Refrigerator
User Manual
970476EI

Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal efficiency
from this high quality product which has been manufactured with state of the art tech-
nology. To do this, carefully read this manual and any other documentation provided
before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to someone
else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause material damage to the product or its
surroundings
Important information or useful tips on operation.
Read the user manual.
Risk of fire / Flammable materials
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

2 /30EN Refrigerator / User Guide
1 Safety Instructions 3
1.1 Purpose of usage . . . . . . . . . . . . . . . . . . 3
1.2 Safety of children, vulnerable persons and
pets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Electrical safety. . . . . . . . . . . . . . . . . . . 4
1.4 Handling Safety. . . . . . . . . . . . . . . . . . . 4
1.5 Installation Safety . . . . . . . . . . . . . . . . . 4
1.6 Operational safety . . . . . . . . . . . . . . . . . 5
1.7 Maintenance and cleaning safety. . . . . . 7
1.8HomeWhiz . . . . . . . . . . . . . . . . . . . . . . . 7
1.9 Lighting . . . . . . . . . . . . . . . . . . . . . . . . 7
1.10-Technical information for Wifi +
Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Environmental instructions 8
2.1 Compliance with the WEEE Directive and
Disposing of the Waste Product: . . . . . . . . 8
2.2 Compliance with RoHS Directive . . . . . . . . . . 8
2.3 Package information. . . . . . . . . . . . . . . . . . . 8
3 Your Refrigerator 9
4 Installation 10
4.1 The right place for installation . . . . . . . . . . . 10
4.2 For Products With Water Fountain / Ice
Maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Attaching the plastic wedges . . . . . . . . . . . 10
4.4 Adjustment of the feet. . . . . . . . . . . . . . . . . 11
4.5 Electrical connection. . . . . . . . . . . . . . . . . . 11
5 Preparation 12
5.1 What to do for energy saving . . . . . . . . . . . 12
5.2 First operation . . . . . . . . . . . . . . . . . . . . . . 12
6 Operating the Product 13
6.1 Turning off the product . . . . . . . . . . . . . . . . 13
6 Operation of the Product 14
6.2 Indicator panel . . . . . . . . . . . . . . . . . . . . . . 14
6.3 Support Service Feature . . . . . . . . . . . . . . . 16
6.4 Entering Phone Number for Support Service 16
6.5 Creating a Request Via Support Service . . . 16
6.6 Cancelling a Support Service Request . . . . 17
6.7 Troubleshooting . . . . . . . . . . . . . . . . . . . . 17
6.8 Humidity controlled crisper (EverFresh+) . . . 18
6.9 Blue Light/HarvestFresh . . . . . . . . . . . . . . 18
6.10 Anti-Odour Module . . . . . . . . . . . . . . . . . . 19
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.11 Ice bucket . . . . . . . . . . . . . . . . . . . . . . . . 20
6.12 Ice maker. . . . . . . . . . . . . . . . . . . . . . . . . 20
6.13 Dairy (cold storage) bin . . . . . . . . . . . . . . . 20
6.14Using the water fountain . . . . . . . . . . . . . . 21
6.15Filling the water tank of the water fountain 21
6.16 Cleaning the water tank . . . . . . . . . . . . . . 21
6.17 Filling the water tank of the water fountain 22
6.18Cleaning the water tank . . . . . . . . . . . . . . 23
6.19 Drip tray. . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.20 Freezing fresh food. . . . . . . . . . . . . . . . . . 24
6.21Recommendations for storing frozen foods in
the freezer compartment . . . . . . . . . . . . . 24
6.22 Deep freezer details . . . . . . . . . . . . . . . . . 25
6.23 Placing food. . . . . . . . . . . . . . . . . . . . . . . 25
6.24 Door open alert . . . . . . . . . . . . . . . . . . . . 25
6.25 Illumination lamp . . . . . . . . . . . . . . . . . . . 25
7 Maintenance and cleaning 26
7.1 Stainless Steel External Surfaces. . . . . . . . . 26
7.2 Cleaning of the Products with Glass Doors. . 26
7.3 Preventing Odours. . . . . . . . . . . . . . . . . . . 27
7.4 Protecting Plastic Surfaces . . . . . . . . . . . . 27
7 Maintenance and cleaning 27
8 Troubleshooting 28

3 / 30EN
Refrigerator / User Guide
1Safety Instructions
• Ths secton ncludes the safety
nstructons necessary to prevent
the rsk of personal njury or materal
damage.
• Our company shall not be held
responsble for damages that may
occur f these nstructons are not
observed.
Installation and repair operations shall always
be performed by Authorized Service.
Always use genuine spare parts and
accessories.
Original spare parts will be provided for
10 years, following the product purchasing date.
Do not repair or replace any part of the
product unless specified expressly in the user
manual.
Do not perform any modifications on the
product.
1.1 Purpose of usage
• This product is not intended for commercial
use and it shall not be used out of its intended
purpose.
This product is intended for operating interiors,
such as households or similar.
For example;
- In the staff kitchens of the stores, offices and
other working environments,
- In farm houses,
- In the units of hotels, motels or other resting
facilities that are used by the customers,
- In hostels, or similar environments,
- In catering services and similar non-retail
applications.
This product shall not be used in open or enclosed
external environments such as vessels, balconies
or terraces. Exposing the product to rain, snow,
sunlight and wind may cause risk of fire.
1.2 Safety of children,
vulnerable persons and pets
• Ths product may be used by chldren
aged 8 years and older and persons
wth underdeveloped physcal,
sensory or mental capabltes or
lack of experence and knowledge
f they have been gven supervson
or nstructon concernng use of the
applance n a the product safe way
and the hazards nvolved.
• Chldren between 3 and 8 years are
allowed to put and take out food to/
from the cooler product.
• Electrcal products are dangerous for
chldren and pets. Chldren and pets
must not play wth, clmb on, or enter
the product.
• Cleanng and user mantenance
should not be performed by chldren
unless there s someone overseeng
them.
• Keep the packagng materals away
from chldren. Rsk of njury and
suffocaton.
• Before dsposng of old products that
shall not be used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cord and remove it from the
appliance together with the plug.
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped over.
6. Do not allow children to play with the scrapped
product.
• Do not dispose of the product by throwing it
into fire. Risk of explosion.
• If there is a lock available in the product’s door,
keep the key out of children’s reach.

4 /30EN Refrigerator / User Guide
Important safety and environment instructions
1.3 Electrical safety
• The product shall not be plugged
nto the outlet durng nstallaton,
mantenance, cleanng, repar, and
transportaton operatons.
• If the power the cord s damaged, t
shall be replaced by authorzed servce
only to avod any rsk that may occur.
• Do not tuck the power cord under the
product or to the rear of the product.
Do not put heavy tems on the power
cord. The power cord should not be
bent, crushed, and come nto contact
wth any heat source.
• Do not use an extenson cord, mult-
plug or adaptor to operate your
product.
• Portable mult sockets or portable
power supples may overheat and
cause fre. Thus, do not have a mult-
plug behnd or n the vcnty of the
product.
• The plug shall be easly accessble. If
ths s not possble, a mechansm that
meets the electrcal legslaton and
that dsconnects all termnals from
the mans (fuse, swtch, man swtch,
etc.) shall be avalable on the electrcal
nstallaton.
• Do not touch the plug wth wet hands.
• When unpluggng the applance, don’t
hold the power cord, but the plug.
• When postonng the applance,
ensure the supply cord s not trapped
or damaged
• Do not locate multple portable
socket-outlets or portable power
supples at the rear of the applance.
1.4 Handling Safety
• Ths product s heavy, do not handle t
by yourself.
• Do not hold the product from ts door
whle handlng the product.
• Be careful not to damage the coolng
system and the ppes whle handlng
the product. Do not operate the
product f the ppes are damaged, and
contact an authorzed servce.
1.5 Installation Safety
• Contact the Authorzed Servce
for the product’s nstallaton. To
prepare the product for nstallaton,
see the nformaton n the user
gude and make sure the electrc
and water utltes are as requred.
If the nstallaton s not sutable, call
a qualfed electrcan and plumber
to have them make the necessary
arrangements. Otherwse, electrc
shock, fre, ssues wth the product or
njures may occur.
• Check for any damage on the product
before nstallng t. Do not have the
product nstalled f t s damaged.
• Place the product on a level and
hard surface and balance wth the
adjustable legs. Otherwse, the
refrgerator may tp over and cause
njures.
• The product shall be nstalled n a
dry and ventlated envronment.
Do not keep carpets, rugs or smlar
floor covers under the product. Ths
may cause rsk of fre as a result of
nadequate ventlaton!
• Do not block or cover ventlaton
holes. Otherwse, power consumpton
may be ncreased and damage to your
product may occur.
• Do not connect the product to supply
systems such as solar power supples.
Otherwse, damage to your product
may occur as a result of the abrupt
voltage fluctuatons!
• The more refrgerant a refrgerator
contans, the bgger ts nstallaton

5 / 30EN
Refrigerator / User Guide
Important safety and environment instructions
room shall be. In very small rooms,
a flammable gas-ar mxture may
occur n case of a gas leak n the
coolng system. At least 1 m of
volume s requred for each 8 grams
of refrgerant. The amount of the
refrgerant avalable n your product
s specfed n the Type Label.
• The nstallaton place of the product
shall not be exposed to drect
sunlght and t shall not be n the
vcnty of a heat source such as
stoves, radators, etc.
If you cannot prevent installation of the product
in the vicinity of a heat source, you shall use a
suitable insulation plate and the minimum distance
to the heat source shall be as specified below.
- At least 30 cm away from heat sources such
as stoves, heating units and heaters, etc.,
- And at least 5 cm away from electric ovens.
• Your product has the protecton
class of I. Plug the product n a
grounded socket that conforms wth
the Voltage, Current and Frequency
values specfed n the type label. The
socket outlet shall be equpped wth a
fuse wth a ratng of 10 A – 16 A. Our
company shall not be responsble for
the damages that shall be ncurred
as a result of operatng the product
wthout ensurng ground and
electrcal connectons made as per
local or natonal regulatons.
• The product’s power cable must
be unplugged durng nstallaton.
Otherwse, rsk of electrc shock and
njury may occur!
• Do not plug the product to loose,
broken, drty, greasy sockets or
sockets that has come out ther
seats or sockets wth a rsk of water
contact.
• Place the power cord and hoses (f
avalable) of the product so that they
shall not cause a rsk of trppng over.
• Penetraton of humdty to lve parts
or to the power cord may cause short
crcut. Thus, do not use the product
n humd envronments or n areas
where water may splash (e.g. garage,
laundry room, etc.) If the refrgerator
s wet by water, unplug t and contact
an authorzed servce.
• Do not connect your refrgerator to
power savng devces. These systems
are harmful for the product.
1.6 Operational safety
• Do not use chemcal solvents on the
product. These materals contan an
exploson rsk.
• In case of a falure of the product,
unplug t and do not operate untl t
s repared by the authorzed servce.
There s a rsk of electrc shock!
• Do not place a source of flame (e.g.
candles, cgarettes, etc.) on the
product or n the vcnty of t.
• Do not get on the product. Rsk of
fallng and njury!
• Do not cause damage to the ppes of
the coolng system usng sharp and
percng tools. The refrgerant that
sprays out n case of puncturng the
gas ppes, ppe extensons or upper
surface coatngs may cause rrtaton
of skn and njures of the eyes.
• Do not place and operate electrc
applances nsde the refrgerators/
deep freezer unless t s advsed by
the manufacturer.
• Do not jam any parts of your hands or
your body to the movng parts nsde
the product. Be careful to prevent
jammng of your fngers between the
refrgerator and ts door. Be careful
whle openng or closng the door f
there are chldren around.

6 /30EN Refrigerator / User Guide
Important safety and environment instructions
• Do not put ce cream, ce cubes or
frozen food to your mouth as soon as
you take them out of the freezer. Rsk
of frostbte!
• Do not touch the nner walls, metal
parts of the freezer or food kept
nsde the refrgerator wth wet
hands. Rsk of frostbte!
• Do not place soda cans or cans
and bottles that contan fluds
that may be frozen to the freezer
compartment. Cans or bottles may
explode. Rsk of njury and materal
damage!
• Do not use or place materals
senstve aganst temperature
such as flammable sprays,
flammable objects, dry ce or other
chemcal agents n the vcnty of
the refrgerator. Rsk of fre and
exploson!
• Do not store explosve materals
such as aerosol cans wth flammable
materals nsde the product.
• Do not place cans contanng fluds
over the product. Splashng of water
on an electrcal part may cause the
rsk of an electrc shock or a fre.
• Ths product s not ntended for
storage and coolng of medcnes,
blood plasma, laboratory preparatons
or smlar materals and products that
are subject to the Medcal Products
Drectve.
• If the product s used aganst ts
ntended purpose, t may cause
damage to or deteroraton of the
products kept nsde.
• If your refrgerator s equpped wth
blue lght, do not look at ths lght
wth optcal devces. Do not stare
drectly at UV LED lght for a long
tme. Ultravolet rays may cause eye
stran.
• Do not fll the product wth more food
than ts capacty. Injures or damages
may occur f the contents of the
refrgerator falls when the door s
opened. Smlar problems may occur
when an object s placed over the
product.
• Ensure that you have removed any
ce or water that may have fallen to
the floor to prevent njures.
• Change the locatons of the racks/
bottle racks on the door of your
refrgerator whle the racks are
empty only. Danger of physcal njury!
• Do not place objects that may fall/
tpped over on the product. These
objects may fall whle openng or
closng the door and cause njures
and/or materal damages.
• Do not ht or exert excessve pressure
on glass surfaces. Broken glass
may cause njures and/or materal
damages.
• The coolng system n your product
contans R600a refrgerant. The
refrgerant type used n the product
s specfed n the the type label.
Ths gas s flammable. Therefore, be
careful not to damage the coolng
system and the ppes whle operatng
the product. In case of damage to the
ppes;
- do not touch the product or the power cord,
- Keep the product away from potential sources
of fire that may cause the product to catch fire.
- ventilation the area where the product is
placed. Do not use a fan.
- Contact authorized service.
• If the product s damaged and you
observe gas leak, please stay away
from the gas. Gas may cause frostbte
f t contacts your skn.

7 / 30EN
Refrigerator / User Guide
Important safety and environment instructions
For Products With Water Fountain / Ice Maker
• Use only drnkng water. Do not fll
the water tank wth frut juce, mlk,
fzzy beverages, alcoholc beverages
or any other lquds ncompatble for
use n the water fountan. Ths may
cause rsk to your health and safety.
• Do not allow the chldren to play wth
the water dspenser or Ice Maker to
prevent accdents and njures.
• Do not nsert your fngers or other
objects nsde the hole of the water
dspenser, ce channel or nsde the
contaner of the Ice Maker. Ths may
cause njures or materal damages.
1.7 Maintenance and
cleaning safety
• Do not pull by the door handle f you
shall move the product for cleanng
purposes. Handle may cause njures
f t s pulled too hard.
• Do not clean the product by sprayng
or pourng water on the product and
nsde the product. Rsk of electrc
shock and fre.
• Do not use sharp or abrasve tools
to clean the product. Do not use
materals such as household cleanng
agents, detergents, gas, gasolne,
alcohol, wax, etc.
• Use cleanng and mantenance
agents that are not harmful for food
only nsde the product.
• Do not use steam or steamed
cleanng materals for cleanng the
product and thawng the ce nsde t.
Steam contacts the lve areas n your
refrgerator and causes short crcut
or electrc shock!
• Take care to keep water away from
the electronc crcuts or lghtng of
the product.
• Use a clean, dry cloth to wpe the dust
or foregn materal on the tps of the
plugs. Do not use a wet or damp pece
of cloth to clean the plug. Otherwse,
rsk of fre or electrc shock may occur.
1.8HomeWhiz
(May not be applicable for all models)
• Follow the safety warnngs even f
you are away from the product whle
operatng the product va HomeWhz
app. Also, pay attenton to the
warnngs n the app.
1.9 Lighting
(May not be applicable for all models)
• Contact an authorzed servce when
you shall replace the LED / bulb usng
for lghtng.
1.10-Technical information
for Wifi + Bluetooth
Frequency Band:
Frequency Band: 2.4GHz (Wi-fi or blue-
tooth operational)
Max. Transmission
Power:
< 100mW (Wi-fi or blue-
tooth operational)
Software
information: Quartz_WiFi.XXX
Conformity Decleration for CE:
Arçelik A.Ş. hereby declares that this appliance com-
plies with Directive 2014/53/EU.
The complete text of the EU declaration of conformity is
available in the following internet address:
Products, From:beko.com.tr

8 /30EN Refrigerator / User Guide
2 Environmental instructions
2.1 Compliance with the WEEE
Directive and Disposing
of the Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other house-
hold wastes at the end of its service life.
Used device must be returned to offical
collection point for recycling of electrical
and electronic devices. To find these collection sys-
tems please contact to your local authorities or re-
tailer where the product was puchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate disposal
of used appliance helps prevent potential negative
consequences for the environment and human
health.
2.2 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
2.3 Package information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

9 / 30EN
Refrigerator / User Guide
1- Freezer compartment
2- Cooler compartment door shelves
3- Egg Holder
4- Water fountain
5- Legumes dispenser
6- Cooler compartment small door shelves
7- Bottle shelf
8- Adjustable stands
9- Crisper, Crisper separator and ethylene filter
10- The dairy (cold storage) binFilter
11- Glass shelves
12- Fan
13- Icematics
14- Freezer compartment glass shelf
15- Freezer compartment
16- Cooler compartment
3 Your Refrigerator
C*Optional: Figures in this user guide are schematic and may not be exactly match your product. If your
product does not comprise the relevant parts, the information pertains to other models.
*12
13
*14
15
16
17
*1
*2
*4
*5
6
3
7
8
8
9
10
11

10 /30EN Refrigerator / User Guide
4 Installation
4.1 The right place for installation
Your product requires adequate air circulation to
function efficiently. If the product will be placed in an
alcove, remember to leave at least 5 cm clearance
between the product and the ceiling, rear wall and
the side walls.
If the product will be placed in an alcove, remember
to leave at least 5 cm clearance between the
product and the ceiling, rear wall and the side
walls. Check if the rear wall clearance protection
component is present at its location (if provided with
the product). If the component is not available, or
if it is lost or fallen, position the product so that at
least 5 cm clearance shall be left between the rear
surface of the product and the wall of the room.
The clearance at the rear is important for efficient
operation of the product.
4.2 For Products With Water
Fountain / Ice Maker
• The hose sets supplied with the product shall be
used. Do not use the old hose sets. Do not extend
the hoses!
• Always connect your product to cold water inlet.
Do not perform installation on the hot water inlet.
The pressure for the cold water inlet shall be 80 PSi
(550 kPa) maximum. If your water pressure exceeds
80Psi or has a water impact effect, use a pressure
limiting valve on your mains system. Ask help from
professional plumbers if you do not know how to
control your water pressure.
High pressure may cause damage to the hose
connections and pose a risk of flooding.
• Take required precautions against the risk of
freezing of hoses. The operating water temperature
interval shall be 0.6°C (33°F) minimum and 38°C
(100°F) maximum. There is a risk of flooding if the
hose is cracked/perforated.
AWARNING: Do not use extension or multi
sockets in power connection.
BWARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
BWARNING: The product's power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
A
WARNING: : If the door span is too
narrow for the product to pass, remove
the door and turn the product sideways; if
this does not work, contact the authorized
service.
• Place the product on a flat surface to avoid
vibration.
• Place the product at least 30 cm away from the
heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.
• Do not expose the product to direct sunlight or
keep in damp environments.
• The product requires adequate air circulation to
function efficiently. If the product will be placed
in an alcove, remember to leave at least 5 cm
distance between the product and the ceiling
and the walls.
4.3 Attaching the plastic wedges
Use the plastic wedges in the provided with
the product to provide sufficient space for air
circulation between the product and the wall.
1. To attach the wedges, remove the screws on
the product and use the screws provided with the
wedges.
Read the “Safety Instructions” section first!

11 / 30EN
Refrigerator / User Guide
Installation
2. Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
4.4 Adjustment of the feet
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.
4.5 Electrical connection
AWARNING: Do not use extension or
multi sockets in power connection.
BWARNING: Damaged power cable
must be replaced by Authorized
Service.
• Our firm will not assume responsibility for any
damages due to usage without earthing and
power connection in compliance with national
regulations.
• The power cable plug must be easily
accessible after installation.
C
Hot surface warning!
The side walls of your product are
equipped with cooler pipes to enhance
the cooling system. High pressure fluid
may flow through these surfaces, and
cause hot surfaces on the side walls.
This is normal and it does not require
servicing. Be careful when you contact
these areas.

12 /30EN Refrigerator / User Guide
5 Preparation
5.1 What to do for energy saving
mehmet
AConnecting the product to electronic
energy-saving systems is harmful, as it
may damage the product.
• For a freestanding appliance; ‘this refrigerating
appliance is not intended to be used as a built-
in appliance’ ;
• Do not keep the refrigerator doors open for
long periods.
• Do not place hot food or beverages into the
refrigerator.
• Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
• Depending on the product's features;
defrosting frozen foods in the cooler
compartment will ensure energy saving and
preserve food quality.
• Food shall be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
• Since hot and humid air will not directly
penetrate into your product when the doors are
not opened, your product will optimize itself
in conditions sufficient to protect your food.
In this energy saving function, functions and
components such as compressor, fan, heater,
defrost, lighting, display and so on will operate
according to the needs to consume minimum
energy while maintaining the freshness of your
foodstuff.
• In case of multiple options are present glass
shelves must be placed so that the air outlets
at the backwall are not blocked, prefably air
outlets are remaining below the glass shelf.
This combination may help impoving air
distribution and energy efficiency.
5.2 First operation
Before using your refrigerator, make sure the
necessary preparations are made in line with
the instructions in "Safety and environment
instructions" and "Installation" sections.
• Keep the product running without placing any
food inside for 12 hours and do not open the
door, unless absolutely necessary.
CA sound will be heard when the
compressor is engaged. It is normal to
hear sound even when the compressor is
inactive, due to the compressed liquids
and gasses in the cooling system.
CIt is normal for the front edges of the
refrigerator to be warm. These areas are
designed to warm up in order to prevent
condensation.
CFor some models, indicator panel turns
off automatically 1 minutes after the door
closes. It will be reactivated when the door
is open or any button is pressed.
ARead the “Safety Instructions” section first!

13 / 30EN
Refrigerator / User Guide
6 Operating the Product
• Do not use any mechanical tools or any
other tools than the recommendations of the
manufacturer to speed up the thawing operation.
• Do not use parts of your refrigerator such
as the door or drawers as a support or a step.
This may cause the product to trip over or its
components to be damaged.
• The product shall be used for storing food
only.
• Turn off the water valve if you will be away
from home (e.g. at vacation) and you will not be
using the Ice Maker or the water dispenser for a
long period of time. Otherwise, water leaks may
occur.
6.1 Turning off the product
•If you shall not be using the product for a long
period;
- unplug it,
- remove the food to prevent odours,
- wait until the ice is thawed,
- clean the inside and wait until it is dried.
- leave the doors open to prevent damage to internal
body plastics.

14 /30EN Refrigerator / User Guide
6 Operation of the Product
6.2 Indicator panel
Indicator panels may vary depending on the model of your product.
Audial and visual functions of the indicator panel will assist in using the refrigerator.
Read the “Safety Instructions” section first!
CShown functions are optional, there may be differences of shape and location in functions found on
your device’s display panel.
1. Support Service Key
2. Quick Freeze Key/ Handle Light Function Setting Key
3. Fault Condition Indicator
4. Energy Saving (Display Off) Indicator
5. Freezing Compartment Temperature Setting Key
6. Compartment Conversion Key
7. Anti-Odour Module Key
8. Cooling Compartment Temperature Setting Key
9. Cooling Compartment OFF (Vacation) Function Key
10. Wireless Key
11. Key for Resetting Wireless Connection Settings
2 5
*6
*7
34
*1
*11
8
*10 9

15 / 30EN
Refrigerator / User Guide
Using the product
1. Support Service Key
Press this key for 3 seconds to activate/deactivate
the support service. Detailed information on the
support service is provided in the “Support Service
Feature” section.
2.Quick Freeze Key
When the quick freeze key is pressed, the quick
freeze symbol ( ) shall be illuminated and the
quick freeze function shall be activated. Freezing
compartment temperature is set to -27 Celcius.
Press the key again to cancel function. The quick
freezing function shall be automatically cancelled
after 52 hours. To freeze a large amount of fresh
food, press the quick freeze key before placing the
food in the freezer compartment.
*Handle Light Function Setting Key
Handle light function might be switched between
open and closed modes by pressing quick
freezing button ( ) for 3 seconds. In the closed
mode, the handle light is only activated when the
appliance door is opened and it goes out after a
while after the door is closed. In the open mode,
the handle light is activated when the appliance
door is opened, the handle light stays on dimly after
a while after the door is closed. The handle light
function is set to the ex-factory closed mode.
3. Fault Condition Indicator
This indicator ( ) shall be active when your
refrigerator cannot perform adequate cooling or in
case of any sensor error. “E” shall be displayed on
the Freezing Compartment temperature indicator
and figures such as 1,2,3... shall be displayed on
the cooling compartment temperature indicator.
These figures provide information to the authorized
service on the error that has occurred.
Exclamation mark may be displayed when you load
warm food to the freezing compartment or keep the
door open for a long period of time. This is not a
fault, this warning shall be removed when the food
is cooled down or when any key is pressed.
4. Energy Saving (Display Off) Indicator
Energy saving function is enabled automatically
and the energy saving symbol () is displayed when
the door of the product is not opened or closed
for some period of time. When the energy saving
function is active, all symbols on the screen
other than the energy saving symbol shall be
turned off. When the energy-saving function is
active, pressing any key or opening the door will
deactivate the energy-saving function and the
display signals will return to normal. The energy-
saving function is a function activated ex-factory
and cannot be cancelled.
5. Freezing Compartment Temperature
Setting Key
Temperature setting is made for cooler
compartment. Pressing this key will enable the
freezer compartment temperature to be set at
-18,-19,-20,-21,-22,-23,-24 Celcius.
6. Compartment Conversion Key
When the compartment conversion key is
pressed for 3 seconds, freezer compartment
switches between cooler, off, and freezer modes
respectively. When it is operated as cooling
compartment, the temperature of the compartment
may be set at 4 Celcius. In case of OFF mode,
compartment temperature indicator shall display
“- -”.
7. Anti-Odour Module Key
Press and hold this button for 3 seconds to
activate/deactivate the anti-odour feature. As the
anti-odour feature is active, the ( ) LED on the
respective button is illuminated. When the feature
is active, the anti-odour module will be operated
periodically.
8. Cooling Compartment Temperature Setting
Key
Allows setting of temperature for cooler
compartment. Pressing this key will enable the
cooling compartment temperature to be set at
8,7,6,5,4,3,2 and 1 Celcius.
9. Cooling Compartment OFF (Vacation)
Function Key
Press the key for 3 seconds to activate the
vacation function. Vacation mode is activated
and the LED on the key is illuminated. “- -”
shall be displayed on the Cooling Compartment
temperature indicator and the cooling

16 /30EN Refrigerator / User Guide
Using the product
compartment does not actively perform cooling.
You should not keep your food in the cooling
compartment if you activate this function. The
other compartments continue to cool according
to temperatures set before. Press the key for 3
seconds again to cancel this function.
10. Wireless Key
This key is used for establishing wireless
connection to your appliance through HomeWhiz
mobile application.
When you press the key for 3 seconds, the
wireless connection symbol on the display/screen
flashes slowly (with intervals of 0.5 seconds). This
introduces your home network to the appliance.
When wireless connection with the product is
established, LED on the key remains still.
Connection may be activated/deactivated by
pressing on this key following the completion
of initial setup. The wireless connection icon
flashes (with the interval of 0,2 seconds) until the
connection is established. When the connection is
active, LED will remain still.
In case the connection cannot be established for
a long time, check your connection settings and
refer to 'Troubleshooting' section in the manual.
HomeWhiz application shall be used for wireless
connection. Installation steps are described on the
application during installation.
You can download the application by using the QR
code of HomeWhiz label on the appliance. The App
is offered through App Store for IOS devices, and
through Play Store for Android devices.
For detailed information please visit https://www.
homewhiz.com address
11. Key for Resetting Wireless Connection
Settings
To reset the wireless connection settings, press
Quick freezing ( ) and wireless connection (
) keys simultaneously for 3 seconds. All user
information recorded previously are removed on
a product where wireless connection settings are
reset/restored to factory defaults.
6.3 Support Service Feature
*May not be available in all models
Support Service is a feature that allows you to
create a request for our expert representatives
through a special offer on your white goods
products. After the request to be created with
the Support Service button, our expert customer
representatives will be able to call you from your
mobile phone number that you have registered in
the HomeWhiz application and help you about all
your questions.
6.4 Entering Phone Number
for Support Service
To ensure that your customer representative
may call you after creating a request by pressing
Support Service button, you shall share your
mobile phone number with the application. You
may add or change your mobile phone number
through the communication menu on the
HomeWhiz application.
6.5 Creating a Request Via
Support Service
To create a Support Service request, your product
must be connected to the internet.
1. Ensure that you have an internet connection
on the product and you have entered your mobile
phone number via HomeWhiz application.
2. Press the support service key for 3 seconds.
3. Support Service symbol shall start to blink.
4. When your request is delivered to the customer
representative successfully, Support Service symbol
shall constantly illuminate.
5. Your customer representative shall call you via the
telephone number that you have specified on the
HomeWhiz application.
6. The symbol shall turn off when the call is
completed.
7. If your request does not reach the customer
representative successfully, the light of the symbol
will turn off after a while. In this case, follow the
guides in the troubleshooting step.

17 / 30EN
Refrigerator / User Guide
Using the product
6.6 Cancelling a Support
Service Request
If you want to cancel your support service request,
your request shall be delivered to the customer
representative successfully and the symbol shall
be illuminated constantly. To cancel;
1. Press the support service button for 3 seconds.
2. Support Service symbol shall start to blink.
3. Symbol shall turn off when your request is
cancelled successfully.
4. If your request does not cancel, Support Service
symbol shall constantly illuminate again.
6.7 Troubleshooting
When you press the support service button, the
light of the symbol does not illuminate constantly,
turned off immediately or if it is constantly blink:
1. Ensure that your product is connected to the
internet.
2. Ensure that you have a HomeWhiz account and
that you have entered your mobile phone number via
HomeWhiz application.
3. Ensure the accuracy of the phone number that you
registered to the HomeWhiz application.
4. If the internet connection is not available, this
feature does not work. Check your home internet
connection.
Info:
• When you press the support service key; If the
wireless connection is off, it shall be turned on
automatically.
• You will not be allowed to turn off your
product’s wireless connection, while the
Support Service process is in progress.
• When the Support Service operation is
complete; Wireless connection shall continue
unless you turn it off.

18 /30EN Refrigerator / User Guide
Using the product
6.8 Humidity controlled
crisper (EverFresh+)
(Optional)
Thanks to the humidity controlled crisper,
vegetables and fruits may be stored for a longer
period at an environment with ideal humidity
conditions. With the humidity setting system with
3 options in front of your crisper, you may control
the humidity inside the compartment as per the
food you store. We recommend you to store your
food by selecting vegetable option when you store
vegetables only, fruit option when you store fruit
only and mixed option when you store mixed food.
We recommend that the vegetables and fruits
shall not be stored in bags to improve the storage
period of the food and to better benefit from the
humidity control system. Leaving them in plastic
bags causes vegetables to rot in a short time.
We recommend that cucumbers and broccolis,
in particular, are not stored in closed bags. In
situations where contact with other vegetables is
not preferred, use packaging materials such as
paper that has a certain level of porosity in terms
of hygiene.
When placing the vegetables, place heavy and
hard vegetables at the bottom and light and soft
ones on the top, taking into account the specific
weights of vegetables.
Do not put fruits that have a high ethylene gas
production such as pear, apricot, peach and
particularly apple in the same crisper with other
vegetables and fruits. The ethylene gas coming out
of these fruits might cause other vegetables and
fruits to mature faster and rot in a shorter period
of time.
6.9 Blue Light/HarvestFresh
(Optional)
For Blue light,
Vegetables and fruit stored in crispers illuminated
with blue light continue to perform photosynthesis
and retain their levels of C vitamin thanks to the
effect of the wavelength of the blue light.
For HarvestFresh,
Vegetables and fruit stored in crispers illuminated
with HarvestFresh technology retain their vitamin
levels (vitamins A and C) for a longer period thanks
to the cycles of blue, green, red lights and dark
that simulate the cycle of the day.
When the door of your refrigerator is opened dur-
ing the dark period of the HarvestFresh technology,
your refrigerator shall sense this automatically and
illuminate the crisper with one of the blue, green
or red lights respectively for your convenience. The
dark period shall be continued when you close the
door of your refrigerator so that it shall represent
the night period of the day cycle.

19 / 30EN
Refrigerator / User Guide
Using the product
6.10 Anti-Odour Module
(FreshGuard)
(This feature is optional)
Anti-odour module removes odour that occur
inside your refrigerator before it permeates on the
surfaces. Thanks to this module positioned on
the roof the fresh food compartment, bad odour is
removed while the air is actively passed through
the odour filter, and the air cleaned in the filter
is directed back to the fresh food compartment.
Thus, undesired odour that may occur during the
storage of food inside the refrigerator is removed
from the environment before it permeates on the
surfaces.
This feature is provided with the fan, LED and
odour filter placed inside the module. Anti-
odour module shall be automatically activated
periodically. If the door of the fresh food
compartment is opened while the module is
active, fan is stopped temporarily, and it continues
to operate when the door is closed. In case of a
power failure, anti-odour module starts to operate
when the power is restored.
İnfo: To prevent bad odours that may occur with
the mixture of odours from different food, we
recommend you to store aromatic food such as
cheese, olives and delicatessen in their packaging
and with their lids closed. For the safety of other
food stored and to prevent bad odours, we
recommend you to remove the food that you have
observed to be spoilt from the refrigerator as soon
as possible.
