Beko DNE 61500 D User manual

Réfrigérateur
DNE 61500 D
DNE 61520 DX
Refrigerator
Ψυγείο
Frigorifero
Frigorífico

EN1
1
2
3
4
5
6
The refrigerator............................................................................2
Warnings >3
Safety warnings...........................................................................3
Electrical safety ...........................................................................3
Placing and assembly of your refrigerator >5
Preparation..................................................................................5
Points to be considered when transporting the product: .............5
Dimensions of your refrigerator ...................................................6
Usage area measures .................................................................6
Adjusting the legs ........................................................................6
Operating your refrigerator ..........................................................7
Using your refrigerator >8
Temperature setting buttons and temperature control.................8
Full protection triangle: ..............................................................11
Dual cooling system: .................................................................11
Using the accessories ...............................................................12
Freezing fresh food....................................................................16
Recommendations for preservation of frozen food....................16
Placing the food.........................................................................17
Replacing the interior light module ............................................17
Things to be done for saving energy .........................................17
Deep-freeze information >18
Cleaning your refrigerator >19
Service >19
Recommended solutions for the problems >20
7
8
Contents

EN2
1The refrigerator
1- Freezer compartment 14- Crisper cover
2- Fridge compartment 15- Crisper or chiller compartment
3- Freezer compartment interior light 16- Crisper or chiller compartment adjustment
slider
4- Icematic 17- Ventilation lid
5- Fresh Freeze compartment 18- Adjustable front legs
6- Freezer compartment shelf 19- Freezer compartment door racks
7- Chiller compartment 20- Fridge compartment door racks
8- Select and Cool compartment 21- Bottle holder
9- Select and Cool compartment indicator 22- Egg holder
10- Odor filter (Carbon) 23- Blue light
11- Fridge compartment glass shelves 24- Temperature setting panel and indicator
12- Adjustable bottle holder 25- Water Spring
13- Fridge compartment interior light
• Figures that take place in this instruction manual are schematic and may not correspond exactly
with your product. If the subject parts are not included in the product you have purchased, then it
is valid for other models.
19
1
2
4
5
6
8
12
10
7
15
16
17
18 18
19
20
3
20
20
20
22
21
13
23
14
9
11
11
24
25

EN3
Warnings
2
Safety warnings
• When you want to dispose/scrap the product,
we recommend you to consult the authorized
service in order to learn the required information
and authorized bodies.
• Do not damage the cooling circuit.
• Do not use any electrical tools other than those
recommended by the manufacturer inside the
food storage compartments of the product.
• Consult your authorized service for all
your questions and problems related to the
refrigerator. Do not intervene or let someone
intervene to the refrigerator without notifying the
authorized services.
• Do not eat cone ice cream and ice cubes
immediately after you take them out of the
freezer compartment! (This may cause frostbite
in your mouth.)
• Do not put bottled and canned liquid beverages
in the freezer compartment. Otherwise, these
may burst.
• Do not touch frozen food by hand; they may
stick to your hand.
• Vapor and vaporized cleaning materials
should never be used in cleaning and defrosting
processes of your refrigerator. In such cases,
the vapor might get in contact with the electrical
parts and cause short circuit or electric shock.
• Never use the parts on your refrigerator such
as kick plate or door as a means of support or
step.
• Do not use electrical devices inside the
refrigerator.
• Do not operate a damaged refrigerator. Consult
your service if you have any doubts.
• Do not damage the parts, where the refrigerant
is circulating, with drilling or cutting tools. The
refrigerant that might blow out when the gas
channels of the evaporator, pipe extensions or
surface coatings are punctured may cause skin
irritations and eye injuries.
• Do not cover or block the ventilation holes on
your refrigerator with any material.
• Only authorized service personnel may make
any repair on electrical appliances. Repairs
performed by incompetent persons may create a
risk for the user.
• In case of any failure or during a maintenance
or repair work, disconnect your refrigerator’s
mains supply by either turning off the relevant
fuse or unplugging your appliance.
• Be careful not to pull by the cable when pulling
the plug out.
• Electrical safety of your refrigerator shall be
guaranteed only if the earth system in your
house complies with standards.
• Do not allow children play with your refrigerator.
They might harm themselves and the refrigerator.
(E.g. do not allow them hang from the door.)
• Place the beverage with higher proofs tightly
closed and vertically.
• Flammable items or products that contain
flammable gases (e.g. spray) as well as the
explosive materials should never be kept in the
appliance.
• Do not use mechanical devices or other means
to accelerate the defrosting process, others than
those recommended by the manufacturer.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised
Electrical safety
This product is designed for indoor use. It is not
appropriate to use it outdoor even if the place is
covered with a roof.
Exposing the product to rain, snow, sun and wind
is dangerous with respect to electrical safety.
If the power cable is damaged, it must be
changed by the manufacturer or customer
services in order to avoid potential risks to you.
Caution: Never plug the refrigerator into the wall
outlet during installation. Otherwise, risk of death
or serious injury may arise.

EN4
HCA Warning
If your product is equipped with a
cooling system that contains R600a:
This gas is ammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
re sources that can cause the product
catch a re and ventilate the room in
which the unit is placed.
Ignore the warning.
If your product is equipped with a
cooling system that contains R134a.
You can see the gas used in production
of your product on the rating plate that
is located on the left inner part of it.
Never dispose the product in re.

EN5
Placing and assembly of your refrigerator
3
• Please remember that the
manufacturer shall not be held
liable if the information given in the
instruction manual is not observed.
This product is designed for
domestic use.
Points to be considered when
transporting the product:
1. Your refrigerator must be emptied and cleaned
prior to any transportation.
2. Shelves, accessories, crisper and etc. in
your refrigerator must be fastened securely
by adhesive tape against any jolt before
repackaging.
3. Packaging must be tied with thick tapes and
strong ropes and the rules of transportation
printed on the package must be followed.
Please remember…
Every recycled material is an indispensable
source for the nature and for our national
resources.
If you wish to contribute to recycling the
packaging materials, you can get further
information from the environmental bodies or
local authorities.
If the entrance door of the room where the
refrigerator will be installed is not wide enough
for the refrigerator to pass through, than call
the authorized service to have them remove the
doors of your refrigerator and pass it sideways
through the door.
1. Install your refrigerator to a place that allows
ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct sunlight.
3. There must be appropriate air ventilation
around your refrigerator in order to achieve an
efficient operation.
If the refrigerator is to be placed in a recess in
the wall, there must be at least 5 cm distance
with the ceiling and at least 5 cm with the wall.
If the floor is covered with a carpet, your product
must be elevated 2.5 cm from the floor.
4. Place your refrigerator on an even floor
surface to prevent jolts.
5. Do not keep your refrigerator in ambient
temperatures under 10°C.
Prior to operating your refrigerator, please
read the instruction manual carefully that
includes important information such as
installation, usage and maintenance of your
product.
Preparation
Your refrigerator should be installed at least
30 cm away from heat sources such as hobs,
ovens, central heater and stoves and at least 5
cm away from electrical ovens and should not be
located under direct sunlight.
• The ambient temperature of the room where
you install your refrigerator should at least be
10°C. Operating your refrigerator under cooler
conditions than this is not recommended with
regard to its efficiency.
• Please make sure that the interior of your
refrigerator is cleaned thoroughly.
• If two refrigerators are to be installed side by
side, there should be at least 2 cm distance
between them.
• Your refrigerator must run smoothly without
any vibration. To ensure this, maintain the
balance of your refrigerator on the floor by
turning the adjustable front legs clockwise or
counterclockwise. This should be done before
the food is placed in the refrigerator.
• When you operate your refrigerator for the first
time, please observe the following instructions
during the initial six hours.
- Temperature adjustment button should not
be turned off.
- The door should not be opened frequently.
- It must be operated empty without any food
in it.
- Do not unplug your refrigerator; if a power
failure occurs out of your control, please see the
warnings in section “Things to be done before
calling the authorized service”.
• Original packaging and foam materials should
be kept for future transportations or moving.

EN6
Dimensions of your refrigerator
Usage area measures
Following figure shows the required place to
allow you use your refrigerator most efficiently.
Adjusting the legs
If your refrigerator is unbalanced;
1. You can balance your refrigerator by turning
the front legs of it as illustrated in the figure. The
corner where the leg exists is lowered when you
turn in the direction of black arrow and raised
when you turn in the opposite direction. Taking
help from someone to slightly lift the refrigerator
will facilitate this process.
74.5 cm
84 cm
143.5 cm
134 cm
Changing the door opening
direction
Opening direction of your refrigerator’s door can
not be changed.

EN7
Operating your refrigerator
Before you start using the fridge/freezer check
the following:
1. Have the feet been adjusted so that the
product stands level?
2. Is the interior of the refrigerator dry and can
the air circulate freely in the rear of it?
3. Clean the interior of the refrigerator as
recommended in the “Cleaning your refrigerator”
section.
4. Plug the refrigerator into the wall outlet.
• When the door is open the respective interior
light will come on.
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed within the
refrigeration system may also give rise to noise,
even if the compressor is not running and this is
quite normal.
Due to the operation of fans inside the
appliance, overall noise level is slightly
higher in comparison to non-frost free
appliances. This is quite normal and is not a
fault.
6. Front edges of the refrigerator may feel warm.
This is normal. These areas are designed to be
warm to avoid condensation.
7. Do not fill the interiors of the refrigerator in
initial operation for the first 12 hours.
8. When the compartments reach the desired
temperatures fans will stop.
9. Especially pay special attention to prevent the
foodstuffs, in particular, small pieces, such as
rice, peas and beans from running into the fan
protectors and air flow ducts. These may cause
clogging of the cooling system and a decrease in
the efficiency of the device.
10. The factory set temperature is 4°C in average
for fridge compartment and -18°C maximum for
freezer compartment.
11. The compressor will start running
approximately 8 minutes after the refrigerator
is plugged in to protect the electronic
components of your appliance. After startup of
the compressor, compartment temperatures will
reach to the setup temperatures in 24 hours
depending on the ambient temperature and load
status of your refrigerator.
12. Pay attention to the following points during
the first 24 hours of the operation:
• Do not open the doors frequently.
• Do not overload your refrigerator.
• Do not put hot food.

EN8
Using your refrigerator
4
Temperature setting buttons and temperature control
Control buttons allow you to make the settings of your refrigerator easily and without opening the
doors. Thus, heat loss is avoided.
Freezer Set Button
Eco Extra /Sleep
Function Button
Fresh Freeze Button Quick Cool Button
Vacation Button / Key Lock
Fridge Set Button
Economy Mode Indicator
Freezer Compartment
Temperature Setting Indicator
Freezer Compartment
Temperature indicator
Fresh Freeze Function
Indicator
Eco Extra Indicator
Freezer
Compartment
Indicator
Sleep
Function
Indicator
Ionizer Indicator
Light
Fridge
Compartment
Indicator Quick Cool
Function
Indicator
Fridge Compartment
Temperature Indicator
Vacation Indicator
Fridge Compartment Temperature
Setting Indicator
Key Lock Indicator
High Temperature/ Error Warning Indicator

EN9
Fresh Freeze Function
Fresh Freeze indicator segments will flash when
the Fresh Freeze function is active. To cancel
this function, press the Fresh Freeze button
again. Fresh Freeze indicator will turn off and
return to its normal settings. Fresh Freeze will
cancel itself automatically after about 12 hours if
you do not cancel it.
If you want to freeze large amounts of fresh food,
press the fresh freeze button 24 hours before
putting the food into the freezer compartment.
Quick Cool Function
When you press the Quick Cool button, the
temperature of the compartment will be colder
than the adjusted values. This function can be
used for food placed in the fridge compartment
and required to be cooled down rapidly.
After activating the Quick Cool function by
pressing the Quick Cool button, Quick Cool
indicator will glow. Quick Cool indicator segments
will flash. To cancel this function press Quick
Cool button again. Quick Cool indicator will turn
off and return to its normal settings. Quick Cool
function will cancel itself automatically within 2
hours in case you do not cancel it.
Vacation Function
In case the fridge compartment will not be
used for a long time, the usage of the fridge
compartment may be cancelled by pressing on
the Vacation Button. By this way, the refrigerator
may operate more economically. Press on
Vacation Button to activate this function. Vacation
indicator lights up, “-” is displayed in the Fridge
Compartment indicator and Fridge Compartment
temperature indicators and Fridge Compartment
indicator go out. This function is cancelled
when any button is pressed. Empty the fridge
compartment before switching your refrigerator
to vacation status. Fridge compartment door
must be kept closed in this status.
Eco-Extra Function (Special
Economy function)
When Eco Extra button is pressed, Eco Extra
function is activated and Eco Extra indicator light
comes on. If the door of the fridge compartment
is kept closed for a long time when this function
is selected, the fridge compartment will switch
to a more economic operation mode to safe
electricity automatically. When the Eco Extra
button is pressed again and the Fresh Freeze
button is pressed, this function is deactivated.
Key Lock Button
The key lock is activated and a short “beep”
signal is heard when this button is pressed for 5
seconds. All buttons are deactivated. If you want
to deactivate key lock press the button again for
5 seconds.
Sleep Function
Sleep function is activated and a short “beep”
signal is heard when the Eco Extra button is
pressed for 3 seconds. Sleep Function indicator
comes on as well. Your refrigerator operates in
silent mode maximum for 45 minutes when this
function is active. Press the Eco Extra button
again for 3 seconds to cancel this function.
Ionizer Indicator Light
Ionizer indicator light lights up continuously. This
light indicates that your refrigerator is protected
against the bacteria.
High Temperature/ Error Warning
Indicator Light
This light comes on during long lasting power
failures, high temperature failures and error
warnings.

EN10
Economy Function Indicator Light
This indicator light comes on when the freezer
compartment is set to -18°C or the special
economy function is activated.
Freezer Compartment Temperature
Setting Indicator
Indicates the temperature set for the Freezer
Compartment.
Fridge Compartment Temperature
Setting Indicator
Indicates the temperature set for the Fridge
Compartment.
Freezer Compartment Temperature
Indicator
Indicates the temperature in the Freezer
Compartment.
Fridge Compartment Temperature
Indicators
Indicates the temperature in the Fridge
Compartment.

EN11
Operating your refrigerator
The factory setup temperature during the first
operation is 4 °C for fridge compartment and -18
°C for freezer compartment.
Your refrigerator’s compressor will start running
approximately 1 minutes after the refrigerator
is plugged in for the first time. After startup of
the compressor, compartment temperatures will
reach to the setup temperatures in 24 hours
depending on the ambient temperature and load
status of your refrigerator.
When your refrigerator is in this mode, pay
attention to the following points during the first
12 hours, or 24 hours depending on the ambient
temperature.
Full protection triangle:
Hygiene: Odor filter in the air duct of the fridge
compartment helps to clean the air in the
refrigerator. This filter reduces the formation of
bad odors by means of its coating.
Silver:Inner surfaces of the refrigerator are
rendered antibacterial by means of the silver-
ion additive. Thus, growth and reproduction of
bacteria on interior body parts are prevented.
Ion: Air is ionized by means of the ionizer system
in the fridge compartment air duct. Thanks to
this system, air-borne bacteria and particles that
cause odor are removed.
Dual cooling system:
Your refrigerator is equipped with two separate
cooling system to cool the fresh food compartment
and freezer compartment. Thus, air in the fresh
food compartment and freezer compartment do
not get mixed. Thanks to these two separate
cooling systems, cooling speed is much
higher then other refrigerators. Odors in the
compartments do not get mixed. Also additional
power saving is provided since the defrosting is
performed individually.
Setting the fridge compartment
temperature
Fridge compartment temperature can be set at
one of the following temperatures:
8, 7, 6, 5, 4, 3 and 2°C. Press the button to
change. The temperature will decrease by 1°C.
Every time you press the button, the temperature
will go down and then return to the highest setting.
Release at the desired temperature and the new
set temperature will be stored.
If you think that your food is colder than you
desired, you can adjust the temperature setting of
fridge compartment to 7 or 8.
Setting the freezer compartment
temperature
Freezer temperature can be set at one of the
following temperatures : -18, -19, -20, -21, -22,
-23 and -24°C. Press the button to change. The
temperature will decrease by 1°C. Every time you
press the button, the temperature will go down and
then return to the highest setting. Release at the
desired temperature and the new set temperature
will be stored.
Freezer Compartment
Adjustment
Fridge
Compartment
Adjustment
Explanations
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the ambient
temperature exceeds 30°C.
Fresh Freeze indicator
flashes 4°C
Use when you wish to freeze your food in a short
time. Your refrigerator will return to its previous mode
when the process is over.
-18°C or colder 2°C
If you think that your fridge compartment is not cold
enough because of the hot conditions or frequent
opening and closing of the door.
-18°C or colder Quick Cool
indicator flashes
You can use it when your fridge compartment is
overloaded or if you wish to cool down your food
rapidly.

EN12
Using the accessories
Humidity control in the crisper
Humidity level can be adjusted by sliding the
humidity adjustment slider to the right or left.
• If you want to maintain humidity in this
compartment, set the humidity adjustment slider
to the closed position. (Right)
• If you want to eliminate humidity in this
compartment, set the humidity adjustment slider
to the open position. (Left)
Blue light
Foodstuff stored in the crispers that are
enlightened with a blue light continue their
photosynthesis by means of the wavelength
effect of blue light and thus, preserve their
freshness and increase their vitamin content.
Sliding shelves
Sliding shelves can be pulled out a little bit in
order to easily reach the food placed at the rear
of the shelf in the fridge compartment and also
for easier cleaning. Sliding shelves must be lifted
up slightly before pulling forwards.


Adjustable bottle holder
You can use the adjustable bottle holders without
sacrificing any place by sliding them to left or
right or by interlacing them.
Installing the adjustable bottle
holders
You mast install the holders into the channels
in the following order in order to use them
appropriately.
-Bottle holder to remain at the left side to the
front channel in the rail.
-Bottle holder to remain in the middle to the
middle channel in the rail.
-Bottle holder to remain at the rear side to the
rear channel in the rail.
Verify the position of the horizontal wires during
installation.

EN13
Fresh Freeze compartment
This compartment freezes your food quickly and
preserves their tastes and nutritional values.
This is activated by pressing the relevant button
on the indicator panel. This compartment can be
removed without using any tools when desired.
Ionizer
It is in the air channel of refrigerator back side
of the crisper. With ionizing the air, airborne
bacteria and the bad smell originated from these
bacteria will be reduced.
Egg holder
You can install the egg holder to the desired door
or body shelf except the freezer compartment.
Icematic and ice storage container
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating to
take ice.
Turn the knobs on it clockwise by 90
degrees.
Ice cubes in the cells will fall down into
the ice storage container below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice cubes
in the ice storage container.
Ice storage container
Ice storage container is only intended for
accumulating the ice cubes. Do not put
water in it. Otherwise, it will break.

EN14
Select and Cool compartment
This compartment allows you to store the food at
+4, +1, -1, -7 °C for the indicated times according
to the type of the food and preserve their tastes
and nutritional values.
Select and Cool compartment
Chiller compartment
-7 °C: Meat and fish products can be
stored 3 times longer then the 0 °C
compartment. Also, the meat stored in
this compartment can be taken out and
sliced easily.
-1 °C: Meat, fish and delicatessen
products can be stored 3 times longer
then the fridge compartment.
+1 °C: Delicatessen products can be
stored 2-3 times longer then the fridge
compartment.
+4 °C: Beverages can be stored at the
same temperature as in the bottle shelf
on the door. Provides an additional
storage area for the beverages.
“Select Button” allow you to select the
desired position.
This compartment can be disabled without
using any tools or can be converted into a tray
by sliding the cover under the compartment as
desired.
Crisper / Chiller Compartment
• The drawer under the fridge compartment
can be adjusted as a crisper or a chiller
compartment.
• The chiller compartment will keep the current
temperature under the temperature level of the
fridge compartment and thus, meat or fish can be
kept fresh for a long time.
Water Spring
In addition to allowing you to obtain cold water
without opening the door of your refrigerator, this
accessory also helps you to save energy since
you do not need to open and close the door of
your refrigerator frequently and thus, the cold air
is kept inside.
Using the water spring
Press in the latch of the water spring with your
glass. Water spring will open and water will pour
into your glass. Latch of the water spring will
return to its original position and water flow will
stop when you take your glass.
0 °C Compartment
In this compartment, delicatessen products can
be stored in a reliable manner for 2-3 times
longer then the fridge compartment.

EN15
Filling in the water reservoir
Open the lid of the water reservoir located inside
of the door as illustrated and fill in with water at
room temperature or colder using a carafe. Close
the lid.
You can remove the water reservoir to fill it
outside the refrigerator and also to clean it.
You can easily carry the water reservoir by its
handle.
Warning!
Water spring is only intended for use with
drinking water. Do not put hot water, juice,
milk and gaseous or alcoholic beverages into
the water reservoir.
If there is a power failure (water can not be
obtained from the water dispenser if your
refrigerator is not energized.)
Dripping Crenel
Water drops that drip while using your water
spring accumulates in the dripping crenel at
the lower side. Remove the dripping crenel to
remove the accumulated water. You can remove
the water with a sponge or a soft cloth.
Cleaning the water reservoir
Take out the water reservoir after removing
the cover mechanism on the left hand side as
illustrated in the figure. Clean the water reservoir
with warm water, replace it and close the cover
on the left hand side.
Make sure that the cover on the right hand side
fits into the water inlet hole after installing the
water reservoir. Otherwise, water leakage may
occur.
(Washing in the dishwasher may cause the water
reservoir to get scratched.)

EN16
Freezing fresh food
• It must be preferred to wrap or cover the
food before placing them in the refrigerator.
• Hot food must cool down to the room
temperature before putting them in the
refrigerator.
• The foodstuff that you want to freeze must
be fresh and in good quality.
• Foodstuff must be divided into portions
according to the family’s daily or meal based
consumption needs.
• Foodstuff must be packaged in an airtight
manner to prevent them from drying even if they
are going to be kept for a short time.
• Materials to be used for packaging must be
tear-proof and resistant to cold, humidity, odor,
oils and acids and they must also be airtight.
Moreover, they must be well closed and they
must be made from easy-to-use materials that
are suitable for deep freeze usage.
• Food to be frozen must be put in the freezer
compartment. (They should not be allowed
to come in contact with the previously frozen
items to prevent their partial thawing. Freezing
capacity of our product is given in the technical
specifications of your refrigerator.)
• Periods given in the information about deep
freeze must be obeyed for storage times.
• Frozen food must be used immediately after
they are thawed and they should never be re-
frozen.
• Please observe the following instructions to
obtain the best results.
1. Do not freeze too large quantities of food
at one time. The quality of the food is best
preserved when it is frozen right through to the
core as quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling system to
operate continuously until the food is frozen
solid.
3. Take special care not to mix already frozen
food and fresh food.
Recommendations for
preservation of frozen food
• Prepacked commercially frozen food should
be stored in accordance with the frozen food
manufacturer’s instructions for a ( 4
stars) frozen food storage compartment.
• To ensure that the high quality achieved
by the frozen food manufacturer and the food
retailer is maintained, the following should be
remembered:
1. Put packages in the freezer as quickly as
possible after purchase.
2. Ensure that contents are labeled and dated.
3. Do not exceed “Use By”, “Best Before” dates
on the packaging.
If there is a power failure do not open the freezer
door. Even if the power failure lasts up to the
“Temperature Increasing Time” indicated in the
“Technical specifications of your refrigerator”
section, frozen food will not be affected. In case
the failure lasts longer, the food must be checked
and when necessary, must be consumed
immediately or must be frozen after cooked.
Defrosting
The fridge and freezer compartments defrost
automatically.

EN17
Placing the food
Freezer
compartment
shelves
Various frozen
food such as meat,
fish, ice cream,
vegetables and etc.
Egg holder Egg
Fridge compartment
shelves
Food in pans, plates,
closed containers
Fridge compartment
door shelves
Small and packaged
food or drinks (such
as milk, fruit juice
and beer)
Crisper Vegetables and
fruits
Chiller compartment Meat and fish to be
thawed
Replacing the interior light
module
To change the light module of your refrigerator,
please call your Authorized Service.
Things to be done for saving
energy
1. Do not leave the doors of your refrigerator
open for a long time.
2. Do not put hot food or drinks in your
refrigerator.
3. Do not overload your refrigerator so that the
air circulation inside of it is not prevented.
4. Do not install your refrigerator under direct
sunlight or near heat emitting appliances such as
ovens, dishwashers or radiators.
5. Pay attention to keep your food in closed
containers.

EN18
Deep-freeze information
5
Food must be frozen as rapidly as possible when
they are put in a refrigerator in order to keep
them in good quality.
The TSE norm requires (according to certain
measurement conditions) the refrigerator to
freeze at least 4.5 kg of foodstuff at 32°C
ambient temperature to -18°C or lower within 24
hours for every 100-liters of freezer volume.
It is possible to keep the food for a long time
only at -18°C or lower temperatures.
You can keep the freshness of food for many
months (at -18°C or lower temperatures in the
deep freeze).
WARNING! A
• Foodstuff must be divided into portions
according to the family’s daily or meal
based consumption needs.
• Foodstuff must be packaged in an airtight
manner to prevent them from drying even if they
are going to be kept for a short time.
Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging the foodstuff
must be tear-proof and resistant to cold,
humidity, odor, oils and acids.
Foodstuff to be frozen should not be allowed to
come in contact with the previously frozen items
to prevent their partial thawing.
You can check the freezing capacity of your
refrigerator from “Technical Specifications”
section in Part 1.
Always follow the values in the tables for storage
periods.
Frozen food must be used immediately after
they are thawed and they should never be
re-frozen.

EN19
Cleaning your
refrigerator
6
Warning!!!
Never use gasoline, benzene or similar
substances for cleaning purposes.
We recommend that you unplug the appliance
before cleaning.
• Never use any sharp abrasive instrument,
soap, household cleaner, detergent and wax
polish for cleaning.
• Use lukewarm water to clean the cabinet of
your refrigerator and wipe it dry.
• Use a damp cloth wrung out in a solution of
one teaspoon of bicarbonate of soda to one pint
of water to clean the interior and wipe it dry.
• Make sure that no water enters the lamp
housing and other electrical items.
• If your refrigerator is not going to be used for
a long period of time, unplug the power cable,
remove all food, clean it and leave the door ajar.
• Vacuum-clean the dusts on your refrigerator
once a year.
• Check door seals regularly to ensure they
are clean and free from food particles.
• To remove door racks, remove all the
contents and then simply push the door rack
upwards from the base.
• To remove a freezer drawer, pull it as far as
possible, and then tilt it upwards, and then pull it
out completely.
• Especially pay special attention to prevent
the foodstuffs, in particular, small pieces, such as
rice, peas and beans from running into the fan
protectors and air flow ducts. These may cause
clogging of the cooling system and a decrease in
the efficiency of the refrigerator.
Protection of plastic surfaces
Do not put the liquid oils or oil-cooked meals in
your refrigerator in unsealed containers as they
damage the plastic surfaces of your refrigerator.
In case of spilling or smearing oil on the plastic
surfaces, clean and rinse the relevant part of the
surface at once with warm water.
Service
7
Important note: Protective
thermic of the compressor will
blow out during sudden power
failures or plug-out plug-ins as
the refrigerant pressure in the
cooling system of the refrigerator
has not been balanced yet. Your
refrigerator will start running
approximately after 6 minutes.
Please call the service if your
refrigerator does not startup at
the end of this period.
Things to be done before calling the
authorized service
Please check the following points before
calling the service.
1. Is the refrigerator properly
plugged in?
2. Is the fuse of the socket which
your refrigerator is connected to or
the main fuse blown out?
3. Are the temperature adjustments
correctly made?
