Beko RDNT360E50VGB User manual

EN
VN
RDNT230I30ZNB
RDNT230I30ZP
RDNT230I50VS
RDNT230I50VWB
RDNT230I50VX
RDNT230I50VZX
RDNT230I55VZNB
RDNT230I55VZX
RDNT250I30ZNB
RDNT250I30ZP
RDNT250I30ZX
RDNT250I50VS
RDNT340I50VZX
RDNT340I55VZX
RDNT360E50DVZX
RDNT360E50VGB
RDNT360E50VZWB
RDNT360E55DVZX
RDNT360E55VZDVG
RDNT440E50VGB
RDNT440E50VZX
RDNT470E50VZDJX
RDNT470E50VZJGB
RDNT250I50VWB
RDNT250I50VX
RDNT250I50VZX
RDNT250I55VZNB
RDNT250I55VZX
RDNT270I50VS
RDNT270I50VWB
RDNT270I50VX
RDNT270I50VZX
RDNT270I55VZNB
RDNT340E55VZVG
RDNT340I50VZWB

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
1 Your Refrigerator 3
2 Important Safety
Warnings 4
Intended use ..................................... 4
General safety .................................. 4
For products with a .......................... 8
water dispenser; ................................ 8
Child safety ........................................ 9
Compliance with WEEE Directive and
Disposing of the Waste Product: ....... 9
Package information .......................... 9
HC warning ....................................... 9
Things to be done for energy saving 10
Recommendations for the fresh food
compartment................................... 10
3 Installation 11
Points to be paid attention to when the
relocation of the refrigerator ............. 11
Electrical connection ........................ 11
Disposing of the packaging ............. 12
Disposing of your old refrigerator ..... 12
Placing and Installation .................... 12
Adjusting the legs ............................ 13
Door Open Warning ......................... 13
Changing the illumination lamp ....... 13
4 Preparation 15
CONTENTS
5 Using your refrigerator 18
Indicator panel................................. 18
Freezing fresh food .......................... 21
Recommendations for preservation of
frozen food ...................................... 21
Placing the food .............................. 21
Deep-freeze information .................. 22
Making ice ....................................... 22
Twist Ice – matic ............................ 23
Ice container .................................... 23
Fan .................................................. 24
Crisper ............................................ 24
Chiller compartment ........................ 24
Description and cleaning of odour
lter: ............................................... 25
Reversing the doors ........................ 26
6 Maintenance and
cleaning 27
Protection of plastic surfaces .......... 27
7 Troubleshooting 28

EN
3
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your Refrigerator
1. Freezer - compartment
door shelf
2. Temperature setting button
3. Moving door shelf
4. Egg section
5. Bottle shelf
6. Adjustable feet
7. Crisper
8. Chiller compartment
9. Lock and key
10. Bottle shelf
11. Fridge - compartment
glass shelf
12. Fan
13. Freezer compartment shelf
14. Icebox / Ice-making
compartment
15. Freezer compartment
16. Fridge compartment
*optional
15
16
*1
*2
*3 4
66
*7
*8
*9
*14
*13
*14
*9
*10
11
12
12
*5

EN
4
2Important Safety Warnings
Please review the
following information.
Failure to observe this
information may cause
injuries or material
damage. Otherwise, all
warranty and reliability
commitments will
become invalid.
The service life of your
product is 10 years.
During this period,
original spare parts will be
available to operate the
product properly.
Intended use
This product is intended
to be used
• indoors and in closed
areas such as homes;
• in closed working
environments such as
stores and offices;
• in closed
accommodation areas
such as farm houses,
hotels, pensions.
• It should not be used
outdoors.
General safety
• When you want to
dispose/scrap the
product, we recommend
you to consult the
authorized service
in order to learn the
required information and
authorized bodies.
• Consult your authorized
service for all your
questions and problems
related to the refrigerator.
Do not intervene or let
someone intervene to
the refrigerator without
notifying the authorised
services.
• For products with a
freezer compartment;
Do not eat cone ice
cream and ice cubes
immediately after you
take them out of the
freezer compartment!
(This may cause frostbite
in your mouth.)
• For products with a
freezer compartment;
Do not put bottled
and canned liquid
beverages in the
freezer compartment.
Otherwise, these may
burst.
• Do not touch frozen food
by hand; they may stick
to your hand.

EN
5
• Unplug your refrigerator
before cleaning or
defrosting.
• Vapor and vaporized
cleaning materials
should never be used in
cleaning and defrosting
processes of your
refrigerator. In such
cases, the vapor may
get in contact with the
electrical parts and
cause short circuit or
electric shock.
• Never use the parts on
your refrigerator such as
the door as a means of
support or step.
• Do not use electrical
devices inside the
refrigerator.
• Do not damage the
parts, where the
refrigerant is circulating,
with drilling or cutting
tools. The refrigerant
that might blow out
when the gas channels
of the evaporator, pipe
extensions or surface
coatings are punctured
causes skin irritations
and eye injuries.
• Do not cover or block
the ventilation holes on
your refrigerator with any
material.
• Electrical devices must
be repaired by only
authorised persons.
Repairs performed by
incompetent persons
create a risk for the user.
• In case of any failure or
during a maintenance or
repair work, disconnect
your refrigerator’s mains
supply by either turning
off the relevant fuse
or unplugging your
appliance.
• Do not pull by the cable
when pulling off the plug.
• Ensure highly alcoholic
beverages are stored
securely with the lid
fastened and placed
upright.
• Never store spray
cans containing
flammable and explosive
substances in the
refrigerator.
• Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those

EN
6
recommended by the
manufacturer.
• This product is not
intended to be used by
persons with physical,
sensory or mental
disorders or unlearned
or inexperienced people
(including children)
unless they are attended
by a person who will
be responsible for their
safety or who will instruct
them accordingly for use
of the product
• Do not operate a
damaged refrigerator.
Consult with the service
agent if you have any
concerns.
• Electrical safety of your
refrigerator shall be
guaranteed only if the
earth system in your
house complies with
standards.
• Exposing the product
to rain, snow, sun and
wind is dangerous with
respect to electrical
safety.
• Contact authorized
service when there is a
power cable damage to
avoid danger.
• Never plug the
refrigerator into the wall
outlet during installation.
Otherwise, risk of death
or serious injury may
arise.
• This refrigerator is
intended for only storing
food items. It must not
be used for any other
purpose.
• Label of technical
specifications is located
on the left wall inside the
refrigerator.
• Never connect your
refrigerator to electricity-
saving systems; they
may damage the
refrigerator.
• If there is a blue light on
the refrigerator, do not
look at the blue light with
optical tools.
• For manually controlled
refrigerators, wait for at
least 5 minutes to start
the refrigerator after
power failure.
• This operation manual
should be handed in to
the new owner of the
product when it is given
to others.

EN
7
• Avoid causing damage
on power cable when
transporting the
refrigerator. Bending
cable may cause fire.
Never place heavy
objects on power cable.
Do not touch the plug
with wet hands when
plugging the product.
• Do not plug the
refrigerator if the wall
outlet is loose.
• Water should not be
sprayed on inner or outer
parts of the product for
safety purposes.
• Do not spray substances
containing inflammable
gases such as propane
gas near the refrigerator
to avoid fire and
explosion risk.
• Never place containers
filled with water on top
of the refrigerator; in the
event of spillages, this
may cause electric shock
or fire.
• Do not overload the
refrigerator with food.
If overloaded, the food
items may fall down and
hurt you and damage
refrigerator when you
open the door.
• Never place objects on
top of the refrigerator;
otherwise, these objects
may fall down when
you open or close the
refrigerator’s door.
• As they require a precise
temperature, vaccines,
heat-sensitive medicine
and scientific materials
and etc. should not be
kept in the refrigerator.
• If not to be used for a
long time, refrigerator
should be unplugged.
A possible problem in
power cable may cause
fire.
• The plug’s tip should be
cleaned regularly with a
dry cloth; otherwise, it
may cause fire.
• Refrigerator may move
if adjustable legs are not
properly secured on the
floor. Properly securing
adjustable legs on the
floor can prevent the
refrigerator to move.
• When carrying the
refrigerator, do not hold
it from door handle.
Otherwise, it may be
snapped.

EN
8
• When you have to place
your product next to
another refrigerator or
freezer, the distance
between devices
should be at least 8cm.
Otherwise, adjacent side
walls may be humidified.
• The product shall never
be used while the
compartment which is
located at the top or
back of your product
and in which electronic
boards are available
(electronic board box
cover) (1) is open.
1
1
For products with a
water dispenser;
• Pressure for cold water
inlet shall be maximum
90 psi (6.2 bar). If your
water pressure exceeds
80 psi (5.5 bar), use a
pressure limiting valve
in your mains system. If
you do not know how
to check your water
pressure, ask for the
help of a professional
plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment
in your installation.
Consult Professional
plumbers is you are not
sure that there is no
water hammer effect in
your installation.
• Do not install on the
hot water inlet. Take
precautions against
of the risk of freezing
of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum
and 100°F (38°C)
maximum.

EN
9
• Use only potable water.
Child safety
• If the door has a lock,
the key should be kept
away from reach of
children.
• Children must be
supervised to prevent
them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Therefore, do not dispose
the product with normal domestic
waste at the end of its service life. Take
it to a collection point for the recycling
of electrical and electronic equipment.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment and
natural resources by recycling used
products. For children’s safety, cut the
power cable and break the locking
mechanism of the door, if any, so
that it will be non-functional before
disposing of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and
our national asset wealth.
If you want to contribute to the
re-evaluation of the packaging
materials, you can consult to your
environmentalist organizations or the
municipalities where you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.

EN
10
Recommendations for the
fresh food compartment
*optional
Do not allow the food to touch the
temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be
hindered by food.
Do not place hot foods in the product.
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
11
3Installation
BIn case the information which are
given in the user manual are not
taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged,
shelves, accessories, crisper, etc.
inside your refrigerator should be
fixed with adhesive tape and secured
against impacts. Package should
be bound with a thick tape or sound
ropes and the transportation rules
on the package should be strictly
observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the refrigerator,
Check the following before you
start to use your refrigerator:
1. Clean the interior of the
refrigerator as recommended in the
“Maintenance and cleaning” section.
2. Connect the plug of the
refrigerator to the wall socket. When
the fridge door is opened, fridge
internal lamp will turn on.
3. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
4. Front edges and both sides of
the refrigerator may feel warm. This is
normal. These areas are designed to
be warm to avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.

EN
12
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw
away on packaging pick up spots
designated by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the
doors of your refrigerator and pass it
sideways through the door.
1. Install your refrigerator to a
place that allows ease of use.
2. Keep your refrigerator away
from heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do not
place your product on the materials
such as rug or carpet.
4. Place your refrigerator on an
even floor surface to prevent jolts.

EN
13
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator
by turning its front legs as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the refrigerator will facilitate
this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call
your AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer
in a safe and comfortable way.The
lamps used in this appliance have to
withstand extreme physical conditions
such as temperatures below -20 °C.
(only chest and upright freezer)
Door Open Warning
(This feature is optional)
An audio warning signal will be given
when the door of your product is
left open for at least 1 minute. This
warning will be muted when the door
is closed or any of the display buttons
(if any) are pressed.

EN
14
1275 mm (A)
1001 mm (B)
115(C)
50 mm 50 mm
50 mm
50 mm
100 mm

EN
15
4Preparation
• Your cooler/freezer should be
installed at least 30 cm away from
heat sources such as hobs, ovens,
central heater and stoves and at least
5 cm away from electrical ovens and
should not be located under direct
sunlight.
• Please make sure that the interior
of your cooler/freezer is cleaned
thoroughly.
• If two coolers are to be installed side
by side, there should be at least 2 cm
distance between them.
• When you operate your cooler/freezer
for the first time, please observe the
following instructions during the initial
six hours.
• Its door should not be opened
frequently.
• It must be operated empty without
placing any food in it.
• Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
• Food contact with the temperature
sensor in the freezer compartment
may increase energy consumption of
the appliance. Thus any contact with
the sensor(s) must be avoided.
• This product has been designed to
function at ambient temperatures
up to 43 °C (90 SDgrF). Even if the
ambient temperature falls to -15
°C, frozen food in the freezer does
not thaw thanks to its Advanced
Electronic Temperature Control
System. For the first installation, the
product should NOT be placed under
low ambient temperatures. This is
because the freezer cannot go down
to standard operation temperature.
When reaching continuous operation,
the product can be moved to
another place. Thus, later you can
place your product in the garage
or an unheated room without the
concern of causing frozen food to
get rotten. However, it is likely that
above mentioned low temperatures
may cause the freezing of the food in
the fridge compartment; thus, please
consume the food items in the fridge
in a controlled way as needed. When
ambient temperature goes back
to normal, you may change button
setting according to your need.
• If the ambient temperature is below
0°C, the food in fridge compartment
will freeze. Therefore, we recommend
not using the fridge compartment
in such low ambient temperatures.
You may continue to use the freezer
compartment as usual.
• In some models, the instrument panel
automatically turns off 5 minutes
after the door has closed. It will
be reactivated when the door has
opened or pressed on any key.
• Due to temperature change as a
result of opening/closing the product
door during operation, condensation
on the door/body shelves and the
glass containers is normal.

EN
16
Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
5Using your refrigerator
45
76
8
9
123
1.Freezer compartment indicator
2.Error status indicator
3.Temperature indicator
4.Vacation function button
5.Temperature setting button
6.Compartment selection button
7.Fridge Compartment Indicator
8.Freezer compartment indicator
9.Economy mode indicator
10. Vacation function indicator
*optional
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

EN
17
1. Freezer compartment indicator
Fridge compartment light is illuminated
while the freezer compartment
temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated. When
this indicator is activated, “E” is
displayed on the freezer compartment
temperature indicator, and numbers
such as “1,2,3...” are displayed on
the fridge compartment temperature
indicator. These numbers on the
indicator inform service personnel
about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling is
performed on the fridge compartment.
It is not suitable to keep the food in the
fridge compartment when this function
is activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press
Vacation button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -16°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Fridge compartment indicator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator operates
in energy saving mode. This display
shall be activated if the freezer
compartment temperature is set to
-16°C.
9. Vacation function indicator
Indicates that vacation is activated.

EN
18
Indicator panel (External Display) *Optional
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
5Using your refrigerator
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1
3
45
6
789
*10
11
2
1. Power failure/High temperature
/ error warning indicator
This indicator ( ) illuminates during
power failure, high temperature failures
and error warnings. During sustained
power failures, the highest temperature
that the freezer compartment reaches
y. After
checking the food located in the
freezer compartment ( ) press the
alarm o rning.
Please refer to "remedies advised
for troubleshooting" section on
your manual if you observe that this
indicator is illuminated.
If the product doors are kept closed
for a long time energy saving function
is automatically activated and energy
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
tur
function is activated, if any button is
pressed or the door is opened, energy
saving function will be canceled and
the symbols on display will return to
normal.

EN
19
Energy saving function is activated
during delivery from factory and cannot
be canceled.
3.Quick fridge function
The button has two functions. To activate or
deactivate the quick cool function press it briey.
Quick Cool indicator will turn o and the product
will return to its normal settings. ( )
compartment. If you want to
cool large amounts of fresh
.the product
.temperature
.
when power restores after a
.
4. Fridge compartment
temperature setting button
Press this button to set the
temperature of the fridge compartment
to 8, 7,6, 5,4,3, 2, 8... respectively.
Press this button to set the fridge
compartment temperature to the
desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated, “- -”
is displayed on the fridge compartment
temperature indicator and no active
cooling is performed on the fridge
compartment. It is not suitable to keep
the food in the fridge compartment
when this function is activated. Other
compartments shall be continued to
be cooled as per their set temperature.
To cancel this function press
Vacation function button again.
6. Alarm o warning:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm o
button ( ) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key lock
symbol
() will light up and key lock mode will
be activated. Buttons will not function
if the Key lock mode is active. Press
key lock button simultaneously for 3
seconds again. Key lock symbol will
turn o and the key lock mode will be
exited.
Press the key lock button if you want
to prevent changing of the temperature
setting of the refrigerator ( ).
8. Eco fuzzy
Press and hold eco fuzzy button for 1
seconds to activate eco fuzzy function.
Refrigerator will start operating in
the most economic mode at least 6
hours later and the economic usage
