. Ensure that contents are
labeled and dated.
3. Do not exceed "Use By", "Best
Before" dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
Placing the food
Freezer compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Egg tray Egg
Fridge compartment
shelves
Food in pans, covered
plates and closed
containers
Fridge compartment
door shelves
Small and packaged food
or drinks (such as milk, fruit
juice and beer)

EN
19
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)
Deep-freeze information
Food must be frozen as rapidly
as possible when they are put in a
refrigerator in order to keep them in
good quality.
It is possible to keep the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A
• Foodstuff must be divided into
portions according to the family’s
daily or meal based consumption
needs.
• Foodstuff must be packaged in an
airtight manner to prevent them
from drying even if they are going to
be kept for a short time.
• Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, odor, oils
and acids.
Foodstuff to be frozen should not
be allowed to come in contact with
the previously frozen items to prevent
their partial thawing.
Frozen food must be used
immediately after they are thawed
and they should never be re-frozen.
- Active”quıck freeze function” at
least 24 hour before loading fresh
food.
- Put 2 pcs ice packs ( if available )
inside the bottom drawer.
- Place fresh food on the shelves of
2 nd&3rd from the bottom.(maximum
capacıty can be achieved by removing
the drawers
