Beko DN 152240 User manual

DN 152240-DN 152140-DN 152140 X-DN 152240 X
DN 156720-DN 156720 X-DN156821-DN156821 X
DN156821 XP
EN/HE
57 7165 0000/AH-EN-HE
Refrigerator
User Manual
שמתשמל ךירדמ
ררקמ

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective service.
For this, we recommend you to carefully read the entire manual of your product before
using it and keep it at hand for future references.
This manual





Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.

EN
2
CONTENTS
1 The refrigerator 3
2 Safety and Environment
Instructions 4
General Safety...................................4
Intended Use.....................................6
Child Safety .......................................7
Compliance with WEEE Directive and
Disposing of the Waste Product.........7
 .......7
Package Information..........................7

compartment.....................................7
3Installation 8
Points to be considered when re-
transporting your refrigerator .............8
 ......8
Electric connection ............................8
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Placing and Installation ......................9
Adjusting the legs ..............................9
Changing the illumination lamp .........9
4 Preparation 10
5 Using your refrigerator 11
Indicator Panel.................................11
Freezing fresh food ..........................15

frozen food ......................................16
Placing the food ..............................16
Deep-freeze information ..................17
Door Open Warning.........................17
Description and cleaning of odor
filter: ................................................18
Egg holder.......................................18
Water Dispenser ..............................19
 .................21
 .........................................22
Auto Icematic .................................22
Icematic and ice storage container ..23
6 Maintenance and
cleaning 24
Protection of plastic surfaces ..........24
7
Troubleshooting 25

EN
3
1The refrigerator
1. Freezer compartment shelf
2. Auto Icematic
3. Ice storage container
4. Auto Icematic water tank
5. Temp e r a ture set t i n g ind i c a tor
6. Adjustable glass shelves
7. Odor filter
8. Illumination lens
9. 
10. Snack compartment
11. Crisper cover
12. Crisper
C Figures that take place in this instruction manual are schematic and may not correspond exactly
with your product. If the subject parts are not included in the product you have purchased, then it
is valid for other models.
1
3*
4
5*
6
9*
7
8
10
12
11
13
14
16*
15
17*
18
*19
20
21
2*
*
13. Adjustable legs
14. Freezer compartment door racks
15. Egg holder
16. Water dispenser filling container
17. Water dispenser tank
18. Fridge compartment door shelves
19. Sliding and rotary storage containers
20. Freezer compartment
21. Fridge compartment
*OPTIONAL

EN
4
2Safety and Environment Instructions
This section provides the
safety instructions necessary
to prevent the risk of injury and
material damage. Failure to
observe these instructions will
invalidate all types of product
warranty.
Intended use
A
WARNING:

openings, in the
appliance enclosure or
in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other
means to accelerate
the defrostingprocess,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
A
WARNING:
Do not store explosive
substances such as
aerosol cans with a
flammable propellant in
this appliance.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
General Safety
 This product should not be used by
persons with physical, sensory and mental
disabilities, without sufficient knowledge
and experience or by children. The device
can only be used by such persons under
supervision and instruction of a person
responsible for their safety. Children should
not be allowed to play with this device.
 In case of malfunction, unplug the device.
 After unplugging, wait at least 5 minutes
before plugging in again.
 Unplug the product when not in use.
 Do not touch the plug with wet hands! Do
not pull the cable to plug off, always hold
the plug.

EN
5
 Do not plug in the refrigerator if the socket
is loose.
 Unplug the product during installation,
maintenance, cleaning and repair.
 If the product will not be used for a while,
unplug the product and remove any food
inside.
 Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.
1
1
 Do not use steam or steamed cleaning
materials for cleaning the refrigerator and
melting the ice inside. Steam may contact
the electrified areas and cause short circuit
or electric shock!
 Do not wash the product by spraying or
pouring water on it! Danger of electric
shock!
 In case of malfunction, do not use the
product, as it may cause electric shock.
Contact the authorized service before
doing anything.
 Plug the product into an earthed socket.
Earthing must be done by a qualified
electrician.
 If the product has LED type lighting,
contact the authorized service for
replacing or in case of any problem.
 Do not touch frozen food with wet hands!
It may adhere to your hands!
 Do not place liquids in bottles and cans
into the freezer compartment. They may
burst out!
 Place liquids in upright position after tightly
closing the lid.
 Do not spray flammable substances near
the product, as it may burn or explode.
 Do not keep flammable materials and
products with flammable gas (sprays, etc.)
in the refrigerator.
 Do not place containers holding liquids on
top of the product. Splashing water on an
electrified part may cause electric shock
and risk of fire.
 Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product, do
not pull by holding the door handle. The
handle may come off.
 Take care to avoid trapping any part of
your hands or body in any of the moving
parts inside the product.
 Do not step or lean on the door, drawers
and similar parts of the refrigerator. This
will cause the product to fall down and
cause damage to the parts.
 Take care not to trap the power cable.
 When positioning the appliance, ensure
the supply cord is not trapped or
damaged.

EN
6
 Do not locate multiple portable socket-
outlets or portable power supplies at the
rear of the appliance.
 Children aged from 3 to 8 years are
allowed to load and unload refrigerating
appliances.
 To avoid contamination of food, please
respect the following instructions:
 – Opening the door for long periods
can cause a significant increase of the
temperature in the compartments of the
appliance.
 – Clean regularly surfaces that can come
in contact with food and accessible
drainage systems.
 – Clean water tanks if they have not been
used for 48 h; flush the water system
connected to a water supply if water has
not been drawn for 5 days.
 – Store raw meat and fish in suitable
containers in the refrigerator, so that it is
not in contact with or drip onto other food.
 – Two-star frozen-food compartments
are suitable for storing pre-frozen food,
storing or making icecream and making
ice cubes.
 – One-, two- and three-star
compartments are not suitable for the
freezing of fresh food.
 – If the refrigerating appliance is left empty
for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent
mould developing within the appliance.
1.1.1 HC Warning
If the product comprises a

gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas is
flammable. If the cooling system
is damaged, keep the product
away from sources of fire and
ventilate the room immediately.
C
The label on the inner left side
indicates the type of gas used in
the product.
1.1.2 For Models with
Water Dispenser
 Pressure for cold water inlet shall be
maximum 90 psi (6.2 bar). If your water
pressure exceeds 80 psi (5.5 bar), use
a pressure limiting valve in your mains
system. If you do not know how to check
your water pressure, ask for the help of a
professional plumber.
 If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in your
installation. Consult Professional plumbers
if you are not sure that there is no water
hammer effect in your installation.
 Do not install on the hot water inlet. Take
precautions against of the risk of freezing
of the hoses. Water temperature operating
interval shall be 33°F (0.6°C) minimum and
100°F (38°C) maximum.
 Use drinking water only.
Intended Use
 This product is designed for home use. It
is not intended for commercial use.
 The product should be used to store food
and beverages only.
 Do not keep sensitive products requiring
controlled temperatures (vaccines, heat
sensitive medication, medical supplies,
etc.) in the refrigerator.

EN
7
 The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
 Original spare parts will be provided for 10
years, following the product purchasing
date.
Child Safety
 
reach.
 Do not allow the children to play with the
product.
 

Compliance with WEEE
Directive and Disposing of
the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the
collection center for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn about these collection
centers.
Compliance with RoHS
Directive
 This product complies with EU
WEEE Directive (2011/65/EU). It
does not contain harmful and pro-
hibited materials specified in the
Directive.
Package Information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment

materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
Recommendations for the
fresh food compartment
*May not be available in all models
Do not allow the food to touch the
temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be hindered
by food.
Do not place hot foods in the product.

EN
8
3 Installation
BPlease remember that the manufacturer
shall not be held liable if the information
given in the instruction manual is not
observed.
Points to be considered
when re-transporting your
refrigerator
1.Your refrigerator must be emptied and
cleaned prior to any transportation.
2.Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any jolt
before repackaging.
3.Packaging must be tied with thick tapes
and strong ropes and the rules of
transportation printed on the package
must be followed.
Please do not forget…
Every recycled material is an indispensable
source for the nature and for our national
resources.
If you wish to contribute to recycling the
packaging materials, you can get further
information from the environmental bodies
or local authorities.
Before operating your
refrigerator

the following:
1.Is the interior of the refrigerator dry and can
the air circulate freely in the rear of it?
2.Please install the 2 plastic wedges as
illustrated in the figure. Plastic wedges will
provide the required distance between
your refrigerator and the wall in order to
allow the air circulation. (The illustrated
figure is only an example and does not
match exactly with your product.)
3.Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section.
4.Plug the refrigerator into the wall outlet.
When the fridge door is open, the fridge
compartment interior light will come on.
5.You will hear a noise as the compressor
starts up. The liquid and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor
is not running and this is quite normal.
6.Front edges of the refrigerator may feel
warm. This is normal. These areas
are designed to be warm to avoid
condensation
Electric connection
Connect your product to a grounded
socket which is being protected by a fuse
with the appropriate capacity.
Important:

national regulations.
 
accessible after installation.

mains voltage.

EN
9
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs of it as illustrated in
the figure. The corner where the leg exists
is lowered when you turn in the direction
of black arrow and raised when you turn
in the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.

not be used for connection.
BA damaged power cable must be replaced
by a qualified electrician.
BProduct must not be operated before it is
repaired! There is danger of electric shock!
Disposing of the packaging
The packing materials may be dangerous

of the reach of children or dispose of them
by classifying them in accordance with the
waste instructions. Do not dispose of them
along with the normal household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.

or waste collection center of your
municipality about the disposal of your
refrigerator.

the electric plug and, if there are any
locks on the door, make them inoperable
in order to protect children against any
danger.
Placing and Installation
AIf the entrance door of the room where
the refrigerator will be installed is not
wide enough for the refrigerator to pass
through, then call the authorised service
to have them remove the doors of your
refrigerator and pass it sideways through
the door.
1. Install your refrigerator to a place that allows
ease of use.

sources, humid places and direct sunlight.
3. There must be appropriate air ventilation
around your refrigerator in order to achieve
an efficient operation. If the refrigerator is
to be placed in a recess in the wall, there
must be at least 5 cm distance with the
ceiling and at least 5 cm with the wall. If
the floor is covered with a carpet, your
product must be elevated 2.5 cm from
the floor.
4. Place your refrigerator on an even floor
surface to prevent jolts.
5. Do not keep your refrigerator in ambient
temperatures under 10°C.
Changing the illumination
lamp
     
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable
way.The lamps used in this appliance have
to withstand extreme physical conditions
such as temperatures below -20 °C.
(only chest and upright freezer)

EN
10
4Preparation
 Your refrigerator should be installed at
least 30 cm away from heat sources such
as hobs, ovens, central heater and stoves
and at least 5 cm away from electrical
ovens and should not be located under
direct sunlight.
 The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating your
refrigerator under cooler conditions is not
recommended with regard to its efficiency.
 Please make sure that the interior of your
refrigerator is cleaned thoroughly.
 If two refrigerators are to be installed side
by side, there should be at least 2 cm
distance between them.
 When you operate your refrigerator for
the first time, please observe the following
instructions during the initial six hours.
 The door should not be opened
frequently.
 It must be operated empty without any
food in it.
 Do not unplug your refrigerator. If a power
failure occurs out of your control, please

solutions for the problems” section.
 Original packaging and foam materials
should be kept for future transportations
or moving.
 The baskets/drawers that are provided
with the chill compartment must always
be in use for low energy consumption and
for better storage conditions.
 Food contact with the temperature sensor
in the freezer compartment may increase
energy consumption of the appliance.
Thus any contact with the sensor(s) must
be avoided.
 In some models, the instrument panel
automatically turns off 5 minutes after
the door has closed. It will be reactivated
when the door has opened or pressed on
any key.
 Due to temperature change as a result of
opening/closing the product door during
operation, condensation on the door/body
shelves and the glass containers is normal
 Since hot and humid air will not directly
penetrate into your product when the
doors are not opened, your product
will optimize itself in conditions sufficient
to protect your food. Functions and
components such as compressor, fan,
heater, defrost, lighting, display and so
on will operate according to the needs to
consume minimum energy under these
circumstances.

EN
11
1 7 3
45*62
Indicator Panel
Indicator panel aids in using your refrigerator with its audio and visual functions.
1. Freezer Compartment Temperature
Indicator
2. Error Status Indicator
3. Fridge Compartment Temperature Indicator
4. Fridge Compartment Temperature Setting

5. Economy Mode Indicator
6. Ioniser Indicator
7. Freezer Compartment Temperature Setting

1. Freezer Compartment Temperature
Indicator
It indicates the temperature set for Freezer
compartment.
2. Error Status Indicator
If your refrigerator does not cool adequately
or if there is a sensor failure, this indicator will
be activated. When this indicator is active,
Freezer Compartment Temperature indicator
will display "e" and Fridge Compartment
Temperature Indicator will display numbers
such as "1,2,3…". These numbers on the
indicator provides information about the
error to the service personnel.
3. Fridge Compartment Temperature
Indicator
Indicates the temperature set for Fridge
compartment.
4. Fridge Compartment Temperature
Setting Button
Press this button to set the temperature
of the fridge compartment to 8, 6, 4, 2,
8... respectively. Press this button to set
the desired temperature for the fridge
compartment.
5. Economy Mode Indicator
Indicates that the refrigerator is running in
energy-efficient mode.
6. Ioniser Indicator
Indicator light lights up continuously.
This light indicates that your refrigerator is
protected against the bacteria.
7. Freezer Compartment Temperature
Setting Button
Press this button to set the temperature of
the freezer compartment to -18, -20, -22,
-24, -18... respectively. Press this button to
set the desired temperature for the freezer
compartment.
5Using your refrigerator
Indicator panels may vary depending on your product's model.

EN
12
1. Freezer compartment setting / Icematic
on-off button
2. Fridge compartment setting button
3. Error status indicator
4. 
5. Eco Extra Function indicator
6. 
7. Vacation function indicator
8. Icematic off indicator (*in some models)
15
14
1
2
3
4
5
13
12
11
10
9
8*
*
7
6
9. Economic usage indicator
10. Quick fridge function indicator
11. Quick fridge function button
12. Fridge compartment temperature setting
indicator
13. Quick freeze function button
14. Freezer compartment temperature setting
indicator
15. Quick freeze function indicator
C Figures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.

EN
13
1. Freezer Compartment Setting /
Icematic On-Off Button
This function allows you to make the
freezer compartment temperature setting.
Press this button to set the temperature of
the freezer compartment to -18, -20, -22
and -24 respectively.
To stop ice formation, press Icematic on-
off button for 3 seconds. Water flow from
water tank will stop when this function is
selected. However, ice made previously can
be taken from the Icematic. To restart ice
formation, press Icematic on-off button for
3 seconds.
2. Fridge Compartment Setting Button
This function allows you to make the
fridge compartment temperature setting.
Press this button to set the temperature
of the fridge compartment to 8, 6, 4, 2
respectively.
3. Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor failure,
this indicator will be activated. When this
indicator is active, Freezer Compartment
Temperature indicator will display "E" and
Fridge Compartment Temperature Indicator
will display numbers such as "1,2,3…".
These numbers on the indicator provides
information about the error to the service
personnel.
When you place hot food into the freezer
compartment or if you leave the door open
for a long time, exclamation mark can
illuminate for some time. This is not a failure;
this warning will disappear when the food
cools down.
4. Key Lock Indicator
Use this function if you do not want your
refrigerator temperature setting changed.
Press Fridge compartment setting button
and Freezer compartment setting button
simultaneously for a long time (3 sec) to
activate this function.
5. Eco Extra Function Indicator
It indicates that the Eco-Extra function is
active.
If this function is active, your refrigerator
will automatically detect the least usage
periods and energy-efficient cooling will be
performed during those times. Economy
indicator will be active while energy-efficient
cooling is performed.
Press the relevant button again to
deactivate this function.
6. Eco Extra/Vacation Button
Press this button briefly to activate the Eco
Extra function. Press and hold this button
for 3 sec. to activate the Vacation function.
Press this button again to deactivate the
selected function.
7. Vacation Function Indicator
Indicates that the vacation function is
active. If this function is active, "- -" appears
on the indicator of the fridge compartment
and no cooling is performed in the fridge
compartment. Other compartments will be
cooled in accordance with the temperature
set for them.
Press the relevant button again to
deactivate this function.
8. Ice Off indicator
Icematic will not run when the indicator of
this function is active. See Item 1 to enable
the Icematic.
9. Economy Mode Indicator
Indicates that the refrigerator is running in
energy-efficient mode. Freezer Compartment
temperature
This indicator will be active if the function
is set to -18 or the energy efficient cooling is
being performed due to Eco-Extra function.
10. Quick Fridge Indicator
This icon flashes in an animated style when
the Quick Fridge function is active.
11. Quick Fridge Function
When you press the Quick Fridge button,
the temperature of the compartment will be
colder than the adjusted values.
This function can be used for food placed
in the fridge compartment and required to be
cooled down rapidly.
If you want to cool large amounts of fresh
food, it is recommended to active this feature
before putting the food into the fridge.

EN
14
Quick Fridge indicator turns on when the
Quick Fridge function is on. To cancel this
function press Quick Fridge button again.
If you do not cancel it, Quick Fridge will
cancel itself automatically after 4 hours or
when the fridge compartment reaches to
the required temperature.
This function is not recalled when power
restores after a power failure.
12. Fridge Compartment Temperature
Setting Indicator
Indicates the temperature set for the
Fridge Compartment.
13. Freezer Compartment Temperature
Setting Indicator
Indicates the temperature set for the
Freezer Compartment.
14. Quick Freeze Function
Quick Freeze indicator turns on when the
Quick Freeze function is active. To cancel
this function press Quick Freeze button
again. Quick Freeze indicator will turn off
and return to its normal settings. If you
do not cancel it, Quick Freeze will cancel
itself automatically after 8 hours or when
the freezer compartment reaches to the
required temperature.
If you want to freeze large amounts of
fresh food, press the Quick Freeze button
before putting the food into the freezer
compartment.
If you press the Quick Freeze button
repeatedly with short intervals, the electronic
circuit protection will be activated and the
compressor will not start up immediately.
This function is not recalled when power
restores after a power failure.
15. Quick Freeze Indicator
This icon flashes in an animated style
when the Quick Freeze function is active.
Sabbath Mode:

seconds to activate or deactivate the
Sabbath Mode. When Sabbath Mode is
activated, the display, alarm, door opening
or light buttons will not function.
If the user does not deactivate the
Sabbath mode, the refrigerator will
automatically cancel it in 76 hours.

EN
15
Freezing fresh food
 
them in the refrigerator.
 
temperature before putting them in the
refrigerator.
 
be fresh and in good quality.
 

based consumption needs.
 
airtight manner to prevent them from
drying even if they are going to be kept for
a short time.
 
must be tear-proof and resistant to cold,
humidity, odor, oils and acids and they
must also be airtight. Moreover, they
must be well closed and they must be
made from easy-to-use materials that are
suitable for deep freeze usage.
 
after they are thawed and they should
never be re-frozen.
 
to obtain the best results.
1. Do not freeze too large quantities of food
at one time. The quality of the food is best
preserved when it is frozen right through
to the core as quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling system
to operate continuously until the food is
frozen solid.
3. Take special care not to mix already frozen
food and fresh food.
Freezer
Compartment
Setting
Fridge
Compartment
Setting
Explanations
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the ambient temperature exceeds 30°C.
Quick Freeze 4°C Use when you wish to freeze your food in a short time. Your refrigerator will return to its
previous mode when the process is over.
-18°C or colder 2°C If you think that your fridge compartment is not cold enough because of the hot conditions
or frequent opening and closing of the door.
-18°C or colder Quick Fridge
You can use it when your fridge compartment is overloaded or if you wish to cool down
your food rapidly. It is recommended that you activate quick fridge function 4-8 hours
before placing the food.

EN
16
Recommendations for
preservation of frozen food
 
should be stored in accordance with the
frozen food manufacturer's instructions
for a ( 4 star) frozen food storage
compartment.
 
the frozen food manufacturer and the food
retailer is maintained, the following should
be remembered:
1. Put packages in the freezer as quickly as
possible after purchase.
2. Ensure that contents are labeled and
dated.
 
dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
Placing the food
Freezer compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Egg holder Egg
Fridge compartment
shelves
Food in pans, covered plates
and closed containers
Fridge compartment door
shelves
Small and packaged food or
drinks (such as milk, fruit juice
and beer)
Crisper Vegetables and fruits
Freshzone compartment Delicatessen products (cheese,
butter, salami and etc.)

EN
17
Deep-freeze information
Food must be frozen as rapidly as possible
when they are put in a refrigerator in order to
keep them in good quality.
It is possible to keep the food for a long
time only at -18°C or lower temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A


consumption needs.
      
airtight manner to prevent them from drying
even if they are going to be kept for a short
time.
Materials necessary for packaging:




Materials to be used for packaging the
foodstuff must be tear-proof and resistant
to cold, humidity, odor, oils and acids.
Foodstuff to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent their
partial thawing.
Frozen food must be used immediately
after they are thawed and they should never
be re-frozen.
Door Open Warning
(This feature may vary depending
on the door of the product and may
not exist in some models.)
A audio warning signal will be given when
the door of your product is left open for at
least 1 minute. This warning will be muted
when the door is closed or any of the display
buttons (if any) are pressed.

EN
18
Description and cleaning of
odor filter:
Odor filter prevents unpleasant odor build-
up in your refrigerator.
Pull the cover, into which the odor filter
is installed, downwards and remove as
illustrated. Leave the filter under sunlight
for one day. Filter will be cleaned during this
time. Install the filter back to its place.
Odor filter must be cleaned once in a year.
Snack compartments
Use these compartments for your food
which you want store at a temperature a
few degrees below the fridge compartment.
You can increase the inner volume of your
refrigerator by removing any of the snack
compartments.
1. Pull the compartment towards yourself
until it rests and stops against the stopper.
2. Lift the front section and pull towards
yourself to remove the compartment from
its seating.
CYou can p lace th e food, that you want to
freeze, in these compartments in order to
prepare them for freezing.
Egg holder
You can install the egg holder to the
desired door or body shelf.
Never store the egg holder in the freezer
compartment

EN
19
Water Dispenser
(in some models)
Water dispenser is a very useful feature
based on reaching cold water without
opening the door of your refrigerator. As you
will not have to open your refrigerator door
frequently, you will have saved energy.
Filling the water dispenser water tank
Water tank filling reservoir is located inside
the door rack. Open the reservoir cover and
fill in clean potable water. And then, close
the lid.
Using the water spring
Push the arm of the water dispenser
with your glass. The dispenser will cease
operating once you release the arm.
When operating the water dispenser,
maximum flow can be obtained by pressing
the arm fully. Please remember that the
amount of flow from the dispenser is subject
to the degree you press the arm.
As the level of the water in your glass/
container rises, slightly lessen the pressure
on the arm to prevent the overspill. If you
slightly press the arm, the water will drop;
this is quite normal and not a failure.
Warning!
 
liquid except for water such as fruit
juices, carbonated beverages or alcoholic
drinks which are not suitable to use in
the water dispenser. Water dispenser will
be irreparably damaged if these kinds of
liquids are used. Warranty does not cover
such usages. Some chemical substances
and additives contained in these kinds of
drinks/liquids may damage the water tank
material.
