Beko RDNE455E30VDZX User manual

RDNE455E30VDZX-RDNE420K20ZW
EN/ES
57 8170 0000/AH- EN-ES
Refrigerator
User Manual
Refrigerador
Manual del usuario

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or
useful hints.
ARisk of injury and damage to
the property.
BRisk of electric shock.
Packaging materials of
the product are manufac-
tured from recyclable ma-
terials in accordance with
our National Environment
Regulations.

2 /39 EN Refrigerator / User Manual
1- Safety Instructions 3
2Your appliance 7
3Installation 8
3.1. Appropriate installation location 8
3.2. Installing the plastic wedges. . . . 8
3.3. Adjusting the feet . . . . . . . . . . . . . . . 9
3.4. Electrical connection . . . . . . . . . . . . 9
3.5. Reversing the doors . . . . . . . . . . . .10
3.6. Reversing the doors . . . . . . . . . . . . 11
4 Preparation 12
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 12
5Operating the product 13
5.1. Temperature setting button . . . 13
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 13
5.3. Vacation function . . . . . . . . . . . . . . 14
5.4. Indicator panel. . . . . . . . . . . . . . . . . . 15
5.5. Indicator panel. . . . . . . . . . . . . . . . . .18
5.6. Twist Ice – matic . . . . . . . . . . . . . . .23
5.7. Ice container . . . . . . . . . . . . . . . . . . . .24
5.8. Egg holder . . . . . . . . . . . . . . . . . . . . . .24
5.9. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
5.10. Crisper. . . . . . . . . . . . . . . . . . . . . . . . . .24
5.11.Chiller compartment. . . . . . . . . . . .24
5.12.Moving door shelf . . . . . . . . . . . . . .25
5.13.Sliding storage container . . . . . .25
5.14.Blue light . . . . . . . . . . . . . . . . . . . . . . .25
5.15.Humidity controlled crisper . . . .26
5.16.Auto Icematic . . . . . . . . . . . . . . . . . .26
5.17.Description and cleaning of odor
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.18HerbBox/HerbFresh. . . . . . . . . . . .27
5.19.Using the water dispenser . . . . .28
5.20.Using the water dispenser. . . . .28
5.21.Filling the water dispenser's tank2 9
5.22. Cleaning the water tank . . . . . .30
5.23.Drip tray . . . . . . . . . . . . . . . . . . . . . . . . 31
5.24.Freezing fresh food . . . . . . . . . . . .32
5.25.Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .33
5.26.Deep-freeze information . . . . . .33
5.27.Placing the food . . . . . . . . . . . . . . . .33
5.28.Door open warning . . . . . . . . . . . .34
5.29.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .34
5.30.Illumination lamp. . . . . . . . . . . . . . .34
6Maintenance and cleaning 35
6.1. Avoiding bad odors . . . . . . . . . . . . .35
6.2. Protecting the plastic surfaces 35
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .35
6Maintenance and cleaning36
7. Troubleshooting 37
Contents

3/39 EN
Refrigerator / User Manual
 This section contains safety instructions
that will help get protected against risks of
personal injury or property damage.
 Our company shall not be responsible for
damages that may arise when these ins-
tructions are not followed.
A Installation and repair procedures must
always be performed by the manufacturer,
authorised service agent or a qualified person
specified by the importer.
A Only use original parts and accessories.
A Original spare parts will be provided for 10
years, following the product purchasing date.
A Do not repair or replace any part of the
product unless specified expressly in the user
manual.
A Do not make any technical modifications to
the product.
A 1.1 Intended Use
 This product is not suitable for commercial
use and it must not be used out of its in-
tended use.
This product is designed to be used in houses
and indoor places.
For example:
- Personnel kitchens in stores, offices and
other working environments,
- Farm houses,
- Areas used by customers at hotels, mo-
tels and other types of accommodation,
- Bed&breakfast type hotels, boardinghouses,
- Catering and similar non-retail applications.
This product should not be used outdoors
with or without a tent above it such as boats,
balconies or terraces. Do not expose the pro-
duct to rain, snow, sun or wind.
There is the risk of fire!
A1.2 - Safety for
children, vulnerab-
le persons and pets
 This product can be used by children at and
above 8 years old and by persons with limi-
ted physical, sensory or mental capabilities
or who lack experience and knowledge
provided that they are supervised or trai-
ned on the safe use of the product and the
risks it brings out.
 Children aged from 3 to 8 years are allowed
to load and unload refrigerating products.
 Electrical products are dangerous for child-
ren and pets. Children and pets must not
play with, climb or enter the product.
 Cleaning and user maintenance should not
be performed by children unless they are
supervised by someone.
 Keep packaging materials away from child-
ren. There is the risk of injury and suffoca-
tion!
 Before disposing of the old or obsolete
product:
1. Unplug the product by gripping from the
plug.
2. Cut the power cable and remove it from the
appliance together with its plug
3. Do not remove the shelves or drawers so
that it is harder for children to enter the
product.
4. Remove the doors.
5. Keep the product in a way that it will not tip
over.
6. Do not allow children play with the old pro-
duct.
 Never throw the product into fire for dis-
posal. There is the risk of explosion!
 If there is a lock on the door of the product,
the key should be kept out of the reach of
children.
A1.3 - Electrical safety
 The product must be unplugged during ins-
tallation, maintenance, cleaning, repairing
and moving procedures.
 If the power cable is damaged, it must be
replaced by a qualified person specified
by the manufacturer, authorised service
agent or importer in order to avoid potenti-
al dangers.
 Do not squeeze the power cable under or
behind the product. Do not place heavy ob-
jects on the power cable. Power cable must
not be bent excessively, pinched or get in
contact with any heat source.
 Do not use extension cords, multi-sockets
or adapters to operate the product.
 Portable multi-sockets or portable po-
wer sources can overheat and cause fire.
Therefore, do not keep any multi-sockets
behind or near the product.
 Plug must be easily accessible. If this is not
possible, the electrical installation to which
the product is connected must contain a
device (such as a fuse, switch, circuit brea-
1- Safety Instructions

Instructions for safety and environment
4 / 39 EN Refrigerator / User Manual
ker, etc.) which conforms to the electri-
cal regulations and disconnects all poles
from the grid.
 Do not touch the power plug with wet
hands.
 Remove the plug from the socket by
gripping the plug and not the cable.
A1.4 -
Transportation safety
 Product is heavy; do not move it alone.
 Do not hold its door when moving the
product.
 Pay attention not to damage the coo-
ling system or the piping during trans-
portation. If the piping is damaged, do
not operate the product and call the
authorised service agent.
A1.5 - Installation
safety
 Call the authorised service agent for
installation of the product. To make
the product ready for use, check the
information in the user manual to make
sure that the electricity and water ins-
tallations are suitable. If they are not,
call a qualified electrician and plumber
to have the necessary arrangements
made. Otherwise, there is the risk of
electric shock, fire, problems with the
product, or injury!
 Prior to installation, check if the product
has any defects on it. If the product is
damaged, do not have it installed.
 Place the product on a clean, flat and
solid surface and balance it with adjus-
table feet. Otherwise, the product may
tip over and cause injuries.
 The installation location must be dry
and well ventilated. Do not place car-
pets, rugs or similar covers under the
product. Insufficient ventilation causes
the risk of fire!
 Do not cover or block the ventilation
openings. Otherwise, power consumpti-
on increases and your product may get
damaged.
 Product must not be connected to supply
systems such as solar power supplies.
Otherwise, your product may get dama-
ged due to sudden voltage changes!
 The more refrigerant a refrigerator con-
tains, the larger the installation location
must be. If the installation location is
too small, flammable refrigerant and air
mixture will accumulate in cases of refri-
gerant leakage in cooling system. The re-
quired space for each 8 gr of refrigerant is
1 m3minimum. The amount of refrigerant
in your product is indicated on the Type
Label.
 Product must not be installed in places
exposed to direct sunlight and it must
be kept away from heat sources such as
hobs, radiators, etc.
If it is inevitable to install the product close
to a heat source, a suitable insulation plate
must be used in between and the following
minimum distances must be kept to the heat
source:
- Minimum 30 cm away from heat sources
such as hobs, ovens, heater units or stoves,
- Minimum 5 cm away from electric ovens.
 Protection class of your product is Type
I. Plug the product in a grounded socket
that conforms the voltage, current and
frequency values stated on the type label
of the product. The socket must be equ-
ipped with a 10 A – 16 A circuit breaker.
Our company shall not be liable for any
damages that will arise when the product
is used without grounding and electrical
connection in accordance with the local
and national regulations.
 Product must not be plugged in during
installation. Otherwise, there is the risk of
electric shock and injury!
 Do not plug the product in sockets that
are loose, dislocated, broken, dirty, greasy
or bear the risk of getting in contact with
water.
 Route the power cable and hoses (if any)
of the product in a way that they do not
cause risk of tripping over.

Instructions for safety and environment
5/39 EN
Refrigerator / User Manual
 Exposing the live parts or power cable
to humidity may cause short circuit.
Therefore, do not install the product in
places such as garages or laundry rooms
where humidity is high or water may
splash. If the refrigerator gets wet with
water, unplug it and call the authorised
service agent.
 Never connect your refrigerator to
energy saving devices. Such systems
are harmful to your product.
A1.6- Operational
safety
 Never use chemical solvents on the pro-
duct. There is the risk of explosion!
 If the product malfunctions, unplug it
and do not operate until it is repaired by
the authorised service agent. There is
the risk of electric shock!
 Do not place flame sources (lit candles,
cigarettes, etc.) on or close to the pro-
duct.
 Do not climb on the product. There is
the risk of falling and getting injured!
 Do not damage the pipes of the coo-
ling system with sharp or penetrating
objects. The refrigerant that might
come out when the refrigerant pipes,
pipe extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
 Unless recommended by the manufac-
turer, do not place or use electrical devi-
ces inside the refrigerator/deep freezer.
 Be careful not to trap your hands or any
other part of your body in the moving
parts inside the refrigerator. Pay atten-
tion not to squeeze your fingers betwe-
en the door and the refrigerator. Be ca-
reful when opening and closing the door
particularly if there are children around.
 Never eat ice cream, ice cubes or frozen
food right after removing them from
the refrigerator. There is the risk of
frostbite!
 When your hands are wet, do not touch
the inner walls or metal parts of the free-
zer or the food stored therein. There is the
risk of frostbite!
 Do not place tins or bottles that contain
carbonated drinks or freezable liquids in
the freezer compartment. Tins and bottles
may burst. There is the risk of injury and
material damage!
 Do not place or use flammable sprays,
flammable materials, dry ice, chemical
substances or similar heat-sensitive mate-
rials near the refrigerator. There is the risk
of fire and explosion!
 Do not store explosive materials that con-
tain flammable materials, such as aerosol
cans, in your product.
 Do not place containers filled with liquid
onto the product. Splashing water on an
electrical part may cause electric shock or
the risk of fire.
 This product is not intended for storing
medicines, blood plasma, laboratory pre-
parations or similar medical substances
and products subject to Medical Products
Directive.
 Using the product against its intended
purpose may cause the products stored
inside it to deteriorate or spoil.
 If your refrigerator is equipped with blue
light, do not look at this light with optical
tools. Do not stare at UV LED lamp directly
for a long time. Ultraviolet light may cause
eye strain.
 Do not overload the product. Objects in
the refrigerator may fall down when the
door is opened, causing injury or damage.
Similar problems may arise if any object is
placed onto the product.
 To avoid injuries, make sure that you have
cleaned all the ice and water that may
have fallen or splashed on the floor.
 Change the position of the shelves/bottle
holders on the door of your refrigerator
only when they are empty. There is the
risk of injury!
 Do not place objects that can fall down/tip
over onto the product. Such objects may
fall down when the door is opened and ca-
use injuries and/or material damage.

Instructions for safety and environment
6 / 39 EN Refrigerator / User Manual
 Do not hit or exert excessive force on
glass surfaces. Broken glass may cause
injuries and/or material damage.
 Cooling system of your product con-
tains R600a refrigerant: Type of the
refrigerant used in the product is indi-
cated on the type label. This refrigerant
is flammable. Therefore, pay attention
not to damage the cooling system or
the piping while the product is in use. If
the piping is damaged:
- Do not touch the product or the
power cable,
- Keep away potential sources of fire
that may cause the product to catch fire.
- Ventilate the area where the product
is located. Do not use fans.
- Call the authorised service agent.
 If the product is damaged and you see
refrigerant leak, please stay away from
the refrigerant. Refrigerant may cause
frostbite in case of skin contact.
For products with a Water
Dispenser/Ice Machine
 Use only potable water. Do not fill
the water tank with any liquids
-such as fruit juice, milk, carbona-
ted beverages or alcoholic drinks-
that are not suitable for use in the
water dispenser.
 There is the risk for health and
safety!
 Do not allow children play with the
water dispenser or ice machine
(Icematic) in order to prevent acci-
dents or injuries.
 Do not insert your fingers or other
objects into the water dispenser
hole, water channel or ice machine
container. There is the risk of injury
or material damage!
A1.7- Maintenance
and cleaning safety
 Do not pull from the door handle if you
need to move the product for cleaning
purposes. Handle may break and cause
injuries if you exert excessive force
on it.
 Do not spray or pour water on or inside
the product for cleaning purposes.
There is the risk of fire and electric
shock!
 Do not use sharp or abrasive tools
when cleaning the product. Do not use
household cleaning products, deter-
gent, gas, gasoline, thinner, alcohol,
varnish etc.
 Only use cleaning and maintenance
products inside the product that are
not harmful for food.
 Never use steam or steam assisted
cleaners to clean or defrost the pro-
duct. Steam gets into contact with the
live parts in your refrigerator, causing
short circuit or electric shock!
 Make sure that no water enters the
electronic circuits or lighting elements
of the product.
 Use a clean and dry cloth to wipe the
foreign materials or dust on the pins
of the plug. Do not use a wet or damp
cloth to clean the plug. There is the
risk of fire and electric shock!
A1.8- HomeWhiz
 When you operate your product thro-
ugh HomeWhiz application, you must
observe the safety warnings even
when you are away from the product.
You must also follow the warnings in
the application.
A1.9- Lighting
 Call the authorised service when it is
required to replace the LED/bulb used
for lighting.

7/39 EN
Refrigerator / User Manual
1. Fridge - compartment door shelf
2. Temperature setting button
3. Water dispenser filling tank
4. Egg section
5. Water dispenser reservoir
6. Storage container under the door shelf
7. Moving door shelf
8. Adjustable feet
9. Crisper
10. Chiller compartment
11. Lock and key
12. Bottle shelf
13. Fridge - compartment glass shelf
14. Fan
15. Freezer compartment shelf
16. Icebox / Ice-making compartment
17. Freezer compartment
18. Fridge compartment
2Your appliance
C*optional:Figures in this user manual are given as an example and may not
match the product exactly. If the relevant parts are not available in the product you
purchased, the figure applies to other models.
*1
*3
*5
*4
*6
*2
*7
8
*9
*10
*11
*12
*13
14
14
17
18
*15
*16
*16
8

8 /39 EN Refrigerator / User Manual
3Installation
3.1.Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
BWARNING: Manufacturer shall
not be held liable for damages that
may arise from procedures carried
out by unauthorized persons.
BWARNING: Product must not
be plugged in during installation.
Otherwise, there is the risk of
death or serious injury!
A
WARNING: If the door clearance
of the room where the product
shall be place is so tight to prevent
passing of the product, remove
the door of the room and pass
the product through the door by
turning it to its side; if this does
not work, contact the authorized
service.

surface to prevent jolts.

away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.

direct sun light and kept in humid
places.

circulation to function efficiently. If
the product will be placed in an alcove,
remember to leave at least 5 cm
clearance between the product and
the ceiling, rear wall and the side walls.

alcove, remember to leave at least 5
cm clearance between the product
and the ceiling, rear wall and the side
walls. Check if the rear wall clearance
protection component is present at its
location (if provided with the product).
If the component is not available, or if
it is lost or fallen, position the product
so that at least 5 cm clearance shall be
left between the rear surface of the
product and the wall of the room. The
clearance at the rear is important for
efficient operation of the product.

where the temperature falls below
-5°C.
3.2.Installing the
plastic wedges
Plastic wedges supplied with the
product are used to create the distance
for the air circulation between the
product and the rear wall.

Installation
9 /39 EN
Refrigerator / User Manual
3.3.Adjusting the feet
If the product stands unbalanced
after installation, adjust the feet on
the front by rotating them to the
right or left.
3.4. Electrical
connection
AWARNING:Do not make
connections via extension
cables or multi-plugs.
BWARNING: Damaged power
cable must be replaced by the
Authorized Service Agent.
CIf two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
 Our company shall not be liable
for any damages that will arise
when the product is used
without grounding and electrical
connection in accordance with the
national regulations.
 Power cable plug must be within
easy reach after installation.
 Do not extension cords or cordless
multiple outlets between your
product and the wall outlet.
C
Hot Surface Warning!
Side walls of your product is
equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with high
temperatures may flow through
these areas, resulting in hot
surfaces on the side walls. This
is normal and does not need any
servicing. Please pay attention
while touching these areas.

Installation
10 / 39 EN Refrigerator / User Manual
3.5.Reversing the doors
Proceed in numerical order .
4
1
5
10 11
3
6
78
12
19
18
14
13
21
21
9
45 °
2
17
16
20
15

Installation
11 /39 EN
Refrigerator / User Manual
3.6. Reversing the doors
Proceed in numerical order .
1
5
10 11
3
6
78
19
18
14
13
9
45 °
2
17
16
12
4
15
20

12 /39 EN Refrigerator / User Manual
4.1. Things to be done
for energy saving
AConnecting the product to electric
energy saving systems is risky
as it may cause damage on the
product.
 Do not leave the doors of your
refrigerator open for a long time.
 Do not put hot food or drinks in your
refrigerator.
 Do not overload the refrigerator, cooling
capacity will fall when the air circulation
inside is hindered.
 In order to store maximum amount
of food in the freezer compartment,
the icematic, available in the freezer
compartment and easily removable by
hand, shall be taken out. Net volume and
energy consumption values declared on
the power data plate of your refrigerator
are measured and tested by removing
the icematic. Do not remove the shelves
inside the freezer compartment and on
the door of freezer compartment shall not
be removed and they shall always be used
they provide ease of use and efficiency in
energy consumption.
 Airflow should not be blocked by placing
foods on the sides of the freezer
compartment fan. A minimum distance
of 3 cm shall be provided on the sides of
protective fan cover.
 The baskets/drawers that are provided
with the chill compartment must always
be in use for low energy consumption and
for better storage conditions.
 Since hot and humid air will not directly
penetrate into your product when the
doors are not opened, your product will
optimize itself in conditions sufficient to
protect your food. In this energy saving
function, functions and components
such as compressor, fan, heater, defrost,
lighting, display and so on will operate
according to the needs to consume
minimum energy while maintaining the
freshness of your foodstuff.
 Food contact with the temperature
sensor in the freezer compartment may
increase energy consumption of the
appliance. Thus any contact with the
sensor(s) must be avoided.
4Preparation
 Depending on the features of your
product, thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
 Do not allow contact of the food with the
fridge compartment temperature sensor
shown in the figure below.
4.2. Initial use
Before starting to use your refrigerator,
ensure that all preparations are made in
accordance with the instructions in sections
"Instructions for safety and environment"
and "Installation".
 Run the product without putting any
food for 6 hours and do not open its door
unless certainly required.
CYou will hear a noise when the
compressor starts up. The liquids
and gases sealed within the
refrigeration system may also
give rise to noise, even if the
compressor is not running and this
is quite normal.
CFront edges of the product may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
CIn some models, the instrument
panel automatically turns off
5 minutes after the door has
closed. It will be reactivated
when the door has opened or
pressed on any key.

13/39 EN
Refrigerator / User Manual
5Operating the product
5.1.Temperature
setting button
The interior temperature of your
refrigerator changes for the following
reasons;
Seasonal temperatures,
Frequent opening of the door and
leaving the door open for long periods,
Food put into the refrigerator
without cooling down to the room
temperature,
The location of the refrigerator in the
room (e.g. exposing to sunlight).
You may adjust the varying interior
temperature due to such reasons by
using the setting button.
The numbers around the control knob
indicate the temperature values in “°C”.
If the ambient temperature is 25°C,
we recommend you to use the
temperature control knob of your
refrigerator at 4°C. This value may be
increased or decreased as required in
other ambient temperatures.
5.2.Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.

Operating the product
14 / 39 EN Refrigerator / User Manual
Remember to turn the temperature
control knob back to its previous
position once food has frozen.
5.3.Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
When the setting operation is
completed, you may press the
temperature control knob and have
it hidden.

Operating the product
15/39 EN
Refrigerator / User Manual
button is not applicable for every
model.)
This indicator ( ) illuminated when
a sensor failure occurs, too. When
this indicator is illuminated, “E”
and figures such as “1,2,3...” are
displayed alternatively on the
temperature indicator. These figures
on the indicator inform the service
personnel about the error.
2. Energy saving function
(display off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
C*Optional: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
5.4. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1
3
45
6
789
11
2
*10
*12
1. Power Failure / High temperature
/ Error status indicator
This indicator ( ) illuminates in case of
power failure, high temperature and
error warnings.
When the temperature of the freezer
compartment is heated up to a
critical level for the frozen food, the
maximum value reached by the freezer
compartment temperature flashes on
the digital indicator.
Check the food in the freezer
compartment.
This is not a malfunction. The warning
may be deleted by pressing any button
or on high temperature alarm off
button. (Cancelling by pressing any

Operating the product
16 / 39 EN Refrigerator / User Manual
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button is
pressed or the door is opened, energy
saving function will be canceled and
the symbols on display will return to
normal.
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quick fridge function
The button has two functions. To
activate or deactivate the quick cool
function press it briefly. Quick Cool
indicator will turn off and the product
will return to its normal settings. ( )
CUse quick cooling function
when you want to quickly cool
the food placed in the fridge
compartment. If you want to
cool large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, quick
cooling will cancel itself
automatically after 8 hours or
when the fridge compartment
reaches to the required
temperature.
CIf you press the quick cooling
button repeatedly with short
intervals, the electronic circuit
protection will be activated
and the compressor will not
start up immediately.
CThis function is not recalled
when power restores after a
power failure.
4. Fridge compartment temperature
setting button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Termination of the High
Temperature Warning
In case of power failure/high
temperature warning, you may
delete the warning ( ) by pressing
any button on the indicator or high
temperature alarm off button for 1
second after checking the food inside
the freezer compartment.
Note: Cancelling by pressing any
button is not applicable for every
model.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol ( ) will light up and key

Operating the product
17/39 EN
Refrigerator / User Manual
lock mode will be activated. Buttons
will not function if the Key lock
mode is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you want to
prevent changing of the temperature
setting of the refrigerator ( ).
8. Eco fuzzy
Press and hold eco fuzzy button for 1
seconds to activate eco fuzzy function.
Refrigerator will start operating in the
most economic mode at least 6 hours
later and the economic usage indicator
will turn on when the function is
active ( ). Press and hold eco fuzzy
function button for 3 seconds to
deactivate eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature setting button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21, -22,
-23,-24, -18... respectively. Press this
button to set the freezer compartment
temperature to the desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic is
not operating. To operate the icematic
again press and hold the On-Off button
for 3 seconds.
CWater flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from
the icematic.
11. Quick freeze function button/
icematic on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
CUse the quick freeze function
when you want to quickly
freeze the food placed in fridge
compartment. If you want to
freeze large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, Quick
Freeze will cancel itself
automatically after 4 hours or
when the fridge compartment
reaches to the required
temperature.
CThis function is not recalled
when power restores after a
power failure.
12. Economic usage indicator
Indicates that the product is running
in energy-efficient mode.This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
CEconomic usage indicator is
turned off when quick cooling
or quick freeze functions are
selected.

Operating the product
18 / 39 EN Refrigerator / User Manual
5.5.Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
45
76
*8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.

Operating the product
19/39 EN
Refrigerator / User Manual
1. Fridge compartment indicator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment indicator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.
