Beko CN160120 User manual

www.beko.com.trwww.beko.com
CN160120
CN161220X
CN161220FCX
EN DE

Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in modern facilities
with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In case the product
changes hands, do not forget to hand the guide to its new owner along with the product.
This guide will help you use the product quickly and safely.
• Pleasereadtheuserguidecarefullybeforeinstallingandoperatingtheproduct.
• Alwaysobservetheapplicablesafetyinstructions.
• Keeptheuserguidewithineasyreachforfutureuse.
• Pleasereadanyotherdocumentsprovidedwiththeproduct.
Keep in mind that this user guide may apply to several product models. The guide clearly indicates any
variations of different models.
CImportant information and useful
tips.
ARisk of life and property.
BRisk of electric shock.
The product’s packaging is made of
recyclable materials, in accordance
with the National Environment
Legislation.

2 /36EN Refrigerator / User manual
1Safety and environment instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . . . . 3
1.2. Intended use . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product . . . . . . . . . 6
1.5. Compliance with RoHS Directive. . . . . . . . . 6
1.6. Package information . . . . . . . . . . . . . . . . . 6
2 Your appliance 7
3 Installation 8
3.1. Appropriate installation location . . . . . . . . . 8
3.2. Installing the plastic wedges. . . . . . . . . . . . 8
3.3. Electrical connection . . . . . . . . . . . . . . . . . 8
3.4. Adjusting the feet. . . . . . . . . . . . . . . . . . . . 9
3.5. Illumination lamp . . . . . . . . . . . . . . . . . . . . 9
3.6. Door open warning. . . . . . . . . . . . . . . . . . . 9
3.7. Transportation of the product . . . . . . . . . . . 9
4 Preparation 10
4.1. Things to be done for energy saving . . . . . 10
4.2. Recommendations on the fridge
compartment. . . . . . . . . . . . . . . . . . . . . . 10
4.3. Initial use. . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Using the product 12
5.1. Indicator panel. . . . . . . . . . . . . . . . . . . . . 12
5.2. Dual cooling system . . . . . . . . . . . . . . . . 17
5.3. Freezing fresh food . . . . . . . . . . . . . . . . . 17
5.4. Recommendations for preserving the frozen
food . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.5. Placement of food . . . . . . . . . . . . . . . . . . 18
5.6. Deep-freeze information. . . . . . . . . . . . . . 18
5.7. Ice machine. . . . . . . . . . . . . . . . . . . . . . . 19
5.8. Icematic . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.9. Ice container . . . . . . . . . . . . . . . . . . . . . . 20
5.10.Blue light. . . . . . . . . . . . . . . . . . . . . . . . . 20
5.11.Egg holder. . . . . . . . . . . . . . . . . . . . . . . . 20
5.12. Description and cleaning of odor filter . . . 21
5.13. Snack compartment . . . . . . . . . . . . . . . . 21
5.14. Sliding storage container. . . . . . . . . . . . . 22
5.15. Rotary storage container . . . . . . . . . . . . . 22
5.16. Crisper . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.17.Using the water dispenser . . . . . . . . . . . . 24
5.18.Filling the water dispenser's tank . . . . . . . 24
5.19. Cleaning the water tank . . . . . . . . . . . . . 25
5.20. Drip tray . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.21.Humidity-controlled crisper (Ever Fresh) . . 26
5.22. Quick bottle cooling/quick ice making
compartment. . . . . . . . . . . . . . . . . . . . . . 30
6 Maintenance and cleaning 33
6.1. Preventing malodour . . . . . . . . . . . . . . . . 33
6.2. Protecting plastic surfaces . . . . . . . . . . . . 33
7 Troubleshooting 34

3 /36EN
Refrigerator / User manual
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all
types of product warranty.
1.1.General safety
• This product should not be
used by persons with physical,
sensory and mental disabilities,
without sufficient knowledge
and experience or by children.
The device can only be used by
such persons under supervision
and instruction of a person
responsible for their safety.
Children should not be allowed
to play with this device.
• In case of malfunction, unplug
the device.
• After unplugging, wait at least
5 minutes before plugging in
again.
• Unplug the product when not in
use.
• Do not touch the plug with wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Wipe the power plug’s tip with
a dry cloth before plugging in.
• Do not plug in the refrigerator if
the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be used
for a while, unplug the product
and remove any food inside.
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1) is
open.
1Safety and environment instructions
1
1

Important instructions for safety and environment
4 /36EN Refrigerator/ User manual
• Do not use steam or
steamed cleaning materials
for cleaning the refrigerator
and melting the ice inside.
Steam may contact the
electrified areas and cause
short circuit or electric
shock!
• Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
• In case of malfunction, do
not use the product, as it
may cause electric shock.
Contact the authorized
service before doing
anything.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED
type lighting, contact the
authorized service for
replacing or in case of any
problem.
• Do not touch frozen food
with wet hands! It may
adhere to your hands!
• Do not place liquids in
bottles and cans into the
freezer compartment. They
may burst out!
• Place liquids in upright
position after tightly closing
the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of
fire.
• Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
• Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
• Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.

Important instructions for safety and environment
5 /36EN
Refrigerator/ User manual
• Take care not to trap the
power cable.
1.1.1 HC warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas
is flammable. If the cooling
system is damaged, keep the
product away from sources
of fire and ventilate the room
immediately.
CThe label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
• Pressure for cold water
inlet shall be maximum 90
psi (6.2 bar). If your water
pressure exceeds 80 psi
(5.5 bar), use a pressure
limiting valve in your mains
system. If you do not know
how to check your water
pressure, ask for the help of
a professional plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers if you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
1.2.Intended use
• This product is designed for
home use. It is not intended
for commercial use.

Important instructions for safety and environment
6 /36EN Refrigerator/ User manual
• The product should be used
to store food and beverages
only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
• Original spare parts will
be provided for 10 years,
following the product
purchasing date.
1.3.Child safety
• Keep packaging materials
out of children’s reach.
• Do not allow the children to
play with the product.
• If the product’s door
comprises a lock, keep the
key out of children’s reach.
1.4. Compliance with WEEE
Directive and Disposing of the
Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult your
local authorities to learn about these
collection centers.
1.5. Compliance with RoHS
Directive
• This product complies with EU WEEE
Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified
in the Directive.
1.6. Package information
• Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the
packaging materials together with the
domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.

7 /36EN
Refrigerator / User manual
*5
*6
*3
4
7
8
10*11 *12
13
*14
*
15
16
17
18
19
9
*1
*2
1. Door shelves of fridge compartment
2. Display
3. Water dispenser filling tank
4. Egg section
5. Water dispenser reservoir
6. Rotary storage container
7. Freezer compartment drawers
8. Icematic drawer
9. Icematic
10. Crisper
11. Water tank
12. Crisper
13. Chiller compartment
14. Bottle shelf
15. Odor filter
16. Glass shelves of fridge compartment
17. Fan
18. Glass shelves of fridge compartment
19. Freezer compartment
*optional
2Your appliance
C*optional:Figures in this user manual are given as an example and may not match the product
exactly. If the relevant parts are not available in the product you purchased, the figure applies to other
models.

8 /36EN Refrigerator / User manual
3Installation
Always have the installation and repairing
procedures carried out by the Authorized Service
Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried
out by unauthorized persons.
Refer to the nearest Authorized Service Agent for
installation of the product. To make the product
ready for use, make sure that the electricity
installation is appropriate before calling the
Authorized Service Agent. If not, call a qualified
electrician to have any necessary arrangements
carried out.
C
Preparation of the location and electrical
installation at the place of installation is
under customer's responsibility.
B
Product must not be plugged in during
installation. Otherwise, there is the risk
of death or serious injury!
B
WARNING: Installation and electrical
connections of the product must be
carried out by the Authorised Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorised
persons.
A
WARNING: Prior to installation, visually
check if the product has any defects
on it. If so, do not have it installed.
Damaged products cause risks for your
safety.
CMake sure that the power cable is not
pinched or crushed while pushing the
product into its place after installation or
cleaning procedures.
3.1. Appropriate installation location
A
WARNING: If the door of the room where
the product will be placed is too small for
the product to pass, then the product's
doors must be removed and the product
must be turned aside to pass it through.
•Chooseaplaceatwhereyouwouldusethe
product comfortably.
•Installtheproductatleast30cmawayfrom
heat sources such as hobs, ovens, heater
cores and stoves and at least 5 cm away from
electrical ovens. Product must not be subjected
to direct sun light and kept in humid places after
installation.
•Appropriateairventilationmustbeprovided
around your product in order to achieve an
efficient operation. If the product is to be placed in
a recess in the wall, pay attention to leave at least
5 cm distance with the ceiling and side walls.
•Donotplacetheproductonthematerialssuchas
rugs or carpets.
•Placetheproductonanevenfloorsurfaceto
prevent jolts.
•Donotinstalltheproductinplaceswherethe
temperature falls below 10°C.
C
If two coolers are to be installed side
by side, there should be at least 8 cm
distance between them. Otherwise,
adjacent side walls may get damp.
3.2. Installing the plastic wedges
Plastic wedges are used to create the distance for
the air circulation between the product and the
rear wall. Insert the 2 plastic wedges onto the rear
ventilation cover as illustrated in the figure. To install
the wedges, remove the screws on the product and
use the screws given in the same pouch with the
wedges.
3.3. Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the values in
the rating plate. Our company shall not be liable
for any damages that will arise when the product is

Installation
9 /36EN
Refrigerator/ User manual
used without grounding in accordance with the
local regulations.
•Electricalconnectionmustcomplywith
national regulations.
•Powercableplugmustbewithineasyreach
after installation.
•Thevoltageandallowedfuseorbreaker
protection are specified in the Rating Plate
which is affixed to interior of the product. If
the current value of the fuse or breaker in
the house does not comply with the value in
the rating plate, have a qualified electrician
install a suitable fuse.
•Thespecifiedvoltagemustbeequaltoyour
mains voltage.
•Donotmakeconnectionsviaextension
cables or multi-plugs.
BWARNING: Damaged power cable
must be replaced by the Authorized
Service Agent.
B
WARNING: If the product has a
failure, it should not be operated
unless it is repaired by the
Authorised Service Agent! There is
the risk of electric shock!
3.4. Adjusting the feet
If the product stands unbalanced after
installation adjust the feet. Taking help from
someone to slightly lift the product will facilitate
this process.
BWARNING: First unplug the product.
Product must not be plugged in when
adjusting the feet. There is the risk of
electric shock!
Turn the front feet to balance the product. The
corner where the foot exists is lowered when
you turn in the direction of arrow and raised
when you turn it in the opposite direction.
3.5. Illumination lamp
Do not attempt to repair yourself but call the
Authorized Service Agent if the illumination
lamps do not go on or are out of order.
The lamp(s) used in this appliance is not
suitable for household room illumination. The
intended purpose of this lamp is to assist the
user to place foodstuffs in the refrigerator/
freezer in a safe and comfortable way.
3.6. Door open warning
(This feature is optional)
An audio warning signal will be given when the
door of your product is left open for 1 minute.
This warning will be muted when the door is
closed or any of the display buttons (if any) are
pressed.
3.7. Transportation of the product
1. Unplug the product before transporting it.
2. Clean the interior of the product as
recommended in the “Maintenance and
cleaning” section.
3. Secure the shelves, accessories, crisper and
etc. in the product by adhesive tape before
repackaging it.
CPackaging must be tied with thick
tapes or strong ropes and the rules of
transportation printed on the package
must be followed.
COriginal packaging and foam
materials should be kept for future
transportations.
APackaging materials are dangerous
for the children. Keep packaging
materials
in a safe place away
from reach of the children.

10 /36EN Refrigerator / User manual
4.1. Things to be done for energy
saving
AConnecting the product to electric energy
saving systems is risky as it may cause
damage on the product.
• Do not leave the doors of your product open for
a long time.
• Do not put hot food or drinks in your product.
• Do not overload the product. Cooling capacity
will fall when the air circulation inside is
hindered.
• Do not place the product in places subject to
direct sunlight. Install the product at least 30 cm
away from heat sources such as hobs, ovens,
heater cores and stoves and at least 5 cm away
from electrical ovens.
• Store your food in product in closed containers.
• You can load maximum amount of food to
the freezer compartment of the product by
removing the freezer compartment shelf of
drawer. Declared energy consumption value of
the product was determined with the freezer
compartment shelf or drawer removed and with
maximum amount of food loaded. There is no
risk in using a shelf or drawer suitable for the
shapes and sizes of the foods to be frozen.
• Thawing frozen food in fridge compartment will
both provide energy saving and preserve the
food quality.
CThe ambient temperature of the room
where you install the product should at
least be -5°C. Operating your product
under cooler conditions than this is not
recommended.
CInside of your product must be cleaned.
CIf two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
4.2. Recommendations on the fridge
compartment
• Do not allow the food to touch the temperature
sensor in fridge compartment. To allow the
fridge compartment keep its ideal storage
temperature, sensor must not be hindered by
food.
• The baskets/drawers that are provided with the
chill compartment must always be in use for
low energy consumption and for better storage
conditions.
• Food contact with the temperature sensor in
the freezer compartment may increase energy
consumption of the appliance. Thus any
contact with the sensor(s) must be avoided.
• Do not put hot food and beverages inside the
product.
4Preparation

Preparation
11 /36EN
Refrigerator / User manual
4.3. Initial use
Before starting to use the product, check that all
preparations are made in accordance with the
instructions in sections "Important instructions for
safety and environment" and "Installation".
• Clean the interior of the product as
recommended in the “Maintenance and
cleaning” section. Check that inside of it is dry
before operating it.
• Plug the product into the grounded wall
outlet. When the door is opened the interior
illumination will turn on.
• Run the product without putting any food for 6
hours and do not open its door unless certainly
required.
CYou will hear a noise when the compressor
starts up. The liquids and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor is
not running and this is quite normal.
CFront edges of the product may feel warm.
This is normal. These areas are designed
to be warm to avoid condensation.
CIn some models, the instrument panel
automatically turns off 5 minutes after
the door has closed. It will be reactivated
when the door has opened or pressed on
any key.

12 /36EN Refrigerator / User manual
5.1. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
45
76
8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional: Figures in this user manual are given as an example and may not match the product
exactly. If the relevant parts are not available in the product you purchased, the figure applies to other
models.
5Using the product

13 /36EN
Refrigerator / User manual
5 Using the product
6. Compartment selection button
Selection button: Press compartment selection
button to switch between fridge and freezer
compartments.
7. Freezer compartment indicator
Fridge compartment light is illuminated while the
freezer compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator operates in energy
saving mode. This display shall be activated if the
freezer compartment temperature is set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.
1. Fridge compartment indicator
Fridge compartment light is illuminated while the
fridge compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform enough
cooling or in case of a sensor fault, this indicator
is activated. When this indicator is activated, “E” is
displayed on the freezer compartment temperature
indicator, and numbers such as “1,2,3...” are
displayed on the fridge compartment temperature
indicator. These numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment temperature.
4. Vacation function button
Press on Vacation Button for 3 seconds to
activate this function. When the vacation function
is activated, “- -” is displayed on the fridge
compartment temperature indicator and no active
cooling is performed on the fridge compartment.
It is not suitable to keep the food in the fridge
compartment when this function is activated. Other
compartments shall be continued to be cooled as
per their set temperature.
To cancel this function press Vacation button
again.
5. Temperature setting button
Changes the temperature of the relevant
compartment between -24°C... -18°C and
8°C...1°C.

14 /36EN Refrigerator / User manual
5 Using the product
C*Optional: Figures in this user manual are given as an example and may not match the product
exactly. If the relevant parts are not available in the product you purchased, the figure applies to other
models.
1. Fridge compartment temperature setting button
2. Key lock button
3. Freezer compartment temperature setting button
4. Error status indicator
5. Key lock indicator
6. Eco Extra Function Indicator
7. Eco Extra / Vacation Button
8. Vacation function indicator
9. Icematic Off Indicator
(*In some models)
10. Economic usage indicator
11. Quick freeze function indicator
12. Quick freeze function button/ Icematic on-off button
13. Freezer compartment temperature indicator
14. Quick cool function
15. Fridge Compartment Temperature indicator
16. Quick cooling function indicator
1
3
2
4
5
6
10
9*
8
7
11
12
13
15
14
16
*optional

Using your appliance
15 /36EN
Refrigerator/ User manual
1. Fridge compartment temperature setting
button
Press this button to set the temperature of the
fridge compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set the fridge
compartment temperature to the desired value.
2. Key lock button
Pressing and holding this button for 3 seconds
will activate the key lock function and the key
lock indicator will turn on. Pressing and holding
this button again for 3 seconds will deactivate
the key lock function.
3. Freezer compartment temperature setting
button
Press this button to set the temperature of the
freezer compartment to -18,-19,-20,-21, -22,
-23,-24, -18... respectively. Press this button
to set the freezer compartment temperature to
the desired value.
4. Error status indicator
If your product does not perform enough
cooling or in case of a sensor fault, this
indicator is activated.
When this indicator is activated, “E” is
displayed on the freezer compartment
temperature indicator, and numbers such
as “1,2,3...” are displayed on the fridge
compartment temperature indicator. The
numbers on the indicator inform service
personnel about the error.
CWhen you place hot food into the
freezer compartment or if you leave
the door open for a long time, an
exclamation mark can be displayed for
some time. This is not a failure; this
warning will disappear when the food
cools down.
5. Key lock indicator
Use this function if you want to prevent
changing of the temperature setting of the
product. To activate it press and hold fridge
compartment temperature setting button and
freezer compartment temperature setting
button simultaneously for 3 seconds.
6. Eco extra function ındicator
Indicates that the Eco Extra function is active.
If this function is active, your product will
automatically detect the least usage periods
and energy-efficient cooling will be performed
during those times.
CEconomy indicator will be active while
energy-efficient cooling is performed.
CPress the relevant button to disable the
function.
7. Eco extra / Vacation button
Pressing this button briefly will activate the
Eco Extra function. Pressing and holding this
button for 3 seconds will activate the Vacation
function. Pressing this button again will
deactivate the selected function.
8. Vacation function indicator
Indicates that the Vacation Function is active.
When this function is active “- -“ appears on
the Fridge Compartment Temperature indicator
and no cooling is performed in the fridge
compartment. Other compartments will be
cooled in accordance with the temperature set
for them.
CPress the relevant button to disable the
function.
9. Icematic off indicator
Indicates whether the icematic is on or off.
If On, then the icematic is not operating. To
operate the icematic again press and hold the
On-Off button for 3 seconds.

Using your appliance
16 /36EN Refrigerator/ User manual
CWater flow from water tank will stop
when this function is selected. However,
ice made previously can be taken from
the icematic.
10. Economic usage indicator
Indicates that the product is running in
energy-efficient mode. This indicator will
be active if the Freezer Compartment
temperature is set to -18 or the energy
efficient cooling is being performed due to
Eco-Extra function.
CEconomic usage indicator is turned
off when quick cooling or quick freeze
functions are selected.
11. Quick freeze function indicator
Flashes in an animated style to indicate that
the Quick Freeze function is enabled.
12. Quick freeze function button/ Icematic
on-off button
Press this button to activate or
deactivate the quick freezing function.
When you activate the function, the
freezer compartment will be cooled to a
temperature lower than the set value.
To turn on and off the icematic press and
hold it for 3 seconds.
CUse the quick freeze function when
you want to quickly freeze the food
placed in fridge compartment. If
you want to freeze large amounts
of fresh food, activate this function
before putting the food into the
product.
CIf you do not cancel it, Quick Freeze
will cancel itself automatically
after 4 hours or when the fridge
compartment reaches to the
required temperature.
CThis function is not recalled when
power restores after a power failure.
13. Freezer compartment temperature indicator
Indicates the temperature set for freezer
compartment.
14. Quick cool function
The button has two functions. To activate or
deactivate the quick cool function press it briefly.
Quick Cool indicator will turn off and the product
will return to its normal settings.
CUse quick cooling function when you
want to quickly cool the food placed
in the fridge compartment. If you want
to cool large amounts of fresh food,
activate this function before putting the
food into the product.
CIf you do not cancel it, quick cooling
will cancel itself automatically after 8
hours or when the fridge compartment
reaches to the required temperature.
CIf you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
CThis function is not recalled when
power restores after a power failure.
15. Fridge compartment temperature indicator
Indicates the temperature set for Fridge
compartment.
16. Quick cooling function indicator
Flashes in an animated style to indicate that the
Quick Cooling function is enabled.

Using your appliance
17 /36EN
Refrigerator/ User manual
5.2. Dual cooling system
Your product is equipped with two separate
cooling systems to cool the fresh food
compartment and freezer compartment. Thus,
air and odor in the fresh food compartment
and frozen food compartment do not get
mixed. Thanks to these two separate cooling
systems, cooling speed is much higher then
other refrigerators. Also additional power saving
is provided since the defrosting is performed
individually.
5.3. Freezing fresh food
• Place the food in the product wrapped or
covered.
• Hot food must be cooled down to the room
temperature before putting them in the
product.
• The food that you want to freeze must be
fresh and in good quality.
• Divided the food into portions according
to your family’s daily or meal based
consumption needs.
• Pack the food in an airtight manner to
prevent them from drying even if they are
going to be stored for a short time.
• Materials to be used for packaging must be
tear-proof and resistant to cold, humidity,
odor, oils and acids and they must also
be airtight. Moreover, they must be well
closed and they must be made from easy-
to-use materials that are suitable for deep-
freezers.
• Frozen food must be used immediately after
they are thawed and they should never be
re-frozen.
• Do not freeze too large quantities of food
at one time. The quality of the food is best
preserved when it is frozen right through to
the core as quickly as possible.
• Placing warm food into the freezer
compartment causes the cooling system to
operate continuously until the food is frozen
solid.
• Take special care not to mix already frozen
food and fresh food.
• If the product has a quick freeze function,
activate the quick freeze function when you
want to freeze the food.
Freezer
compartment
setting
Fridge
compartment
setting
Remarks
-18°C 4°C This is the normal recommended setting.
-20, -24 or -24°C 4°C These settings are recommended when the ambient temperature
exceeds 30°C.
Quick freeze 4°C Use when you wish to freeze your food in a short time. Your product
will return to its previous mode when the process is over.
-18°C or colder 2°C Use these settings if you think that your fridge compartment is not cold enough because of the hot ambient conditions or frequent
opening and closing of the door.
-18°C or colder Quick fridge
Use this function when you place too much into the fridge
compartment or when you need to cool your food quickly. It is
recommended that you activate quick fridge function 4-8 hours before
placing the food.

Using your appliance
18 /36EN Refrigerator/ User manual
5.4. Recommendations for
preserving the frozen food
•Frozenfoodthatyouhavepurchasedshould
be stored in accordance with the frozen food
manufacturer's instructions for a frozen food
storage compartment.
Note the following to ensure that the high quality
achieved by the frozen food manufacturer and
the food retailer is maintained:
1. Put packages in the freezer as quickly as
possible after purchase.
2. Ensure that contents are labeled and dated.
3. Do not exceed "Use By", "Best Before" dates
on the packaging.
5.5. Placement of food
Freezer compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Egg section Eggs
Refrigerator
compartment
shelves
Food in pans, covered
plates and closed
containers
Door shelves
of fridge
compartment
Small and packaged food
and beverage (such as
milk, fruit juice, beer and
etc.)
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)
5.6. Deep-freeze information
Food must be frozen as rapidly as possible
when they are put in a product refrigerator in
order to keep them in good quality.
It is possible to preserve the food for a long time
only at -18°C or lower temperatures.
You can keep the freshness of food for many
months (at -18°C or lower temperatures in the
deep freeze).
Divided the food into portions according to
your family’s daily or meal based consumption
needs.
Pack the food in an airtight manner to prevent
them from drying even if they are going to be
stored for a short time.
Materials necessary for packaging:
•Coldresistantadhesivetape
•Self-adhesivelabel
•Rubberrings
•Pen
Materials to be used for packaging the
foodstuff must be tear-proof and resistant to
cold, humidity, dour, oils and acids.
Foods to be frozen should not be allowed to
come in contact with the previously frozen
items to prevent them from getting thawed
partially.
Frozen food must be used immediately after
they are thawed and they should never be re-
frozen.

Using your appliance
19 /36EN
Refrigerator/ User manual
5.7. Ice machine
*optional
Icematic allows you to obtain ice from the
product easily.
Using the icematic
1. Remove the water tank from the fridge
compartment.
2. Fill water tank with water.
3. Replace the water tank. First ice cubes
will be ready in approximately four hours in
the icematic drawer located in the freezer
compartment.
CWhile the water tank is completely
filled, you will be able to obtain
approximately 60-70 ice cubes.
CThe water within the tank should be
renewed in every 2-3 weeks.
5.8. Icematic
*optional
Icematic allows you to obtain ice from the
product easily.
Using the icematic
1. Take out the icematic pulling it out carefully.
2. Fill the Icematic with water.
3. Place Icematic in place. About two hours
later, the ice is ready.
4. To obtain ice, turn the knobs on the ice
reservoirs clockwise by 90˚ degrees. Ice cubes
in the reservoirs will fall down into the ice
storage container below.
5. You may take out the ice storage container
and serve the ice cubes.
CDo not remove the Icematic from its
seating to obtain ice.
CIf you wish, you may keep the ice
cubes in the ice storage container.
The ice storage container is just for
accumulating ice cubes. Do not put
water in it. Otherwise, it will break.
