Beko BU 1200 HCA User manual

BU 1200 HCA
Refrigerator
Kühlschrank
De Koelkast
Le Réfrigérateur

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
For this, we recommend you to carefully read the entire manual of your product before
using it and keep it at hand for future references.
This manual...
…will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
Contents
1 Your refrigerator 3
Technical specifications of your
refrigerator 4
2 Warnings 5
General safety 5
Starting Up 6
If there are any children at home... 6
Intended use 6
Safety instructions 6
Things to be done for energy saving 6
3 Installation 7
Preparation 7
Points to be considered when re-
transporting your refrigerator 7
Before operating your refrigerator 7
Adjusting the legs 8
Electrical connection 8
Initial startup 8
Disposing of the packaging 8
Disposing of your old refrigerator 8
4 Using your refrigerator 9
Temperature setting button 9
Storing the frozen food 9
Defrost 9
LED indicators and control panel 10
5 Maintenance and cleaning 11
Protection of plastic surfaces 11
6 Recommended solutions for
the problems 12

EN
3
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1
5
3
3
2
4
1Your refrigerator
1- Control panel
2- Fast freeze compartment
3- Frozen food storage compartment
4- Ventilation lid
5- Adjustable legs

EN
4
Technical specifications of your refrigerator
Energy Class
Annual Energy Consumption (kWh/year)*
Fridge Compartment Volume (Net-lt)
Total Frozen Food Compartment Volume
(Net-lt)
Star Class
Temperature Increasing Time (hours)**
Freezing Capacity (kg/24 hours)
Climate Class
Noise Level (dB(A))
Total Net Volume (lt)
(H) Height (cm)
(W) Width (cm)
(D) Depth (cm)
Weight (kg)
Total Power (W)
Electric Supply (V/Hz)
CTechnical specifications can be changed to increase the product quality without being
subject to prior notice.
CValues stated on the markings on the product or in the printed materials supplied
with the product are the values obtained in laboratory in accordance with relevant
standards. Such values may vary depending on the usage of the product and the
ambient conditions.
CThe dimensions given on the table describe the minimum required space to place the
unit with doors closed.
A
205
-
87
4
19
10
SN
39
87
82-87
59,8
54,5
33
50
220-240/50

EN
5
2Warnings
Please examine the following information.
In case these are not followed, personal
injury or material damage may occur. Then
all warranty and reliability commitments will
become invalid.
The usage life of the unit you purchased is
10 years. This is the period for keeping the
spare parts required for the unit to operate
as described.
General safety
• When you want to dispose/scrap
the product, we recommend you to
consult the authorized service in order
to learn the required information and
authorized bodies.
• Consult your authorized service for all
your questions and problems related to
the refrigerator. Do not intervene or let
someone intervene to the refrigerator
without notifying the authorized
services.
• Do not eat cone ice cream and ice
cubes immediately after you take them
out of the freezer compartment! (This
may cause frostbite in your mouth.)
• Do not put bottled and canned liquid
beverages in the freezer compartment.
Otherwise, these may burst.
• Do not touch frozen food by hand; they
may stick to your hand.
• Vapor and vaporized cleaning materials
should never be used in cleaning
and defrosting processes of your
refrigerator. In such cases, the vapor
might get in contact with the electrical
parts and cause short circuit or electric
shock.
• Never use the parts on your refrigerator
such as the door as a means of
support or step.
• Do not use electrical devices inside the
refrigerator.
• Do not damage the cooling circuit,
where the refrigerant is circulating,
with drilling or cutting tools. The
refrigerant that might blow out when
the gas channels of the evaporator,
pipe extensions or surface coatings are
punctured may cause skin irritations
and eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Repairs of the electrical appliances
must only be made by qualified
persons. Repairs performed by
incompetent persons may create a risk
for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the relevant
fuse or unplugging your appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Flammable items or products that
contain flammable gases (e.g. spray) as
well as the explosive materials should
never be kept in the appliance.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, others than those
recommended by the manufacturer.
• This unit you have purchased is
environment-friendly.

EN
6
Starting Up
• Do not operate a damaged refrigerator.
Consult your service if you have any
doubts.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
If there are any children at
home...
• Do not allow children play with
your refrigerator. They might harm
themselves and the refrigerator. (E.g.
do not allow them hang from the door.)
Intended use
• This product is designed for domestic
use.
• It should not be used outdoors. It is not
appropriate to use it outdoor even if the
place is covered with a roof.
Safety instructions
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact the authorized service when
there is a power cable damage and
etc. so that it will not create a danger
for you.
• Caution: Never plug the refrigerator
into the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
Things to be done for energy
saving
CDo not leave the doors of your
refrigerator open for a long time.
CDo not put hot food or drinks in your
refrigerator.
CDo not overload your refrigerator so
that the air circulation inside of it is not
prevented.
CDo not install your refrigerator under
direct sunlight or near heat emitting
appliances such as ovens, dishwashers
or radiators.
CPay attention to keep your food in
closed containers.
AYour product is equipped with a natural
cooling system (R600a) which does
not contain CFC and HFC gases.
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed. Never dispose
the product in fire.

EN
7
3Installation
CPlease remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not be
located under direct sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
• Please make sure that the interior of
your refrigerator is cleaned thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least 2
cm distance between them.
• Original packaging and foam
materials should be kept for future
transportations or moving.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be emptied and
cleaned prior to any transportation.
2. Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the rules of
transportation printed on the package
must be followed.
Please remember…
Every recycled material is an indispensable
source for the nature and for our national
resources.
If you wish to contribute to recycling the
packaging materials, you can get further
information from the environmental bodies
or local authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1- Is the interior of the refrigerator dry and
can the air circulate freely in the rear of
it?
2- Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3- Plug the refrigerator into the wall outlet.
When the door is open the respective
interior light will come on.
4- You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal. Due to the
operation of fans inside the appliance,
overall noise level is slightly higher
in comparison to non-frost free
appliances. This is quite normal and is
not a fault.
5- Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.

EN
8
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs of it as illustrated in
the figure. The corner where the leg exists
is lowered when you turn in the direction
of black arrow and raised when you turn
in the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.
Electrical connection
Connect your refrigerator to a grounded
socket which is being protected by a fuse
with the appropriate capacity.
Important:
• The connection must be in compliance
with national regulations.
• The power cable plug must be easily
accessible after installation.
• Voltage and permitted fuse protection
are indicated in the “Specifications”
section.
• The specified voltage must be equal to
your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
before it is repaired! There is danger of
electric shock!
Initial startup
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- Temperature adjustment button
should not be turned off.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator; if
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
Disposing of the packaging
The packing materials may be dangerous
for children. Keep the packing materials
out of the reach of children or dispose
them of by classifying them in accordance
with the waste instructions. Do not dispose
them of along with the normal household
waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old machine without giving
any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator, cut
out the electric plug and, if there are any
locks on the door, make them inoperable
in order to protect children against any
danger.

EN
9
4Using your refrigerator
Temperature setting button
The interior temperature of your refrigerator
changes for the following reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long periods,
• Food put into the refrigerator without
cooling down to the room temperature,
• The location of the refrigerator in the
room (e.g. exposing to sunlight).
You may adjust the varying interior
temperature due to such reasons by using
the thermostat. If the ambient temperature
is higher than 32°C, turn the thermostat
button to maximum position.
Storing the frozen food
• Frozen food can be stored up to 3
months in general in temperatures
under -18°C. Storage periods may vary
depending on the type of the food.
Storage periods of expiry dates of such
food are indicated on the food package
by their manufacturers.
• Frozen food that you have purchased
should be placed in the freezer before
they thaw.
• Frozen food may be kept in the
compartments with drawers.
Defrost
Increase in the thickness of the ice that
forms on the evaporator of your refrigerator
will decrease the cooling efficiency of it.
Therefore, you must defrost the ice when
the thickness of the ice layer around the
evaporator reaches to approximately 5
mm. It is recommended to defrost the ice
when the refrigerator is not filled too much
or is empty.
Wrap the food in the refrigerator by a
few sheets of paper and keep them in
the coolest place possible or in another
refrigerator.
Turn the thermostat setting button to “off”
or unplug the power cable in order to
perform the defrosting.
Remove the drawers of your refrigerator
(it is not required to remove the lid of
the compartment equipped with a lid).
After some time, the water that melts will
accumulate in the pool located at the
bottom of your refrigerator.
Remove the accumulating water by means
of a soft sponge or etc. and dry the pool
thoroughly.
Do not forget to turn the thermostat setting
button to a position other than the “off” in
order to restart your refrigerator.
Operate your refrigerator for 2 hours while
it is empty and its doors are closed before
replacing your food into it.

EN
10
LED indicators and control
panel
LED indicators in the front section of your
refrigerator are intended to help you in
monitoring the operation of your appliance.
Keep your food in the refrigerator in a safe
manner by monitoring and using these
LEDs and controls as explained below:
Fast Freeze Button (1): Used to freeze the
food fastly. Compressor may not operate
immediately but after some time when the
button is pressed and this is quite normal.
Thermostat Setting Button (2): Used to set
your refrigerator between minimum and
maximum values.
Orange LED (3): Lights up when the fast
freeze button on the LED panel is pressed.
In this case, your refrigerator operates
continuously.
Press the button again when the food
you would like to fast freeze comes to the
desired temperature and the orange LED
will turn off.
Green LED (4): Lights up continuously after
plugging in your refrigerator.
Red LED (5): It warns you by lighting up
continuously when your refrigerators start
to operates, if not enough cooling effect
is obtained, when the door remains open
for a long time and when excessive food is
loaded.
If the red LED lights up continuously when
the conditions stated in the adjacent
column do not exist, then call our
Authorized Service.

EN
11
5Maintenance and cleaning
ANever use gasoline, benzene or similar
substances for cleaning purposes.
BWe recommend that you unplug the
appliance before cleaning.
• Never use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
• Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
• Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
• Make sure that no water enters the
lamp housing and other electrical
items.
• If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food, clean
it and leave the door ajar.
• Check door seals regularly to ensure
they are clean and free from food
particles.
• To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
Protection of plastic
surfaces
• Do not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the plastic
surfaces of your refrigerator. In case of
spilling or smearing oil on the plastic
surfaces, clean and rinse the relevant
part of the surface at once with warm
water.

EN
12
6Recommended solutions for the problems
Please review this list before calling the service. It might save you time and money. This list
includes frequent complaints that are not arising from defective workmanship or material
usage.
Complaint Possible Reason Solution
The refrigerator
does not
operate
Is the refrigerator properly
plugged in?
Insert the plug to the wall
socket.
Is the fuse of the socket which
your refrigerator is connected to
or the main fuse blown out?
Check the fuse.
Condensation
on the side wall
of the fridge
compartment.
Very cold ambient conditions.
Frequent opening and closing
of the door. Highly humid
ambient conditions. Storage of
food containing liquid in open
containers. Leaving the door ajar.
Switching the thermostat to a
colder degree.
Decreasing the time the
door left open or using it less
frequently.
Covering the food stored in
open containers with a suitable
material.
Wipe the condensation using
a dry cloth and check if it
persists.
Compressor is
not running
Protective thermic of the
compressor will blow out during
sudden power failures or plug-
out plug-ins as the refrigerant
pressure in the cooling system
of the refrigerator has not been
balanced yet.
Your refrigerator will start
running approximately after
6 minutes. Please call the
service if your refrigerator does
not startup at the end of this
period.
The fridge is in defrost cycle. This is normal for a full-
automatically defrosting
refrigerator. Defrosting cycle
occurs periodically.
Your refrigerator is not plugged
into the socket.
Make sure that he plug is
inserted tightly to the wall
socket.
Are the temperature adjustments
correctly made?
There is a power failure. Call your electricity supplier.

EN
13
The fridge
is running
frequently or for
a long time.
Your new refrigerator may be
wider than the previous one.
This is quite normal. Large
refrigerators operate for a
longer period of time.
The ambient room temperature
may be high.
This is quite normal.
The refrigerator might have been
plugged in recently or might have
been loaded with food.
Cooling down of the refrigerator
completely may last for a
couple of hours longer.
Large amounts of hot food might
have been put in the refrigerator
recently.
Hot food causes longer
running of the refrigerator until
they reach the safe storage
temperature.
Doors might have been opened
frequently or left ajar for a long
time.
The warm air that has entered
into the refrigerator causes the
refrigerator to run for longer
periods. Open the doors less
frequently.
Freezer or fridge compartment
door might have been left ajar.
Check if the doors are tightly
closed.
The
temperatures
are too low
The temperature of your
refrigerator is adjusted to a very
low degree.
Adjust the temperature of your
refrigerator to a higher degree
and check.
The
temperatures
are too high.
The temperature of your
refrigerator is adjusted to a very
high degree.
Change the temperature of the
fridge or freezer until the fridge
or freezer temperature reaches
to a sufficient level.
Doors might have been opened
frequently or left ajar for a long
time.
Warm air rushes into the fridge
compartment when the doors
are opened. Open the doors
less frequently.
The door might be left ajar. Close the door completely.
Large amounts of hot food might
have been put in the refrigerator
recently.
Wait until the fridge or
freezer reaches the desired
temperature.
The refrigerator might have been
plugged in recently.
Cooling down of the refrigerator
completely takes time because
of the size.

EN
14
Noise
The operation
noise increases
when the
refrigerator is
running.
The operating performance
characteristics of the refrigerator
may change according to
the changes in the ambient
temperature.
It is normal and not a fault.
Vibrations or
noise.
The floor is not even or it is weak.
The refrigerator rocks when
moved slowly.
Make sure that the floor is level,
strong and capable to carry the
refrigerator.
The noise may be caused by the
items put onto the refrigerator.
Such items should be removed
from the top of the refrigerator.
There are
noises like
liquid spilling or
spraying.
Liquid and gas flows happen in
accordance with the operating
principles of your refrigerator.
It is normal and not a fault.
Water/condensation in the refrigerator.
Condensation
on the inner
walls of
refrigerator.
Hot and humid weather increases
the condensation.
It is normal and not a fault.
The doors are ajar. Make sure that the doors are
closed completely.
Doors might have been opened
very frequently or they might have
been left open for along time.
Open the door less frequently.
Water/condensation outside the refrigerator.
Humidity
occurs on the
outside of the
refrigerator or
between the
doors.
The weather may be humid. This is quite normal in humid
weather. When the humidity
is less, condensation will
disappear.

EN
15
Bad odor inside
the refrigerator.
Inside of the refrigerator must be
cleaned.
Clean the inside of the
refrigerator with a sponge,
warm water or carbonated
water.
Some containers or packaging
materials might be causing the
smell.
Use a different container or
different brand packaging
material.
Opening and closing of the doors
The door(s)
is (are) not
closing.
Food packages may prevent the
door’s closing.
Replace the packages that are
obstructing the door.
The refrigerator is probably not
completely vertical on the floor
and it might be rocking when
slightly moved.
Adjust the elevation screws.
The floor is not level or strong.
Make sure that the floor is
level and capable to carry the
refrigerator.

Bitte lesen Sie zuerst diese Anleitung!
Sehr geehrte Kundin, sehr geehrter Kunde,
Wir sind sicher, dass Ihnen dieses Produkt, das in modernsten Fertigungsstätten
hergestellt und den strengsten Qualitätsprüfungen unterzogen wurde, lange Zeit gute
Dienste leisten wird.
Wir empfehlen Ihnen, vor Inbetriebnahme des Gerätes das gesamte Handbuch
durchzulesen und es anschließend aufzubewahren.
Diese Anleitung...
... hilft Ihnen, Ihr Gerät schnell und sicher bedienen zu können.
• Lesen Sie die Anleitung, bevor Sie Ihr Produkt aufstellen und bedienen.
• Halten Sie sich an die Anweisungen, beachten Sie insbesondere die
Sicherheitshinweise.
• Bewahren Sie die Anleitung an einem leicht zugänglichen Ort auf, damit Sie jederzeit
darin nachschlagen können.
• Lesen Sie auch die weiteren Dokumente, die mit Ihrem Produkt geliefert wurden.
Bitte beachten Sie, dass diese Anleitung eventuell auch für andere Geräte eingesetzt
werden kann.
Symbole und ihre Bedeutung
In dieser Anleitung finden Sie die folgenden Symbole:
CWichtige Informationen oder nützliche Tipps.
A Warnung vor Verletzungen oder Beschädigungen.
BWarnung vor elektrischem Strom.

DE
2
Inhalt
1 Ihr Kühlschrank 3
Technische Daten Ihres Kühlschranks4
2 Warnhinweise 5
Allgemeine Hinweise zu Ihrer
Sicherheit 5
Inbetriebnahme 6
Wenn Kinder in der Nähe sind... 6
Bestimmungsgemäßer Gebrauch 6
Sicherheitshinweise 6
Dinge, die Sie zum Energiesparen
beachten sollten 6
3 Installation 7
Vorbereitung 7
Was Sie bei einem weiteren Transport
Ihres Kühlschranks beachten müssen7
Bevor Sie Ihren Kühlschrank
einschalten 7
Füße einstellen 8
Elektrischer Anschluss 8
Erste Inbetriebnahme 8
Entsorgung der
Verpackungsmaterialien 8
Entsorgung von Altgeräten 8
4 So bedienen Sie Ihren
Kühlschrank 9
Temperatureinstellung 9
Lagerung von Tiefkühlkost 9
Abtauen 9
LED-Anzeigen und Bedienfeld 10
5 Wartung und Reinigung 11
Schutz der Kunststoffflächen 11
6 Empfehlungen zur
Problemlösung 12

DE
3
C Abbildungen und Angaben in dieser Anleitung sind schematisch und können etwas
von Ihrem Produkt abweichen. Wenn die Teile nicht im gekauften Produkt enthalten
sind, gelten Sie für andere Modelle.
1
5
3
3
2
4
1Ihr Kühlschrank
1- Bedienungskonsole
2- Schockgefrierfach
3- Tiefkühlfach
4- Belüftungsdeckel
5- Einstellbare Füße
