Beko RDNE455E30DSN User manual

RDNE455E30DSN
EN/İT
58 4745 0000/AA-EN-İT
Refrigerator
User Manual
Frigorifero
Manuale utente

Please read ths user manual frst!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual wll help you use the product n a fast and safe way.
•Read the manual before nstallng and operatng the product.
•Make sure you read the safety nstructons.
•Keep the manual n an easly accessble place as you may need t later.
•Read the other documents gven wth the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanaton of symbols
Throughout this user manual the following symbols are used:
CImportant nformaton or
useful hnts.
ARsk of njury and damage to
the property.
BRsk of electrc shock.
Packagng materals of
the product are manufac-
tured from recyclable ma-
terals n accordance wth
our Natonal Envronment
Regulatons.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

2 /39 EN Refrigerator / User Manual
1. Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with the WEEE Directive
and Disposing of the Waste
Product: . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5. Compliance with RoHS Directive 6
1.6. Package information . . . . . . . . . . . . 6
2Your appliance 7
3Installation 8
3.1. Appropriate installation location8
3.2. Installing the plastic wedges. . . . 8
3.3. Adjusting the feet . . . . . . . . . . . . . . . 9
3.4. Electrical connection . . . . . . . . . . . . 9
3.5. Reversing the doors . . . . . . . . . . . .10
3.6. Reversing the doors . . . . . . . . . . . . 11
4 Preparation 12
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 12
5Operating the product 13
5.1. Temperature setting button . . . 13
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 13
5.3. Vacation function . . . . . . . . . . . . . . 14
5.4. Indicator panel. . . . . . . . . . . . . . . . . . 15
5.5. Indicator panel. . . . . . . . . . . . . . . . . .18
5.6. Twist Ice – matic . . . . . . . . . . . . . . .23
5.7. Ice container. . . . . . . . . . . . . . . . . . . .24
5.8. Egg holder . . . . . . . . . . . . . . . . . . . . . .24
5.9. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
5.10. Crisper. . . . . . . . . . . . . . . . . . . . . . . . . .24
5.11.Chiller compartment. . . . . . . . . . . .24
5.12.Moving door shelf . . . . . . . . . . . . . .25
5.13.Sliding storage container . . . . . .25
5.14.Humidity controlled crisper . . . .26
5.15.Auto Icematic . . . . . . . . . . . . . . . . . .26
5.16.Description and cleaning of odor
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.17.HerbBox/HerbFresh. . . . . . . . . . . .27
5.18.Using the water dispenser. . . . .28
5.19.Using the water dispenser . . . . .28
5.20.Filling the water dispenser's tank29
5.21. Cleaning the water tank . . . . . . .30
5.22.Drip tray . . . . . . . . . . . . . . . . . . . . . . . . 31
5.23.Blue light/HarvestFresh . . . . . . . 31
5.24.Freezing fresh food . . . . . . . . . . . .32
5.25.Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .33
5.26.Deep-freeze information . . . . . .33
5.27.Placing the food . . . . . . . . . . . . . . . .33
5.28.Door open warning . . . . . . . . . . . .34
5.29.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .34
5.30.Illumination lamp. . . . . . . . . . . . . . .34
6Maintenance and cleaning 35
6.1. Avoiding bad odors . . . . . . . . . . . . .35
6.2. Protecting the plastic surfaces 35
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .35
6Maintenance and cleaning36
7. Troubleshooting 37
Contents

3/39 EN
Refrigerator / User Manual
Ths secton provdes the safety
nstructons necessary to prevent
the rsk of njury and materal
damage. Falure to observe these
nstructons wll nvaldate all types
of product warranty.
Intended use
A
WARNING:
Keep ventlaton
openngs, n the applance
enclosure or n the bult-
nstructure, clear of
obstructon.
A
WARNING:
Do not use mechancal
devces or other means
to accelerate the
defrostng process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrgerant crcut.
A
WARNING:
Do not use electrcal
applances nsde
the food storage
compartments of
the applance, unless
they are of the type
recommended by the
manufacturer.
Ths applance s ntended to be
used n household and smlar
applcatons such as
– staff ktchen areas n shops,
offces and other workng
envronments;
– farm houses and by clents
n hotels, motels and other
resdental type envronments;
– bed and breakfast type
envronments;
– caterng and smlar non-retal
applcatons.
1.1.General safety
• Ths product should not be
used by persons wth physcal,
sensory and mental dsabltes,
wthout suffcent knowledge
and experence or by chldren.
The devce can only be used by
such persons under supervson
and nstructon of a person
responsble for ther safety.
Chldren should not be allowed
to play wth ths devce.
• In case of malfuncton, unplug
the devce.
• After unpluggng, wat at least
5 mnutes before pluggng n
agan.
• Unplug the product when not
n use.
• Do not touch the plug wth wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Do not plug n the refrgerator f
the socket s loose.
• Unplug the product durng
nstallaton, mantenance,
cleanng and repar.
• If the product wll not be used
for a whle, unplug the product
and remove any food nsde.
• Do not use the product when
the compartment wth crcut
cards located on the upper back
part of the product (electrcal
card box cover) (1) s open.
1. Safety and envronment nstructons

Instructions for safety and environment
4 / 39 EN Refrigerator / User Manual
1
1
• Do not use steam or steamed
cleanng materals for
cleanng the refrgerator and
meltng the ce nsde. Steam
may contact the electrfed
areas and cause short crcut
or electrc shock!
• Do not wash the product by
sprayng or pourng water on
t! Danger of electrc shock!
• In case of malfuncton, do
not use the product, as t may
cause electrc shock. Contact
the authorsed servce before
dong anythng.
• Plug the product nto an
earthed socket. Earthng
must be done by a qualfed
electrcan.
• If the product has LED
type lghtng, contact the
authorsed servce for
replacng or n case of any
problem.
• Do not touch frozen food wth
wet hands! It may adhere to
your hands!
• Do not place lquds n bottles
and cans nto the freezer
compartment. They may
explode.
• Place lquds n uprght
poston after tghtly closng
the ld.
• Do not spray flammable
substances near the product,
as t may burn or explode.
• Do not keep flammable
materals and products wth
flammable gas (sprays, etc.)
n the refrgerator.
• Do not place contaners
holdng lquds on top of the
product. Splashng water on
an electrfed part may cause
electrc shock and rsk of fre.
• Exposng the product to ran,
snow, sunlght and wnd
wll cause electrcal danger.
When relocatng the product,
do not pull by holdng the
door handle. The handle may
come off.
• Take care to avod trappng
any part of your hands or
body n any of the movng
parts nsde the product.
• Do not step or lean on the
door, drawers and smlar
parts of the refrgerator. Ths
wll cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.

Instructions for safety and environment
5/39 EN
Refrigerator / User Manual
1.1.1 HC warning
If the product comprses a
coolng system usng R600a
gas, take care to avod
damagng the coolng system
and ts ppe whle usng and
movng the product. Ths gas
s flammable. If the coolng
system s damaged, keep the
product away from sources
of fre and ventlate the room
mmedately.
CThe label on the nner left
sde ndcates the type of
gas used n the product.
1.1.2 For models with
water dispenser
• Pressure for cold water nlet
shall be maxmum 90 ps (6.2
bar). If your water pressure
exceeds 80 ps (5.5 bar), use
a pressure lmtng valve n
your mans system. If you
do not know how to check
your water pressure, ask for
the help of a professonal
plumber.
• If there s rsk of water
hammer effect n your
nstallaton, always
use a water hammer
preventon equpment n
your nstallaton. Consult
Professonal plumbers f you
are not sure that there s no
water hammer effect n your
nstallaton.
• Do not nstall on the hot
water nlet. Take precautons
aganst of the rsk of
freezng of the hoses. Water
temperature operatng
nterval shall be 33°F (0.6°C)
mnmum and 100°F (38°C)
maxmum.
• Use drnkng water only.
1.2.Intended use
• Ths product s desgned for
home use. It s not ntended
for commercal use.
• The product should be used
to store food and beverages
only.
• Do not keep senstve
products requrng controlled
temperatures (vaccnes,
heat senstve medcaton,
medcal supples, etc.) n the
refrgerator.
• The manufacturer assumes
no responsblty for any
damage due to msuse or
mshandlng.
• Orgnal spare parts wll
be provded for 10 years,
followng the product
purchasng date.
1.3.Child safety
• Keep packagng materals
out of chldren’s reach.
• Do not allow the chldren to
play wth the product.
• If the product’s door
comprses a lock, keep the
key out of chldren’s reach.

Instructions for safety and environment
6 / 39 EN Refrigerator / User Manual
1.4. Compliance with
the WEEE Directive
and Disposing of the
Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classifica-
tion symbol for waste electrical and electronic
equipment (WEEE).
This symbol indicates that this prod-
uct shall not be disposed with other
household wastes at the end of its
service life. Used device must be re-
turned to offical collection point for
recycling of electrical and electronic devices. To
find these collection systems please contact to
your local authorities or retailer where the prod-
uct was puchased. Each household performs
important role in recovering and recycling of old
appliance. Appropriate disposal of used appli-
ance helps prevent potential negative conse-
quences for the environment and human
health.
1.5.Compliance with
RoHS Directive
The product you have purchased complies with
EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials speci-
fied in the Directive.
1.6.Package
information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging materials to-
gether with the domestic or other wastes. Take
them to the packaging material collection points
designated by the local authorities.

7/39 EN
Refrigerator / User Manual
1. Frdge - compartment door shelf
2. Temperature settng button
3. Water dspenser fllng tank
4. Egg secton
5. Water dspenser reservor
6. Storage contaner under the door shelf
7. Movng door shelf
8. Adjustable feet
9. Crsper
10. Chller compartment
11. Lock and key
12. Bottle shelf
13. Frdge - compartment glass shelf
14. Fan
15. Freezer compartment shelf
16. Icebox / Ice-makng compartment
17. Freezer compartment
18. Frdge compartment
2Your applance
C*optional:Fgures n ths user manual are gven as an example and may not
match the product exactly. If the relevant parts are not avalable n the product you
purchased, the fgure apples to other models.
*1
*3
*5
*4
*6
*2
*7
8
*9
*10
*11
*12
*13
14
14
17
18
*15
*16
*16
8

8 /39 EN Refrigerator / User Manual
3Installaton
3.1.Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
BWARNING: Manufacturer shall
not be held lable for damages that
may arse from procedures carred
out by unauthorzed persons.
BWARNING: Product must not
be plugged n durng nstallaton.
Otherwse, there s the rsk of
death or serous njury!
A
WARNING: If the door clearance
of the room where the product
shall be place s so tght to prevent
passng of the product, remove
the door of the room and pass
the product through the door by
turnng t to ts sde; f ths does
not work, contact the authorzed
servce.
•Placetheproductonanevenfloor
surface to prevent jolts.
•Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrcal ovens.
•Productmustnotbesubjectedto
drect sun lght and kept n humd
places.
•Appropriateairventilationmustbe
provded around your product n order
to acheve an effcent operaton. If the
product s to be placed n a recess n
the wall, pay attenton to leave at least
5 cm dstance wth the celng and sde
walls.
•Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2.Installing the
plastic wedges
Plastc wedges suppled wth the
product are used to create the dstance
for the ar crculaton between the
product and the rear wall.
1. To nstall the wedges, remove the
screws on the product and use the
screws suppled together wth the
wedges.
2. Insert the 2 plastc wedges onto the
rear ventlaton cover as llustrated n
the fgure.

Installation
9 /39 EN
Refrigerator / User Manual
3.3.Adjusting the feet
If the product stands unbalanced
after nstallaton, adjust the feet on
the front by rotatng them to the rght
or left.
3.4. Electrical
connection
AWARNING:Do not make
connectons va extenson
cables or mult-plugs.
BWARNING: Damaged power
cable must be replaced by the
Authorzed Servce Agent.
CIf two coolers are to be
nstalled sde by sde, there
should be at least 4 cm
dstance between them.
• Our company shall not be lable
for any damages that wll arse
when the product s used
wthout groundng and electrcal
connecton n accordance wth the
natonal regulatons.
• Power cable plug must be wthn
easy reach after nstallaton.
• Do not extenson cords or cordless
multple outlets between your
product and the wall outlet.
C
Hot Surface Warnng!
Sde walls of your product s
equpped wth refrgerant
ppes to mprove the coolng
system. Refrgerant wth
hgh temperatures may flow
through these areas, resultng
n hot surfaces on the sde
walls. Ths s normal and does
not need any servcng. Please
pay attenton whle touchng
these areas.

Installation
10 / 39 EN Refrigerator / User Manual
3.5.Reversing the doors
Proceed in numerical order .
4
1
5
10 11
3
6
78
12
19
18
14
13
21
21
9
45 °
2
17
16
20
15

Installation
11 /39 EN
Refrigerator / User Manual
3.6. Reversing the doors
Proceed in numerical order .
1
5
10 11
3
6
78
19
18
14
13
9
45 °
2
17
16
12
4
15
20

12 /39 EN Refrigerator / User Manual
4.1. Things to be done
for energy saving
AConnectng the product to electrc
energy savng systems s rsky
as t may cause damage on the
product.
• For a freestandng applance; ‘ths
refrgeratng applance s not ntended
to be used as a bult-n applance.
• Do not leave the doors of your
refrgerator open for a long tme.
• Do not put hot food or drnks n your
refrgerator.
• Do not overload the refrgerator,
coolng capacty wll fall when the ar
crculaton nsde s hndered.
• In order to store maxmum amount
of food n the freezer compartment,
the cematc, avalable n the freezer
compartment and easly removable by
hand, shall be taken out. Net volume
and energy consumpton values
declared on the power data plate of
your refrgerator are measured and
tested by removng the cematc. Do
not remove the shelves nsde the
freezer compartment and on the door
of freezer compartment shall not be
removed and they shall always be
used they provde ease of use and
effcency n energy consumpton.
• Arflow should not be blocked by
placng foods on the sdes of the
freezer compartment fan. A mnmum
dstance of 3 cm shall be provded on
the sdes of protectve fan cover.
• The baskets/drawers that are
provded wth the chll compartment
must always be n use for low energy
consumpton and for better storage
condtons.
• Snce hot and humd ar wll not
drectly penetrate nto your product
when the doors are not opened,
your product wll optmze tself n
condtons suffcent to protect your
food. Functons and components such
as compressor, fan, heater, defrost,
lghtng, dsplay and so on wll operate
accordng to the needs to consume
mnmum energy under these
crcumstances.
4Preparaton
• Food contact wth the temperature
sensor n the freezer compartment
may ncrease energy consumpton of
the applance. Thus any contact wth
the sensor(s) must be avoded.
• Dependng on the features of your
product, thawng frozen food n frdge
compartment wll both provde energy
savng and preserve the food qualty.
• Do not allow contact of the food wth
the frdge compartment temperature
sensor shown n the fgure below.
4.2. Initial use
Before startng to use your refrgerator,
ensure that all preparatons are made
n accordance wth the nstructons n
sectons "Instructons for safety and
envronment" and "Installaton".
• Run the product wthout puttng any
food for 6 hours and do not open ts
door unless certanly requred.
CYou wll hear a nose when the
compressor starts up. The lquds
and gases sealed wthn the
refrgeraton system may also
gve rse to nose, even f the
compressor s not runnng and ths
s qute normal.
CFront edges of the product may
feel warm. Ths s normal. These
areas are desgned to be warm to
avod condensaton.
CIn some models, the nstrument
panel automatcally turns off
5 mnutes after the door has
closed. It wll be reactvated
when the door has opened or
pressed on any key.

13/39 EN
Refrigerator / User Manual
5Operating the product
5.1.Temperature
setting button
The interior temperature of your
refrigerator changes for the following
reasons;
•Seasonal temperatures,
•Frequent openng of the door and
leavng the door open for long perods,
•Food put nto the refrgerator
wthout coolng down to the room
temperature,
•The locaton of the refrgerator n the
room (e.g. exposng to sunlght).
•You may adjust the varyng nteror
temperature due to such reasons by
usng the settng button.
•The numbers around the control knob
ndcate the temperature values n “°C”.
•If the ambent temperature s 25°C,
we recommend you to use the
temperature control knob of your
refrgerator at 4°C. Ths value may be
ncreased or decreased as requred n
other ambent temperatures.
5.2.Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.

Operating the product
14 / 39 EN Refrigerator / User Manual
Remember to turn the temperature
control knob back to its previous
position once food has frozen.
5.3.Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
•When the settng operaton s
completed, you may press the
temperature control knob and have
t hdden.

Operating the product
15/39EN
Refrigerator / User Manual
automatically activated and energy
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button
is pressed or the door is opened,
energy saving function will be
canceled and the symbols on display
will return to normal.
Energy saving function is activated
during delivery from factory and
cannot be canceled.
C*Optonal: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
5.4. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1
3
45
6
789
11
2
*10
*12
1. Power falure/Hgh temperature /
error warnng ndcator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
2. Energy savng functon (dsplay
off):
If the product doors are kept closed for
a long time energy saving function is

Operating the product
16 / 39 EN Refrigerator / User Manual
3.Quck frdge functon
The button has two functons. To
actvate or deactvate the quck cool
functon press t brefly. Quck Cool
ndcator wll turn off and the product
wll return to ts normal settngs. (
)
CUse quck coolng functon
when you want to quckly cool
the food placed n the frdge
compartment. If you want to
cool large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
CIf you do not cancel t, quck
coolng wll cancel tself
automatcally after 8 hours or
when the frdge compartment
reaches to the requred
temperature.
CIf you press the quck coolng
button repeatedly wth short
ntervals, the electronc crcut
protecton wll be actvated
and the compressor wll not
start up mmedately.
CThs functon s not recalled
when power restores after a
power falure.
4. Frdge compartment
temperature settng button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warnng:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button ( ) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
() will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).

Operating the product
17/39EN
Refrigerator / User Manual
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature settng button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
CWater flow from water tank
wll stop when ths functon s
selected. However, ce made
prevously can be taken from
the cematc.
11. Quck freeze functon button/
cematc on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
CUse the quck freeze functon
when you want to quckly
freeze the food placed n frdge
compartment. If you want to
freeze large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
CIf you do not cancel t, Quck
Freeze wll cancel tself
automatcally after 4 hours or
when the frdge compartment
reaches to the requred
temperature.
CThs functon s not recalled
when power restores after a
power falure.
12. Economc usage ndcator
Indicates that the product is running
in energy-efficient mode.This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
CEconomc usage ndcator s
turned off when quck coolng
or quck freeze functons are
selected.

Operating the product
18 / 39 EN Refrigerator / User Manual
5.5.Indicator panel
Indcator panels may vary accordng to the product model.
Audo – vsual functons on the ndcator panel helps you n usng your product.
45
76
8
9
123
1. Frdge Compartment Indcator
2. Error status ndcator
3. Temperature ndcator
4. Vacaton functon button
5. Temperature settng button
6. Compartment selecton button
7. Freezer compartment ndcator
8. Economy mode ndcator
9. Vacaton functon ndcator
*optonal
C*Optonal: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.

Operating the product
19/39EN
Refrigerator / User Manual
1. Frdge compartment ndcator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status ndcator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature ndcator
Indicates freezer, fridge compartment
temperature.
4. Vacaton functon button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature settng button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selecton button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment ndcator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode ndcator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacaton functon ndcator
Indicates that vacation is activated.
