Beko RCSA340K20W User manual

RCSA340K20W
Refrigerator - Freezer
Chłodziarko - Zamrażarki
Hladilno - Zamrzovalni
Chladnička - Mraznička
Chladnička - Mraznička

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep it as
a reference. If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.

1 Your refrigerator 4
2 Important Safety Warnings 5
5
Intended use.........................................
General safety.......................................
For products with a water dispenser......
Child safety............................................
Compliance with the AEEE Regulation
and Disposing of the Waste Product…..
Package information..............................
HCA warning..........................................
Things to be done for energy saving…..
3 Installation 9
Points to be paid attention to when the
relocation of the refrigerator....................
Before you start the refrigerator,............
Electrical connection............................
Disposing of the packaging..................
Disposing of your old refrigerator.........
Placing and Installation........................
Changing the illumination lamp ............
Adjusting the legs................................
CONTENTS
4 Preparation 12
5 Using your refrigerator 13
Thermostat setting button...................
Defrost………………...........................
Freezing fresh food............................
Recommendations for preservation of
frozen food.........................................
Recommendations for the fresh food
compartment......................................
Reversing the doors..........................
6 Maintenance and cleaning 1
Avoiding bad odours………………….
Protection of plastic surfaces ..............
7 Troubleshooting 20
2
3
4
4
4
6
6
6
7
7
7
8
8
8
9
9
9
9
9
9
11
12
12
13
14
15
15
16
17
17
17
18

Your refrigerator
1
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
3
Optional
1. Setting knob and interior light
2. Adjustable Cabinet shelves
3. Cover glass
4. Salad crispers
5. Ice tray support & ice tray
6. Compartment for quickly freezing
7. Compartments for frozen foods keeping
8. Adjustable front feet
9. Shelf for jars
10. Shelf for bottles
11*. Freezer fan

Important Safety Warnings
2
Please review the following information.
Failure to observe this information may
cause injuries or material damage.
Otherwise, all warranty and reliability
commitments will become invalid.
The service life of your product is 10
years. During this period, original spare
parts will be available to operate the
product properly.
Intended use
This product is intended to be used
indoors and in closed areas such as
homes;
in closed working environments such
as stores and offices;
in closed accommodation areas such
as farm houses, hotels, pensions.
It should not be used outdoors.
General safety
When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment. Otherwise, these may
burst.
Do not touch frozen food by hand;
they may stick to your hand.
Unplug your refrigerator before
cleaning or defrosting.
Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
Never use the parts on your
refrigerator such as the door as a
means of support or step.
Do not use electrical devices inside
the refrigerator.
Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
Do not cover or block the ventilation
holes on your refrigerator with any
material.
Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
4

In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
Do not pull by the cable when pulling
off the plug.
Place the beverage with higher proofs
tightly closed and vertically.
Never store spray cans containing
flammable and explosive substances
in the refrigerator.
Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of the
product.
Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
Contact authorized service when
there is a power cable damage to
avoid danger.
Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
Label of technical specifications is
located on the left wall inside the
refrigerator.
Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
This operation manual should be
handed in to the new owner of the
product when it is given to others.
Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may cause
fire. Never place heavy objects on
power cable.
Do not touch the plug with wet hands
when plugging the product.
Do not plug the refrigerator if the wall
outlet is loose.
Water should not be sprayed on
inner or outer parts of the product for
safety purposes.
5

6
Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
Never place containers filled with
water on top of the refrigerator; in the
event of spillages, this may cause
electric shock or fire.
Do not overload the refrigerator with
food. If overloaded, the food items
may fall down and hurt you and
damage refrigerator when you open
the door.
Never place objects on top of the
refrigerator; otherwise, these objects
may fall down when you open or
close the refrigerator's door.
As they require a precise
temperature, vaccines, heat-sensitive
medicine and scientific materials
and etc. should not be kept in the
refrigerator.
If not to be used for a long time,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.
The plug's tip should be cleaned
regularly with a dry cloth; otherwise, it
may cause fire.
Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
When carrying the refrigerator, do not
hold it from door handle. Otherwise, it
may be snapped.
When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
Use only potable water.
Child safety
If the door has a lock, the key should
be kept away from reach of children.
Children must be supervised to
prevent them from tampering with the
product.
Compliance with the AEEE
Regulation and Disposing of the
Waste Product
The symbol on the product or on
packaging indicates that this product may
not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, you
household waste disposal service or the
shop where you purchased the product.

7
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and our
national asset wealth.
If you want to contribute to the
reevaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities
where you are located.
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
Saving
Do not leave the doors of your
refrigerator open for a long time.
Do not put hot food or drinks in your
refrigerator.
Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
Pay attention to keep your food in
closed containers.
You can load maximum amount of food
to the freezer compartment of the
refrigerator by removing the freezer
compartment drawers. Declared
energy consumption value of the
refrigerator was determined with the
freezer compartment drawers
removed. There is no risk in using a
shelf or drawer suitable for the shapes
and sizes of the foods to be frozen.
Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
The ambient temperature of the room
where you install the refrigerator should
at least be -15°C. Operating your
refrigerator under colder conditions
than this is not recommended.
Inside of your refrigerator must be
cleaned thoroughly.

8
Installation
3
In case the information which are
given in the user manual are not
taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes
and the transportation rules on the
package should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
refrigerator,
Check the following before you start
to use your refrigerator:
1. Attach 2 plastic wedges as illustrated
below. Plastic wedges are intended
to keep the distance which will ensure
the air circulation between your
refrigerator and the wall. (The picture
is drawn up as a representation and it
is not identical with your product.)
2. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3. Connect the plug of the refrigerator
to the wall socket. When the fridge
door is opened, fridge internal lamp
will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is
not running and this is quite normal.
5. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.

9
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
The power plug must be easily
accessible after installation.
Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
Extension cables and multi plugs
must not be used for connection.
A damaged power cable must be
replaced by a qualified electrician.
Product must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
Refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
If the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the doors
of your refrigerator and pass it sideways
through the door.
1. Install your refrigerator to a place that
allows ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator
in order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.

10
Changing the illumination
Lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
Authorized Service.
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction
of black arrow and raised when you
turn in the opposite direction. Taking
help from someone to slightly lift the
refrigerator will facilitate this process.

11
Preparation
4
Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
The door should not be opened
frequently.
It must be operated empty without
any food in it.
Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
This product has been designed to
function at ambient temperatures
up to 43 °C (110 °F).

Using your refrigerator
5
12
Thermostat setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long periods,
• Food put into the refrigerator without
cooling down to the room temperature,
• The location of the refrigerator in the
room (e.g. exposing to sunlight).
• You may adjust the varying interior
temperature due to such reasons by
using the thermostat.
Operating temperatures are controlled by
the thermostat knob and may be set at
any position between 0 and 5 (the
coldest position).
The average temperature inside the
fridge should be around +5°C (+41°F).
Therefore adjust the thermostat to obtain
the desired temperature. Some sections
of the fridge may be cooler or warmer
(such as salad crisper and top part of the
cabinet) which is quite normal. We
recommend that you check the
temperature periodically with a
thermometer to ensure that the cabinet is
kept to this temperature. Frequent door
openings cause internal temperatures to
rise, so it is advisable to close the door
as soon as possible after use.

13
Defrost
A) Fridge compartment
Fridge compartment performs full-
automatic defrosting. Water drops and a
frosting up to 7-8 mm can occur on the
inner rear wall of the fridge compartment
while your refrigerator cools down. Such
formation is normal as a result of the
cooling system. The frost formation
is defrosted by performing automatic
defrosting with certain intervals thanks to
the automatic defrosting system of the
rear wall. User is not required to scrape
the frost or remove the water drops
Water resulting from the defrosting
passes from the water collection groove
and flows into the evaporator through the
drain pipe and .evaporates here by itself.
Check regularly to see if the drain pipe is
clogged or not and clear it with the stick
in the hole when necessary
Deep freezer compartment does not
perform automatic defrosting in order to
prevent decaying of the frozen food.
B) Freezer compartment
Defrosting is very straightforward and
without mess, thanks to a special defrost
collection basin.
Defrost twice a year or when a frost layer
of around 7 (1/4”) mm has formed. To
start the defrosting procedure, switch off
the appliance at the socket outlet and
pull out the mains plug.
All food should be wrapped in several
layers of newspaper and stored in a cool
place (e.g.) fridge or larder.
Containers of warm water may be placed
carefully in the freezer to speed up the
defrosting.
Do not use pointed or sharp-edged
objects, such as knives or forks to
remove the frost.
Never use hair dryers, electrical heaters
or other such electrical appliances for
defrosting.
Sponge out the defrost water collected in
the bottom of the freezer compartment.
After defrosting, dry the interior
thoroughly Insert the plug into the wall
socket and switch on the electricity
supply.

14
• Hot food and beverages must cool
down to the room temperature before
puttıng them in the refrigerator.
• Maximum frozen food storage volume
is achieved without using the drawers
and the upper shelf cover provided in the
freezer compartment .Energy
consumption of your appliance is
declared while the freezer compartment
is fully loaded on shelves without the use
of the drawers and upper shelf cover.
•If there is a power failure do not open
the freezer door. Even if the power
failure lasts up to the “Temperature
Increasing Time” indicated in the
“Technical specifications of your
refrigerator” section, frozen food will not
be affected. In case the failure lasts
longer, the food must be checked and
when necessary, must be consumed
immediately or must be frozen after
cooked.
• Please pay attention to the expiry date,
maximum allowed storage period and
recommended storage temperature of
fodstuffs when purchased. If expiry date
is passed, do not consume.
Freezing fresh food
• It must be preferred to wrap or cover
the food before placing them in the
refrigerator.
• Hot food must cool down to the room
temperature before putting them in
the refrigerator.
• The foodstuff that you want to freeze
must be fresh and in good quality.
• Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
• The foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be
kept for a short time.
• Materials to be used for packaging
must be tear-proof and resistant to
cold, humidity, odor, oils and acids
and they must also be airtight.
Moreover, they must be well closed
and they must be made from easyto-
use materials that are suitable for
deep freeze usage.
• Frozen food must be used
immediately after they are thawed and
they should never be re-frozen.
• Please observe the following
instructions to obtain the best results.
1. Do not freeze too large quantities
of food at one time. The quality of
the food is best preserved when it
is frozen right through to the core as
quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling
system to operate continuously until
the food is frozen solid.
3. Take special care not to mix already
frozen food and fresh food.

15
Recommendations for the
fresh food compartment
*optional
Do not allow the food to touch the
temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be
hindered by food.
Do not place hot foods in the product.
Recommendations for
preservation of frozen food
Prepacked commercially frozen food
should be stored in accordance
with the frozen food manufacturer's
instructions for a ( 4 star)
frozen food storage compartment.
• To ensure that the high quality
achieved by the frozen food
manufacturer and the food retailer is
maintained, the following should be
remembered:
1. Put packages in the freezer as quickly
as possible after purchase.
2. Ensure that contents are labeled and
dated.
3. Do not exceed "Use By", "Best
Before" dates on the packaging.

Reversing the doors
Proceed in numerical order
16

17
Maintenance and cleaning
6
Avoiding bad odours
Materials that may cause odour are not
used in the production of our
refrigerators.
However, due to inappropriate food
preserving conditions and not cleaning
the inner surface of the refrigerator as
required can bring forth the problem of
odour. Pay attention to following to avoid
this problem:
• Keeping the refrigerator clean is
important.
Food residuals, stains, etc. can cause
odour. Therefore, clean the refrigerator
with carbonate dissolved in water every
15 days. Never use detergents or soap.
• Keep the food in closed containers.
Microorganisms spreading out from
uncovered containers can cause
unpleasant odours.
• Never keep the food that have expired
best before dates and spoiled in the
refrigerator.
Protection of plastic
surfaces
Do not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator.
In case of spilling or smearing oil on
the plastic surfaces, clean and rinse
the relevant part of the surface at
once with warm water.
Never use gasoline, benzene or
similar substances for cleaning
purposes.
We recommend that you unplug the
ppliance before cleaning.
Never use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for
cleaning.
Use lukewarm water to clean the
cabinet of your refrigerator and wipe
it dry.
Use a damp cloth wrung out in a
solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
Make sure that no water enters the
lamp housing and other electrical
items.
If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
Check door seals regularly to ensure
they are clean and free from food
particles.
To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
Never use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.

18
Troubleshooting
7
The refrigerator does not operate.
• The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
• The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
• Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10 °C.
• Door has been opened frequently. >>>Do not open and close the door of
refrigerator frequently.
• Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
• Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
• Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
• Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running
• Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
• The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit
into the socket.
• Temperature settings are not made correctly. >>>Select the suitable temperature
value.
• There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
The operation noise increases when the refrigerator is running.
• The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.
Please review this list before calling the service. It will save your time and money. This
list includes frequent complaints that are not arising from defective workmanship or
material usage. Some of the features described here may not exist in your product.
