Beko CM 9120 BI User manual

Washing Machine
User Manual
CM 9120 BI
2820530904/ EN/ / 08/02/2023 16:05

EN / 2
Table of Contents
1 Safety Instructions........................ 4
1.1 Intended Use.................................. 4
1.2 Safety of Children, Vulnerable
Persons and Pets ..........................
4
1.3 Electrical Safety............................. 5
1.4 Handling Safety ............................. 5
1.5 Installation Safety.......................... 6
1.6 Operational Safety......................... 7
1.7 Maintenance and Cleaning Safety 8
2 Important Instructions for Envir-
onment...........................................
9
2.1 Compliance with WEEE Directive . 9
2.2 Package Information..................... 9
3 Technical Specifications.............. 10
4 Installation ..................................... 11
4.1 Appropriate Installation Location. 11
4.2 Assembly of Bottom Panel Cov-
ers...................................................
11
4.3 Removing Transportation Safety
Bolts ...............................................
12
4.4 Connecting to Water Supply ......... 12
4.5 Connecting the Drain Hose to the
Drain ...............................................
13
4.6 Adjusting the Stands..................... 13
4.7 Electrical Connection .................... 13
4.8 Start Up .......................................... 14
5 Preparation.................................... 14
5.1 Sorting the Laundry ....................... 14
5.2 Preparing Laundry for Washing.... 14
5.3 Tips for Energy and Water Saving 15
5.4 Loading the Laundry...................... 15
5.5 Correct Load Capacity .................. 15
5.6 Using Detergent and Softener ...... 15
5.7 Tips for Efficient Washing ............ 17
5.8 Displayed Programme Duration ... 18
6 Operating the Product.................. 18
6.1 Control Panel ................................. 19
6.2 Symbols on the Display................. 20
6.3 Programme and Consumption
Table...............................................
21
6.4 Programme Selection ................... 23
6.5 Programmes.................................. 23
6.6 Temperature Selection.................. 26
6.7 Spin Speed Selection .................... 26
6.8 Auxiliary Function Selection.......... 27
6.8.1 Auxiliary Functions..................... 27
6.8.2 Functions/Programmes Selec-
ted by Pressing the Function
Keys for 3 Seconds ....................
28
6.9 End Time ........................................ 29
6.10 Starting the Programme................ 30
6.11 Loading Door Lock......................... 31
6.12 Changing the Selections After
Programme has Started ................
31
6.13 Cancelling the Programme ........... 32
6.14 End of Programme......................... 32
6.15 HomeWhiz Feature and Remote
Control Function ............................
32
6.15.1 HomeWhiz Setup........................ 33
6.15.2 Setting up a Washing Machine
Connected to Someone Else's
Account.......................................
34
6.15.3 Remote Control Function and
Using It........................................
35
6.15.4 Troubleshooting ......................... 35
7 Maintenance and Cleaning........... 36
7.1 Cleaning the Detergent Drawer..... 36
7.2 Cleaning the Loading Door and
the Drum.........................................
36
7.3 Cleaning the Body and Control
Panel...............................................
37
7.4 Cleaning the Water Intake Filters.. 37
7.5 Draining Remaining Water and
Cleaning the Pump Filter ...............
37
8 Troubleshooting ............................ 38
9 DISCLAIMER / WARNING ............. 42

EN / 3
Please read this user manual first!
Dear Customer,
Thank you for choosing Beko product. We hope that you get the best results from your
product which has been manufactured with high quality and state-of-the-art technology.
Therefore, please read this entire user manual and all other accompanying documents
carefully before using the product.
Follow all warnings and information in the user manual. Thus, you protect yourself and
your product against possible dangers.
Keep the user manual. If you hand over the product to someone else, provide the user
manual as well. Warranty terms, usage and troubleshooting methods of your product are in
user guide.
Symbols and Definitions
The following symbols are used in the user guide:
Danger that could result in death or injury.
Important information or useful hints about usage.
Read the user manual.
Recyclable materials.
Hot surface warning.
WARNING Danger that may result in property damage to the product or its environment.

EN / 4
1 Safety Instructions
This section includes the safety
instructions necessary to pre-
vent the risk of personal injury or
material damage.
Our company shall not be held
responsible for damages that
may occur if these instructions
are not observed.
• Installation and repair opera-
tions shall always be per-
formed by Authorised Service.
• Use original spare parts and
accessories only.
• Do not repair or replace any
component of the product un-
less it is clearly specified in the
user manual.
• Do not modify the product.
1.1 Intended Use
• The product's bench life is 10
years. During this period, ori-
ginal spare parts will be avail-
able to operate the appliance
properly.
• This product has been de-
signed for domestic use. It is
not for commercial purposes
or it should not be used out of
its intended use.
• The product must only be used
for washing and rinsing of
laundry that are marked ac-
cordingly
• This appliance is intended to
be used in household and sim-
ilar applications. For example;
– Personnel kitchens of stores,
offices and other work envir-
onments;
– Ranches,
– By customers of hotels, mo-
tels and other accommoda-
tion facilities,
– Bed and breakfasts, hostel-
like environments,
– Common areas of apartment
blocks or laundries.
1.2 Safety of Children,
Vulnerable Persons
and Pets
• This product may be used by
children aged 8 years and
older and persons with under-
developed physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervi-
sion or instruction concerning
use of the appliance in a the
product safe way and the haz-
ards involved.
• Children under the age of 3
should be kept away unless
continuously supervised.

EN / 5
• Electrical products are danger-
ous for children and pets. Chil-
dren or pets should not play
with, climb on top or inside the
product. Check inside the
product before use.
• Use child lock to prevent chil-
dren from intervening with the
product.
• Do not forget to close the load-
ing door when leaving the
room where the product is loc-
ated. Children and pets may
get locked inside and drown.
• Children should not perform
cleaning and user mainten-
ance works without an adult’s
supervision.
• Keep the packaging materials
away from children. Risk of in-
jury and suffocation.
• Keep all detergents and addit-
ives used for the product away
from children’s reach.
• Cut the power cable and break
and deactivate the locking
mechanism of the loading
door before disposing of the
product for children’s safety.
1.3 Electrical Safety
• Product should be unplugged
during installation, mainten-
ance, cleaning and repair pro-
cedures.
• If the power cable is damaged,
it must be replaced by the au-
thorised service in order to
avoid possible risks.
• Do not tuck the power cable
under and behind the product.
Do not place heavy objects on
the power cable. Do not over
bend, crush and touch the
power cable to sources of
heat.
• Do not use an extension cord,
multi-plug or adaptor to oper-
ate your product.
• The plug shall be easily ac-
cessible. If this is not possible,
a mechanism that meets the
electrical legislation and that
disconnects all terminals from
the mains (fuse, switch, main
switch, etc.) shall be available
on the electrical installation.
• Do not touch the plug with wet
hands.
• When unplugging the appli-
ance, don't hold the power
cord, but the plug.
• Make sure the plug is not wet,
dirty or dusty.
1.4 Handling Safety
• Unplug the product before
moving, remove the water out-
let and water main connec-
tions. Drain any water left in-
side the product.

EN / 6
• The product is heavy, do not
move alone. Do not hold ex-
truding parts such as the laun-
dry loading door to lift and
move the product. The upper
tray should be tightly fixed for
moving.
• Your product is heavy; it
should be carried carefully by
two people if a staircase is in-
volved. It may cause injuries if
your product falls on you. Do
not hit and drop the product
while carrying.
• Carry the product in an upright
position.
• Make sure that the hoses as
well as the power cable are not
folded, pinched or crushed
after the product is fitted into
its place after installation or
cleaning procedures.
1.5 Installation Safety
• Check the information on the
manual and installation in-
structions to prepare the
product for installation and
make sure the electrical mains,
clean water mains and water
outlet are suitable. If not, call a
qualified electrician and
plumber to have them make
the necessary arrangements.
These operations are the re-
sponsibility of the customer.
• Check for any damage on the
product before installing it. Do
not have the product installed
if it is damaged.
• Injuries may occur if hands are
put into uncovered slots. Close
the holes of the transportation
safety bolts with plastic plugs.
• Do not install or leave the
product at locations where it
may be exposed to external en-
vironment conditions.
• Do not install the product at
locations where the temperat-
ure drops below 0 ºC.
• Do not place the product on a
carpet or similar surface. It
would create fire hazard since
it cannot receive air from un-
derneath.
• Place the product on a level
and hard surface and balance
with the adjustable legs.
• Connect the product to a
grounding plug protected by a
fuse suitable to the current val-
ues on the type label. Make
sure the grounding is carried
out by an expert electrician. Do
not use the product without
suitable grounding to local/na-
tional regulations.
• Plug the product in a socket
with voltage and frequency val-
ues suitable to those indicated
on the type label.

EN / 7
• Do not plug the product to
loose, broken, dirty, greasy
sockets or sockets that has
come out their seats or sock-
ets with a risk of water con-
tact.
• Use the new hose set provided
with the product. Do not re-use
old hose sets. Do not make ad-
ditions to the hoses.
• Connect the water inlet hose
directly to the water tap. The
pressure from the tap should
be minimum 0.1 MPa (1 bar)
and maximum 1MPa (10 bars).
10 to 80 litres of water should
be running from the tap in a
minute in order for the product
to function properly. If the wa-
ter pressure is above 1 MPa
(10 Bars), a pressure-reducing
valve should be fitted. The
maximum allowed temperat-
ure is 25°C.
• Fit the end of the water dis-
charge hose to the dirty water
discharge drain, the sink or the
bathtub.
• Place the power cable and
houses in locations without
risk of tripping.
• Do not install the product be-
hind a door, a sliding door or at
another location that will pre-
vent the door from opening
completely.
• If a drier is to be placed on the
product, fix with a suitable con-
nection apparatus obtained
from the authorised service.
• There is a risk of contact with
electrical pieces when the up-
per trays is removed. Do not
dismantle the upper tray of the
product.
• Place the product at least 1 cm
away from the edges of fur-
niture.
1.6 Operational Safety
• When you are using the appli-
ances, use only detergents,
softeners and supplements
suitable for washing ma-
chines.
• Do not use chemical solvents
on the product. These materi-
als contain an explosion risk.
• Do not operate defective or
damaged products. Unplug the
product (or turn off the fuse it
is connected to), turn off the
water tap and call an author-
ised service.
• Do not place sources of igni-
tion (burning candle, cigar-
ettes, etc.) or sources of heat
(irons, furnaces, ovens, etc.) on
top of or near the product. Do
not put inflammable/explosive
materials near the product.
• Do not get on the product.

EN / 8
• Unplug the product and turn
off the tap if you will not be us-
ing the product for long peri-
ods.
• Detergent/maintenance mater-
ials may splash out of the de-
tergent drawer if it is opened
while the machine is working
Contact of the detergent with
your skin and eyes is danger-
ous.
• Make sure pets do not climb
inside the product. Check in-
side the product before use.
• Do not force open the locked
loading door. The door will
open once the washing is com-
pleted. If the door does not
open, use the solutions for
“loading door does not open”
error in the Troubleshooting
section.
• Do not wash elements contam-
inated with gasoline, kerosene,
benzene, reducers, alcohol or
other inflammable or explosive
materials and industrial chem-
icals.
• Do not directly use dry clean-
ing detergent and do not wash,
rinse or spin laundry contamin-
ated with dry cleaning deter-
gent.
• Do not place your hands into
the rotating drum. Wait until
the drum no longer rotates.
• Do not place your hand or a
metal object under the wash-
ing machine.
• If washing laundry at high tem-
peratures, the discharged
washing water would burn your
skin if in contact with your
skin, for ex. when the dis-
charge hose is connected to
the tap. Do not touch the dis-
charge water.
• Take the following precautions
to prevent formation of biofilm
and malodours:
– Make sure the room where
the washing machine is
placed is well ventilated.
– Wipe the door gasket and
loading door glass with a dry
and clean cloth at the end of
the programme.
• The glass of the loading door
will heat up when washing at
high temperatures. Therefore,
do not touch the loading door
glass while washing, especially
children.
1.7 Maintenance and
Cleaning Safety
• Do not wash the product with
pressure washers, by spraying
vapour, water or pouring water.

EN / 9
• Do not use sharp or abrasive
tools to clean the product. Do
not use household cleaners,
soap, detergent, gas, gasoline,
thinner, alcohol, varnish, etc.
while cleaning.
• Cleaning agents containing
solvents might reek poisonous
fumes( for ex. cleaning
solvent. Do not use cleaning
products containing solvents.
• There may be detergent
residues in the detergent
drawer when you open it for
cleaning.
• Do not dismantle the filter of
the discharge pump while the
product is running.
• The temperature in the ma-
chine may rise up to 90ºC.
Clean the filter after the water
in the machine cools down in
order to avoid risk of getting
burnt.
2 Important Instructions for Environment
2.1 Compliance with WEEE Directive
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classifica-
tion symbol for waste electrical
and electronic equipment
(WEEE).
This product has been manufactured with
high quality parts and materials which can
be reused and are suitable for recycling. Do
not dispose of the waste product with nor-
mal domestic and other wastes at the end
of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult your
local authorities to learn about these collec-
tion centers.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
2.2 Package Information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the pack-
aging materials together with the domestic
or other wastes. Take them to the pack-
aging material collection points designated
by the local authorities.

EN / 10
3 Technical Specifications
Supplier’s name or commercial brand Beko
Model name CM 9120 BI
7115442900
Nominal Capacity (kg) 9
Maximum spin speed (cycle/min) 1200
Built-In No
Height (cm) 84
Width (cm) 60
Depth (cm) 58
Single Water inlet / Double Water inlet + / -
Electrical connection (V/Hz) 230 V / 50 Hz
Total current (A) 10
Total power (W) 2200
Main model code 1621
The consumption values apply when wireless network connection is turned off.

EN / 11
4 Installation
Please read the “Safety Instruc-
tions” section first!
Your washing machine automatic-
ally detects the amount of laundry
placed inside when selecting a pro-
gram.
While installing the product, before
the first use, calibration should be
done to ensure that the laundry
amount is detected in the most ac-
curate way.
To do this, select the Drum Clean-
ing* program and cancel the spin
function. Start the program without
laundry. Wait for the program to fin-
ish, which will take about 15
minutes.
*The program name may vary de-
pending on the model. For the ap-
propriate program selection, review
the program descriptions section.
• Please contact the nearest Authorised
Service for the installation of the appli-
ance.
• Make sure that the installation and elec-
trical connections of the product are per-
formed by authorised service agent. Man-
ufacturer shall not be held responsible
for damages caused by operations per-
formed by unauthorised persons.
• Preparation of the location and electrical,
tap water and waste water installations
at the place of installation is under cus-
tomer's responsibility.
• Make sure that the water inlet and dis-
charge hoses as well as the power cable
are not folded, pinched or crushed while
pushing the product into its place after
installation or cleaning procedures.
• Prior to installation, visually check if the
product has any defects on it. Do not
have the product installed if it is dam-
aged. Damaged products cause risks for
your safety.
4.1 Appropriate Installation Location
• Place the product on a hard and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces. Pla-
cing on an improper floor shall cause
noise and vibration problems.
• Total weight of the washing machine and
the dryer -with full load- when they are
placed on top of each other reaches to
approx. 180 kilograms. Place the product
on a solid and flat floor that has suffi-
cient load carrying capacity.
• Do not place the product on the power
cable.
• Do not install the product at places where
temperature may fall below 0 ºC. Freez-
ing might damage your product.
• Leave a minimum space of 1 cm
between the product and the furniture.
• If you will install the product on a surface
with steps, never place it close to the
edge.
• Do not place the product on any platform.
• Do not place heat sources such as
cooker, irons, ovens, heater etc. on the
appliance and do not use them on the
product.
4.2 Assembly of Bottom Panel Covers
• In order to increase the sound comfort of
the product, attach cover A after remov-
ing the package foam.
Cover A
Tilt the machine back slightly. Rest the tabs
of Cover A against the lower panel. Com-
plete the assembly by rotating the cover.

EN / 12
• Cover B and the Cap are optional. If avail-
able, attach cover B and the Cap.
Cover B
Rest the tabs of Cover B against the lower
panel. Complete the assembly by rotating
the cover.
Cap
Insert the cap by pushing it with your finger.
4.3 Removing Transportation Safety
Bolts
1. Loosen all transportation safety bolts
with an appropriate wrench until they
turn freely.
2. Bend the inner part by pressing it at the
grip areas and pull the part out.
3. Attach the plastic covers supplied in the
User Manual bag into the holes on the
rear panel.
NOTICE
Remove the transportation safety
bolts before operating the product.
Otherwise, the product will get
damaged.
NOTICE
Keep the transportation safety
bolts in a safe place to reuse when
the product needs to be moved
again in the future.
Install the transportation safety
bolts in reverse order of the disas-
sembly procedure.
Never move the product without the
transportation safety bolts properly
fixed in place.
4.4 Connecting to Water Supply
NOTICE
Models with a single water inlet
shall not be connected to the hot
water tap. In such a case the laun-
dry will get damaged or the product
will switch to protection mode and
will not operate.
Do not use old or used water inlet
hoses on a new product. It may
cause water leakage from your ma-
chine and stain your laundry.
1. Tighten all hose nuts by hand. Never use
a tool when tightening the nuts.
2. Open the taps completely after making
the hose connection to check for water
leaks at the connection points. If any
leak occurs, turn off the tap and remove
the nut. Check the gasket and tighten
the nut carefully again. In order to pre-
vent the water leaks and resultant dam-
ages, keep the taps closed when you do
not use the product.

EN / 13
4.5 Connecting the Drain Hose to the
Drain
1. Attach the end of the drain hose directly
to waste water drain, washbasin or
bathtub.
Your house will be flooded if the
water draining hose is dislocated
during water draining. There is also
a risk of burning due to the high
washing temperatures. In order to
prevent such situations and make
sure that the product performs wa-
ter intake and drain processes
without any problem, fix the drain
hose securely.
2. Connect the drain hose to a minimum
height of 40 cm and a maximum height
of 100 cm.
3. Installing the water draining hose at
ground level or close to the floor (40 cm
below) and then raising it makes water
discharge difficult and the laundry may
come out extremely wet. Thus, follow
the heights provided in the figure.
4. To prevent the waste water to go back
into the product again and to ensure
easy drainage, do not immerse the end
of the hose into the waste water or do
not insert it into the drain for more than
15 cm. If it is too long, cut it short.
5. The end of the hose should not be bent,
it should not be stepped on and the
hose must not be pinched between the
drain and the product. Otherwise, water
discharge issues may emerge.
6. If the length of the hose is too short, use
it by adding an original extension hose.
The overall length of the hose shall not
be longer than 3.2 m. To prevent water
leaks, always secure the connection
between the extension hose and the
draining hose of the product with a suit-
able clamp so that it does not come off
and cause leaks.
4.6 Adjusting the Stands
NOTICE
In order to ensure that the product
operates more silently and vibra-
tion-free, it must stand level and
balanced on its feet. Ensure that
the product is balanced by adjust-
ing the feet. Otherwise, the product
may move from its place and cause
crushing, noise and vibration prob-
lems.
To avoid damaging the lock nuts,
do not use any tools to loosen the
nuts.
1. Loosen the lock nuts on the feet by
hand.
2. Adjust the feet until the product stands
level and balanced.
3. Tighten all lock nuts again by hand.
4.7 Electrical Connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company
shall not be responsible for the damages
that shall be incurred due to using the
product without grounding according to
local regulations.
• Connection must comply with national
regulations.
• The electrical connection cable infra-
structure of the product must be ad-
equate and suitable for product require-
ments. It is recommended to use a resid-
ual current device.
• Power cable plug must be within easy
reach after installation.

EN / 14
• If the current supply to the fuse or
breaker in the house is less than 16
Amps, have a qualified electrician install
a 16 amp supply.
• The voltage specified in the "Technical
specifications" section must be equal to
your mains voltage.
• Do not make connections via extension
cables or multi-plugs. Overheating and
burning may occur due to the connecting
cable.
Damaged power cables should be
replaced by the authorised service
in order to prevent possible danger.
4.8 Start Up
Before starting to use the product make
sure that the preparations described in sec-
tion “Environmental instructions” and “In-
stallation”. To prepare the product for
washing laundry, perform first operation in
Drum Cleaning programme. If this pro-
gramme is not available in your product, ap-
ply the method which is described in sec-
tion "Cleaning the loading door and the
drum".
Some water has remained in the
product due to the quality control
processes in the production. It is
not harmful for the product.
5 Preparation
Please read the “Safety Instruc-
tions” section first
5.1 Sorting the Laundry
• Sort laundry according to type of fabric,
colour, and degree of soiling and allow-
able water temperature.
• Always observe the instructions given on
the garment care labels.
5.2 Preparing Laundry for Washing
• Laundry items with metal attachments
such as, underwiring, belt buckles or
metal buttons will damage the product.
Remove the metal pieces or wash such
clothes by putting them in a laundry bag
or pillow case.
• Take out all substances in the pockets
such as coins, pens and paper clips, and
turn pockets inside out and brush. Such
objects may damage the product or
cause noise problem.
• Put small size clothes such as infant’s
socks and nylon stockings in a laundry
bag or pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Curtain attachment items may cause
pulling and tearing on the curtain.
• Fasten zippers, sew loose buttons and
mend rips and tears.
• Wash “Machine washable” or “Hand
washable” labelled products only with an
appropriate programme.
• Do not wash colours and whites together.
New, dark coloured cottons release a lot
of dye. Wash them separately.
• Tough stains must be treated properly
before washing.
• Wash trousers and delicate laundry
turned inside out.
• Laundry that are subjected to materials
such as flour, lime dust, milk powder, etc.
intensely must be shaken off before pla-
cing into the product. Such dusts and

EN / 15
powders on the laundry may build up on
the inner parts of the product in time and
can cause damage.
5.3 Tips for Energy and Water Saving
Following information will help you use the
product in an ecological and energy/water-
efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See
"Programme and consumption table"
• Observe the temperature instructions on
the detergent packaging.
• Wash slightly soiled laundry at low tem-
peratures.
• Use faster programmes for small quantit-
ies of lightly soiled laundry.
• Do not use prewash and high temperat-
ures for laundry that is not heavily soiled
or stained.
• If you plan to dry your laundry in a dryer,
select the highest spin speed recommen-
ded during washing process.
• Do not use more detergent than the re-
commended amount on the detergent
packaging.
5.4 Loading the Laundry
1. Open the loading door.
2. Put the laundry items into the product in
a loose manner.
3. Push the loading door to close until you
hear a locking sound. Ensure that no
items are caught in the door. The load-
ing door is locked while a programme is
running. The door lock will open once
the programme is completed. Then you
can open the loading door. If the door
does not open, apply the solutions
provided for “Loading door cannot be
opened” error in the Troubleshooting
section.
5.5 Correct Load Capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts the wa-
ter amount according to the weight of the
laundry put inside it.
Follow the instructions in “Pro-
gramme and consumption table”.
When the appliances is overloaded
product’s washing performance will
drop. Moreover, noise and vibration
problems may occur.
5.6 Using Detergent and Softener
WARNING
Read the manufacturer instructions
on the package while using deter-
gents, softeners, starch, bleach and
decolourants, anti-limescale and
follow the dosage information
provided. Use a measuring cup, if
any.
The detergent drawer comprises of three
compartments:
(1) for prewash,
(2) for main washing,
(3) for softener,
( ) a syphon piece in the softener com-
partment,
( ) there is a liquid detergent apparatus
for liquid detergent use in the main wash-
ing compartment.
Detergent, Softener and Other Cleaning
Agents
• Add detergent and softener before start-
ing the washing programme.

EN / 16
• Do not leave the detergent drawer open
when the washing programme is on.
• If you are using a programme without
pre-washing, do not put detergent in the
pre-wash compartment (compartment
no. “1”).
• If you are using a program with prewash,
start the machine after adding powder
detergent to the prewash and main wash
compartments (compartments 1 and 2).
• Do not select a programme with pre-
washing if you are using a detergent pod
or dispensing ball. Place the detergent
pod or the dispensing ball directly among
the laundry in the product.
• If you are using a liquid detergent, follow
the directions under “Liquid detergent
use” and do not forget to bring the liquid
detergent apparatus to the correct posi-
tion.
Choosing the Detergent type
Detergent type to be used depends on the
washing programme, fabric type and col-
our.
• Use different detergents for coloured and
white laundry.
• Wash your delicate clothes only with spe-
cial detergents (liquid detergent, wool
shampoo, etc.) intended solely for delic-
ate clothes and at suggested pro-
grammes.
• When washing dark coloured clothes and
quilts, it is recommended to use liquid
detergent.
• Wash woollens at suggested programme
with special detergent made specifically
for woollens.
• Please review the programme descrip-
tions part for suggested programme for
different textiles.
• All recommendations about detergents
are valid for selectable temperature
range of programmes.
Only detergents, softeners and ad-
ditives suitable for washing ma-
chines should be used.
Do not use soap powder.
Adjusting the Detergent Amount
The amount of detergent depends on the
amount of laundry, how soiled they are and
the water hardness.
• Do not exceed the recommended dosage
values on the detergent packaging in or-
der to eliminate excessive foam and poor
rinsing problems, to save money and pro-
tect the environment.
• Use less amounts of detergent for fewer
or less soiled laundry.
Using Softeners
Put the softener in the softener compart-
ment of the detergent drawer.
• Do not exceed the (>max<) level sign in
the softener compartment.
• If the softener is not fluid, dilute with wa-
ter before placing in the softener com-
partment.
WARNING
Do not use liquid detergents or
other materials with cleaning prop-
erties unless they are intended for
use in washing machines for
softening the laundry.
Using Liquid Detergents
If the Product Has a Liquid Detergent
Apparatus
• Press and rotate the apparatus at where
it is shown when you want to use liquid
detergents. The part falling below will
serve as a barrier for liquid detergent.
• Clean with water at its place or by remov-
ing from its place when it is necessary.
Do not forget to place the apparatus in
the main washing compartment (com-
partment no. “2”) after cleaning.
• The apparatus should be up if you will
use a powder detergent. The fan that you
would see in this position will mix the
powder detergent and help it to dissolve.

EN / 17
Use of Gel and Tablet Detergents
• If the detergent is fluid and there is no li-
quid detergent compartment in your
product, place the gel detergent in the
main washing detergent compartment in
first water intake. If your product has a li-
quid detergent compartment, fill the com-
partment with detergent before starting
the programme.
• If the gel detergent is not fluid or is in a
capsule liquid tablet, place directly inside
the drum before washing.
• Put the tablet detergent in the main
washing compartment (compartment no.
“2”) or directly inside the drum before
washing.
Using Starch
• Put in the liquid starch, powder starch or
fabric dye in the softener compartment.
• Do not use softener and starch in the
same washing programme simultan-
eously.
• Wipe the inside of the product with a
damp and clean cloth after using starch.
Using Anti-Limescale
• When necessary, only use anti-limescale
produced for washing machines.
Using Bleach and Decolourants
• Select a programme with pre-washing
and add bleach at the start of pre-wash-
ing. Do not put detergent in the pre-wash
compartment. As an alternative applica-
tion, select a programme with additional
rinsing and add the bleach while the
product is receiving water to the deter-
gent compartment in the first rinsing
step.
• Do not mix and use bleach and detergent
together.
• As bleach may cause skin irritation use
only small amounts (1/2 tea cups - ap-
proximately 50 ml and rinse the laundry
well.
• Do not pour bleach directly onto the laun-
dry.
• Do not use bleach for coloured clothes.
• Select a programme with low temperat-
ure washing while using oxygen-based
decolourants.
• Oxygen-based decolourants can be used
together with detergents. However, if it
does not have the same viscosity as the
detergent, first place the detergent in
compartment no. “2” in the detergent
drawer and wait for the product to rinse
away the detergent during water intake.
Add the decolourant to the same com-
partment while the machine continues
taking in water.
5.7 Tips for Efficient Washing
Clothes
Light Colours and
Whites Colours Black/Dark Col- ours
Delicates/Wool-
lens/Silks
(Recommended temperat-
ure range based on soil
level: 40-90 °C)
(Recommended temper-
ature range based on
soil level: cool -40 °C)
(Recommended
temperature range
based on soil level:
cool -40 °C)
(Recommended
temperature
range based on
soil level: cool -30
°C)

EN / 18
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits
and blood.)
It may be necessary to
pre-treat the stains or per-
form prewash.
Powder and liquid deter-
gents recommended for
whites can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to
clean clay and soil stains
and the stains that are
sensitive to bleaches.
Powder and liquid deter-
gents recommended for
colours can be used at
dosages recommended
for heavily soiled
clothes. It is recommen-
ded to use powder de-
tergents to clean clay
and soil stains and the
stains that are sensitive
to bleaches. Detergents
which do not contain de-
colourant should be
used.
Liquid detergents
suitable for colours
and black/dark col-
ours can be used at
doses recommen-
ded for heavily
soiled clothes.
Prefer liquid deter-
gents produced
for delicate
clothes. Woollen
and silk clothes
must be washed
with special wool-
len detergents.
Normally
Soiled
(For example,
stains caused
by body on col-
lars and cuffs)
Powder and liquid deter-
gents recommended for
whites can be used at
dosages recommended
for normally soiled
clothes.
Powder and liquid deter-
gents recommended for
colours can be used at
dosages recommended
for normally soiled
clothes. Detergents
which do not contain de-
colourant should be
used.
Liquid detergents
suitable for colours
and black/dark col-
ours can be used at
doses recommen-
ded for moderately
soiled clothes.
Prefer liquid deter-
gents produced
for delicate
clothes. Woollen
and silk clothes
must be washed
with special wool-
len detergents.
Lightly Soiled
(No visible
stains exist.)
Powder and liquid deter-
gents recommended for
whites can be used at
dosages recommended
for lightly soiled clothes.
Powder and liquid deter-
gents recommended for
colours can be used at
dosages recommended
for lightly soiled clothes.
Detergents which do not
contain decolourant
should be used.
Liquid detergents
suitable for colours
and black/dark col-
ours can be used at
doses recommen-
ded for lightly
soiled clothes.
Prefer liquid deter-
gents produced
for delicate
clothes. Woollen
and silk clothes
must be washed
with special wool-
len detergents.
5.8 Displayed Programme Duration
You can view the programme duration on
the display of your machine while selecting
a programme. Depending on the amount of
laundry you have loaded into your machine,
foaming, unbalanced load conditions, fluc-
tuations in power supply, water pressure
and programme settings, the programme
duration is automatically adjusted while the
programme is running.
SPECIAL CASE: At programme start of Cot-
tons and Cotton Eco programmes, display
shows the duration of half load. It is the
most common use case. After programme
starts, in 20-25 minutes actual load is de-
tected by the machine. And if the detected
load is higher than half load; washing pro-
gramme will be adjusted accordingly and
programme duration increased automatic-
ally. You can follow this change on the dis-
play.
6 Operating the Product
Please read the “Safety Instruc-
tions” section first!

EN / 19
6.1 Control Panel
1
2 3 4
56789101112
1 Programme Selection Button 2 Temperature Level Lights
3 Spin Level Indicator Lights 4 Display
5 Start/Pause Button 6 Remote Control Button
7 End Time Setting Button 8 Auxiliary Function Button 3
9 Auxiliary Function Button 2 10 Auxiliary Function Button 1
11 Spin Speed Adjustment Button 12 Temperature Setting Button

EN / 20
6.2 Symbols on the Display
1 2 3 4 5
6
7
8
91011121314151617
1 Temperature Indicator 2 Spin Speed Indicator
3 Duration information 4 Door lock is engaged symbol
5 Programme follow-up indicator 6 No Water indicator
7 Add Garment Indicator 8 Bluetooth Connection Indicator
9 Remote Control Indicator 10 Delayed Start Enabled Indicator
11 Auxiliary Function Indicators 3 12 Child Lock Enabled symbol
13 Auxiliary Function Indicators 2 14 Auxiliary Function Indicators 1
15 No spin indicator 16 Rinse Hold Indicator
17 Cold Water indicator
The visuals used for machine de-
scription in this section are schem-
atic and may not match exactly
with the features of your machine.
