Beko RSNE445 E 22 User manual

Kühlschrank/Gefrierschrank
Bedienungsanleitung
Réfrigérateur
Manuel d'utilisation
Koelkast
Gebruiksaanwijzing
RSNE445 E 22
RSNE 445 E 33 W
RSNE 445 E 33 X
RSNE 445 E 33 DW
RSNE 445 E 33 DX
EN DE FR NL
Refrigerator
User manual

Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in
modern facilities with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In
case the product changes hands, do not forget to hand the guide to its new owner
along with the product.
This guide will help you use the product quickly and safely.
• Please read the user guide carefully before installing and operating the product.
• Always observe the applicable safety instructions.
• Keep the user guide within easy reach for future use.
• Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide
clearly indicates any variations of different models.
CImportant nformaton and
useful tps.
ARsk of lfe and property.
BRsk of electrc shock.
The product’s packagng
s made of recyclable
materals, n accordance
wth the Natonal
Envronment Legslaton.

3 / 26 EN
Refrigerator/User Manual
1Safety and environment
instructions 4
General safety ............................................... 4
Intended use ...................................................7
Child safety ......................................................7
Compliance with WEEE Directive and
Disposing of the Waste Product ............ 8
Compliance with RoHS Directive............8
Package information...................................8
2 Your refrigerator 9
3 Installation 10
Appropriate installation location.........10
Installing the plastic wedges ................10
Adjusting the feet.......................................11
Electrical connection .................................11
4 Preparation 12
5 Operating the product 13
Freezing fresh food ...................................15
Recommendations for preserving the
frozen food....................................................16
Deep-freeze information........................16
Placing the food.......................................... 17
Door open warning.................................... 17
Changing the door opening direction 17
6 Maintenance and cleaning 22
Avoiding bad odours .................................22
Protecting the plastic surfaces ...........22
7 Troubleshooting 23

4 / 26 EN Refrigerator/User Manual
1 Safety and environment instructions
Ths secton provdes the safety nstructons necessary
to prevent the rsk of njury and materal damage.
Falure to observe these nstructons wll nvaldate all
types of product warranty.
1.1. General safety
• Ths product should not be used by persons wth
physcal, sensory and mental dsabltes, wthout
suffcent knowledge and experence or by chldren.
The devce can only be used by such persons under
supervson and nstructon of a person responsble
for ther safety. Chldren should not be allowed to
play wth ths devce.
• In case of malfuncton, unplug the devce.
• After unpluggng, wat at least 5 mnutes before
pluggng n agan.
• Unplug the product when not n use.
• Do not touch the plug wth wet hands! Do not pull
the cable to plug off, always hold the plug.
• Wpe the power plug’s tp wth a dry cloth before
pluggng n.
• Do not plug n the refrgerator f the socket s loose.
• Unplug the product durng nstallaton,
mantenance, cleanng and repar.
• If the product wll not be used for a whle, unplug
the product and remove any food nsde.
• Do not use the product when the compartment wth
crcut cards located on the upper back part of the
product (electrcal card box cover) (1) s open.

5 / 26 EN
Refrigerator/User Manual
Safety and envronment nstructons
1
1
• Do not use steam or steamed cleanng materals for
cleanng the refrgerator and meltng the ce nsde.
Steam may contact the electrfed areas and cause
short crcut or electrc shock!
• Do not wash the product by sprayng or pourng
water on t! Danger of electrc shock!
• In case of malfuncton, do not use the product, as
t may cause electrc shock. Contact the authorzed
servce before dong anythng.
• Plug the product nto an earthed socket. Earthng
must be done by a qualfed electrcan.
• If the product has LED type lghtng, contact the
authorzed servce for replacng or n case of any
problem.
• Do not touch frozen food wth wet hands! It may
adhere to your hands!
• Do not place lquds n bottles and cans nto the
freezer compartment. They may burst out!
• Place lquds n uprght poston after tghtly closng
the ld.
• Do not spray flammable substances near the
product, as t may burn or explode.

6 / 26 EN Refrigerator/User Manual
Safety and envronment nstructons
• Do not keep flammable materals and products wth
flammable gas (sprays, etc.) n the refrgerator.
• Do not place contaners holdng lquds on top of the
product. Splashng water on an electrfed part may
cause electrc shock and rsk of fre.
• Exposng the product to ran, snow, sunlght and
wnd wll cause electrcal danger. When relocatng
the product, do not pull by holdng the door handle.
The handle may come off.
• Take care to avod trappng any part of your hands or
body n any of the movng parts nsde the product.
• Do not step or lean on the door, drawers and smlar
parts of the refrgerator. Ths wll cause the product
to fall down and cause damage to the parts.
• Take care not to trap the power cable.
1.1.1 HC warning
If the product comprses a coolng system usng R600a
gas, take care to avod damagng the coolng system and
ts ppe whle usng and movng the product. Ths gas
s flammable. If the coolng system s damaged, keep
the product away from sources of fre and ventlate the
room mmedately.
CThe label on the nner left sde ndcates the
type of gas used n the product.

7 / 26 EN
Refrigerator/User Manual
Safety and envronment nstructons
1.1.2 For models with water fountain
• In order for the water system nsde the refrgerator
to operate properly, pressure n the water mans
must be between 1-8 bars. A pressure regulator
must be used f the pressure n the water mans
s hgher than 5 bars. If the pressure n the mans
s hgher than 8 bars, the refrgerator must not
be connected to the mans. If you are not sure
about how to measure the water pressure, ask for
professonal help.
• Use drnkng water only.
1.2. Intended use
• Ths product s desgned for home use. It s not
ntended for commercal use.
• The product should be used to store food and
beverages only.
• Do not keep senstve products requrng controlled
temperatures (vaccnes, heat senstve medcaton,
medcal supples, etc.) n the refrgerator.
• The manufacturer assumes no responsblty for any
damage due to msuse or mshandlng.
• The product’s bench lfe s 10 years. The spare
parts necessary for the product to functon wll be
avalable for ths perod.
1.3. Child safety
• Keep packagng materals out of chldren’s reach.
• Do not allow the chldren to play wth the product.
• If the product’s door comprses a lock, keep the key
out of chldren’s reach.

8 / 26 EN Refrigerator/User Manual
Safety and envronment nstructons
1.4. Compliance with WEEE Directive
and Disposing of the Waste Product
Ths product comples wth EU WEEE Drectve (2012/19/EU). Ths product
bears a classfcaton symbol for waste electrcal and electronc equpment (WEEE).
Ths product has been manufactured wth hgh qualty parts and
materals whch can be reused and are sutable for recyclng. Do not
dspose of the waste product wth normal domestc and other wastes at
the end of ts servce lfe. Take t to the collecton center for the recyclng
of electrcal and electronc equpment. Please consult your local
authortes to learn about these collecton centers.
1.5. Compliance with RoHS Directive
• Ths product comples wth EU WEEE Drectve (2011/65/EU). It does not contan
harmful and prohbted materals specfed n the Drectve.
1.6. Package information
• Packagng materals of the product are manufactured from recyclable materals
n accordance wth our Natonal Envronment Regulatons. Do not dspose of the
packagng materals together wth the domestc or other wastes. Take them to
the packagng materal collecton ponts desgnated by the local authortes.

9 / 26 EN
Refrigerator/User Manual
2Your refrigerator
C
Figures that take place in this instruction manual are schematic and
may not correspond exactly with your product. If the subject parts are
not included in the product you have purchased, then it is valid for other
models.
1. Indicator panel
2. Butter & Cheese sections
3. Water dispenser filling tank
4. Egg section
5. Water dispenser reservoir
6. Adjustable door shelves
7. Bottle shelves
8. Adjustable front feet
9. Chiller
10.Chiller cover and glass
11.Movable shelves
12.Wine cellar
*OPTIONAL
1
*
2
*
6
8
9
10
11
12*
7
5
*3
4

10 / 26 EN Refrigerator/User Manual
3Installation
3.1. Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
WARNING:Manufacturer shall
not be held lable for damages
that may arse from procedures
carred out by unauthorzed
persons.
B
WARNING:Product must
not be plugged n durng
nstallaton. Otherwse, there
s the rsk of death or serous
njury!
A
WARNING:
If the door clearance of the
room where the product shall
be place s so tght to prevent
passng of the product, remove
the door of the room and pass
the product through the door
by turnng t to ts sde; f ths
does not work, contact the
authorzed servce.
• Placetheproductonanevenfloor
surface to prevent jolts.
• Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.
• Productmustnotbesubjectedto
direct sun light and kept in humid
places.
• Appropriateairventilationmustbe
provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in
the wall, pay attention to leave at least
5 cm distance with the ceiling and side
walls.
•
3.2. Installing the
plastic wedges
Plastc wedges suppled wth the
product are used to create the dstance
for the ar crculaton between the
product and the rear wall.
1. To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
2. Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in
the figure.

11 / 26 EN
Refrigerator/User Manual
Installaton
3.3. Adjusting the feet
If the product stands unbalanced after
nstallaton, adjust the feet on the front
by rotatng them to the rght or left.
3.4.Electrical connection
AWARNING: Do not make
connectons va extenson
cables or mult-plugs.
BWARNING:Damaged
power cable must be
replaced by the Authorzed
Servce Agent.
C
If two coolers are to be
nstalled sde by sde, there
should be at least 4 cm
dstance between them.
• Our company shall not be lable
for any damages that wll arse
when the product s used wthout
groundng and electrcal connecton
n accordance wth the natonal
regulatons.
• Power cable plug must be wthn easy
reach after nstallaton.
• Connect your refrgerator to a
grounded outlet rated for a voltage
value of 220-240V /50 Hz. Outlet
shall have 10 to 16A fuse.
• Do not extenson cords or cordless
multple outlets between your
product and the wall outlet.
• The condenser of your appliance
islocated on the back as shown
below. In order to achieve better
energy efficiency with lower energy
consumption, please pull the condenser
towards yourself as illustrated in
picture below. The condenser position
will be fixed firmly by means of locking
mechanisim of the top holders on each
side.
*OPTIONAL
v

12 / 26 EN Refrigerator/User Manual
4Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not be
located under direct sunlight.
• The ambient temperature of the room
where you install your refrigerator
should at least be 5°C. Operating your
refrigerator under cooler conditions is
not recommended with regard to its
efficiency.
• Please make sure that the interior of
your refrigerator is cleaned thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least 2
cm distance between them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
• The door should not be opened
frequently.
• It must be operated empty without any
food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
• Food contact with the temperature
sensor in the freezer compartment may
increase energy consumption of the
appliance. Thus any contact with the
sensor(s) must be avoided.
• In some models, the instrument panel
automatically turns off 5 minutes
after the door has closed. It will be
reactivated when the door has opened
orpressed on any key.
• Due to temperature change as a result
of opening/closing the product door
during operation, condensation on
the door/body shelves and the glass
containers is normal

13 / 26 EN
Refrigerator/User Manual
CFgures n ths user manual are schematc and may not match the product
exactly. If the subject parts are not ncluded n the product you have
purchased, then those parts are vald for other models.
5Operating the product
1
78
12
10
11 9
235
4 6
13
1.On/Off Indicator:
Ths con ( ) come on when the frdge
s turned off. All the other cons turn off.
2.Economic Usage Indicator:
This icon ( ) comes on when the
Frdge Compartment s set to 8°C whch s
the most economcal set value. Economc
Usage Indcator turns off when the Quck
Frdge or Quck Freeze functon s selec-
ted.
3.Fridge Compartment Temperature
Setting Indicator:
Indcates the temperature set for the
Frdge Compartment.
4.Power failure/High temperature /
error warning indicator :
This light () illuminates during power
failure, high temperature failures and
error warnings. During sustained power
failures, the highest temperature that
the fridge compartment reaches will
flash on the digital display.
5. Vacation Indicator:
Ths con ( )lghts up when the
Vacaton Functon s actve.
6.Key Lock Indicator:
This icon ( ) lights up when the Key
Lock mode is activated.
7.Key Lock Mode:
Press Key Lock ( ) button continuously
for 3 seconds. Key lock icon will light
up and key lock mode will be activated.
Buttons will not function if the Key Lock
mode is active. Press Key Lock button
continuously for 3 seconds again. Key
lock icon will turn off and the key lock
mode will be exite.

14 / 26 EN Refrigerator/User Manual
Operatng the product
8. Vacation Function:
When you press Vacaton button,
vacaton functon ( ) s actvated and
vacaton ndcator lghts. You can use
ths functon when you wll not use your
frdge for a long tme. Note that there
should be no food nsde your frdge,
otherwse frdge can not preserve your
food at Vacaton mode.
If ths functon s actvated, frdge
compartment temperature s kept at 15
C° n order to prevent bad smellng. Press
Vacaton button agan to deactvate
vacaton functon.
9. Fridge Set Function:
Ths functon ( ) allows you to make
the Frdge compartment temperature
settng. Press ths button to set the
temperature of the frdge compartment
to 8,7,6,5,4,3, and 1 respectvely.
10. Quick Fridge Function:
Quck Frdge ndcator ( ) turns on when
the Quck Frdge functon s on. Press
Quck Frdge button agan to cancel ths
functon. Quck Frdge ndcator wll turn
off and normal settngs wll be resumed.
Quck Frdge functon wll be cancelled
automatcally 1 hours later f you do not
cancel t manually. If you want to cool
plenty amount of fresh food, press Quck
Frdge button before you place the food
nto the frdge compartment.
11.On/Off Function:
This function ( ) allows you to make
the Fridge turn off when pressed for 3
seconds.The fridge could be turned on
by pressing On/Off button for 3 seconds
again .
12.Energy Saving Indicator :
If the product doors are kept closed
for a long time energy saving function
is automatically activated and energy
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will turn
off. When the Energy Saving function is
activated, if any button is pressed or the
door is opened, energy saving function
will be canceled and the symbols on
display will return to normal.
Energy saving function is activated
during delivery from factory and cannot
be canceled.
13.Quick Freeze Indicator :
This icon ( ) comes on when the Quick
Freeze function is on.

15 / 26 EN
Refrigerator/User Manual
Operatng the product
5.1. Freezing fresh food
• In order to preserve the qualty of
the food, t shall be frozen as quckly
as possble when t s placed n the
freezer compartment, use the fast
freezng feature for ths purpose.
• You may store the food longer n
freezer compartment when you
freeze them whle they are fresh.
• Pack the food to be frozen and close
the packng so that t would not allow
entrance of ar.
• Ensure that you pack your food
before puttng them n the freezer.
Use freezer contaners, fols and
mosture-proof papers, plastc bags
and other packng materals nstead
of tradtonal packng papers.
• Label each pack of food by addng
the date before freezng. You may
dstngush the freshness of each
food pack n ths way when you open
your freezer each tme. Store the
food frozen before n the front sde of
compartment to ensure that they are
used frst.
CThe freezer compartment
defrosts automatcally.
• Frozen food must be used
mmedately after they are thawed
and they should not be re-frozen.
• Do not freeze too large quanttes of
food at one tme.

16 / 26 EN Refrigerator/User Manual
Operatng the product
Freezer
Compartment
Settng
Frdge
compartment
Settng
Remarks
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the
ambient temperature exceeds 30°C.
Quick Freeze 4°C
Use when you wish to freeze your food in a short
time. Your product will return to its previous
mode when the process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge
compartment is not cold enough because of the
hot ambient conditions or frequent opening and
closing of the door.
5.2. Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at least.
1. Put packages in the freezer
as quickly as possible after purchase
without allowing the to thaw.
2. Check whether the "Use By" and
"Best Before" dates on the packaging are
expired or not before freezing it.
3. Ensure that the package of the
food is not damaged.
5.3. Deep-freeze
information
Accordng to IEC 62552 standards, the
product shall freeze at least 4.5 kg of
food at 32°C ambent temperature to
-18°C or lower wthn 24 hours for every
100-ltres of freezer volume.
It s possble to preserve the food for
a long tme only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures n the deep freeze).
Foods to be frozen should not be allowed
to come n contact wth the prevously
frozen tems to prevent them from
gettng thawed partially.
Boil the vegetables and drain their water
in order to store vegetables for a longer
time as frozen. After draining their
water, put them in air-proof packages
and place them inside the freezer. Food
such as bananas, tomatoes, lettuce,
celery, boiled eggs, potatoes are not
suitable for freezing. When these foods
are frozen, only their nutritional value
and taste shall be affected negatively.
They shall not be spoiled so that they
would create a risk for human health.

17 / 26 EN
Refrigerator/User Manual
Operatng the product
5.4. Placing the food
Freezer
compartment
shelves
Various frozen food
such as meat, fish,
ice cream, vegetables
and etc.
Refrigerator
compartment
shelves
Food in pans, covered
plates and closed
containers, eggs (in
closed container)
Door shelves
of fridge
compartment
Small and packaged
food or beverage
Crisper Vegetables and fruits
Fresh zone
compartment
Delicatessen
(breakfast food,
meat products that
shall be consumed in
a short time)
5.5. Door open warning
(This feature is optional)
An audio warning signal will be given
when the door of your product is left
open for at least 1 minute. This warning
will be muted when the door is closed
or any of the display buttons (if any) are
pressed.
Door open warning is given to user both
visually and acoustically. If the warning
continues for 10 minutes, interior lights
will be turned off.
5.6. Changing the door
opening direction
Door openng drecton of your refrge-
rator can be changed accordng to the
place you are usng t.If ths s neces-
sary, please call your nearest Authorzed
Servce.
Above descrpton s a general express-
on.For nformaton on changng the ope-
nng drecton of the door, you must refer
to the warnng label located on the nner
sde of the door.

18 / 26 EN Refrigerator/User Manual
Operatng the product
Usng the water dspenser
*optional
CIt is normal for the first few
glasses of water taken from
the dispenser to be warm.
CIf the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push in the lever of the water
dispenser with your glass. If you
are using a soft plastic cup, pushing
the lever with your hand will be
easier.
2. After filling the cup up to the level
you want, release the lever.
CPlease note, how much
water flows from the
dispenser depends on how
far you depress the lever. As
the level of water in your cup
/ glass rises, gently reduce
the amount of pressure on
the lever to avoid overflow.
If you slightly press the
arm, the water will drip; this
is quite normal and not a
failure.

19 / 26 EN
Refrigerator/User Manual
Operatng the product
Fllng the water
dspenser's tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking water.
3. Close the cover.
CDo not fill the water tank
with any other liquid except
for water such as fruit juices,
carbonated beverages or
alcoholic drinks which are not
suitable to use in the water
dispenser. Water dispenser
will be irreparably damaged
if these kinds of liquids are
used. Warranty does not cover
such usages. Some chemical
substances and additives
contained in these kinds of
drinks/liquids may damage the
water tank.
CUse clean drinking water only.

20 / 26 EN Refrigerator/User Manual
Operatng the product
CCapacity of the water tank is 3
litres; do not overfill.
Cleanng the water tank
1. Remove the water filling reservoir inside
the door rack.
2. Remove the door rack by holding from
both sides.
3. Grab the water tank from both sides and
remove it with an angle of 45°C.
4. Remove the cover of the water tank and
clean the tank.
CComponentsof thewatertank
and water dispenser should not
be washed in dishwasher.
